Summary of Contents for D-Link KVM-440

  • Page 2: Package Contents

    (1) 8- Port or 16- Port PS2/USB Combo KVM Switch (4) 4-in-1 PS2/USB Combo KVM cable (1) Rack Mount Bracket Kit Set (1) Power Adapter (1) CD-ROM with Manual If any item is missing or damaged, please contact your local D-Link reseller for replacement.

  • Page 3: Product Overview

    Product Overview Front Panel Figure 1- KVM-440 Front Panel Figure 2 - KVM-450 Front Panel Device Status LEDs and Buttons Item Feature Description Selected (Red): Status LEDs A Red LED indicates that the corresponding PC is selected. Online (Green): A Green LED indicates that the corresponding PC is online.

  • Page 4: Rear Panel

    Rear Panel Figure 3 - KVM-440 Rear Panel Figure 4 - KVM-450 Rear Panel KVM Port Connections Item Feature Description PS/2 Mouse Console Port Connects to the PS/2 mouse PS/2 Keyboard Console Connects to the PS/2 keyboard Port VGA Monitor Console Port...

  • Page 5: Console Connection

    Installation: Precautions: • Please turn off computers and attached devices before installing the KVM Switch. • For computers with Keyboard Power On function, please unplug the power cords in advance. Otherwise, the switch may not work properly. • Some older computers may require you to enable USB in BIOS to make the USB interface work.
  • Page 6 Note: Please contact your reseller to purchase additional 4-in-1 KVM combo cables. Figure 5: 4-in-1 KVM combo cable You can connect the KVM switch to computers using one of the three methods shown below: A. Connect USB, PS/2 Keyboard, PS/2 Mouse and VGA connectors to your computer.
  • Page 7 B. Connect only PS/2 Keyboard, PS/2 Mouse and VGA connectors to your computer. (Figure 7) Figure 7: PS/2 and VGA Setup C. Connect only USB and VGA connectors to your computer. (Figure 8) Figure 8: USB and VGA Setup...
  • Page 8 Cascade Chaining The KVM switch supports cascades of up to 3 levels. Control up to 64/256/4096 PCs from a single console. Cascaded units do not require any special configuration Once connected, the KVM Switches will automatically configure themselves appropriately as the Master or Slave. To install a cascade chain, please follow the instruction below.
  • Page 9 Rack Mounting Figure 9 shows you how to attach the mounting brackets to the KVM Switch unit for a standard 19-inch rack cabinet. 1. Attach the mounting brackets onto the sides of the KVM Switch unit using screws. (Figure 9). 2.
  • Page 10 Notes...
  • Page 11 Notes...

  • Page 12: Technical Support

    Copyright ©2011 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, and the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property of their respective owners. Product specifications, size and shape are subject to change without notice, and actual product appearance may differ from...

This manual is also suitable for:

Kvm-450
