CONTENTS
Content
Table of contents ................................
Unpacking ..................................................
Transporting ...............................................
Sound Data ................................................
I
ntroduction, personal safety ...................... 3
Registration of the product ..................... 4
General safety message ............................
Safety warnings .........................................
Excel series blades ...................................
Blade and skid plate installation ................
What is what? ............................................
Operating instructions ...............................
Fuel and fuel safety warnings .................
Recommended fuels .................................
Recommended oils ...............................
Maintenance ......................................
Sawing contraction joints ......................
Maximizing the Soff-Cut system ..............
Troubleshooting ........................................
Technical specifications ............................
Conformity certificates ..............................
Warranty ...................................................
Page
Your 150 saw has been shipped from the factory thoroughly
2
inspected. Only minimal assembly is required to start using the
2
saw. Remove the saw from the container using proper lifting
2
techniques. Discard or recycle the packing material per your
2
regional laws. In your container will be the 150 saw, a blade
shaft cover, two (2) blade shaft wrenches, spark plug wrench,
an owner's manual, an engine owner's manual, a part list, a
warranty card and a joint protector sample pack.
4
NOTE: No diamond cutting blade or skid is included with
the saw. Purchase the appropriate Excel Series 6 inch
5
blade and skid plate from your local Husqvarna Construc-
tion Product dealer.
6
6
7
The 150 saw weights approximately 91 pounds (41 kilograms)
8
when ready to use . Use safe lifting practices when handling
the saw. Always remove the diamond blade when transporting
9
the saw. Pull the handle locking pin and fold the handle for-
9
ward. Fold the guide arm back. The saw can be lifted from the
9
center handle on the roll cage. If 2 people are lifting the saw,
use the roll cage bar on each side of the saw and lift with 2
10
hands. Always store the saw in a completely lowered position
and secured from moving.
11
12
13
14
14
15
2

UNPACKING

TRANSPORTING

Upper handle
Lower handle
Guide arm
CAUTION
Only use the roll cage when lifting the 150.
Roll cage
