PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M4 x 16mm
M6 Split M8 Split M4 x 22mm
M8 Locknut
Screw (43)–4
Washer (74)–4 Washer (64)–8 (72)–4 Screw (31)–4
M8 x 16mm M10 x 95mm
M6 x 20mm
Screw (65)–4 Screw (53)–4
Screw (18)–4
5
