Beech ovens REC1250 Brochure & Specs

Type: Rectangular Stone Hearth Oven
Model: REC1250
The Beech REC1250 Stone Hearth Oven is manufactured from a high
grade castable ceramic material and completely enclosed in a housing
of 5mm mild steel. This mild steel outer casing and incorporated lifting
hooks make installation easy which reduces potential damage to the
oven. The inside measurements of the oven are 1250mm x 850mm
with a 1.06m² cooking surface (0.91m² for full gas). This style of oven
can be fired using wood, gas back-up or full gas.
The spectacular performance of a Beech Oven is a result of the huge
thermal mass of the unique ceramic cast interior. Beech Ovens have
TWICE the mass (thermal mass) of any other pre-cast oven on the
market. The unique oven design results in superior cooking
performance and exceptional thermal efficiency.
The cooking surface of the oven (stone hearth) in constructed using
high quality 75mm thick Fire bricks, renowned for their excellent
cooking attributes and incredible wear resistance. The use of bricks
eliminates the unsightly cracking associated with one piece floors. The
bricks sit upon a 25mm VF insulating board and a further 5mm
reinforced mild steel base.
The unique three (3) piece oven design allows all Beech Ovens to be installed through a standard 700mm doorway. All Beech
Ovens can be installed without the use of a crane therefore significantly reducing the costs of installation. The oven body comes
with an exclusive 4 year guarantee.
The oven can be installed within 75mm (including 50mm of insulating wool and 25mm air gap) of non-combustible material
(check local building and fire codes). The oven exhausts through a spigot above the oven mouth. The oven must be vented in
accordance with local and/or national codes. Refer to "Duct Design Options" on the following pages or for more information,
refer to the Installation and Operation Manual located on our website
Allow 400mm sq ventilation into the underside of the oven for secondary air to the gas burner (if applicable).
www.beechovens.com
Unique Features
Custom features: Wood or thermostatically controlled gas system.
Easy installation into most areas (three (3) piece assembly).
Stainless steel plug door for oven mouth.
Upper
Any gas type – Specify at order time.
Section

Optional Accessories

•
Internal spotlight.
•
Gas fired Char Grill with slide out drawer.
•
Base
Viewing window available in any location.
Section •
Various shape/design facades and Stainless Steel Hearths.
•
Thermostatically controlled Display burner.
•
Exhaust fan.
•
Flue transitions, Spray filters, Canopy hoods and fluing
options (See "Ducting Design Options").
Legs
Approximate Pizza Capacity Per Hour
At 250°C floor temperature the oven will cook:
Size
Pizza / hour
200mm 250mm 300mm
(8") (10") (12")
90 60 30
400mm
(16")
25
