Monogram Free-Standing Side-by-Side Stainless Steel Refrigerator Owner's Manual
Free-standing side-by-side stainless steel refrigerator
Hide thumbs
Also See for Free-Standing Side-by-Side Stainless Steel Refrigerator:
- Owner's manual (32 pages)
Related Manuals for Monogram Free-Standing Side-by-Side Stainless Steel Refrigerator
Summary of Contents for Monogram Free-Standing Side-by-Side Stainless Steel Refrigerator
- Page 1 Monogram ® Owner’s Manual Free-Standing Side-by-Side Stainless Steel Refrigerator monogram.com...
-
Page 2: Table Of Contents
Whether you chose it for its purity of design, practical storage arrangements or assiduous attention to detail—or for all of these reasons—you’ll find that your Monogram refrigerator’s superior blend of form and function will delight you for years to come. - Page 3 Write You’ll see them on a label inside the fresh food Before sending in this card, please also write compartment at the top on the right side. these numbers here: down the model & Please write these numbers on the Consumer serial Product Ownership Registration Card included Model Number...
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS located on the bottom of the icemaker. WARNING— When using Do not place fingers or hands on the this appliance, always exercise basic safety automatic icemaking mechanism while precautions, including the following: the refrigerator is plugged in. - Page 5 LIRE ET CONSERVER CES INSTRUCTIONS • Éloignez les doigts des parties du AVERTISSEMENT : réfrigérateur où l’on peut facilement se Lorsque vous utilisez le réfrigérateur, observez pincer : les espaces entre les portes et entre toujours certaines précautions de base, les portes et les placards sont toujours étroits.
-
Page 6: How To Connect Electricity
IMPORTANT SAFETY INSTRUCTIONS HOW TO CONNECT ELECTRICITY Do not, under any circumstances, cut or This provides the best performance and also remove the third (ground) prong from the prevents overloading house wiring circuits power cord. For personal safety, this appliance which could cause a fire hazard from must be properly grounded. -
Page 7: Cordons Prolongateurs
RACCORDEMENT ÉLECTRIQUE Ne coupez ni retirez en aucun cas la troisième Cette précaution est recommandée pour broche (mise à la terre) de la fiche du cordon garantir un rendement optimum et éviter d’alimentation. Pour votre sécurité, cet une surcharge des circuits électriques de la appareil doit être correctement mis à... -
Page 8: Temperature Controls
Air Tower along the top instructions, on-line, 24 hours a day, contact us and back walls of the fresh food compartment and at www.monogram.com or call 800.444.1845. the Air Tunnel on the bottom portion of the In Canada, call us at 1.888.880.3030.) freezer rear wall. - Page 9 CustomCool™ Stainless Steel Refrigerator The CustomCool™ feature is a system of the pan’s temperature from causing How it works dampers, a fan, a temperature thermistor, temperature fluctuations in the rest and a heater. Depending on the function of the refrigerator. selected, a combination of these will be The controls for this pan are located at used to quickly chill items, thaw items or...
- Page 10 CustomCool™ Stainless Steel Refrigerator NOTE: Results may vary depending on packaging, starting temperature, and other food traits. CustomCool ™ chart 0.5 Lbs. (4 hours) 15 Minutes Citrus Setting (43°F) • Hamburger Patties (0.5 lb) • 1 Beverage Can (12 oz) •...
-
Page 11: Water And Freshsaver Filters
Water and FreshSaver™ Filters Stainless Steel Refrigerator The water filter cartridge is located Run water from the dispenser for 3 minutes Water filter in the back upper right corner of (about one and a half gallons) to clear the cartridge the fresh food compartment. -
Page 12: Shelves And Bins
Shelves and Bins Stainless Steel Refrigerator Large Bins Fresh food Snugger compartment The larger fresh food compartment door bins and freezer tilt-out door bins are adjustable. door bins and freezer To remove: Lift the front of the bin straight up, then lift up and out. - Page 13 Shelves and Bins Stainless Steel Refrigerator This shelf splits in half and slides under itself QuickSpace ™ for storage of tall items on the shelf below. shelf This shelf can be removed and replaced or relocated just like Slide-Out Spillproof Shelves. On some models, this shelf can not be used in the lowest position.
-
Page 14: Additional Features
Additional Features Stainless Steel Refrigerator The beverage rack is designed to hold Removable a bottle on its side. It can be attached to beverage any slide-out shelf. rack To install: Line up the large part of the slots on the top of the rack with the tabs under the shelf. -
Page 15: Crispers And Pans
Crispers and Pans Stainless Steel Refrigerator Excess water that may accumulate in the Fruit and bottom of the drawers should be wiped dry. vegetable The bottom drawer has a cover that slides back crispers as the drawer is opened. This allows full access to the drawer. -
Page 16: Automatic Icemaker
Automatic Icemaker Stainless Steel Refrigerator A newly-installed refrigerator may take 12 to 24 hours to begin making ice. Automatic icemaker The icemaker will produce seven cubes NOTE: In homes with lower-than-average water per cycle—approximately 100–130 cubes pressure, you may hear the icemaker cycle multiple in a 24-hour period, depending on freezer times when making one batch of ice. -
Page 17: Ice And Water Dispenser
Ice and Water Dispenser Stainless Steel Refrigerator Using the Select CUBED ICE , CRUSHED ICE dispenser or WATER Press the glass gently against the top of the dispenser cradle. The spill shelf is not self-draining. To reduce water spotting, the shelf and its grille should be cleaned regularly. - Page 18 Ice and Water Dispenser Stainless Steel Refrigerator Ice storage To remove: Set the icemaker power switch to the 0 (off) drawer position. Pull the drawer straight out and then lift past the stop position. To replace: When replacing the drawer, be sure to press it firmly into place.
-
Page 19: Care And Cleaning
Care and Cleaning Stainless Steel Refrigerator Cleaning The dispenser drip The stainless steel panels and handles can be area, beneath the cleaned with a commercially available stainless the outside grille, should be steel cleaner such as Stainless Steel Magic™ . wiped dry. -
Page 20: Moving
Care and Cleaning Stainless Steel Refrigerator Behind the Be careful when moving the refrigerator away When pushing the refrigerator back, make sure from the wall. All types of floor coverings can you don’t roll over the power cord or icemaker refrigerator be damaged, particularly cushioned coverings supply line. -
Page 21: Replacing The Light Bulbs
Replacing the Light Bulbs Stainless Steel Refrigerator Fresh food Setting the controls to OFF does not remove power to the light circuit. compartment— 1 Unplug the refrigerator. upper light 2 The bulbs are located at the top of the compartment, inside the light shield. Tabs On some models, a screw at the front of the light shield will have to be removed. -
Page 22: Normal Operating
The Problem Solver Stainless Steel Refrigerator These sounds are normal and are due mostly to highly efficient operation. Normal operating sounds The new high efficiency compressor runs faster and will have a higher pitch hum or pulsating sound while operating. The fans circulating air inside the freezer and fresh food compartments which keep the temperatures uniform throughout. - Page 23 The Problem Solver Stainless Steel Refrigerator Questions? PROBLEM POSSIBLE CAUSE Use this REFRIGERATOR • Refrigerator may be in defrost cycle when motor does not operate for DOES NOT OPERATE about 30 minutes. problem • Either or both controls set to OFF. Set to a temperature setting. solver! •...
- Page 24 The Problem Solver Stainless Steel Refrigerator Questions? PROBLEM POSSIBLE CAUSE Use this ICE CUBES HAVE • Old cubes need to be discarded. ODOR/TASTE problem • Ice storage bin needs to be emptied and washed. solver! • Unsealed packages in fresh food and/or freezer compartments may be transmitting odor/taste to ice cubes.
- Page 25 The Problem Solver Stainless Steel Refrigerator Questions? PROBLEM POSSIBLE CAUSE Use this CUBED ICE WAS • • The last setting was CRUSHED ICE and a few cubes were left in the SELECTED BUT crusher from the previous setting. This is normal. problem CRUSHED ICE solver!
- Page 26 The Problem Solver Stainless Steel Refrigerator Questions? PROBLEM POSSIBLE CAUSE Use this ACTUAL • Unit just plugged in. Allow 24 hours for the system to stabilize. TEMPERATURE NOT problem • Door open for too long. Allow 24 hours for the system to stabilize. EQUAL TO SET solver! •...
-
Page 27: Performance Data Sheet
Performance Data Sheet GE SmartWater Filtration System GWF Cartridge Health Claim Performance Certified by NSF/ANSI* (100% safety factors built in for unmetered usage) Standard No. 42: Aesthetic Effects Parameter USEPA Influent Effluent % Reduction Challenge Average Maximum Average Minimum Chlorine –... - Page 28 State of California Department of Health Services Water Treatment Device Certificate Number 00 - 1434 Date Issued: May 30, 2000 Date Revised: February 9, 2001 GE Smart Water Filtration Systems - GWF06 GWF06 GE Smart Water Filtration Systems - GWF Hotpoint Refrigerator Systems - HWF General Electric Appliances Cysts (protozoan)
- Page 29 Place 1st Class Letter Stamp Here General Electric Company Warranty Registration Department P.O. Box 32150 Louisville, KY 40232-2150...
-
Page 30: Model And Serial Numbers
Consumer Product Ownership Registration Dear Customer: Thank you for purchasing our product and thank you for placing your confidence in us. We are proud to have you as a customer! Follow these three steps to protect your new appliance investment: Complete and mail your After completing the Read your “Owner’s... -
Page 31: Consumer Services
With the purchase of your new Monogram appliance, receive the assurance that if you ever need information or assistance from GE, we’ll be there. All you have to do is call—toll- free! GE Answer Whatever your question about any Monogram major appliance, GE Answer Center ® Center ®... - Page 32 Warranty Stainless Steel Refrigerator YOUR MONOGRAM REFRIGERATOR WARRANTY Staple sales slip or cancelled check here. Proof of original purchase date is needed to obtain service under warranty. WHAT IS FULL ONE-YEAR WARRANTY For one year from date of original purchase, we will provide, free of charge, parts and service labor in COVERED your home to repair or replace any part of the refrigerator that fails because of a manufacturing defect.
