2. Set a sturdy piece of packing material under the
rear of the Frame (1). Have a second person
hold the Frame to prevent it from tipping
while you complete this step.
Identify the Rear Stabilizer (3). Note: The Front
Stabilizer (not shown) has wheels.
Orient the Rear Stabilizer (3) so that the welded
tubes are facing away from the Frame (1).
Attach the Rear Stabilizer (3) to the Frame (1)
with two M10 x 95mm Screws (53).
Remove the packing material.
3. Set a sturdy piece of packing material under the
front of the Frame (1). Have a second person
hold the Frame to prevent it from tipping
while you complete this step.
Orient the Front Stabilizer (2) so that the wheels
are facing away from the Frame (1).
Attach the Front Stabilizer (2) to the Frame (1)
with two M10 x 95mm Screws (53).
Remove the packing material.
2
3
53 Welded
Tubes
3
7
1
Wheel
53
2
1
