Page 1 Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems AM/FM stereo with CDX6/MP3 Auxiliary input jack Rear seat controls Satellite radio information Family entertainment system Navigation system Climate Controls Dual automatic temperature control Rear window defroster Lights Headlamps Turn signal control...
Page 2: Table Of Contents
Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction Control™/AdvanceTrac Air suspension Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch...
Page 3: Table Of Contents
Table of Contents Maintenance and Specifications Engine compartment Engine oil Battery Engine coolant Fuel information Air filter(s) Part numbers Maintenance product specifications and capacities Engine data Accessories Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.
Page 4: Introduction
– Special handling may apply for service or vehicle end of life disposal. See www.dtsc.ca.gov/hazardouswaste/perchlorate. CONGRATULATIONS Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on the Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.
Page 6 Introduction Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.
Page 7 Introduction SPECIAL NOTICES New Vehicle Limited Warranty For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, refer to the Warranty Guide that is provided to you along with your Owner’s Guide. Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls.
Page 8 Introduction Event Data Recording Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as: •...
Page 9 Introduction Cell phone use The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations.
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Airbag - Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor...
Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 12: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 13 Instrument Cluster damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately by your authorized dealer. Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.
Page 14 Instrument Cluster authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated. Airbag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately by your authorized dealer.
Page 15 Instrument Cluster Low tire pressure warning: Illuminates when your tire pressure is low. If the light remains ON at start up or while driving, the tire pressure should be checked. Refer to Inflating Your Tires in the Tires, Wheels and Loading chapter. When the ignition is first turned to ON, the light will illuminate for 3 seconds to ensure the bulb is working.
Page 16 Instrument Cluster AdvanceTrac (RTT) (if equipped): Displays when the AdvanceTrac with RSC system is active. If the light remains on, have the system serviced immediately by your authorized dealer. Speed control: Illuminates when the speed control is activated. Turns off when the speed control system is deactivated.
Page 17: Gauges
Instrument Cluster Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.
Page 18 Instrument Cluster Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 19 Instrument Cluster Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position).
Page 20: Entertainment Systems
Entertainment Systems AUDIO SYSTEMS AM/FM In-dash six CD/MP3 satellite compatible sound system Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window controls, radio and moon roof (if equipped) may be used for up to ten minutes after the ignition is turned off or until either front door is opened.
Page 21 Entertainment Systems In satellite Radio mode (if equipped), there are 18 available presets, six each for SAT1, SAT2 and SAT3. To save satellite channels in your memory presets, tune to the desired channel then press and hold a preset control until sound returns. Satellite radio is available only with a valid SIRIUS subscription.
Page 22 Entertainment Systems SIRIUS satellite radio channels. To select a different category, press MENU until the category appears in the display. Press to select a different category. You may also select CATEGORY ALL to seek all available Sirius categories and channels. Satellite radio is available only with a valid SIRIUS subscription.
Page 23 Entertainment Systems Speed sensitive volume: Radio volume automatically changes slightly with vehicle speed to compensate for road and wind noise. Use to adjust. Recommended level is 1–3. Level 7 is the maximum setting. Occupancy mode: Use to select and optimize sound for ALL SEATS, DRIVERS SEAT or REAR SEATS.
Page 24 Entertainment Systems 9. TEXT/SCAN: In radio mode, when listening to a RBDS-equipped station, press and hold for a brief sampling of radio stations. In CD/MP3 mode, press and release to view the track title, artist name or disc title. Press and hold for a brief sampling of all tracks on the current disc.
Page 25 Entertainment Systems CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Dirty, warped or damaged CDs, irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 26: Auxiliary Input Jack
Entertainment Systems Auxiliary input jack Your vehicle is equipped with an Auxiliary Input Jack (AIJ). The Auxiliary Input Jack provides a way to connect your portable music player to the in-vehicle audio system. This allows the audio from a portable music player to be played through the vehicle speakers with high fidelity.
Page 27: Troubleshooting
Entertainment Systems 6. Press AUX on the vehicle radio repeatedly until LINE IN appears in the display. You should hear audio from your portable music player although it may be low. 7. Adjust the sound on your portable music player until it reaches the level of the FM station or CD by switching back and forth between the AUX and FM or CD controls.
Page 28: Rear Seat Controls
Entertainment Systems 1. MEDIA: Push repeatedly to cycle through available playing medias such as AM, FM1, FM2, CD, SAT1, SAT2, SAT3 (Satellite radio if equipped), or DVD (if equipped). If in Dual Play mode, SHARED illuminates in the radio display when the front and rear modes are set to the same media.
Page 29 Entertainment Systems If there is a discrepancy between the rear seat controls and the front audio controls (such as both trying to listen to the same playing media), the front audio system will receive the desired selection. To activate Dual Play mode (rear seat passengers listen to a different playing media than the front seat passengers): •...
Page 30 Entertainment Systems “enable” them again by simultaneously pressing the 3 and 5 preset controls. The settings of the front seat controls will always override those of the rear seat controls. GENERAL AUDIO INFORMATION Radio frequencies: AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC).
Page 31: Satellite Radio Information
Entertainment Systems the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your authorized dealer for further information. Audio system warranty and service Refer to the Warranty Guide for audio system warranty information.
Page 32 Entertainment Systems • Online media player providing access to all 65 SIRIUS music channels over the internet (U.S. customers only). For information on extended subscription terms, contact SIRIUS at 1–888–539–7474. Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you.
Page 33 Entertainment Systems Radio Display Condition Action Required UNSUBSCRIBED Subscription not Contact SIRIUS at available for this 1–888–539–7474 to channel. subscribe to the channel or tune to another channel. NO TEXT Artist information not Artist information not available. available at this time on this channel.
Page 34: Family Entertainment System
Entertainment Systems FAMILY ENTERTAINMENT DVD SYSTEM (IF EQUIPPED) Your vehicle may be equipped with a Family Entertainment System (FES) which allows you to listen to audio CDs, MP3 discs, watch DVDs and to plug in and play a variety of standard video game systems. The DVD player is capable of playing standard DVDs, CDs, MP3s and is compatible with CD-R/W, CD-R and certain CD-ROM media.
Page 35 Entertainment Systems Press the power button to turn the system OFF. The indicator light will turn off indicating the system is off. Note: The audio from the DVD system will play over all vehicle speakers and can be adjusted by the radio volume control. To play a CD in the DVD system: The DVD system can play audio CDs, CD-R and CD-R/W, CD-ROM and video CDs.
Page 36 Entertainment Systems 3. The disc will begin to play and the ’MP3 Audio Disc’ screen will display and allow you to access the COMPRESSION, SHUFFLE, SCAN and FOLDER MODE features. To play an auxiliary source through the DVD system The DVD system can be used to connect and play auxiliary electronic devices such as game systems, personal camcorders, video cassette recorders, etc.
Page 37 Entertainment Systems To listen to audio over the headphones (Dual play mode): 1. You may listen to channels A and B over wired or wireless headphones. Refer to Using the infrared wireless headphones and Using wired headphones for further information. •...
Page 38 Entertainment Systems 2. Adjust the volume levels using the volume controls on the DVD system. To adjust display brightness: To decrease/increase the brightness level on the display screen, press the brightness control on the DVD system. A display will appear at the bottom of the screen indicating the brightness level.
Page 39 Entertainment Systems Note: Headphone A can access any possible media (AM, FM1, FM2, SAT (if equipped), CD, CASSETTE, DVD, DVD-AUX). Headphone B can only access DVD and DVD-AUX. For further information, refer to Single play/Dual play later in this section. (Stop/Eject): Press once to stop and press a second time to eject a disc from the DVD system.
Page 40 Entertainment Systems 9. LCD screen: The eight inch diagonal screen rotates down to view and up into housing to store when not in use. Ensure that the screen is latched into the housing when being stored. 10. Volume: When in Single Play, press to increase ( ) or decrease ) the volume over all speakers.
Page 41 Entertainment Systems 16. Cursor /Brightness controls: Use the cursor controls to make various selections when in any menu. When not in a menu, and in DVD mode, press to adjust the brightness. A display bar will appear at the bottom of the screen indicating the brightness levels.
Page 42 Entertainment Systems 4. RETURN: Press to return to the previous menu screen. 5. ANGLE (DVD dependent): Press to select the angle to view the scene. 6. Channel A/B: Press to select either A or B headphones and then use the MEDIA control to select the desired playing media for the headphones.
Page 43 Entertainment Systems 19. MENU: Press to access the DVD disc menu for selections. Press MENU again when in the DVD disc menu to access the system set-up menu. 20. SUBTITLE (DVD dependent): Press to turn the subtitle feature ON or OFF. 21.
Page 44 Entertainment Systems Headphones Wireless headphones Your FES system is equipped with two sets of battery powered, infrared wireless headphones. Two AAA batteries are needed to operate the headphones. (Batteries are included.) Additional infrared wireless headphones may be purchased for use with the system.
Page 45 Entertainment Systems To operate the headphones: • Press ON/OFF on the ear piece to turn on the headphones. A red indicator light will illuminate indicating the headphones are ON. Press ON/OFF again to turn the headphones off. • Adjust the headphones to comfortably fit your head using the headband adjustment.
Page 46 Entertainment Systems Channel A source. The wired headphone jack for Channel B is located on the right side of the FES and is labeled B. Headphones plugged into this headphone jack will hear audio from the audio source selected to be the Channel B source.
Page 47 Entertainment Systems Press the Headphone Control button A to change the audio source for Channel A. Press MEDIA to change the audio source for Channel A. This information will display on the DVD system screen. Press the Headphone Control button B to change the audio source for Channel B.
Page 48 Entertainment Systems Press MENU twice to access the DVD set-up menu and the following features: 1. ZOOM 2. ANGLE 3. ASPECT RATIO 4. LANGUAGE 5. SUB TITLES Angle mode Select ANGLE to select various angles of view for the DVD. This is disc dependent —...
Page 49 Entertainment Systems You can select from: WIDE, LETTER BOX or PAN SCAN. Once you have made your selection, press ENTER to confirm. The LCD screen display will immediately change to your selection after the system resumes playback of the DVD. The system default is WIDE (16:9).
Page 50 Entertainment Systems Once you have made your selection, press ENTER to confirm. This is disc dependent. Audio CDs To play audio CDs on your DVD system: 1. Ensure that the vehicle ignition is in the RUN or ACCESSORY position. 2. Ensure that the DVD system is ON. 3.
Page 51 Entertainment Systems 4. The folder, track and elapsed time will appear in the status bar. The screen will list the Artist, Title, Album and File Name. COMP (Compression): Compression brings soft and loud CD/MP3 passages together for a more consistent listening level when in CD mode.
Page 52 Entertainment Systems CD, MP3 and CD player care • Handle discs by their edges only. Never touch the playing surface. • Do not expose discs to direct sunlight or heat sources for extended periods of time. • Do not insert more than one disc into the slot of the CD player (if equipped).
Page 53 Entertainment Systems 4. Use the DVD bezel controls to: Press to play or pause a DVD. Press to stop or eject a DVD. Press and release to go to the previous chapter. Press and hold for a fast reverse search. Press and release to go to the next chapter.
Page 54 Entertainment Systems 2. Press the right cursor button. The DVD will advance one frame. Each press of the right cursor button will advance the DVD video by one frame. Headphone/auxiliary jacks There are wired headphones (not included) and auxiliary jacks on the left and right side of your DVD system.
Page 55 Entertainment Systems Audio displays Your DVD system interacts closely with the front audio system. Status messages will appear in the radio display showing the DVD status. Some possible radio display messages: • SINGLE PLAY or DUAL PLAY • DVD LOAD •...
Page 56 Entertainment Systems When the DVD system is ON, you can then press the memory preset controls 2 and 4 simultaneously to toggle between Single Play and Dual Play. In Single Play mode, all speakers listen to the same media. In Dual Play mode, rear seat passengers can use the infrared wireless, or wired (not included) headphones to listen to a different playing media than the front seat passengers.
Page 57 Federal Communication Commission (FCC) Compliance Changes or modifications not approved by Ford Lincoln-Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 58 Entertainment Systems However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to consult the dealer or an experienced radio/TV technician for help.
Page 59: Navigation System
Entertainment Systems screen gently until the dust, dirt or fingerprints are removed. Do not spray the screen directly with water or glass cleaning solvents. Overspray from these fluids could drip down into the internal electronics of the screen and cause damage. Do not apply excessive pressure while cleaning the screen.
Page 60: Climate Controls
Climate Controls DUAL ZONE AUTOMATIC TEMPERATURE CONTROL WITH REAR PASSENGER COMPARTMENT CLIMATE CONTROL (IF EQUIPPED) Defrost: Distributes outside air through the windshield defroster vents and demister vents. Can be used to clear thin ice or fog from the windshield. 2. Rear temperature control: Press to enable the auxiliary system and set the desired rear cabin airflow temperature with the front control.
Page 61 Climate Controls odors from reaching the interior of the vehicle. Recirculated air can be engaged manually in any airflow selection except . Recirculated air may turn off automatically in all airflow selections. 7. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency.
Page 62: Dual Automatic Temperature Control
Climate Controls Dual automatic temperature control with heated and cooled seats and rear passenger compartment climate control (if equipped) Defrost: Distributes outside air through the windshield defroster vents and demister vents. Can be used to clear thin ice or fog from the windshield.
Page 63 Climate Controls Passenger cooled seat control: Press once to activate the high cool setting (3 indicator lights). Continue pressing to scroll through the other settings; medium cool (2 indicator lights), low cool (1 indicator light) or off. 8. REAR: Press to enable the control located in the rear floor console (if equipped).
Page 64 Climate Controls 17. EXT: Press to display the outside temperature. Press again to display cabin temperature settings. Note: Exterior readings are more accurate when the vehicle is moving. Recirculated air: Press to activate/deactivate air recirculation in the vehicle cabin. Recirculated air may reduce the amount of time to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle.
Page 65: Rear Window Defroster
Climate Controls AUXILIARY CLIMATE CONTROL (IF EQUIPPED) 1. Fan speed: Turn to select the desired fan speed. 2. Temperature/mode selection: The distribution of air from the overhead and floor registers is based on the temperature selected. Turn to select for comfort. To use the rear climate controls, ensure that REAR is pressed on the main climate control face.
Page 66: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to turn on the headlamps. Autolamp control The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 67 Lights High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate. Flash to pass Pull toward you slightly to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) Turns the foglamps on at full intensity output. To activate: •...
Page 68 Lights • Rotate fully to the right (past detent) to turn on interior lamps. • Rotate to the left position (past detent) to turn off the interior lamps and will also disable the illuminated entry feature. At dusk and dawn, the LEDs are illuminated at six times the normal intensity to enhance contrast and visibility.
Page 69: Turn Signal Control
Lights 4. On the wall or screen you will observe a light pattern with a distinct horizontal edge towards the right. If this edge is not at the horizontal reference line, the beam will need to be adjusted so the edge is at the same height as the horizontal reference line.
Page 70 Lights INTERIOR LAMPS Front row map lamps To turn on the map lamps, press the outer edge of the clear lens. The front row map lamp lights when: • any door is opened. • the instrument panel dimmer switch is rotated until the courtesy lamps come on.
Page 71: Bulb Replacement
Lights Rear cargo lamp The dome lamp lights when: • any door is opened, and the switch is in the middle position. • the instrument panel dimmer switch is rotated until the courtesy lamps come on. • any of the remote entry controls are pressed and ignition is OFF (and switch is in the middle position).
Page 72 Lights Function Number Trade number of bulbs Headlamps (low and *See your dealer high-beam) Front park lamps 3157K or 4157K Front turn lamps 3157A (amber) Front sidemarker 168A (amber) Foglamps Front row map lamps 1600XB 2nd row reading lamp 1600XB Rear cargo lamp 211–2XB Rear turn/tail/brake lamps...
Page 73 Lights Replacing front parking lamp/turn signal/sidemarker bulbs The front parking lamp/turn signal/sidemarker bulbs are located in the headlamp assembly. Follow the same steps to replace either bulb: 1. Make sure the headlamp control is in the OFF position. 2. Open the hood. 3.
Page 74 Lights Replacing tail/stop/turn/backup lamp bulbs The tail/stop/turn/backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other. Follow the same steps to replace either bulb: 1. Make sure the headlamp switch is in the OFF position.
Page 75 Lights 6. Pull bulb straight out of socket and push in the new bulb. 7. Install the bulb socket into the lamp assembly and rotate clockwise. 8. Install the lamp assembly on the vehicle and secure with four nuts. 9. Install the interior trim panel. High-mount brakelamp To change the high-mount brakelamp bulbs:...
Page 76 Lights Replacing license plate lamp bulb The license plate bulbs are located in the license plate housing assembly on the liftgate. To change the license plate bulbs: 1. Make sure the headlamp switch is in the OFF position. 2. Remove the license lamp screw from the assembly.
Page 77: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed.
Page 78 Driver Controls For rear wash cycle, rotate (and hold as desired) the rear wiper/washer control to either position. From either position, the control will automatically return to the INT 2 or OFF position. POWER TILT STEERING The steering column can be adjusted manually by moving the two-way rocker adjustment control located below the turn signal/wiper...
Page 79 Driver Controls On vehicles with memory feature, to prevent damage to the steering column, the steering column is designed to set a stopping position just short of the end of the column position. If the steering column encounters an object while moving up or down, a new stopping position will be set.
Page 80 Driver Controls Forward storage bin (if equipped) The storage compartment may be used to store a pair of sunglasses. Press the release area on the rear edge of the bin door to open the storage compartment. The door will open to full open position. Conversation mirror (if equipped) On double bin overhead consoles, the conversation mirror allows the driver to view the rear seating area.
Page 81 Driver Controls Do not leave children unattended in the vehicle and do not let children play with the power rear quarter windows. They may seriously injure themselves. When closing the power rear quarter windows, you should verify that it is free of obstructions and ensure that children and/or pets are not in the proximity of the window opening.
Page 82 Driver Controls AUXILIARY POWER POINT (12VDC) Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet as this will damage the outlet and blow the fuse. Do not hang any type of accessory or accessory bracket from the plug.
Page 83: Power Windows
Driver Controls A third auxiliary power point is located on the right rear quarter panel. The power point is accessible from the liftgate. Cigar lighter (if equipped) Do not plug optional electrical accessories into the cigarette lighter socket. Do not hold the lighter in with your hand while it is heating, this will damage the lighter element and socket.
Page 84 Driver Controls • Lowering a front window approximately two to three inches or • Open 3rd Row Power Quarter Glass, for vehicles equipped with this option Express up or down (One Touch Up or Down, Front windows only) This feature allows the driver’s and passenger’s window to open or close fully without holding the control down.
Page 85 Driver Controls Security Override If during a bounce-back condition, the switch is released to the neutral position, then held in the one touch up position within two seconds after the window reaches the bounce-back position, the window will travel up with no bounce-back protection. If the switch is released before the window reaches fully closed or the ignition is turned OFF (without accessory delay being active), the window will stop.
Page 86: Mirrors
Driver Controls With Navigation System The mirror will automatically return to the normal state whenever the vehicle is placed in R (Reverse) to ensure a bright clear view when backing up. Do not block the sensors on the front and back of the interior rear view mirror since this may impair proper mirror performance.
Page 87 Driver Controls Powerfold mirrors Rotate the 4–way adjustment switch to the center position. Press the POWER FOLD switch down to auto fold in and down again to auto fold back to design position. Powerfold the side mirrors in carefully when driving through a narrow space, like an automatic car wash.
Page 88 Driver Controls Signal indicator mirrors When the turn signal is activated, the lower portion of the mirror housing will blink. POWER ADJUSTABLE FOOT PEDALS The accelerator and brake pedal should only be adjusted when the vehicle is stopped and the gearshift lever is in the P (Park) position.
Page 89 Driver Controls Automatic power deploy: • The running boards will extend down and out when the doors are opened. Automatic power stow: • The running boards will return to the stowed position when the doors are closed. There will be a two second delay before the running boards move in to the stowed position.
Page 90: Speed Control
Driver Controls Note: Do not use the running boards, front and rear hinge assemblies, running board motors, or the running board under body mounts to lift the vehicle when jacking. Please utilize proper jacking points. Refer to Changing tires in the Roadside Emergencies chapter. In extreme climates, excessive ice buildup may occur, causing the running boards not to deploy.
Page 91 Driver Controls 3. Press the SET + control and release it. 4. Take your foot off the accelerator pedal. 5. The indicator light on the instrument cluster will turn on. Note: • Vehicle speed may vary momentarily when driving up and down a steep hill.
Page 92 Driver Controls Increasing speed while using speed control There are two ways to set a higher speed: • Press and hold the SET + control until you get to the desired speed, then release the control. You can also use the SET + control to operate the Tap-Up function.
Page 93 Driver Controls Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal. This will not erase your vehicle’s previously set speed. • Press the speed control OFF control. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased.
Page 94 Driver Controls In CD mode: • Press SEEK to select the next selection on the CD or press and hold to forward or reverse the CD. In any mode: • Press VOL + or - to adjust the volume. Climate control features Press TEMP + or - to adjust temperature.
Page 95: Moon Roof
Driver Controls Navigation control features (if equipped) Press and hold control briefly to use the Navigation voice command. Press the control again to hear previous command repeated from the navigation system. MOON ROOF (IF EQUIPPED) The moon roof control is located on the overhead console. Do not let children play with the moon roof or leave children unattended in the vehicle.
Page 96 Driver Controls The moon roof has a built-in sliding shade that can be manually opened or closed when the glass panel is shut. To close the shade, pull it toward the front of the vehicle. HOMELINK WIRELESS CONTROL SYSTEM The HomeLink Wireless Control System, located on the driver’s visor, provides a convenient way to replace up to three hand-held...
Page 97 Driver Controls 1. Press and hold the two outside buttons releasing only when the indicator light begins to flash after 20 seconds. Do not repeat Step 1 to program additional hand-held transmitters to the remaining two HomeLink buttons. This will erase previously programmed hand-held transmitter signals into HomeLink .
Page 98 Driver Controls Note: There are 30 seconds in which to initiate Step 7. 7. Return to the vehicle and firmly press, hold for two seconds and release the programmed HomeLink button. Repeat the press/hold/release sequence again, and, depending on the brand of the garage door opener (or other rolling code equipped device), repeat this sequence a third time to complete the programming.
Page 99 Driver Controls Operating the HomeLink Wireless Control System To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.).
Page 100: Message Center
Driver Controls MESSAGE CENTER With the ignition in the ON position, the message center, located on your instrument cluster, displays important vehicle information through a constant monitor of vehicle systems. You may select display features on the message center for a display of status preceded by a brief indicator chime.
Page 101 Driver Controls Outside air temperature (if equipped) Press and hold the INFO button for 2 seconds to display the outside temperature. To switch from a blank display to the temperature display, hold the INFO button for 2 seconds until the temperature is seen in the display.
Page 102 Driver Controls 5. Press and release the RESET until the message center displays a selection to change the current zone setting. 6. Press and release the RESET control until the message center display changes to show the current zone setting (XX). 7.
Page 103 Driver Controls Distance to empty (DTE) Selecting this function from the INFO menu estimates approximately how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition OFF when refueling to allow this feature to correctly detect the added fuel. The DTE function will display XXX MILES TO E FUEL LEVEL and sound a tone for one second when you have approximately 50 miles (80 km) to empty.
Page 104 Driver Controls Instantaneous fuel economy Press INFO until the menu displays “MPG”. This will display your fuel economy as a Bar Graph ranging from poor economy to excellent economy. Your vehicle must be moving to calculate instantaneous fuel economy. When your vehicle is not moving, this function shows one or no bars illuminated.
Page 105 Driver Controls Reset to English (if in another language) When entering the SETUP MENU and a non-English language has been selected, “PRESS RESET FOR ENGLISH” will be displayed to change back to English. Press and hold the RESET control to set the language choice. Easy entry/exit This feature automatically moves the drivers seat backwards for easy exit from the vehicle.
Page 106 Driver Controls Autolock (if equipped) This feature automatically locks all vehicle doors when the vehicle is shifted into any gear, putting the vehicle in motion. 1. To disable/enable the autolock feature, select this function from the SETUP control for the current display mode.
Page 107 Driver Controls Language 1. Select this function from the SETUP menu for the current language to be displayed. 2. Waiting 4 seconds or pressing the RESET control cycles the message center through each of the language choices. Selectable languages are English, Spanish, or French. 3.
Page 108 Driver Controls The sequence of the system check report and how it appears in the message center is as follows: 1. OIL LIFE 2. CHARGING SYSTEM 3. WASHER FLUID LEVEL 4. DOOR STATUS 5. LIFTGATE/GLASS 6. BRAKE FLUID LEVEL 7. TIRE PRESSURE SYSTEM (if equipped) 8.
Page 109 Driver Controls Warning display Status Driver door ajar Warning can be reset. Will return if reset and warning is cleared and set Passenger door ajar again within the same ignition cycle. Rear left door ajar Will return on ignition cycle. Rear right door ajar Door ajar Liftgate/glass ajar...
Page 110 Driver Controls Warning display Status Press reset to clear This can be reset, it will remain on the display for 4 seconds. Park aid <ON> OFF This cannot be reset. Pressing reset (if equipped) will change the option from ON to OFF.
Page 111 Driver Controls XXX MILES TO EMPTY FUEL LEVEL LOW. Displayed as an early reminder of a low fuel condition. AIR SUSPENSION OFF. Displayed when the air suspension is off. For more information, refer to Air suspension in the Driving chapter. BRAKE FLUID LEVEL LOW.
Page 112 Driver Controls To reset the oil monitoring system to 100% after each oil change [approximately 5,000 miles (8,000 km) or 180 days] perform the following: 1. Press and release the SETUP control to display “OIL LIFE = XXX% HOLD RESET = NEW”. 2.
Page 113 Driver Controls Note: The liftgate can be reversed with a second press on a control button or key fob and can be manually closed at any time. The liftgate will only operate with the vehicle in P (Park). The chime will beep once if conditions are not correct to start an operation.
Page 114 Driver Controls Note: If weight is added to the gate (bike rack, snow, etc.) the gate may automatically start a power close event immediately after a power open. In this mode a unique continuous chime will sound. To close the liftgate with the rear cargo area control button: Press and release the control on the left rear quarter panel to close the...
Page 115 Driver Controls • a low voltage or dead battery • disconnected battery • the liftgate is manually closed and left ajar (unlatched) To reset the power liftgate: 1. Manually close and fully latch the liftgate. 2. Power open the liftgate by using the keyfob or instrument panel button.
Page 116 Driver Controls MANUAL LIFTGATE (IF EQUIPPED) To open the liftgate, pull the liftgate handle. • Do not open the liftgate or liftgate glass in a garage or other enclosed area with a low ceiling. If the liftgate glass is raised and the liftgate is also opened, both liftgate and glass could be damaged against a low ceiling.
Page 117 Driver Controls LUGGAGE RACK Your vehicle is equipped with a roof rack for transporting items on the exterior of the vehicle. The maximum recommended load to be carried on the roof rack is 200 lbs (90 kg), evenly distributed. The cross-bars can be adjusted by using the thumbwheels at each end.
Page 118: Locks And Security
Locks and Security KEYS One key operates all the locks and starts the vehicle. Always carry a spare key with you in case of an emergency. Your keys are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start. If you lose your authorized dealer supplied keys, replacement keys are available through your authorized dealer.
Page 119 Locks and Security • the vehicle attains a speed greater than 12 mph (20 km/h). The autolock feature repeats when: • any door is opened then closed while the ignition is in the 3 (ON) position and the vehicle speed is 9 mph (15 km/h) or lower, and •...
Page 120 Locks and Security Keyless entry key pad procedure 1. Turn the ignition to the 1 (OFF/LOCK) position. 2. Close all doors, the liftgate and liftgate window. 3. Enter 5–digit entry code 4. Press and hold the 3 • 4. While holding the 3 • 4 press the 7 • 8. 5.
Page 121 Locks and Security The remote entry system allows you to lock or unlock all vehicle doors and liftgate and open the liftgate window without a key. The remote entry lock/unlock feature operates in any ignition position. The liftgate glass features operate as long as vehicle speed is less than 5 mph (8 km/h).
Page 122 Locks and Security To confirm all doors are closed and locked, press the control a second time within three seconds; the park/turn signal lamps will flash once and the horn will chirp. • 4–button remote • 5–button remote If any of the doors or liftgate are ajar, the horn will make two quick chirps, reminding you to properly close all doors.
Page 123 Locks and Security • 5–button remote Opening the power liftgate (if equipped) Press the control twice to fully unlatch and open the liftgate. Make sure all persons are clear of the liftgate area before using power liftgate control. In order to fully lower and latch the liftgate, press the control twice. If the liftgate stops mid travel, it may have detected an obstacle, Check to ensure the liftgate swing zone is free from obstruction and reset the power assist by manually closing the liftgate.
Page 124 Locks and Security • 4–button remote • 5–button remote To deactivate the alarm, press the control again or turn the ignition to the 2 (ACCESSORY) or 3 (ON) position. Memory feature The remote entry system can also control the memory feature. Press the control once to unlock the driver’s door.
Page 125 Locks and Security • 5–button remote Activating the memory feature To activate this feature: 1. Position the seat, rearview mirror, and adjustable pedals to the positions you desire. 2. Press the SET control on the driver’s seat. 3. Within 5 five seconds, press one control on the remote transmitter and then press the 1 or 2 memory seat control to which you would like to associate with Driver 1 or Driver 2 positions.
Page 126 Locks and Security Replacing the battery The remote entry transmitter uses one coin type three-volt lithium battery CR2032 or equivalent. To replace the battery: 1. Twist a thin coin between the two halves of the remote entry transmitter near the key ring. DO NOT TAKE THE RUBBER COVER AND CIRCUIT BOARD OFF THE FRONT HOUSING OF THE...
Page 127 Locks and Security Replacing lost transmitters If a remote transmitter has been lost and you would like to remove it from the vehicle’s memory, or you would like to purchase additional remote transmitters and have them programmed to your vehicle: •...
Page 128 Locks and Security Illuminated entry The lamps illuminate when the remote entry system is used to unlock the door(s). The system automatically turns off after 25 seconds or when the ignition is turned to the 2 (ACCESSORY) or 3 (ON) position. The dome lamp control must not be set to the off position for the illuminated entry system to operate.
Page 129 Locks and Security 1. The ignition must be OFF to begin the sequence. 2. Place the key in the ignition and turn the ignition to the 3 (RUN) position. 3. Press the power door unlock control on the door panel three times.
Page 130 Locks and Security 2. Within five seconds press the 1 • 2 on the keypad. 3. Enter your personal 5–digit code. Each number must be entered within five seconds of each other. 4. Three unique personal entry codes can be stored: •...
Page 131 Locks and Security To unlock all doors and liftgate, press the 3 • 4 control within five seconds. To lock all doors and liftgate, press the 7 • 8 and the 9 • 0 at the same time. Note: The driver’s door must be closed. You do not need to enter the keypad code first.
Page 132 Check to make sure the coded key is an approved Lincoln coded key. If your keys are lost or stolen you will need to do the following: •...
Page 133 Locks and Security Please read and understand the entire procedure before you begin. 1. Insert the first previously programmed coded key into the ignition and turn the ignition from the 1 (OFF/LOCK) to the 3 (ON) position [maintain ignition in 3 (ON) for at least three seconds, but no more than ten seconds].
Page 134: Seating And Safety Restraints
Seating and Safety Restraints SEATING Front row adjustable head restraints Your vehicle’s seats are equipped with two-way adjustable head restraints. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 135 Seating and Safety Restraints Adjusting the front power seat Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 136 Seating and Safety Restraints Press the switch in the direction of the arrows to move the seat forward, backward, up or down. Press the control to recline the seatback forward or rearward. Note: On vehicles with memory seats, to prevent damage to the seat, the power seats are designed to set a stopping position just short of the end of the seat track.
Page 137 Seating and Safety Restraints Memory seats/power mirrors/adjustable pedals (if equipped) This system allows automatic positioning of the driver seat, power mirrors, and adjustable pedals to two programmable positions. The memory seat control is located on the outboard side of the seat cushion.
Page 138 Seating and Safety Restraints The controls for the climate controlled seats are located on the dual electronic automatic temperature control (DEATC) system. Refer to Climate controls for more information. If the vehicle falls below 350 RPMs while the cooled seats are on, the feature will turn itself off and will need to be reactivated.
Page 139 Seating and Safety Restraints • Remove filter. To install a filter: • First, position the filter in it’s housing making sure that the far forward end is all the way up in the housing. Then push in on the center of the outside edge of the filter and rotate up into the housing until it clips into position.
Page 140 Seating and Safety Restraints 1. Lower the head restraints by pulling on the strap. 2. Locate handle on the side of the seat cushion by the door. 3. Pull up on the handle and push the seatback forward toward the front of the vehicle.
Page 141 Seating and Safety Restraints 3. Lift up on the head restraint until it locks into its original position. Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched.
Page 142 Seating and Safety Restraints 2. Pull the cargo mode lever up to release the seat into a kneel down load floor position. A moderate force may be required to move the seat forward and down. Returning to the upright position from full lowered load floor position The seatback cannot be returned to the upright position until the seat is returned from the kneel down position.
Page 143 Seating and Safety Restraints 2. Pull the handle up again until the seat releases from the floor. 3. Push the seat upward and fold it away from the third row. Always latch the vehicle seat to the floor, whether the seat is occupied or empty.
Page 144 Seating and Safety Restraints Exiting the 3rd row 1. Pull the strap located at the bottom outboard of the seat back to release the seat from the floor, and rotate the seat up towards the front seat. 2. Follow the directions above to return the seat from the E-Z entry and to the upright position.
Page 145 Seating and Safety Restraints To prevent possible damage to the seat or safety belts, ensure that the safety belts are not buckled when moving the seat to the load floor position. 2. With the latch released the seatback can be lowered into the load floor position.
Page 146 Seating and Safety Restraints Adjusting the 2nd row center 20% seat (if equipped) Lift the handle to move the seat forward or backward. Note: This seat can be moved forward to keep a child in a child restraint close to the front seat occupants. The seat should be moved to the full rearward position when it is occupied by older children or adults.
Page 147 Seating and Safety Restraints Pull up on the handle located behind the seatback while pushing the seatback forward and down into the seat cushion. To return the seatback to its original position lift the seatback until it latches into place. Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback.
Page 148: Safety Restraints
Seating and Safety Restraints Push the bottom portion of the control button to lower the desired seatback. Push the top of the control button to return the seatback to its original position. The power fold down seats will operate for 10 minutes after the ignition switch is in Off.
Page 149 Seating and Safety Restraints Your vehicle’s Personal Safety System consists of: • Driver and passenger dual-stage airbag supplemental restraints. • Front safety belts with pretensioners, energy management retractors, and safety belt usage sensors. • Driver’s seat position sensor. • Front crash severity sensor. •...
Page 150 Seating and Safety Restraints allows your Personal Safety System to distinguish between different levels of crash severity and modify the deployment strategy of the dual-stage airbags and safety belt pretensioners. Driver’s seat position sensor The driver’s seat position sensor allows your Personal Safety System tailor the deployment level of the driver dual-stage airbag based on seat position.
Page 151 Seating and Safety Restraints safety belt pretensioners, front safety belt buckle sensors, and the driver seat position sensor. In addition, the RCM also monitors the restraints warning light in the instrument cluster. A difficulty with the system is indicated by one or more of the following: •...
Page 152 Seating and Safety Restraints In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a safety belt. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
Page 153 Seating and Safety Restraints • Front and rear seats All safety restraints in the vehicle are combination lap and shoulder belts except for the front row center lap belt (if equipped). Front center lap belt To fasten the front center lap belt, insert the tongue into the center buckle until you hear a snap and feel it latch.
Page 154 Seating and Safety Restraints When to use the automatic locking mode • Anytime a child safety seat (except a booster) is installed in the vehicle. Children 12 years old and under should be properly restrained in the rear seat whenever possible. Refer to Safety restraints for children or Safety seats for children later in this chapter.
Page 155 Seating and Safety Restraints BELT AND RETRACTOR ASSEMBLY MUST BE REPLACED if the safety belt assembly “automatic locking retractor” feature or any other safety belt function is not operating properly. In addition, all safety belts should be checked for proper function. Failure to replace the belt and retractor assembly could increase the risk of injury in collisions.
Page 156 Seating and Safety Restraints squeeze the side release buttons and slide the height adjuster up. Pull down on the height adjuster to make sure it is locked in place. Position the safety belt height adjusters so that the belt rests across the middle of your shoulder.
Page 157 Seating and Safety Restraints Position the safety belt comfort guide so that the belt rests across the middle of your shoulder. Failure to adjust the safety belt properly could reduce the effectiveness of the safety belt and increase the risk of injury in a collision. Safety belt extension assembly If the safety belt is too short when fully extended, there is a 8 inch (20 cm) safety belt extension assembly that can be added (part number...
Page 158 Seating and Safety Restraints Conditions of operation If... Then... The driver safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the ON warning chime sounds 4-8 seconds. position...
Page 159 Seating and Safety Restraints If... Then... The driver’s safety belt is not The Belt-Minder feature is buckled approximately 5 seconds activated - the safety belt warning after the safety belt warning light light illuminates and the warning has turned off... chime sounds for 6 seconds every 30 seconds, repeating for approximately 5 minutes or until...
Page 160 Seating and Safety Restraints Reasons given... Consider... “Traffic is light” Nearly 1 of 2 deaths occur in single-vehicle crashes, many when no other vehicles are around. “Belts wrinkle my Possibly, but a serious crash can do much more clothes” than wrinkle your clothes, particularly if you are unbelted.
Page 161 Seating and Safety Restraints While the design allows you to deactivate your Belt-Minder , this system is designed to improve your chances of being safely belted and surviving an accident. We recommend you leave the Belt-Minder system activated for yourself and others who may use the vehicle.
Page 162: Airbags
Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Airbags DO NOT inflate slowly; there is a risk of injury from a deploying airbag.
Page 163 Seating and Safety Restraints Never place your arm over the airbag module as a deploying airbag can result in serious arm fractures or other injuries. To properly position yourself away from the airbag: • Move your seat to the rear as far as you can while still reaching the pedals comfortably.
Page 164 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 165 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 166 Seating and Safety Restraints impact sensors, the system wiring, the airbag system readiness light, the airbag back up power and the airbag ignitors). Determining if the system is operational The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system.
Page 167 Seating and Safety Restraints All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided. How does the side airbag system work? The design and development of the side airbag system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 168 Seating and Safety Restraints to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration. Several air bag system components get hot after inflation. Do not touch them after inflation. If the side airbag has deployed, the airbag will not function again.
Page 169 Seating and Safety Restraints Do not attempt to service, repair, or modify the Safety Canopy system, its fuses, the A, B, C or D pillar trim, or the headliner on a vehicle containing a Safety Canopy . See your authorized dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an airbag SRS and Safety Canopy...
Page 170 Seating and Safety Restraints • Two crash sensors mounted in the front doors (one on each side of the vehicle). • Two crash sensors located at the C pillar behind the rear doors (one on each side of the vehicle). •...
Page 171 Seating and Safety Restraints If the Safety Canopy system has deployed, the Safety Canopy will not function again unless replaced. The Safety Canopy system (including the A, B, C, and D pillar trim) must be inspected and serviced by an authorized dealer.
Page 172: Child Restraints
Seating and Safety Restraints Important child restraint precautions You are required by law to use safety restraints for children in the U.S. and Canada. If small children (generally children who are four years old or younger and who weigh 40 lb. [18 kg] or less) ride in your vehicle, you must put them in safety seats made especially for children.
Page 173 Seating and Safety Restraints To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 174 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 175 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 176 Seating and Safety Restraints Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or death in a collision. SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child.
Page 177 Seating and Safety Restraints for children up to 60 pounds (27 kg) in a child restraint, and to provide upper torso restraint for children up to 80 pounds (36 kg) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap.
Page 178 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 179 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 180 Seating and Safety Restraints Installing child safety seats in the center front seating position (if equipped) Always transport children 12 years old and under in the rear seats and always properly use appropriate child restraints. It is safer to install child safety seats in seating positions that have child seat anchors.
Page 181 Seating and Safety Restraints The tether strap anchors in your vehicle are in the following positions (shown from top view): • Second row bench seat • Second row bucket seats Attach the tether strap only to the appropriate tether anchor as shown.
Page 182 Seating and Safety Restraints • center seating position (if equipped) 3. Route the child safety seat tether strap under the head restraint (outboard seats) and over the back of the seat. 4. Grasp the tether strap and position it to the seat frame. 5.
Page 183 Seating and Safety Restraints 6. Rotate the tether strap clip. 7. Tighten the child safety seat tether strap according to the manufacturer’s instructions. Third row seating position 1. Position the child safety seat on the center of the seat cushion. 2.
Page 184 Seating and Safety Restraints 4. Clip the tether strap through the anchor loop as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. Install the child safety seat tightly using the LATCH anchors or safety belts.
Page 185 Seating and Safety Restraints Your vehicle has LATCH anchors for child seat installation at the seating positions marked with the child seat symbol: Never attach two LATCH child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death.
Page 186 Seating and Safety Restraints Attach LATCH lower attachments of the child seat only to the anchors shown. If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it.
Page 187: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
Page 188 Tires, Wheels and Loading Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter. Information on transfer case maintenance can be found in the Maintenance and Specifications chapter.
Page 189 Tires, Wheels and Loading • Narrower — to provide greater maneuverability in tight spaces, particularly in off-road use. As a result of the above dimensional differences, SUV’s and trucks often will have a higher center of gravity and a greater difference in center of gravity between the loaded and unloaded condition.
Page 190 Tires, Wheels and Loading government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and may depart significantly from the norm due to variations in driving habits, service practices, and differences in road characteristics and climate.
Page 191 Tires, Wheels and Loading • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture. Also referred to as DOT code. • Inflation pressure: A measure of the amount of air in a tire. •...
Page 192: Tire Inflation
Tires, Wheels and Loading At least once a month and before long trips, inspect each tire and check the tire pressure with a tire gauge (including spare, if equipped). Inflate all tires to the inflation pressure recommended by Ford Motor Company. Use a tire gauge to check the tire inflation pressure, including the spare (if equipped), at least monthly and before long trips.
Page 193 Tires, Wheels and Loading To check the pressure in your tire(s): 1. Make sure the tires are cool, meaning they are not hot from driving even a mile. If you are checking tire pressure when the tire is hot, (i.e. driven more than 1 mile [1.6 km]), never “bleed”...
Page 194 Tires, Wheels and Loading cracking, cuts, bruises and other signs of damage or excessive wear. If internal damage to the tire is suspected, have the tire demounted and inspected in case it needs to be repaired or replaced. For your safety, tires that are damaged or show signs of excessive wear should not be used because they are more likely to blow out or fail.
Page 195 Tires, Wheels and Loading U.S. DOT Tire Identification Number (TIN) Both U.S. and Canada Federal regulations require tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a U.S. DOT Tire Identification Number for safety standard certification and in case of a recall.
Page 196 Tires, Wheels and Loading When mounting replacement tires and wheels, you should not exceed the maximum pressure indicated on the sidewall of the tire to set the beads without additional precautions listed below. If the beads do not seat at the maximum pressure indicated, re-lubricate and try again.
Page 197 Tires, Wheels and Loading If your vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires; spinning the tires can tear the tire and cause an explosion. A tire can explode in as little as three to five seconds. Do not spin the wheels at over 35 mph (56 km/h).
Page 198 Tires, Wheels and Loading • Rear Wheel Drive (RWD) vehicles/Four Wheel Drive (4WD)/ All Wheel Drive (AWD) vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 199 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
Page 200 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 81 mph (130 km/h) 87 mph (140 km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h)
Page 201 Tires, Wheels and Loading 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
Page 202 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 203 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 204: Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
Page 205 Tires, Wheels and Loading Changing tires with TPMS Each road tire is equipped with a tire pressure sensor fastened to the inside rim of the wheel. The pressure sensor is covered by the tire and is not visible unless the tire is removed. The pressure sensor is located opposite (180 degrees) from the valve stem.
Page 206 Tires, Wheels and Loading no longer capable of functioning as intended. Please refer to the following chart for information concerning your Tire Pressure Monitoring System: Low Tire Pressure Possible cause Customer Action Required Warning Light Solid Warning Light Tire(s) 1. Check your tire pressure to under-inflated ensure tires are properly inflated;...
Page 207 Tires, Wheels and Loading Low Tire Pressure Possible cause Customer Action Required Warning Light Flashing Warning Spare tire in use Your temporary spare tire is in Light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.
Page 208: Vehicle Loading
Tires, Wheels and Loading any tire is under-inflated, carefully drive the vehicle to the nearest location where air can be added to the tires. Inflate all the tires to the recommended inflation pressure. SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle.
Page 209 Tires, Wheels and Loading your vehicle, familiarize yourself with the following terms for determining your vehicle’s weight ratings, with or without a trailer, from the vehicle’s Tire Label or Safety Compliance Certification Label: Base Curb Weight – is the weight of the vehicle including a full tank of fuel and all standard equipment.
Page 210 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 211 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 212 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 213 Tires, Wheels and Loading Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.” on your vehicle’s placard. 2.
Page 214: Trailer Towing
Tires, Wheels and Loading to transport the cement to your home? If you and your friend each weigh 220 lb. (99 kg), the calculation would be: 1400 - (2 x 220) - (12 x 100) = 1400 - 440 - 1200 = - 240 lb. No, you do not have enough cargo capacity to carry that much weight.
Page 215 Tires, Wheels and Loading • Thoroughly prepare your vehicle for towing. Refer to Preparing to tow in this chapter. • Use extra caution when driving while trailer towing. Refer to Driving while you tow in this chapter. • Service your vehicle more frequently if you tow a trailer. Refer to the severe duty schedule in the scheduled maintenance guide.
Page 216 Tires, Wheels and Loading Trailer weight Rear axle Maximum range Engine ratio GCWR - lb. (kg) (0 - maximum) - lb. (kg) 5.4L with standard trailer 12100 (5489) 0–6000 (0–2721) tow package 5.4L with optional trailer 15000 (6804) 0–9000 (0–4082) tow package 5.4L with standard trailer...
Page 217 Tires, Wheels and Loading Trailer weight Rear axle Maximum GCWR range Engine ratio - lb. (kg) (0 - maximum) lb. (kg) Navigator L 4x4 5.4L with standard trailer 12500 (5670) 0–6000 (0–2721) tow package 5.4L with optional trailer 15000 (6804) 0–8600 (0–3900 ) tow package Note: For vehicles not equipped with the optional trailer tow package,...
Page 218 Tires, Wheels and Loading Mode Maximum Maximum Tongue Gross Trailer Weight - lb. (kg) Weight - lb. (kg) Weight carrying 6000 (2721) 600 (272) Weight 8950 (4059) 895 (405) distributing These are hitch ratings only; actual vehicle ratings are dependent on engine, transmission and axle combinations.
Page 219 Tires, Wheels and Loading Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle. See your authorized dealer or a reliable trailer dealer if you require assistance. Hitches Do not use hitches that clamp onto the vehicle’s bumper or attach to the axle.
Page 220 Tires, Wheels and Loading Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. The braking system of the tow vehicle is rated for operation at the GVWR not GCWR.
Page 221 Tires, Wheels and Loading Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. •...
Page 222: Recreational Towing
Tires, Wheels and Loading Replace the rear axle lubricant any time the axle has been submerged in water. Rear axle lubricant quantities are not to be checked or changed unless a leak is suspected or repair required. RECREATIONAL TOWING (ALL WHEELS ON THE GROUND) An example of recreational towing would be towing your vehicle behind a motorhome.
Page 223: Driving
Driving STARTING Positions of the ignition 1. OFF/LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 2. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 3. ON, all electrical circuits operational.
Page 224 Driving If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs higher than normal in order to warm the engine.
Page 225 Driving 4. Make sure the parking brake is set. 5. Turn the key to 3 (ON) without turning the key to 4 (START). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights.
Page 226 Driving fails to start, press the accelerator to the floor and try again; this will allow the engine to crank with the fuel shut off in case the engine is flooded with fuel. This vehicle has a computer assisted cranking system which assists in starting the engine.
Page 227: Brakes
Driving (the heater can be plugged in the night before starting the vehicle). To plug the heater in, remove the cap from the plug and insert the plug into a 110 volt grounded outlet. Be sure to re-attach the cap onto the plug when the heater is not in use.
Page 228 Driving functioning of the vehicle’s anti-lock brake system. The ABS performs a self-check after you start the engine and begin to drive away. A brief mechanical noise may be heard during this test. This is normal. If a malfunction is found, the ABS warning light will come on. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by an authorized dealer.
Page 229 Driving Parking brake with auto-release (if equipped) Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the BRAKE ignition is turned ON) until the...
Page 230 Driving If the parking brake fails to release after completing this procedure, use the manual parking brake release lever. Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy.
Page 231 Driving If your vehicle should become stuck in deep snow or mud, try switching the AdvanceTrac with RSC system off by pressing the AdvanceTrac with RSC button momentarily. This will allow your tires to “dig” for traction. If the AdvanceTrac with RSC system is activated excessively in a short period of time, the brake portion of the system will disable to allow the brakes to cool down.
Page 232 Driving • Driving on slick surfaces. • Cornering while towing a heavily loaded trailer (refer to Trailer towing in the Tires, Wheels and Loading chapter.) Roll Stability Control (RSC) The RSC system works in conjunction with the AdvanceTrac system to help maintain roll stability of the vehicle during aggressive maneuvers by applying brake force to one or more wheels.
Page 233 Driving If the vehicle is above 25 mph (40 km/h), momentarily pressing the AdvanceTrac with RSC button will steadily illuminate the “sliding car” icon, however, the AdvanceTrac with RSC system will remain enabled until the vehicle speed drops below 25 mph. If the vehicle speed decreases below 25 mph (40 km/h), the system will become deactivated, but if the vehicle speed subsequently increases to above 25 mph (40 km/h), the system will again become active.
Page 234 Driving Aggressive driving in any road conditions can cause you to lose control of your vehicle increasing the risk of severe personal injury or property damage. The occurrence of a AdvanceTrac with RSC event is an indication that at least some of the tires have exceeded their ability to grip the road;...
Page 235: Air Suspension
Driving • High crosswinds • Wheels out of alignment • Loose or worn suspension components Variable assist steering Your vehicle is equipped with variable assist power steering. At low engine RPM, steering assist will adjust to reduce efforts and improve low speed maneuverability.
Page 236: Transmission Operation
Driving PREPARING TO DRIVE Utility vehicles have a significantly higher rollover rate than other types of vehicles. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Utility vehicles and trucks have larger tires and increased ground clearance, giving the vehicle a higher center of gravity than a passenger car.
Page 237 Driving If the fuse is not blown, perform the following procedure: 1. Apply the parking brake, turn the ignition to OFF, then remove the key. 2. Using a screwdriver or similar tool, remove the protective cover to the interlock release access hole, located to the right of the gearshift lever.
Page 238 Driving Driving with a 6–speed automatic transmission This vehicle is equipped with an Adaptive Transmission Shift Strategy. The Adaptive Transmission Shift Strategy offers the optimal transmission operation and shift quality. When the engine is turned off, the shift data which includes the adaptive information will be stored automatically in the Transmission Control Module (TCM).
Page 239 Driving N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. D (Drive) with Overdrive The normal driving position for the best fuel economy. Transmission operates in gears one through six except in 4X4 where transmission operates in gears two through six.
Page 240 Driving 2 (Second) Transmission operates in 2nd gear only. Use 2 (Second) to start-up on slippery roads or to provide additional engine braking on downgrades. 1 (First) • Transmission operates in 1st gear only. • Provides maximum engine braking. • Allows upshifts by moving gearshift lever. •...
Page 241 Driving To help avoid personal injury, always use caution when in R (Reverse) and when using the reverse sensing system. This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting objects to avoid damaging the vehicle.
Page 242 Driving Audible Warnings Distance to Object Warning Speed above 2.5 mph (4 km/h) up to 1.6 feet (.5 meters) Solid 1.6 feet (.5 meters) to 3.1 feet (1 meter) Fast beep 3.1 feet (1 meter) to 5.7 feet (1.8 meters) Medium/fast beep 5.7 feet (1.8 meters) to 9 feet (2.8 meters)
Page 243 Driving CONTROL TRAC FOUR-WHEEL DRIVE (4X4) OPERATION (IF EQUIPPED) For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. Do not use 4X4 mode on dry, hard surfaced roads. Doing so will produce excessive noise, increase tire wear and may damage drive components.
Page 244 Driving “4X4” when this position is selected. This position is not recommended for use on dry pavement. This position is only intended for severe winter or off-road conditions, such as deep snow, ice or shallow sand. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 245 Driving Maintain steering wheel control at all times, especially in rough terrain. Since sudden changes in terrain can result in abrupt steering wheel motion, make sure you grip the steering wheel from the outside. Do not grip the spokes. Drive cautiously to avoid vehicle damage from concealed objects such as rocks and stumps.
Page 246 Driving If your vehicle gets stuck If your vehicle gets stuck in mud or snow it may be rocked out by shifting between forward and reverse gears, stopping between shifts, in a steady pattern. Press lightly on the accelerator in each gear. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur.
Page 247 Driving Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 248 Driving Avoid excessive speed because vehicle momentum can work against you and cause the vehicle to become stuck to the point that assistance may be required from another vehicle. Remember, you may be able to back out the way you came if you proceed with caution. If your vehicle is equipped with AdvanceTrac with RSC, press the AdvanceTrac with RSC button (refer to AdvanceTrac with Roll Stability Control (RSC) Stability Enhancement System in this...
Page 249 Driving “Tread Lightly” is an educational program designed to increase public awareness of land-use regulations and responsibilities in our nations wilderness areas. Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 250 Driving Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating. Do not descend in neutral; instead, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control.
Page 251 Driving Company strongly recommends that you do not make modifications such as adding or removing parts (such as lift kits or stabilizer bars) or by using replacement parts not equivalent to the original factory equipment. Any modifications to a vehicle that raise the center of gravity can make it more likely the vehicle will roll over as a result of a loss of control.
Page 252: Roadside Emergencies
• winch out – available within 100 feet (30.5 meters) of a paved or county maintained road, no recoveries. • towing – Ford/Mercury/Lincoln eligible vehicle towed to an authorized dealer within 35 miles (56.3 km) of the disablement location or to the nearest authorized dealer.
Page 253 Owner Guide portfolio in the glove compartment. In Canada, the card is found in the Customer Information Guide in the glove compartment. U.S. Ford or Mercury vehicle customers who require roadside assistance, call 1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006.
Page 254: Fuel Pump Shut-Off Switch
Roadside Emergencies Note: With extended use, the flasher may run down your battery. FUEL PUMP SHUT-OFF SWITCH FUEL RESET The fuel pump shut-off switch is a device intended to stop the electric fuel pump when your vehicle has been involved in a substantial jolt. After a collision, if the engine cranks but does not start, the fuel pump shut-off switch may have been activated.
Page 255: Fuses And Relays
Roadside Emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
Page 256 Roadside Emergencies To remove the trim panel for access to the fuse box, pull the panel toward you and swing it out away from the side and remove it. To reinstall it, line up the tabs with the grooves on the panel, then push it shut.
Page 257 Roadside Emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Smart window #1 Driver side power seat memory FES, Audio rear seat controls, SDARS Smart window #2 Keypad illumination, 3rd row seat enable, Brake Shift Interlock (BSI), SPDJB Turn signals...
Page 258 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Demand lamps, Glovebox, Visor Instrument panel cluster Ignition switch Radio Instrument panel cluster Not used (Spare) Compass, Automatic dimming rear view mirror Restraints control module Ebrake Not used (spare) Rear park assist, 4x4 PATS transceiver Climate control...
Page 259 Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
Page 260 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 40A** Power running boards 40A** Heated/cooled seats 60A** ABS (pump) 20A** Rear console power point 30A** Auxiliary blower 25A* Trailer tow connector (park lamps) 30A* Trailer tow connector (battery charge) —...
Page 261 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 20A* Back-up lamps 25A* Trailer tow connector (stop/turn lamps) 20A* 4x4 module 10A* Powertrain Control Module (PCM) – Keep alive power, Canister vent 15A* Transmission B+ 30A** Third row seats (passenger side) 50A** Air suspension pump 30A**...
Page 262 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — One-touch Start diode — A/C clutch diode — Fuel pump diode 15A* Trailer tow connector (back-up lamp) — Not used 10A* Air suspension logic — Not used 10A* Blower coil —...
Page 263 Roadside Emergencies for your vehicle loads (GAWR and GVWR). This temporary spare tire is not equipped with a Tire Pressure Monitor System (TPMS) sensor. The use of tire sealants may damage your tires. The use of tire sealants may also damage your Tire Pressure Monitoring System. Refer to Tire Pressure Monitoring System (TPMS) in the Tires, Wheels and Loading chapter for important information.
Page 264 Roadside Emergencies • Use commercial car washing equipment • Try to repair the dissimilar spare tire Use of one of the dissimilar spare tires listed above at any one wheel location can lead to impairment of the following: • Handling, stability and braking performance •...
Page 265 Roadside Emergencies Drive cautiously when using a full-size dissimilar spare tire/wheel and seek service as soon as possible. Stopping and securing the vehicle 1. Park on a level surface, activate the hazard flashers and set the parking brake. 2. Place the gearshift in P (Park) and turn the engine OFF.
Page 266 Roadside Emergencies Removing the jack and tools 1. Open the liftgate, then locate the access panel on the floor behind the 3rd row seat. Unlatch and remove the panel. 2. Remove the jack and tools assembly tray from the compartment by turning the wing-nut counterclockwise to relieve tension against the jack assembly tray.
Page 267 Roadside Emergencies Tire change procedure To help prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block the wheels (both front or both rear) on the opposite end of the vehicle from the wheel being changed.
Page 268 Roadside Emergencies 2. Place gearshift lever in P (Park), turn engine OFF and block the wheels (both front or both rear) on the opposite end of the vehicle from the wheel being changed. If on a grade, block both wheels on the downward side of the hill.
Page 269 Roadside Emergencies When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the transmission is in P (Park). To prevent the vehicle from moving when you change the tire, be sure that the parking brake is set and the block the wheels (both front or both rear) on the opposite end of the vehicle from the wheel being changed.
Page 270 Roadside Emergencies • Never use the front or rear differential as a jacking point. To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack.
Page 271: Lug Nut Torque
Roadside Emergencies 2. Slide the wheel partially under the vehicle and install the retainer through the wheel center. If equipped, you may have to remove the wheel center cap prior to pushing the retainer through the center of the wheel. To remove the center cap, press it off with the jack tool from the inner side of the wheel.
Page 272: Jump Starting
Roadside Emergencies When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel. Ensure that any fasteners that attach the rotor to the hub are secured so they do not interfere with the mounting surfaces of the wheel.
Page 273 Roadside Emergencies 5. Turn the heater fan on in both vehicles to protect from any electrical surges. Turn all other accessories off. Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
Page 274 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to the jump starting stud located in the rear of the engine compartment, behind the battery.
Page 275 Roadside Emergencies Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped. A spark may cause an explosion of the gases that surround the battery. 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts.
Page 276 Roadside Emergencies Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery.
Page 277 Roadside Emergencies 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 278: Wrecker Towing
Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member of a roadside assistance program, your roadside assistance service provider. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.
Page 279 Roadside Emergencies With a disabled vehicle (without access to wheel dollies, car hauling trailer or flatbed transport vehicle) your vehicle can be towed (all wheels on the ground) under the following conditions: Special Conditions: • Release the parking brake. • Turn the air suspension control to OFF. •...
Page 280: Customer Assistance
GETTING THE SERVICES YOU NEED At home You must take your Lincoln or Mercury vehicle to an authorized dealer for warranty repairs. While any authorized dealer handling your vehicle line will provide warranty service, we recommend you return to your selling authorized dealer who wants to ensure your continued satisfaction.
Page 281 1-800-565-3673 (FORD) www.ford.ca If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 282 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the BBB AUTO LINE before taking action under the Magnuson-Moss Warranty Act, or to the extent allowed by state law, before pursuing replacement or repurchase remedies provided by certain state laws.
Page 283 Customer Assistance THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. Experience has shown that our customers have been very successful in achieving satisfaction by following the three-step procedure outlined on the front page of the Warranty Guide.
Page 284 Customer Assistance UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 285 Customer Assistance If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your authorized dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.
Page 286 Customer Assistance ORDERING ADDITIONAL OWNER’S LITERATURE To order the publications in this portfolio, contact Helm, Incorporated at: HELM, INCORPORATED P.O. Box 07150 Detroit, Michigan 48207 Or call: For a free publication catalog, order toll free: 1-800-782-4356 Monday-Friday 8:00 a.m. - 6:00 p.m. EST Helm, Incorporated can also be reached by their website: www.helminc.com.
Page 287: Reporting Safety Defects (U.s. Only)
Customer Assistance REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 288: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 289 Cleaning • Use Custom Bright Metal Cleaner (ZC-15), available from your authorized dealer. Apply the product as you would a wax to clean bumpers and other chrome parts; allow the cleaner to dry for a few minutes, then wipe off the haze with a clean, dry rag. •...
Page 290 Cleaning • Some automatic car washes may cause damage to the finish on your wheel rims or covers. Chemical-strength cleaners, or cleaning chemicals, in combination with brush agitation to remove brake dust and dirt, could wear away the clearcoat finish over time. •...
Page 291 Cleaning PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3-A). • If tar or grease spots are present, use Motorcraft Bug and Tar Remover (ZC-42).
Page 292 Cleaning INSTRUMENT PANEL/INTERIOR TRIM AND CLUSTER LENS Clean the instrument panel, interior trim areas and cluster lens with a clean and damp white cotton cloth, then with a clean and dry white cotton cloth; you may also use Motorcraft Dash & Vinyl Cleaner (ZC-38-A) on the instrument panel and interior trim areas.
Page 293 Cleaning • Do not use household cleaning products or glass cleaners, which can stain and discolor the fabric and affect the flame retardant abilities of the seat materials. Do not use cleaning solvents, bleach or dye on the vehicle’s safety belts, as these actions may weaken the belt webbing. Do not use chemical solvents or strong detergents when cleaning the seat-mounted side airbag (if equipped).
Page 294 Cleaning FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 295: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide to find out which parts and services are covered.
Page 296 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.
Page 297: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 5.4L 3V–V8 engine 1. Windshield washer fluid reservoir 2. Engine oil dipstick 3. Brake fluid reservoir 4. Engine coolant reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Power distribution box 8.
Page 298 Maintenance and Specifications WINDSHIELD WASHER FLUID Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16-A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash.
Page 299 Maintenance and Specifications CHANGING THE WIPER BLADES It is recommended that wiper blades are renewed before winter. To replace the wiper blades: 1. Fold back the wiper arm and position the wiper blade at right angles to the wiper arm. 2.
Page 300: Engine Oil
Maintenance and Specifications ENGINE OIL Checking the engine oil Refer to the scheduled maintenance information for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
Page 301 Maintenance and Specifications • If required, add engine oil to the engine. Refer to Adding engine oil in this chapter. • Do not overfill the engine with oil. Oil levels above this mark may cause engine damage. If the engine is overfilled, some oil must be removed from the engine by an authorized dealer.
Page 302 Maintenance and Specifications Engine oil and filter recommendations Look for this certification trademark. Use SAE 5W-20 engine oil Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). An oil with this trademark symbol conforms to the current engine and emission system protection standards and fuel economy requirements of the International Lubricant Standardization and Approval Committee (ILSAC), comprised of U.S.
Page 303: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
Page 304 Maintenance and Specifications Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.
Page 305: Engine Coolant
Maintenance and Specifications If the battery has been disconnected or a new battery has been installed, the clock and radio settings must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 306 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 307 Maintenance and Specifications Note: Use of Motorcraft Cooling System Stop Leak Pellets or an equivalent product meeting Ford specification WSS-M99B37-B6, may darken the color of Motorcraft Premium Gold Engine Coolant from yellow to golden tan. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, or DEX-COOL brand with the factory-filled coolant.
Page 308 Maintenance and Specifications 3. Step back while the pressure releases. 4. When you are sure that all the pressure has been released, use the cloth to turn it counterclockwise and remove the cap. 5. Fill the coolant reservoir slowly with the proper coolant mixture (see above), to within the “COLD FILL RANGE”...
Page 309 Maintenance and Specifications Severe climates If you drive in extremely cold climates (less than –34°F [–36°C ]): • It may be necessary to increase the coolant concentration above 50%. • NEVER increase the coolant concentration above 60%. • Increased engine coolant concentrations above 60% will decrease the overheat protection characteristics of the engine coolant and may cause engine damage.
Page 310 Maintenance and Specifications • The symbol will illuminate. • The indicator light will illuminate. If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation. Each disabled cylinder acts as an air pump and cools the engine. When this occurs the vehicle will still operate.
Page 311 Maintenance and Specifications FUEL FILTER For fuel filter replacement, see your authorized dealer. Refer to scheduled maintenance information for the appropriate intervals for changing the fuel filter. Replace the fuel filter with an authorized Motorcraft part. The customer warranty may be void for any damage to the fuel system if an authorized Motorcraft fuel filter is not used.
Page 312 Maintenance and Specifications • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury. If fuel is swallowed, call a physician immediately, even if no symptoms are immediately apparent.
Page 313 Maintenance and Specifications Refueling Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
Page 314 Maintenance and Specifications If you must replace the fuel filler cap, replace it with a fuel filler cap that is designed for your vehicle. The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used.
Page 315 Maintenance and Specifications Fuel quality If you are experiencing starting, rough idle or hesitation driveability problems, try a different brand of unleaded gasoline. “Premium” unleaded gasoline is not recommended for vehicles designed to use “Regular” unleaded gasoline because it may cause these problems to become more pronounced.
Page 316 Maintenance and Specifications ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver. You must gather information as accurately and consistently as possible. Fuel expense, frequency of fill-ups or fuel gauge readings are NOT accurate as a measure of fuel economy.
Page 317 Maintenance and Specifications Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in miles or kilometers). 2. Each time you fill the tank, record the amount of fuel added (in gallons or liters). 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading.
Page 318 Maintenance and Specifications • You may want to turn off the speed control in hilly terrain if unnecessary shifting between the top gears occurs. Unnecessary shifting of this type could result in reduced fuel economy. • Warming up a vehicle on cold mornings is not required and may reduce fuel economy.
Page 319 Maintenance and Specifications EPA window sticker The characteristics of the four wheel drive vehicle, like those of many, similar competitive products, fit within categories where the fuel economy labeling regulations do not apply. Therefore, the following information applies only to the two wheel drive vehicle. Every new vehicle should have the EPA window sticker.
Page 320 Maintenance and Specifications Illumination of the indicator, charging system warning light or the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power could indicate that the emission control system is not working properly. An improperly operating or damaged exhaust system may allow exhaust to enter the vehicle.
Page 321 Maintenance and Specifications These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel, properly tightening the fuel cap or letting the electrical system dry out. After three driving cycles without these or any other temporary malfunctions present, the indicator should stay off the next time the engine is started.
Page 322 Maintenance and Specifications Allow the vehicle to sit for at least eight hours without starting the engine. Then, start the engine and complete the above driving cycle. The engine must warm up to its normal operating temperature. Once started, do not turn off the engine until the above driving cycle is complete. If the vehicle is still not ready for I/M testing, the above driving cycle will have to be repeated.
Page 323: Air Filter(S)
Maintenance and Specifications TRANSMISSION FLUID Checking automatic transmission fluid The automatic transmission does not have a transmission fluid dipstick. Refer to your scheduled maintenance information for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, (i.e., if the transmission slips or shifts slowly) or if you notice some sign of fluid leakage.
Page 324 Maintenance and Specifications 2. Reposition the locking clip on the connector (connector shown from below for clarity), squeeze the connector and pull it off of the air outlet tube. 3. Clean the area around the air tube to air cover connection to prevent debris from entering the system and then loosen the bolt on the air tube clamp so the clamp is...
Page 325 Maintenance and Specifications 6. Remove the air filter element from the air filter housing. 7. Install a new air filter element. 8. Replace the air filter housing cover and secure the clamps. Be careful not to crimp the filter element edges between the air filter housing and cover and ensure that the tabs on the edge are properly aligned into the slots.
Page 326: Part Numbers
Maintenance and Specifications MOTORCRAFT PART NUMBERS Component 5.4L 3V V8 engine Air filter element FA-1883 BXT-65-650 or Battery BXT-65-750 (if equipped) Fuel filter FG-986B Oil filter FL-820-S PCV valve Spark plugs The PCV valve is a critical emission component. It is one of the items listed in scheduled maintenance information and is essential to the life and performance of your vehicle and to its emissions system.
Page 327 Maintenance and Specifications 2007 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)
Page 328 Maintenance and Specifications 2007 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)
Page 329 Maintenance and Specifications 2007 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)
Page 330: Engine Data
Maintenance and Specifications ENGINE DATA Engine 5.4L V8 engine Cubic inches Required fuel 87 octane Firing order 1-3-7-2-6-5-4-8 Ignition system Coil on plug Spark plug gap 0.040–0.050 inch (1.02–1.27 mm) Compression ratio 9.85:1 Spark plug gap not adjustable Engine drivebelt routing •...
Page 331 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
Page 332 Maintenance and Specifications The Vehicle Identification Number (VIN) contains the following information: 1. World manufacturer identifier 2. Brake system / Gross Vehicle Weight Rating (GVWR) / Restraint System 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6.
Page 333: Accessories
Accessories GENUINE LINCOLN ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Lincoln Accessories are available for your vehicle through your local Lincoln or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 334 Accessories Peace of mind Mobile-Ease hands-free communication system Remote start Vehicle security systems Wheel locks Not all accessories are available for all models. For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: •...
Page 335: Index
Index Battery ........303 ABS (see Brakes) .....227 acid, treating emergencies ..303 Accessory delay ......85 jumping a disabled battery ..272 AdvanceTrac ......230 maintenance-free ....303 replacement, specifications ...326 Air cleaner filter ....323, 326 servicing ........303 Air suspension ......235 Belt-Minder ......158 description ......235 Booster seats ......172 Airbag supplemental restraint system ......162, 166, 168...
Page 336 Index interior ......292–293 Dipstick plastic parts ......291 automatic transmission washing ........288 fluid ..........323 waxing ........289 engine oil .........300 wheels ........289 Driving under special wiper blades ......291 conditions ....240, 246, 249 Clock ..........81 sand .........247 snow and ice ......250 Compass, electronic through water ....248, 251 set zone adjustment ....101 DVD system .........34...
Page 337 Index Family entertainment system ..34 Headlamps ........66 aiming ........68 Floor mats .........112 autolamp system .......66 Fluid capacities ......327 bulb specifications ....71 daytime running lights .....67 Foglamps ........66 flash to pass ......67 Four-Wheel Drive vehicles ..243 high beam .........67 control trac ......243 turning on and off ....66 description ......243 Homelink wireless...
Page 338 Index heated ........87 programmable memory ..124 signal .........88 Lamps autolamp system .......66 Moon roof ........95 bulb replacement Motorcraft parts ..294, 311, 326 specifications chart ....71 daytime running light ....67 fog lamps ........66 headlamps .........66 Navigation system .......59 headlamps, flash to pass ..67 interior lamps .....70, 72 replacing bulbs ......75 Octane rating ......314...
Page 339 Index Preparing to drive Safety Compliance your vehicle .......236 Certification Label ....331 Satellite Radio Information ..31 Seats ..........134 child safety seats ....176 Radio ..........20 climate control ......138 Rear seat memory seat ....124, 137 entertainment system ....34 SecuriLock passive Rear window defroster ....65 anti-theft system ....131–132 Relays ........255 Servicing your vehicle ....295...
Page 340 Index checking the pressure ....193 inflating ........191 label .........203 Vehicle Identification Number replacing ........195 (VIN) ..........331 rotating ........197 safety practices .......196 Vehicle loading ......208 sidewall information ....198 Ventilating your vehicle ...226 snow tires and chains ....208 spare tire .........263 terminology ......190 tire grades .......190 Warning lights (see Lights) ..12 treadwear ......189, 194...

This manual is also suitable for:

2007 navigator

Lincoln Navigator 2007 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Quick Links

Table of Contents

Related Manuals for Lincoln Navigator 2007

Summary of Contents for Lincoln Navigator 2007

This manual is also suitable for:

Table of Contents
