- Page 1 Ness 104-443 HD-SDI camera User’s Manual REV1.3 Nov11...
- Page 2 All rights reserved. No part of this publication may be reproduced, transmitted or stored in a retrieval system in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Ness. Ness reserves the right to make changes to features and specifications at any time without prior notification in the interest of ongoing product development and improvement.
-
Page 3: Table Of Contents
Table of Contents Overview ..........................2 Features ........................2 Package Contents ......................3 Dimensions........................3 Camera Cabling........................4 Product Application ....................... 4 Connectors ........................5 TV System/Resolution/Frame Rate Setup ..............6 Lens Mounting....................... 6 Appendix A: Technical Specifications..................7 Appendix B: Back Focus Adjustment ................... 8... -
Page 4: Overview
Overview HD-CCTV standard offers a new opportunity for traditional CCTV surveillance industry. It makes CCTV Camera transmit high definition image through coaxial cable. Combing SDI standard with high quality SONY CMOS sensor, the SDI Box Camera provides 1920x1080 resolution high quality image as well as easy and low-cost installation. -
Page 5: Package Contents
Package Contents Please check the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact your dealer for assistance. SDI Box Camera Back focus adjuster Quick Guide (bundled software and documentation) Dimensions... -
Page 6: Camera Cabling
Camera Cabling Please follow the instructions below to complete SDI Box Camera cable connections. Product Application Connect the SDI Box Camera to other devices as shown in the diagram to complete a video surveillance solution. -
Page 7: Connectors
Connectors The diagram below shows the IP Camera’s reset button and various connectors. Definition for each connector will be given as follows. Single Board Dual Board Item Definition Remark Power connection indication (green light) AUTO IRIS Connector Auto Iris Lens connector RESET Reset SDI OUTPUT... -
Page 8: Tv System/Resolution/Frame Rate Setup
TV System/Resolution/Frame Rate Setup Please refer to the illustrations below to set up the Camera TV system, resolution and frame rate. Setting Definition TV System NTSC Resolution 720P 1080P Frame Rate 50/60 25/30 Reserved Reserved Please kindly notice that while BNC output is on, there will be no SDI signal. -
Page 9: Appendix A: Technical Specifications
Appendix A: Technical Specifications Camera 1/2.8” Sony Progressive CMOS Sensor 2144 (H) x 1588 (V), 3.4M Total Pixel 1/30 ~ 1/10000 sec. Shutter Speed 10 /12 bit A/D Converter Lens Fixed / Vari-focal C/CS Mount Lens Operation 1080P / 720P Video Streaming 30/60 fps, 25/50 fps @1080P Frame Rate... -
Page 10: Appendix B: Back Focus Adjustment
Appendix B: Back Focus Adjustment When to adjust back focus Back Focus refers to the distance from the rear lens element to the camera focal plane. In most cases, it is required to adjust back focus only when the camera’s lens cannot hold focus throughout its zoom range.
