- Page 1 Design Guide with Installation Instructions 36” Built-In French Door, Bottom-Freezer Refrigerators Pub. No. 49-60700 Part No. 224D3560P001 12-13 GE monogram.com...
-
Page 2: Table Of Contents
• Les réparations doivent être faites par un technicien qualifié. À cause du poids et de la taille de ce réfrigérator et pour réduire le risque de blessure et de dommages, IL For Monogram local service in your area, call FAUT TROIS PERSONNES POUR FAIRE L’INSTALLATION 1.800.444.1845. CORRECTEMENT. -
Page 3: The Installation Space
Design Guide DIMENSIONS AND CLEARANCES THE INSTALLATION SPACE 35-1/2" 25-3/8" Framed Models 35" Finished Width 25-3/4" Stainless Steel Models Case Width Case Depth The finished Wall View 2-5/16" * Shipping height. The cutout width refrigerator can be must be 6" adjusted to fit into a 35-1/2”. -
Page 4: 130° Door Swing
Design Guide Frameless Cabinets: The case trim overlaps cabinets at the top and sides. Therefore, frameless cabinets Refrigerator may require filler strips to prevent 23-7/8" From interference with cabinet door swing. Rear of The opening must allow for filler strips. Refrigerator 1"... -
Page 5: 90° Door Swing
Design Guide Frameless Cabinets: The case trim overlaps cabinets at the top and Refrigerator sides. Therefore, frameless cabinets may require Case Trim filler strips to prevent interference with cabinet door swing. The opening must allow for filler strips. 23-7/8" From Rear of Refrigerator 1/4"... -
Page 6: Customization Basics
Stainless Steel Wrapped Refrigerators Stainless steel wrapped refrigerators with beveled edges and tubular stainless steel handles that coordinate with other Monogram appliances. These models are shipped ready for installation. Trimmed Refrigerators Trimmed refrigerators are designed to be customized with decorative panels. -
Page 7: Panel Dimensions
Design Guide 1/4” FRAMED PANEL DIMENSIONS 5/16" Trim If you choose to install framed panels, they must be cut Door Reveal to the dimensions shown. The panels will slide into the frame on the door, drawer and grille. 1/4" If the custom panel is less than 1/4” thick and if it fits Panel loosely in the door frame, it can be backed up with a piece of filler material or foam tape to improve the fit. -
Page 8: Side Panels
Design Guide SIDE PANELS 24" * Depending on Side panels must be used whenever the sides of the installation height. refrigerator will be exposed. The 1/4 side panels will ” slip into the side case trim. Secure the panels to the 3/16"... -
Page 9: Installation Instructions Tools, Hardware, Materials
Installation Instructions TOOLS REQUIRED MATERIALS REQUIRED • Tinsnips to cut banding • 35” long 2x4 for Anti-Tip support • Stepladder • 1/4” copper water line tubing or GE SmartConnect ™ • Bucket Refrigerator Tubing kits • Level • Water shut-off valve •... -
Page 10: Step 1 Remove Packaging
GE SmartConnect Refrigerator Tubing Kits are available ™ in the following lengths: 2 ft (.6 m) WX08X10002 6 ft (1.8 m) WX08X10006 15 ft (4.6 m) WX08X10015 25 ft (7.6 m) WX08X10025 Shut off the main water supply. Turn on the nearest faucet long enough to clear the line of water. -
Page 11: Step 2A, Ro Water Line
Installation Instructions STEP 4 INSTALL ANTI-TIP BRACKETS STEP 2A WATER LINE INSTALLATION WITH A REVERSE OSMOSIS SYSTEM WARNING: ANTI-TIP PRECAUTIONS The refrigerator is top-heavy and must be secured to prevent the Skip this step when not using an RO System possibility of tipping forward. -
Page 12: Step 5, Level Refrigerator
Installation Instructions STEP 6 ALTERNATE ANTI-TIP STEP 5 LEVEL REFRIGERATOR PROCEDURE All models have 4-point leveling. The front is supported by leveling legs, the rear is supported by adjustable The refrigerator must be secured to prevent tipping. wheels. Both are accessible from the front of the The anti-tip brackets cannot be used on metal wall refrigerator. -
Page 13: Step 8, Adjust Door Swing
Installation Instructions STEP 8 ADJUST DOOR SWING STEP 9 INSTALL GRILLE PANEL NOTE: This refrigerator has a 2-position door stop. • Raise the grille panel to stop position. When space does not allow the door to swing open fully to 130°, you may change the door swing to a 90° opening. -
Page 14: Step 10, Install Framed Panels
Installation Instructions STEP 10 INSTALL 1/4” FRAMED PANELS IF YOU ARE INSTALLING OVERLAY PANELS, GO TO STEP 10A. Standard supplied handle shown in 1/4” panel position. 194Dia12 Install door and drawer panels: • Open door to 90°. Remove the 4 Phillips head screws •... -
Page 15: Step 10A Install Overlay Panels
Installation Instructions STEP 10A INSTALL OVERLAY PANELS Right hand models shown. Use the same instructions for left hand models. Use Front Holes to Secure Handle Use Rear Holes to Secure Trim 729Dia93 Supplied handle shown in the overlay panel position. Install door and drawer panels: •... -
Page 16: Step 11 Connect Water Supply
Installation Instructions STEP 11 CONNECT WATER SUPPLY STEP 12 CONNECT POWER • Check to be sure the power cord is plugged into the receptacle. Raise Grille Panel Electrical Master Outlet Light Switch House Refrigerator Water Supply Water Supply • Check to make sure power to refrigerator is on by opening refrigerator door to see if interior lights are •... -
Page 17: Step 14, Install Toekick
Installation Instructions STEP 14 INSTALL TOEKICK INSPECT FINAL INSTALLATION • Locate the supplied toekick (shipped taped to Check door alignment the side of the refrigerator). Install the toekick Stand back away from the refrigerator to inspect the assembly with the 3 screws provided, adjust to the final installation. - Page 18 Notes...
- Page 19 Notes...
- Page 20 NOTE: While performing installations described in this book, safety glasses or goggles should be worn. For Monogram local service in your area, call ® 1.800.444.1845. NOTE: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice.
