Specifications

General Specifications

Display
Functions
Polarity
Overload indication
Relative Mode
Display rate
Battery
Operating conditions
Storage conditions
Altitude
Power consumption
Weight
Dimensions
Jaw opening
Standards

Range Specifications

Range / Resolution
AC Current
40.00mA
400.0mA
4.000A
40.00A
60.0A (0 to 50A)*
60.0A (50 to 60A)*
AC Voltage
400.0V
Resistance and Continuity
Range
40.0 to 400.0Ω
Specification Notes
•
Open Circuit Voltage: 0.4V
•
AC Voltage Input Impedance: 10MΩ
•
Accuracy specified at 25
* Displays over 60A are possible but the accuracy of such measurements is not specified
3-3/4 digit (4000 count) LCD with 40 segment bargraph
ACA, ACV, Resistance, and Continuity
Minus sign ( - ) indicates negative polarity
Left blinking digit
ZERO front panel key
2 readings per second (20 readings per second for bargraph)
Two 1.5V AA batteries
0 0 0
4 F to 122 F (-10 C to 50
0 0 0
- 4 F to 140 F (-20
Operate at less than 2000 meters (Indoor use only)
Approximately 10mA DC
7 oz. (200g) including battery
8.3 x 2.4 x 1.4" (210 x 62 x 35.6mm) (HWD)
1.2" (30mm)
IEC 1010 Category III 300V, Category II 600V
Accuracy
50/60Hz
± (1.0% + 3 digits)
± (1.0% + 3 digits)
± (1.0% + 3 digits)
± (1.0% + 3 digits)
± (1.5% + 3 digits)
± (3.0% + 5 digits)
± (1.5% + 2 digits)
Accuracy
± (1.5% + 2d)
o
C
2
0
C); < 85% Relative Humidity
0
C to 60 C); < 75% Relative Humidity
Accuracy
40Hz to 1Khz
± (2.0% + 5 digits)
± (2.0% + 3 digits)
± (2.0% + 3 digits)
± (2.0% + 3 digits)
± (3.0% + 5 digits)
± (3.5% + 5 digits)
± (2.0% + 4 digits)
Audible
Continuity
Beeps < 38Ω
Model 380943
Overload
Protection
100A AC
800V AC
Overload
Protection
600V AC
Ver. 2.1 11/2002
