Related Manuals for Supero X9DRFR

Summary of Contents for Supero X9DRFR

  • Page 1 Инструкция для SuperMicro X9DRFR Перейти в карточку товара 8 800 775 98 98...
  • Page 2 X9DRFR USER’S MANUAL Revision 1.0...
  • Page 3 Manual Revision 1.0 Release Date: July 26, 2012 Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this document. Information in this document is subject to change without notice. Other products and companies referred to herein are trademarks or registered trademarks of their respective companies or mark holders.

  • Page 4: About This Motherboard

    X9DRFR motherboard. About This Motherboard The Super X9DRFR motherboard supports dual Intel E5-2600 Series (Socket R) processors that offer QPI (Intel QuickPath Interface) Technology (V.1.1), providing point-to-point connection with a transfer speed of up to 8.0 TG/s. With the C602 ®...

  • Page 5: Conventions Used In The Manual

    X9DRFR Motherboard User’s Manual Conventions Used in the Manual Pay special attention to the following symbols for proper system installation and to prevent damage to the system or injury to yourself: Danger/Caution: Instructions to be strictly followed to prevent catastrophic...

  • Page 6: Contacting Supermicro

    Preface Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 7: Table Of Contents

    X9DRFR Motherboard User’s Manual Table of Contents Preface Chapter 1 Overview Overview ......................1-1 Processor and Chipset Overview..............1-11 Special Features ................... 1-12 PC Health Monitoring ..................1-12 ACPI Features ....................1-13 Power Supply ....................1-13 Super I/O ....................... 1-13 Overview of the Nuvoton WPCM450 Controller .......... 1-14 Chapter 2 Installation Static-Sensitive Devices ..................
  • Page 8 Table of Contents PWM to Fans/PWR Good to PWR Adaptor Card ........2-20 Fan Speed Signals ................... 2-21 UID Button/LAN LED Signal ..............2-21 Power Button ................... 2-22 Connecting Cables ..................2-23 Power Supply ..................2-23 Fan Headers ..................... 2-24 TPM Header/Port 80 ................
  • Page 9 X9DRFR Motherboard User’s Manual Chapter 4 BIOS Introduction ...................... 4-1 Starting BIOS Setup Utility ................4-1 ............4-2 Starting the Setup Utility ................. 4-2 Main Setup ...................... 4-2 ..............4-4 Event Logs ....................4-26 IPMI ....................... 4-28 Boot .......................4-30 Security ......................4-31 Save &...

  • Page 10: Chapter 1 Overview

    Chapter 1: Overview Chapter 1 Overview Overview Checklist Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. This motherboard was designed to be used in an SMC-proprietary system as a part of an integrated system platform.
  • Page 11 X9DRFR Motherboard User’s Manual Motherboard Image Note: All graphics shown in this manual were based upon the latest PCB Revision available at the time of publishing of the manual. The motherboard you've received may or may not look exactly the same as the graphics...
  • Page 12 COM1 JTPM1 JIPMB1 USB2 JPBR1 JPB1 P1-DIMMC1 P2-DIMME1 P1-DIMMC2 P2-DIMME2 P1-DIMMD2 P2-DIMMF1 P1-DIMMD1 P2-DIMMF2 FAN3 FAN2 P2-DIMMH2 P2-DIMMH1 LED1 P2-DIMMG2 FANA P1-DIMMB2 JPL1 P2-DIMMG1 P1-DIMMB1 S-SATA0 P1-DIMMA2 P1-DIMMA1 I-SATA5 I-SATA3 I-SATA1 S-SATA1 JSD1 I-SATA4 I-SATA2 I-SATA0 FAN1 T-SGPIO2 T-SGPIO1 JRST1 JWD1 JNMI1 ALWAYS POPULATE DIMMx1 FIRST...
  • Page 13 X9DRFR Motherboard User’s Manual X9DRFR Quick Reference VGA1 USB1 IPMI LAN2 LAN1 _LAN LEM1 CTRL JBAT1 JI2C1 JPG1 JI2C2 JBT1 JBRST1 BIOS JPW2 X9DRFR Rev. 1.02 CPU1 JITP0 CPU2 Notes: See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front panel connections.
  • Page 14 Chapter 1: Overview X9DRFR Jumpers Jumper Description Default Setting JBRST1 BMC (BaseBoard Controller) Reset Off (Normal) JBT1 Clear CMOS See Chapter C1/JI SMB to PCI-E Slots Off (Disabled) JPB1 BMC Enabled Pins 1-2 (Enabled) JPG1 VGA Enabled Pins 1-2 (Enabled)
  • Page 15 X9DRFR Motherboard User’s Manual X9DRFR LED Indicators Description State Status Onboard PWR LED Green: On Onboard Power On SATA Activity LED Green: Blinking SATA Active LED1 UID LED Blue: On LEM1 BMC Heartbeat LED Green: Blinking BMC Normal Steady On BMC Disabled or Failed Note 1: Slot J4 was designed to support SMC-Proprietary add-on cards.

  • Page 16: Motherboard Features

    Chapter 1: Overview Motherboard Features ® Dual Intel E5-2600 Series (Socket R) processors; each processor supports four full-width Intel Quick- Path Interconnect (QPI) links (with support of up to 25.6 GT/s per QPI link and with Data Transfer Rate of up to 8.0 GT/s per direction) Memory Integrated Memory Controller supports up to 512 GB of 240-pin DDR3 Registered (RDIMM)/Load Re-...
  • Page 17 X9DRFR Motherboard User’s Manual Integrated IPMI 2.0 IPMI 2.0 supported by the WPCM450R BMC Serial (COM) Port One (1) Fast UART 16550 Connection: 9-pin RS- 232 port Super I/O Winbond Super I/O 83527 Peripheral USB Devices Devices Two (2) USB ports on the rear I/O panel (USB 1/2), ®...
  • Page 18 Chapter 1: Overview System Management 2.0 support System resource alert via SuperDoctor III SuperDoctor III, Watch Dog, NMI Chassis Intrusion Header and Detection Dimensions 19.44" (L) x 6.80" (W) (493.78 mm x 172.72 mm) Note 1: CPU Maximum Thermal Design Power (TDP) is subject to chassis and heatsink cooling restrictions.

  • Page 19: System Block Diagram

    X9DRFR Motherboard User’s Manual CPU FRONT FAN Side Socket 1 E5-2600 CPU REAR (I/O Side) Socket 0 E5-2600 3/1.5 SATA2 #5 3/1.5 SATA2 #4 3/1.5 SATA2 #3 SATA DOM 3/1.5 SATA2 #2 Gen3 x8 PWR CONN 6/3/1.5 SATA3 #1 AT25321 SATA3 #0 6/3/1.5...

  • Page 20: Processor And Chipset Overview

    Chapter 1: Overview Processor and Chipset Overview Built upon the functionality and the capability of Intel E5-2600 Series (Socket R) processors and the C602 chipset, the X9DRFR motherboard provides the performance and feature sets required for dual_processor-based HPC/Cluster/ Database server platforms.

  • Page 21: Special Features

    X9DRFR Motherboard User’s Manual Special Features Recovery from AC Power Loss The Basic I/O System (BIOS) provides a setting that determines how the system will respond when AC power is lost and then restored to the system. You can choose for the system to remain powered off (in which case you must press the power switch to turn it back on), or for it to automatically return to the power-on state.

  • Page 22: Acpi Features

    SMC-Proprietary Adaptor (BPN-ADP-F418) to provide power to the system. Super I/O and Power Interface), which includes support of legacy and ACPI power manage- ment through an SMI or SCI function pin. It also features auto power management to reduce power consumption.

  • Page 23: Overview Of The Nuvoton Wpcm450 Controller

    It supports USB 2.0 and 1.1 for remote keyboard/mouse/virtual media emulation. It also provides LPC interface support to control Super IO functions. The WPCM450R Controller is connected to the network via an external Ethernet PHY module or shared NCSI connections.
  • Page 24 Chapter 1: Overview Event Log X-Bus parallel interface for I/O expansion Multiple ADC inputs, Analog and Digital Video outputs Reduced Media Independent Interface (RMII) OS (Operating System) Independency Provides remote Hardware Health Monitoring via IPMI. Key features Provides Network Management Security via remote access/console redirection. Supports the following Management tools: IPMIView, CLI (Command Line Interface) RMCP+ protocol supported...
  • Page 25 X9DRFR Motherboard User’s Manual Notes 1-16...

  • Page 26: Chapter 2 Installation

    Chapter 2: Installation Chapter 2 Installation Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam- aging your system board, it is important to handle it very carefully. The following Precautions Use a grounded wrist strap designed to prevent static discharge. Touch a grounded metal object before removing the board from the antistatic bag.

  • Page 27: Processor And Heatsink Installation

    X9DRFR Motherboard User’s Manual Processor and Heatsink Installation Warning: When handling the processor package, avoid placing direct pressure on the label area. Notes: Always connect the power cord last, and always remove it before adding, removing or changing any hardware components. Make sure that you in- stall the processor into the CPU socket before you install the CPU heatsink.
  • Page 28 Chapter 2: Installation 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Pull lever away from Press down on Load the the socket Lever labeled 'Close 1st' Pin 1 3.
  • Page 29 X9DRFR Motherboard User’s Manual from the socket. keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 3. Once they are aligned, carefully lower the CPU straight down into the socket. (Do not drop the CPU on the socket. Do not move the CPU horizontally or vertically.
  • Page 30 Chapter 2: Installation 4. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. 5. Close the load plate with the CPU inside the socket. Lock the lever labeled thumb to gently push the load levers down to the lever locks.

  • Page 31: Installing A Passive Cpu Heatsink

    X9DRFR Motherboard User’s Manual Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the re- quired amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Motherboard's and the Heatsink Bracket under- neath.

  • Page 32: Removing The Heatsink

    Chapter 2: Installation Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instruc- tions below to avoid damaging the CPU or the CPU socket. 1.

  • Page 33: Installing And Removing The Memory Modules

    X9DRFR Motherboard User’s Manual Installing and Removing the Memory Modules Note: Check Supermicro's Website for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing & Removing DIMMs 1. Insert the desired number of DIMMs into the memory slots, starting with P1- DIMM #1A.
  • Page 34 Chapter 2: Installation Memory Support for the X9DRFR Motherboard The X9DRFR Motherboard supports up to 512 GB of 240-pin Registered (RDIMM)/ Load Reduced (LRDIMM) ECC or up to 128 GB of Unbuffered (UDIMM) ECC/Non- ECC DDR3 800/1066/1333/1600 MHz DDR3 memory in 4- channel 16 DIMM slots.
  • Page 35 X9DRFR Motherboard User’s Manual Intel E5-2600 Series Processor UDIMM Memory Support Ranks Per Memory Capacity Speed (MT/s) and Voltage Validated by Slot per DIMM & Per DIMM Channel (SPC) and DIMM Per Channel (DPC) Data Width 1 Slot Per 2 Slots Per Channel...
  • Page 36 Chapter 2: Installation Intel E5-2600 Series Processor LRDIMM Memory Support Ranks Per Memory Capacity Speed (MT/s) and Voltage Validated DIMM & Data Per DIMM by Slot per Channel (SPC) and Width DIMM Per Channel (DPC) 1 Slot Per 2 Slots Per (See the Note Channel Channel...

  • Page 37: Motherboard Installation

    X9DRFR Motherboard User’s Manual Motherboard Installation Make sure that the locations of all the mounting holes for both motherboard and chassis match. Although a chassis may have both plastic and metal mounting fas- teners, metal ones are highly recommended because they ground the motherboard to the chassis.

  • Page 38: Installing The Motherboard

    Chapter 2: Installation Installing the Motherboard 1. Install the I/O shield into the chassis. 2. Locate the mounting holes on the motherboard. 3. Locate the matching mounting holes on the chassis. Align the mounting holes on the motherboard against the mounting holes on the chassis. 4.

  • Page 39: Control Panel Connectors And I/O Ports

    X9DRFR Motherboard User’s Manual Control Panel Connectors and I/O Ports the picture below for the colors and locations of the various I/O ports. Back Panel Connectors and I/O Ports VGA1 USB1 IPMI LAN2 LAN1 _LAN LEM1 CTRL JBAT1 JI2C1 JPG1...

  • Page 40: Universal Serial Bus (Usb)

    See the tables on the Ground Video Connection A Video (VGA) port is located next to JUSB1 on the I/O backplane. Refer to the board layout below for the location. 1. USB1 2. USB2 3. VGA X9DRFR Rev. 1.02 2-15...

  • Page 41: Ethernet Ports

    X9DRFR Motherboard User’s Manual Ethernet Ports LAN Ports Two Gigabit Ethernet ports (LAN1, LAN2) are located on the I/O back- P2V5SB SGND plane on the motherboard. In addition, TD0+ Act LED an IPMI LAN is also on the backplane. TD0-...

  • Page 42: Front Control Panel

    LEM1 CTRL JBAT1 JI2C1 JPG1 JI2C2 JBT1 JBRST1 BIOS JPW2 X9DRFR Rev. 1.02 CPU1 PMBUS CLK PMBUS DAT JITP0 SMBUS Alert for Hot Swap on SMBUS DAT for Hot Swap on BPN-ADD-F418 PWR Adp. Card BPN-ADD-F418 PWR Adp. Card SMBUS CLK for Hot Swap on...

  • Page 43: Power Management Bus

    X9DRFR Motherboard User’s Manual Power Management Bus PMBUS Button The Power Management Bus header is located on pins 19 and 20 of JF1. PMBUS Clock Refer to the table on the right for pin PMBUS Data SMBUS for Hot Swap Circuit on...

  • Page 44: Smbus For Hot Swap Circuit On Pwr Adaptor Card & Ps Failure

    JI2C1 JPG1 JI2C2 D. Red LED (for OH/Fan Fail) JBT1 JBRST1 BIOS JPW2 X9DRFR Rev. 1.02 PMBUS DAT PMBUS CLK CPU1 SMBUS Alert for Hot Swap on SMBUS DAT for Hot Swap on BPN-ADD-F418 PWR Adp. Card BPN-ADD-F418 PWR Adp. Card...

  • Page 45: Front Panel Power On Led

    X9DRFR Motherboard User’s Manual Front Panel Power On LED FP PWR On LED Connect an LED Cable to pins 9 and 10 of JF1 to indicate if onboard power Front Panel PWR LED is on. Refer to the table on the right...

  • Page 46: Fan Speed Signals

    JBAT1 D. LAN LED Signal JI2C1 JPG1 JI2C2 JBT1 JBRST1 BIOS JPW2 X9DRFR Rev. 1.02 PMBUS CLK PMBUS DAT CPU1 SMBUS Alert for Hot Swap on SMBUS DAT for Hot Swap on BPN-ADD-F418 PWR Adp. Card BPN-ADD-F418 PWR Adp. Card...

  • Page 47: Power Button

    X9DRFR Motherboard User’s Manual Power Button Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily Signal contacting both pins will power on/off Ground the system. This button can also be con- (with a setting in BIOS - See Chapter 4).

  • Page 48: Connecting Cables

    SMC-Proprietary Adaptor (PN# BPN-ADP-F418) that is installed in the chassis to provide power to the system. A. J4: Add-On Card Slot VGA1 USB1 B. JPW2 IPMI LAN2 LAN1 _LAN LEM1 CTRL JBAT1 JI2C1 JPG1 JI2C2 JBT1 JBRST1 BIOS JPW2 X9DRFR Rev. 1.02 CPU1 JITP0 CPU2 2-23...

  • Page 49: Fan Headers

    X9DRFR Motherboard User’s Manual Fan Headers Fan Header This motherboard has four system/CPU/ fan headers (Fan 1-Fan 3, Fan A) on Ground the motherboard. All these 4-pin fans +12V headers are backward compatible with Tachometer the traditional 3-pin fans. The fan speeds...

  • Page 50: Ipmb

    Front Control Panel (JF1) on the motherboard. See the table on the Ground A. IPMB B. COM1 VGA1 USB1 IPMI LAN2 LAN1 _LAN LEM1 CTRL JBAT1 JI2C1 JPG1 JI2C2 JBT1 JBRST1 BIOS JPW2 X9DRFR Rev. 1.02 CPU1 JITP0 CPU2 2-25...

  • Page 51: T-Sgpio 1/2 Headers

    X9DRFR Motherboard User’s Manual T-SGPIO 1/2 Headers T-SGPIO Two SGPIO (Serial-Link General Purpose Input/Output) headers are located on the motherboard. These Ground Data headers support Serial_Link interface Load Ground for onboard SATA connections. See Clock Note: NC= No Connection tions.

  • Page 52: Jumper Settings

    The Enabled (default) default setting is Enabled. Disabled VGA1 USB1 IPMI LAN2 LAN1 _LAN A. GLAN1 Enable LEM1 CTRL JBAT1 JI2C1 JPG1 JI2C2 JBT1 JBRST1 BIOS JPW2 X9DRFR Rev. 1.02 CPU1 JITP0 CPU2 2-27...

  • Page 53: Cmos Clear

    X9DRFR Motherboard User’s Manual CMOS Clear JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such as a small screwdriver to touch both pads at the same time to short the connection.

  • Page 54: Vga Enable

    KVM support on the motherboard. See the table on the right for jumper settings. VGA Enabled VGA1 USB1 BMC Enabled IPMI LAN2 LAN1 _LAN LEM1 CTRL JBAT1 JI2C1 JPG1 JI2C2 JBT1 JBRST1 BIOS JPW2 X9DRFR Rev. 1.02 CPU1 JITP0 CPU2 2-29...

  • Page 55: Bmc Reset

    X9DRFR Motherboard User’s Manual C Bus to PCI-Exp. Slots C to PCI-Exp Jumper Settings Jumpers JI C1 and JI C2 allow you to connect the System Management Bus Closed Enabled C) to PCI-Express slots. The default Open Disabled (Default) setting is Open to disable the connec- tion.

  • Page 56: Onboard Led Indicators

    Speed Green: Solid 100 Mbps VGA1 USB1 IPMI LAN2 LAN1 _LAN LEM1 CTRL JBAT1 JI2C1 JPG1 JI2C2 JBT1 JBRST1 BIOS JPW2 X9DRFR A. LAN1/2 LEDs Rev. 1.02 B. IPMI LAN LEDs CPU1 JITP0 CPU2 2-31...

  • Page 57: Onboard Power Led

    X9DRFR Motherboard User’s Manual Onboard Power LED Onboard PWR LED Indicator LED Settings An Onboard Power LED is located at LE1 on the motherboard. When this LED is on, System Off (PWR cable not connected) the system is on. Be sure to turn off the...

  • Page 58: Sata Activity Led

    A. SATA Activity LED VGA1 USB1 B. UID LED IPMI LAN2 LAN1 _LAN LEM1 CTRL JBAT1 JI2C1 JPG1 JI2C2 JBT1 JBRST1 BIOS JPW2 X9DRFR Rev. 1.02 CPU1 JITP0 CPU2 2-33...

  • Page 59: Serial Ata Connections

    X9DRFR Motherboard User’s Manual Serial ATA Connections Serial ATA Ports SATA2/SATA3 There are eight Serial_ATA ports on the motherboard. I-SATA ports 0/1 support SATA 3.0 connections. I-SATA 2-5 from Ground the PCH chip, and S-SATA 0/1 from the TX_P SCU chip are SATA 2.0 connectors. These...

  • Page 60: Chapter 3 Troubleshooting

    Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Note: Always disconnect the power cord before adding, changing or installing any hardware components.

  • Page 61: When The System Becomes Unstable

    X9DRFR Motherboard User’s Manual 1. Make sure that you are using a high quality power supply. A poor quality power supply may cause the system to lose the CMOS setup information. Refer to Section 2-6 for details on recommended power supplies.

  • Page 62: Technical Support Procedures

    Chapter 3: Troubleshooting B. The system becomes unstable before or during the OS installation When the system becomes unstable before or during OS installation, check the following: 1. Source of installation: Make sure that the devices used for installation are working properly, including boot devices such as CD/DVD disc, CD/DVD- ROM.
  • Page 63 X9DRFR Motherboard User’s Manual 3. If you still cannot resolve the problem, include the following information when contacting Supermicro for technical support: Motherboard model and PCB revision number BIOS release date/version (This can be seen on the initial display when your An example of a Technical Support form is on our website at (http://www.

  • Page 64: Battery Removal And Installation

    Chapter 3: Troubleshooting Battery Removal and Installation Battery Removal To remove the onboard battery, follow the steps below: 1. Power off your system and unplug your power cable. 2. Locate the onboard battery as shown below. 3. Using a tool such as a pen or a small screwdriver, push the battery lock out- wards to unlock it.

  • Page 65: Frequently Asked Questions

    X9DRFR Motherboard User’s Manual Frequently Asked Questions Question: What are the various types of memory that my motherboard can support? Answer: The motherboard supports Registered (RDIMM)/Load Reduced (LRDIMM) ECC or Unbuffered (UDIMM) ECC/Non-ECC DDR3 modules. To enhance memory performance, do not mix memory modules of different speeds and sizes. Please follow all memory installation instructions given on Section 2-3 in Chapter 2.

  • Page 66: Returning Merchandise For Service

    Chapter 3: Troubleshooting Returning Merchandise for Service A receipt or copy of your invoice marked with the date of purchase is required before any warranty service will be rendered. You can obtain service by calling your ven- dor for a Returned Merchandise Authorization (RMA) number. When returning the motherboard to the manufacturer, the RMA number should be prominently displayed on the outside of the shipping carton, and the shipping package is mailed prepaid or hand-carried.
  • Page 67 X9DRFR Motherboard User’s Manual Notes...

  • Page 68: Chapter 4 Bios

    BIOS Introduction This chapter describes the AMI BIOS Setup utility for the X9DRFR. It also provides the instructions on how to navigate the AMI BIOS Setup utility screens. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated.

  • Page 69: Starting The Setup Utility

    X9DRFR Motherboard User’s Manual entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing <Delete> at the appropriate time during system boot. Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Re- covery User Guide posted @http://www.supermicro.com/support/manuals/.
  • Page 70 Day MM/DD/YY format. The time is entered in HH:MM:SS format. (Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00.). Supermicro X9DRFR Version This item displays the SMC version of the BIOS ROM used in this system.

  • Page 71: Boot Feature

    X9DRFR Motherboard User’s Manual Select the Advanced tab to access the following submenu items. Boot Feature Quiet Boot This feature allows the user to select bootup screen display between POST mes- sages and the OEM logo. Select Disabled to display the POST messages. Select Enabled to display the OEM logo instead of the normal POST messages.
  • Page 72 Chapter 4: AMI BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup and allow the drives that are attached to these host adaptors to function as bootable disks.
  • Page 73 X9DRFR Motherboard User’s Manual CPU Signature Microcode Patch CPU Stepping Maximum / Minimum CPU Speed Processor Cores Intel HT (Hyper-Threading) Technology Intel VT-x Technology Intel SMX Technology L1 Data Cache / L1 Code Cache L2 Cache L3 Cache CPU Speed This item displays the speed of the CPU installed in Socket 1/Socket 2.
  • Page 74 Chapter 4: AMI BIOS Limit CPUID Maximum This feature allows the user to set the maximum CPU ID value. Enable this function to boot the legacy operating systems that cannot support processors with extended CPUID functions. The options are Enabled and Disabled (for the Windows OS). Execute-Disable Bit (Available if supported by the OS &...
  • Page 75 X9DRFR Motherboard User’s Manual Note: If there is any change to this setting, you will need to reboot the system for the change to take effect. Refer to Intel’s website for details.) ment settings. Power Technology tomize system power settings. Select Disabled to disable power-saving settings.
  • Page 76 Chapter 4: AMI BIOS Package C-State limit (Available when Power Technology is set to Custom) This feature allows the user to set the limit on the C-State package register. The options are C0, C2, C6, and No Limit. Energy/Performance Bias Use this feature to select an appropriate fan setting to achieve maximum system via IPMI 2.0.

  • Page 77: North Bridge

    X9DRFR Motherboard User’s Manual North Bridge ® Intel VT-d Select Enabled to enable Intel Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to the VMM (Virtual Machine Monitor) through the DMAR ACPI Tables. This feature offers fully-protected I/O resource sharing across Intel platforms, providing greater reliability, security and availability in networking and data-sharing.
  • Page 78 Chapter 4: AMI BIOS CPU1 MLP PCI-E 3.0 x8 Link Speed Select GEN1 to enable PCI-Exp Generation 1 support for this port Select GEN2 to enable PCI-Exp Generation 2 support for this port. Select GEN3 to enable PCI-Exp Generation 3 support. The options are GEN1, GEN2, and GEN3. IOU2-PCIe Port This feature allows the user to set the PCI-Exp bus speed between IOU3 and PCI-e port.
  • Page 79 X9DRFR Motherboard User’s Manual QPI (Quick Path Interconnect) Link Speed Mode Use this feature to select data transfer speed for QPI Link connections. The options are Slow and Fast. QPI Link Frequency Select Use this feature to select the desired QPI frequency. The options are Auto, 6.4 GT/s, 7.2 GT/s, and 8.0 GT/s.
  • Page 80 Chapter 4: AMI BIOS DRAM RAPL Mode RAPL (Running Average Power Limit) provides mechanisms to enforce power consumption limits on supported processors The options are Disabled, DRAM RAPL MODE0, and DRAM RAPL MODE1. DDR Speed Use this feature to force a DDR3 memory module to run at a frequency other than DDR3-1066, Force DDR3-1333, Force DDR3-1600 and Force SPD, and Auto.

  • Page 81: South Bridge

    X9DRFR Motherboard User’s Manual Thermal Throttling Throttling improves reliability and reduces power consumption in the proces- sor via automatic voltage control during processor idle states. The options are Disabled and CLTT (Closed Loop Thermal Throttling). South Bridge PCH Information This feature displays the following PCH information.
  • Page 82 Chapter 4: AMI BIOS When this submenu is selected, the AMI BIOS automatically detects the presence of IDE or SATA devices and displays the following items. SATA Port0~SATA Port5: The AMI BIOS displays the status of each SATA port as detected by the BIOS. SATA Mode Disabled, IDE Mode, AHCI Mode and RAID Mode.
  • Page 83 X9DRFR Motherboard User’s Manual RAID Mode The following items are displayed when RAID Mode is selected: SATA RAID Option ROM Use this feature to determine which SATA RAID device the system will boot from. The options are Legacy and EFI.
  • Page 84 Chapter 4: AMI BIOS PERR# Generation Select Enabled to allow a PCI device to generate a PERR number for a PCI Bus Signal Error Event. The options are Enabled and Disabled. SERR# Generation Select Enabled to allow a PCI device to generate an SERR number for a PCI Bus Signal Error Event.
  • Page 85 Extensible Firmware Interface) for network stack support. The options are Enabled and Disabled. Super IO Chip: This item displays the Super IO chip used in the motherboard. Serial Port Select Enabled to enable the COM serial port. The options are Enabled and Dis- abled.

  • Page 86: Serial Port Console Redirection

    Chapter 4: AMI BIOS Device Settings This item displays the settings of the SOL serial port. Change Settings of the SOL Port. Select Disabled to prevent the serial port from accessing any system resources. When this option is set to Disabled, the serial port becomes unavailable.
  • Page 87 X9DRFR Motherboard User’s Manual Bits Per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.

  • Page 88: Console Redirection Settings (For Ems)

    Chapter 4: AMI BIOS Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support. The options are 80x24 and 80x25. Putty KeyPad This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS.

  • Page 89: Acpi Settings

    X9DRFR Motherboard User’s Manual Flow Control ing data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None, Hardware RTS/ CTS, and Software Xon/Xoff. Data Bits, Parity, Stop Bits The setting for each of these features is displayed.
  • Page 90 Chapter 4: AMI BIOS TPM State Select Enabled to enable TPM security settings to improve data integrity and network security. The options are Disabled and Enabled. Pending Operation Use this item to schedule an operation for the security device. The options are None, Enable Take Ownership, Disable Take Ownership, and TPM Clear.
  • Page 91 X9DRFR Motherboard User’s Manual Intel TXT (LT-SX) Dependencies This feature displays the features that need to be enabled for the Intel Trusted Execution Technology to work properly in the system. VT-d Support: Intel Virtualization Technology with Direct I/O support VT Support: Intel Virtualization Technology support...
  • Page 92 Chapter 4: AMI BIOS ® Intel Ethernet Controller I350 Gigabit Network Connection These items display the following information on the Intel I350 Gigabit network connections. Link Speed Use this feature to change the link speed and duplex for the current port. The op- tions are AutoNeg, 10Mbps Half, 10Mbps Full, 100Mbps Half, and 100Mbps full.

  • Page 93: Event Logs

    X9DRFR Motherboard User’s Manual Event Logs Select the Event Logs tab to access the following submenu items. Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot. The options are Enabled and Disabled.
  • Page 94 Chapter 4: AMI BIOS Erasing Settings Erase Event Log Select Enabled to erase the SMBIOS (System Management BIOS) Event Log, which is completed before a event logging is initialized upon system reboot. The options are No, Yes, Next reset, and Yes, Every reset. When Log is Full Select Erase Immediately to immediately erase SMBIOS error event logs that ex- ceed the limit when the SMBIOS event log is full.

  • Page 95: Ipmi

    X9DRFR Motherboard User’s Manual IPMI Select the IPMI (Intelligent Platform Management Interface) tab to access the fol- lowing submenu items. IPMI Firmware Revision IPMI Status System Event Log Enabling/Disabling Options SEL Components Select Enabled for all system event logging at bootup. The options are Enabled and Disabled.
  • Page 96 Chapter 4: AMI BIOS When SEL is Full This feature allows the user to decide what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately. LAN Channel 1 This feature allows the BIOS to implement any IP/MAC address changes at the next system boot.

  • Page 97: Boot

    X9DRFR Motherboard User’s Manual Boot system. Boot Option Priorities Boot Option #1, Boot Option #2, etc. Use this feature to specify the sequence of boot device priority. Network Devices Use these options to set the order of the legacy network devices detected by the motherboard.

  • Page 98: Security

    Chapter 4: AMI BIOS Security system. Password Check Use this feature to determine when a password entry is required. Select Setup to require the password only when entering setup. Select Always to require the pass- word when entering setup and on each boot. The options are Setup and Always. Administrator Password Use this feature to set the Administrator Password which is required to enter the BIOS setup utility.

  • Page 99: Save & Exit

    X9DRFR Motherboard User’s Manual Save & Exit system. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes and Exit, and press <Enter>. When the dialog box appears, asking you if you want to exit the BIOS setup without saving, select Yes to quit BIOS without saving the changes, or select No to quit the BIOS and save changes.
  • Page 100 Chapter 4: AMI BIOS Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previ- ous values, select Yes to load the values previous saved, or select No to keep the changes you've made so far.
  • Page 101 X9DRFR Motherboard User’s Manual Notes 4-34...

  • Page 102: Appendix A Software Installation Instructions

    Appendix A: Software Installation Instructions Appendix A Software Installation Instructions A-1 Installing Software Programs After you've installed the operating system, a screen as shown below will appear. You are ready to install software programs and drivers that have not yet been in- stalled.
  • Page 103 X9DRFR Motherboard User’s Manual The SuperDoctor III program is a Web-based management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called the SD III Client. The SuperDoctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 104 Appendix A: Software Installation Instructions SuperDoctor III Interface Display Screen-II (Remote Control) The SDIII utility and the user guide can be downloaded from our website at: http://www.supermicro.com/products/accessories/soft- ware/SuperDoctorIII.cfm. For Linux, we will still recommend that you use SuperDoctor II.
  • Page 105 X9DRFR Motherboard User’s Manual Notes...
  • Page 106 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products for use in such ultra-hazardous applications, it does so entirely at its own risk.
