GROUND ZERO
Mobile Entertainment
Amplifier
Owner's Manual
PLUTONIUM
GZPA 1.6000D
GZPA 1.8000D
Linkable Class D Mono Amplifier
GROUND ZERO
Mobile Entertainment
PLEASE READ BEFORE INSTALLATION
Thank you for selecting a Ground Zero Plutonium amplifier. We are
providing a helpful hints list which should keep you from experiencing
unnecessary shut down.
FEATURES:
•
Class-D High Power Mono Amp
•
Efficiency >89%
•
Damping Factor >200 at 20Hz 4Ω
•
16 Volt max. Power supply
•
Linkable
•
1 Ω stabil (Linkmode 2Ω stabil)
•
Full Power MOSFET Amplifier
•
Power und Protect LED
•
Lowpass 50Hz-150Hz with 24dB/Oct
•
Subsonicfilter 15Hz-60Hz with 24dB/Oct
•
Aluminium heat sink
•
Input Sensitivity 200 mV-8 Volt
•
RCA Input/Output
•
Bassremote Control
•
Bassboost 0-12 dB
•
Phase Shift 0°-180°
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Plutonium GZPA 1.6000D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ground Zero Plutonium GZPA 1.6000D

Summary of Contents for Ground Zero Plutonium GZPA 1.6000D

  • Page 1 GROUND ZERO GROUND ZERO Mobile Entertainment Mobile Entertainment PLEASE READ BEFORE INSTALLATION Amplifier Thank you for selecting a Ground Zero Plutonium amplifier. We are Owner’s Manual providing a helpful hints list which should keep you from experiencing unnecessary shut down. FEATURES: •...
  • Page 2 Tools and materials you need Mounting your amplifier • Screwdriver, electric drill, 1/8 carbide drill bit The mounting position of your amplifier will have a great effect on its ability to dissipate the heat generated • Use 2 AWG power wire (min. 35 mm²/ 1.38”) during normal operation.
  • Page 3 Connection and operation CONNECTION AND OPERATION INPUT L/R These inputs are for signal cables from the source, always use high quality RCA type GZPA 1.6000D / GZPA 1.8000D shielded cables Output L/R for more amplifiers Input Slave / Master Input for linkmode Power/ Protection LED Power: This GREEN LED will illuminate when the amplifier is turned “ON”...
  • Page 4 Adjustment and tuning CONNECTION AND OPERATION TURNING ON THE AMPLIFIER GZPA 1.6000D / GZPA 1.8000D The amplifier automatically turns on a few seconds after you turn your vehicle’s ignitions switch to ACC ON or turn on your auto sound system, depending on how you wired the system. The POWER LED on the side of the amplifier lights when the amplfier is on.

  • Page 5: Trouble Shooting Guide

    Speaker connection mode Trouble shooting guide One speaker mono mode SYMPTOMS CHECK POINTS CURE NO SOUND Is the POWER LED illuminated? Check fuses in amplifier. Make sure remote lead is connected check signal leads. Check gain control Check Tuner/Deck volume level Is the PROTECT LED illuminated? Check for speaker short or amplifier overheating...
  • Page 6 Die Gewährleistung entspricht der gesetzlichen Regelung. Eine Rücksendung kann nur nach vorheriger Absprache und in der Originalverpackung erfolgen. Bitte unbedingt einen maschinell erstellten Kaufbeleg und eine Fehlerbeschreibung beilegen. Von der Gewährleistung ausgeschlossen sind Defekte, die durch Überlastung, unsachgemäße Behandlung oder bei Teilnahme an Wettbewerben entstanden sind.
