Carrier 5+2 DAY PROGRAMMABLEDIGITAL THERMOSTAT Owner's Manual page 21

Programming Worksheet
DAY PERIOD
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Please be certain to program each time period in
chronological order to ensure proper programmed
operation of the thermostat. For example, if the
Morning Start Time is 6:30am, then the Day Start
Time MUST be programmed for any time AFTER the
6:30am Morning Start Time. Also, if the Day Start time
is set for 10:30am, then the Evening Start Time MUST
be programmed for any time AFTER the 10:30am
Day Start Time. Finally, if the Evening Start Time is
set for 5:30pm, then the Night Start Time MUST be
programmed for any time AFTER the 5:30pm Night
Start Time.
Printed on recycled paper.
P/N 88-399
START TIME COOL
Morning
Day
Evening
Night
Morning
Day
Evening
Night
Rev. 2
see page 8
HEAT
Form No. OM-TSTAT-36
Catalog No. 03TS-TA51
