This manual should be considered a permanent part of the motorcycle and should remain
with the motorcycle when it is resold.
This Owner's Manual covers the
INTERCEPTOR
and
INTERCEPTOR ABS
models. You
may find descriptions of equipment and features that are not on your particular model.
All illustrations are based on the
INTERCEPTOR ABS
model.
This publication includes the latest production information available before printing. Honda
Motor Co., Ltd. reserves the right to make changes at any time without notice and without
incurring any obligation.
No part of this publication may be reproduced without written permission.
2004 Honda Motor Co., Ltd.

Advertisement

Table of Contents
loading

Related Manuals for Honda VFR800A 2005

Summary of Contents for Honda VFR800A 2005

  • Page 1 All illustrations are based on the INTERCEPTOR ABS model. This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation. No part of this publication may be reproduced without written permission.
  • Page 2 2005 Honda VFR800/A INTERCEPTOR/ABS OWNER’S MANUAL...
  • Page 3 It’s full of facts, instructions, safety information, When you own a Honda, you’re part of a and helpful tips. To make it easy to use, worldwide family of satisfied customers the manual contains a detailed list of people who appreciate Honda’s...
  • Page 4 California to cause cancer and birth motorcycle best and is dedicated to your defects or other reproductive harm. complete satisfaction. Please report any change of address or ownership to your Honda dealer so we will be able to contact you concerning important production information. Introduction...
  • Page 5 A Few Words About Safety Your safety, and the safety of others, is very important. And operating this motorcycle safely is an important responsibility. To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in this manual. This information alerts you to potential hazards that could hurt you or others.
  • Page 6 A Few Words About Safety You WILL be KILLED or SERIOUSLY HURT if you don’t follow instructions. You CAN be KILLED or SERIOUSLY HURT if you don’t follow instructions. You CAN be HURT if you don’t follow instructions. Safety Headings ––...
  • Page 7 Contents These pages give an overview of the Before Riding ........contents of your owner’s manual. The first The importance of wearing a helmet page of each section lists the topics and other protective gear, how to make covered in that section. sure you and your motorcycle are ready to ride, and important information about loading.
  • Page 8 ...... ID numbers, technical specifications, Why your motorcycle needs regular and other technical facts. maintenance, what you need to know before servicing your Honda, an owner maintenance schedule, and instructions Consumer Information ..... for specific maintenance and Information on warranties, emission adjustment items.

  • Page 10: Motorcycle Safety

    Motorcycle Safety This section presents some of the most Important Safety Information ....important information and Accessories & Modifications ....recommendations to help you ride your Safety Labels ........... motorcycle safely. Please take a few moments to read these pages. This section also includes information about the location of safety labels on your motorcycle.

  • Page 11: Important Safety Information

    Important Safety Information Your motorcycle can provide many years Always Wear a Helmet of service and pleasure if you take It’s a proven fact: helmets significantly responsibility for your own safety and reduce the number and severity of head understand the challenges you can meet injuries.

  • Page 12: Motorcycle Safety

    Important Safety Information Take Time to Learn & Practice Always pay attention to other vehicles Even if you have ridden other motorcycles, around you, and do not assume that other take time to become familiar with how drivers see you. Be prepared to stop this motorcycle works and handles.
  • Page 13 Important Safety Information Ride within Your Limits Keep Your Honda in Safe Condition Pushing limits is another major cause of It’s important to keep your motorcycle motorcycle accidents. Never ride beyond properly maintained and in safe riding your personal abilities or faster than condition.
  • Page 14 Before you consider making any modifications or adding an We strongly recommend that you use only accessory, be sure to read the following genuine Honda accessories that have been information. specifically designed and tested for your motorcycle. Because Honda cannot test all...
  • Page 15 Accessories & Modifications Do not add any electrical equipment Modifications that will exceed the motorcycle’s electrical system capacity (page A blown fuse can cause a loss of lights We strongly advise you not to remove any or engine power (page original equipment or modify your Do not pull a trailer or sidecar with your motorcycle in any way that would change...

  • Page 16: Safety Labels

    Safety labels on your motorcycle either warn you of potential hazards that could cause serious injury or they provide important safety information. Read these labels carefully and don’t remove them. If a label comes off or becomes hard to read, contact your Honda dealer for a replacement. Motorcycle Safety...
  • Page 17 Safety Labels For USA For CANADA Motorcycle Safety...

  • Page 18: Table Of Contents

    Instruments & Controls This section shows the location of all Component Locations ......11 gauges, indicators, and controls you would Gauges, Indicators & Displays ....14 normally use before or while riding your Multi-function Display ...... . 24 motorcycle.
  • Page 19 Instruments & Controls Controls & Features Ignition Switch ........35 Start Button ......... 36 Engine Stop Switch ......36 Hazard Switch ........37 Headlight Dimmer Switch ....38 Turn Signal Switch ......38 Horn Button ........

  • Page 20: Instruments & Controls

    Component Locations left multi-function display right multi-function display rearview mirror tachometer ignition switch rearview mirror clutch fluid reservoir front brake fluid reservoir headlight dimmer engine stop switch switch clutch lever front brake lever turn signal switch throttle grip horn button hazard switch start button front spring pre-load adjuster...

  • Page 21: Component Locations

    Component Locations rear spring pre-load adjuster knob rear brake fluid reservoir (INTERCEPTOR ABS only) fuse box tool kit compartment/ storage compartment for U-shaped lock helmet holder passenger footpeg oil filler cap footpeg rear brake pedal oil inspection window Instruments & Controls...

  • Page 22: Component Locations

    Component Locations rear rebound rear spring pre-load adjuster damping adjuster (INTERCEPTOR only) fuse box battery owner’s manual storage (INTERCEPTOR ABS only) coolant reserve tank helmet holder shift lever side stand footpeg passenger footpeg center stand Instruments & Controls...

  • Page 23: Gauges, Indicators & Displays

    Gauges, Indicators & Displays The gauges, indicators and displays on (1) tachometer your motorcycle keep you informed, alert (2) tachometer red zone you to possible problems, and make your (3) anti-lock brake system (ABS) riding safer and more enjoyable. Refer to indicator the gauges, indicators and displays (INTERCEPTOR ABS only)
  • Page 24 ON. If one of these indicators does not come on when it should, have your Honda dealer (INTERCEPTOR ABS only) check for burned-out bulbs or other The anti-lock brake system (ABS) problems.
  • Page 25 ( ) will If any part of these displays does not come temporarily show all the modes and digital on when it should, have your Honda dealer segments so you can make sure the liquid check for problems.
  • Page 26 Gauges, Indicators & Displays (1) left multi-function display (2) right multi-function display Instruments & Controls...
  • Page 27 Gauges, Indicators & Displays tachometer Shows engine speed in revolutions per minute (rpm). tachometer red zone Shows excessive engine rpm range (indicated from the beginning of the tachometer red zone) in which operation may damage the engine. Do not let the tachometer needle enter the red zone.
  • Page 28 ON and the engine stop switch is at RUN. If the indicator comes on at any other time, reduce speed and take your motorcycle to a Honda dealer as soon as possible. Lamp Check. right turn signal Flashes when the right turn signal operates.
  • Page 29 Gauges, Indicators & Displays right multi-function The display includes the following functions: display Display Check. tripmeter A & B Shows the number of miles or kilometers ridden since you last reset the meter. The tripmeter has two sub modes, ‘‘A’’ and ‘‘B.’’ To zero (0) the tripmeter, press the RESET button (page odometer Shows the total miles or kilometers ridden (page...
  • Page 30 Gauges, Indicators & Displays RESET button Selects odometer and tripmeter A or B and resets the tripmeter to zero (0) (page Also used to set the digital clock (page SELECT button Selects coolant or air temperature meter (page and changes speed and mileage units for the speedometer/odometer/tripmeter (page Also used to set the digital clock (page Instruments &...
  • Page 31 Gauges, Indicators & Displays left multi-function The display includes the following functions: display Display Check. speedometer Shows riding speed in miles or kilometers per hour (page coolant temperature Shows engine coolant temperature digitally (page meter USA: Fahrenheit (°F), Canada: Centigrade (°C). If the display begins to flash and a red bar appears on the display, pull safely to the side of the road.
  • Page 32 Gauges, Indicators & Displays left turn signal indicator Flashes when the left turn signal operates. (amber) low oil pressure indicator Lights when engine oil pressure is low enough to (red) cause engine damage. If the low oil pressure indicator lights during operation, pull safely to the side of the road.

  • Page 33: Multi-Function Display

    Gauges, Indicators & Displays Multi-function Display The left multi-function display ( ) includes the following functions: coolant/air temperature meter speedometer The right multi-function display ( ) includes the following functions: odometer/tripmeter fuel gauge (1) left multi-function display (2) coolant/air temperature meter digital clock (3) speedometer Both the digital clock and tripmeter will...

  • Page 34: Fuel Gauge

    Gauges, Indicators & Displays Fuel Gauge The fuel gauge liquid crystal display ( ) shows the approximate fuel supply available in a graduated display. When segment F ( ) goes on, the fuel tank capacity is: 5.81 US gal (22.0 ) When segment E ( ) flashes, you should refill the tank as soon as possible.

  • Page 35: Coolant Temperature Meter

    Gauges, Indicators & Displays Temperature Display Coolant Temperature Meter Below ‘‘--’’ is displayed 94 °F (34 °C) The coolant temperature meter ( ) shows Between Actual coolant the coolant temperature digitally. 95 °F 270 °F temperature is (35 °C 132 °C) displayed.
  • Page 36 Gauges, Indicators & Displays Overheating Message: When the coolant temperature reaches 251°F (122°C), the numbers in the Continuing to ride with an overheated temperature display start flashing and the engine can cause serious engine damage. black bar ( ) under the numbers becomes For USA a red bar ( ).

  • Page 37: Air Temperature Meter

    Gauges, Indicators & Displays Temperature Display Air Temperature Meter Below ‘‘--’’ is displayed 14 °F ( 10 °C) The air temperature meter ( ) shows the Between Actual air air temperature digitally. 15 °F 122 °F temperature is ( 9 °C 50 °C) indicated.
  • Page 38 Gauges, Indicators & Displays For USA For Canada (1) air temperature meter (2) SELECT button Instruments & Controls...

  • Page 39: Speedometer

    Gauges, Indicators & Displays Speedometer The speedometer ( ) shows riding speed in miles or kilometers per hour. The speedometer will show ‘‘mph’’ (USA) or ‘‘km/h’’ (Canada) when the battery is reconnected. (1) speedometer Instruments & Controls...

  • Page 40: Odometer/Tripmeter A & B

    Gauges, Indicators & Displays Odometer/Tripmeter A & B The odometer ( ) shows the total miles or kilometers ridden. The tripmeter shows number of miles or kilometers ridden since you last reset the meter. The tripmeter has two sub modes, A ( ) and B ( ).

  • Page 41: Changing The Speed And Mileage Unit

    Gauges, Indicators & Displays Changing the Speed and Mileage Unit The speedometer displays both ‘‘mph’’ and ‘‘km/h.’’ The odometer/tripmeter displays both ‘‘mile’’ and ‘‘km.’’ Press and hold the SELECT button ( ) to select ‘‘mph’’/‘‘mile’’ and ‘‘km/h’’/ ‘‘km.’’ (1) SELECT button Instruments &...

  • Page 42: Digital Clock

    Gauges, Indicators & Displays Digital Clock Shows hour and minute. To adjust the time, proceed as follows: Turn the ignition switch ON. Push and hold both the SELECT button ( ) and RESET button ( ) for more than 2 seconds. The digital clock ( ) will be set in the adjust mode with the display flashing.
  • Page 43 Gauges, Indicators & Displays Push the RESET button until the To end the adjustment, press the desired time and AM/PM are displayed. RESET button 5 seconds after the last The time is advanced by one minute, adjustment, or turn the ignition switch each time the button is pushed.

  • Page 44: Instruments & Controls

    Controls & Features Ignition Switch Key Position Function When the hazard The ignition switch ( ) is used for starting (hazard) switch is ON, both and stopping the engine (page ) and to the left and right lock the steering for theft prevention (page turn signals flash.

  • Page 45: Start Button

    Controls & Features Start Button Engine Stop Switch The start button ( ) is used for starting the RIGHT HANDLEBAR engine. Pushing the button in starts the engine. See Starting Procedure, page When the start button is pushed, the starter motor will crank the engine;...

  • Page 46: Hazard Switch

    Controls & Features If your motorcycle is stopped with the Be sure to turn the switch off when the ignition switch ON and the engine stop hazard warning is no longer required, or switch OFF, the headlight and taillight the turn signals will not work properly, will remain on, resulting in battery and may confuse other drivers.

  • Page 47: Headlight Dimmer Switch

    Controls & Features Headlight Dimmer Switch Turn Signal Switch The headlight dimmer switch ( ) is used The turn signal switch ( ) is used to signal to change between the high and low beams a turn or a lane change. To operate, move of the headlight.

  • Page 48: Horn Button

    Controls & Features Horn Button RESET Button The horn is used to alert other motorists. The RESET button is used to switch To operate, push the horn button ( ). between the odometer and the two tripmeter (A & B) displays. To operate, SELECT Button press the button.
  • Page 49 Instruments & Controls...

  • Page 50: Before Riding

    Before Riding Before each ride, you need to make sure Are You Ready to Ride ..... . 42 you and your Honda are both ready to ride. Protective Apparel ......42 To help get you prepared, this section Rider Training ........

  • Page 51: Before Riding

    Are You Ready to Ride? Before you ride your motorcycle for the If you must carry an extra helmet while first time, we urge you to: riding, use a commercially-available Read this owner’s manual. elastic cord, strap, or net to secure the Make sure you understand all the safety helmet to the seat.

  • Page 52: Before Riding

    Are You Ready to Ride? Helmets and Eye Protection Your helmet is your most important piece of riding gear because it offers the best Not wearing a helmet increases protection against head injuries. A helmet the chance of serious injury or death in a crash.

  • Page 53: Rider Training

    Are You Ready to Ride? A motorcycle riding suit or jacket for We urge all riders to take a certified comfort as well as protection. course approved by the Motorcycle Safety Bright-colored and reflective clothing Foundation (MSF). New riders should can help make you more noticeable in start with the basic course, and even traffic.

  • Page 54: Is Your Motorcycle Ready To Ride

    Is Your Motorcycle Ready to Ride? Before each ride, it’s important to inspect Pre-ride Inspection your motorcycle and make sure any problem you find is corrected. A pre-ride inspection is a must, not only for safety, Check the following items before you get but because having a breakdown, or even on the motorcycle: a flat tire, can be a major inconvenience.
  • Page 55 Is Your Motorcycle Ready to Ride? Leaks, Walk around your If you are carrying a passenger or cargo, Loose motorcycle and look for also check the following: Parts anything that appears unusual, such as a leak or Load Limits Make sure you do not loose cable.
  • Page 56 Pull the brake lever and press on the brake pedal Remember, be sure to take care of any to check that they problem you find, or have your Honda operate normally. dealer correct it before you ride. Indicators Turn the ignition on and...

  • Page 57: Load Limits & Guidelines

    Overloading or improper loading can cause a crash and you can be braking, and stability. Non-Honda accessories, improper modifications, and seriously hurt or killed. poor maintenance can also reduce your Follow all load limits and other safety margin.

  • Page 58: Load Limits

    If you wish to carry more cargo, check passenger, all cargo, and all accessories. with your Honda dealer for advice, and be sure to read the information regarding maximum cargo weight: accessories on page...
  • Page 59 Load Limits & Guidelines Follow these guidelines whenever you carry a passenger or cargo: Check that both tires are properly inflated (page If you change your normal load, you may need to adjust the front suspension (page ) and the rear suspension (page To prevent loose items from creating a hazard, make sure that all cargo is tied...
  • Page 60 Basic Operation & Riding This section gives basic riding instructions, Safe Riding Precautions ......52 including how to start and stop your Starting & Stopping the Engine .... . 53 engine, and how to use the throttle, clutch, Preparation .........

  • Page 61: Basic Operation & Riding

    Safe Riding Precautions Before riding your motorcycle for the first time, please review the Motorcycle Saf ety section beginning on page 1, and the Bef ore Riding section beginning on page Even if you have ridden other motorcycles, take time to become familiar with how this motorcycle works and handles.

  • Page 62: Starting & Stopping The Engine

    Starting & Stopping the Engine Always follow the proper starting clutch lever pulled in. After starting with procedure described below. the side stand down, the engine will stop if the transmission is put in gear before For your safety, avoid starting or operating raising the side stand.

  • Page 63: Starting Procedure

    Starting & Stopping the Engine The low oil pressure indicator should go Starting Procedure off a few seconds after the engine starts. If the low oil pressure indicator lights during operation, stop the engine This motorcycle has a fuel-injected engine immediately and check the engine oil level.

  • Page 64: Flooded Engine

    Starting & Stopping the Engine Flooded Engine Bank Angle Sensor Ignition Cut-off System If the engine fails to start after repeated attempts, it may be flooded with excess Your motorcycle’s banking (lean angle) fuel. To clear a flooded engine: sensor system is designed to automatically Leave the engine stop switch set to stop the engine and fuel pump if the RUN.

  • Page 65: How To Stop The Engine

    Starting & Stopping the Engine Emergency Engine Stop How to Stop the Engine To stop the engine in an emergency, use the engine stop switch. To operate, press Normal Engine Stop the switch to the OFF position. To stop the engine, shift into neutral and turn the ignition switch OFF.

  • Page 66: Shifting Gears

    Shifting Gears Close the throttle and pull the clutch lever in completely before shifting. Improper shifting may damage the engine, transmission, and drive train. Learn to recognize the engagement point as you release the clutch lever. It is at this point the transmission of shifting pattern power to the rear wheel resumes.
  • Page 67 Shifting Gears Avoid downshifting to help slow your Shif ting Up: motorcycle when engine rpm is near its From 1st to 2nd: 12 mph (20 km/h) allowable maximum (near the From 2nd to 3rd: 19 mph (30 km/h) tachometer red zone). In this situation, From 3rd to 4th: 25 mph (40 km/h) the rev limiter in the engine ignition...

  • Page 68: Braking

    Braking Your motorcycle is equipped with a to match your speed. Linked Braking System. Operating the front brake lever applies the front brake Gradually increase braking as you feel the and a portion of the rear brake. Operating brakes slowing your speed. The increase the rear brake pedal applies the rear brake in engine compression from downshifting and a portion of the front brake.
  • Page 69 Braking When possible, reduce your speed or your safety, exercise extreme caution complete braking before entering a turn. when braking, accelerating or turning. Avoid braking or closing the throttle quickly while turning. Either action may When descending a long, steep grade, cause one or both wheels to slip and use engine compression braking by reduce your control of your motorcycle.

  • Page 70: Anti-Lock Brake System (Abs)

    Braking the brakes. It is still your responsibility to Anti-Lock Brake System (ABS) ride at reasonable speeds for weather, road surface, and traffic conditions, and to (INTERCEPTOR ABS) leave a margin of safety. This model is also equipped with an Anti- lock Brake System (ABS) designed to help ABS is self-checking and always on.

  • Page 71: Abs Indicator (Interceptor Abs)

    ABS Indicator Linked Braking System and provide normal stopping ability. However, you (INTERCEPTOR ABS) should have the system checked by Honda Normally, this indicator comes on when dealer as soon as possible. the ignition is turned ON, and goes off...

  • Page 72: Parking

    Parking Look for a level parking area. If you Use the side stand to support the can’t park on a paved surface, make motorcycle while parked. sure the ground surface is firm. To lower the side stand, use your foot If you must park on a hill, leave the to guide it down.
  • Page 73 Parking If you have to park on a soft surface, Use the steering lock, which locks the insert something solid under the handlebar in place. Turn the handlebar center stand for support. all the way to the left or right. Push in To lower the center stand, stand on on the ignition key ( ) and turn it to the left side of the motorcycle.
  • Page 74 Parking Use the helmet holder to secure your helmet with your motorcycle: Remove the seat (page Riding with a helmet attached to Hang your helmet on the holder the holder can interfere with the rear wheel or suspension and hooks ( ). Install the seat.
  • Page 75 Parking If you decide to use an anti-theft device, Theft-Prevention Tips select one of good quality and be sure to follow the manufacturer’s instructions. Park your motorcycle in a locked The rear fender has a storage garage whenever possible. If a garage compartment to store a U-shaped lock isn’t available, park in a concealed area under the seat.
  • Page 76 Parking UNDER SEAT (1) rubber band Keep your owner’s manual, current registration, and insurance information with your motorcycle. This will make it easier for the authorities to find you if your motorcycle is stolen and recovered. Basic Operation & Riding...

  • Page 77: Riding With A Passenger Or Cargo

    Riding with a Passenger or Cargo Your motorcycle is a high-performance Before riding with a passenger, make sure sport model designed to carry you and one your passenger is wearing the proper passenger. Whenever you add a passenger protective apparel (page ).

  • Page 78: Servicing Your Honda

    You’ll also find important safety ‘‘certified’’ to EPA standards. precautions, information on fuels and oils, and tips for keeping your Honda looking Bef ore You Service Your Honda great. The Importance of Maintenance ...
  • Page 79 Servicing Your Honda Service Preparations Engine Component Locations ......85 Throttle ..........120 Tool Kit ........... 88 Clutch System ........122 Owner’s Manual Storage ......89 Engine Idle Speed ........ . 125 Seat Removal .........
  • Page 80 Servicing Your Honda The following table summarizes the three types of inspections and servicing recommendations for your motorcycle. Both the pre-ride inspection and the scheduled maintenance at the recommended intervals are necessary to assure safe and dependable performance. The periodic checks provide additional confidence in your motorcycle’s performance.

  • Page 81: The Importance Of Maintenance

    Maintenance Schedule in this section. If your motorcycle overturns or is involved in a crash, be sure your Honda dealer inspects all major parts, even if you are able to make some repairs. Servicing Your Honda...

  • Page 82: Maintenance Safety

    Other tasks that are more difficult and require special tools are best performed by professionals. Wheel removal should Failure to properly follow normally be handled only by a Honda maintenance instructions and technician or other qualified mechanic. Instructions are included in this manual precautions can cause you to be seriously hurt or killed.

  • Page 83: Important Safety Precautions

    Keep cigarettes, sparks, and Burns from hot motorcycle parts. flames away from all fuel-related parts. the engine and exhaust system cool before touching. Injury from moving parts. Do not run the engine unless instructed to do so. Servicing Your Honda...
  • Page 84 Maintenance Safety Remember that your Honda dealer knows your motorcycle best and is fully equipped to maintain and repair it. To ensure the best quality and reliability, use only new genuine Honda parts or their equivalents for repair and replacement. If you have the...

  • Page 85: Periodic Maintenance

    It’s a good idea to perform this maintenance any time you clean your motorcycle. Check the odometer reading and perform any scheduled maintenance checks that are needed (page ). Remember, more frequent checks may be needed for riding in severe conditions. Servicing Your Honda...
  • Page 86 ) and rear brake pedal. Drive Chain Check condition, adjust slack, and lubricate as needed (page Fuses Make sure you have a full supply of spare fuses. Nuts & Bolts Check the major fasteners and tighten as needed. Servicing Your Honda...

  • Page 87: Maintenance Schedule

    We recommend that you have your Honda dealer perform these The service intervals in this Maintenance tasks unless you have advanced Schedule are based on average riding mechanical skills and the required tools conditions.
  • Page 88 If you decide to do information and tools. Consult your your own maintenance, use only genuine Honda dealer. Honda parts or their equivalents for repair or replacement to ensure the best quality Should be serviced by your Honda and reliability.
  • Page 89 Service more frequently if the R: replace motorcycle is ridden in unusually wet or dusty areas. Replace every 2 years, or at indicated odometer interval, whichever comes first. Replacement requires mechanical skill. Refer to the official Honda service manual. Servicing Your Honda...
  • Page 90 EVAPORATIVE EMISSION CONTROL SYSTEM Should be serviced by your Honda dealer, unless you have the proper tools and service data and are mechanically qualified. Refer to the official Honda Service Manual (page In the interest of safety, we recommend these items be serviced only by your Honda dealer.
  • Page 91 STEERING HEAD BEARINGS Should be serviced by your Honda dealer, unless you have the proper tools and service data and are mechanically qualified. Refer to the official Honda Service Manual (page In the interest of safety, we recommend these items be serviced only by your Honda dealer.

  • Page 92: Maintenance Record

    Use the space under Notes to record anything you want to remind yourself about or mention to your dealer. Miles (km) Odometer Date Performed By: Notes (1,000) 4,000 (6,400) 8,000 (12,800) 12,000 (19,200) 16,000 (25,600) 20,000 (32,000) Servicing Your Honda...
  • Page 93 Maintenance Record Miles (km) Odometer Date Performed By: Notes 24,000 (38,400) 28,000 (44,800) 32,000 (51,200) 36,000 (57,600) 40,000 (64,000) 44,000 (70,400) 48,000 (76,800) 52,000 (83,200) 56,000 (89,600) 60,000 (96,000) 64,000 (102,400) 68,000 (108,800) Servicing Your Honda...

  • Page 94: Servicing Your Honda

    Component Locations clutch fluid front brake fluid reservoir reservoir front spring pre-load adjuster throttle grip fuel fill cap Servicing Your Honda...
  • Page 95 (INTERCEPTOR ABS only) seat spark plugs grab rails helmet rear brake engine idle speed holder fluid reservoir fuse box spark plugs front brake caliper tool kit compartment oil inspection window rear brake caliper oil filler cap Servicing Your Honda...
  • Page 96 (INTERCEPTOR only) rear spring damping adjuster battery owner’s manual storage inner panel fuse box (INTERCEPTOR ABS only) coolant reserve tank helmet holder inner fairing drive chain lower fairing shift lever center stand side stand Servicing Your Honda...

  • Page 97: Tool Kit

    8 mm box wrench 0.7 mm feeler gauge pin spanner (for drive chain adjustment) pin spanner (for rear suspension adjustment) (INTERCEPTOR) The following tool is also provided with your motorcycle. extension bar (1) tool kit (2) extension bar Servicing Your Honda...

  • Page 98: Owner's Manual Storage

    ( ) in the storage compartment ( ) under the seat. Be careful not to flood this area when washing your motorcycle. UNDER SEAT (1) owner’s manual storage bag (2) owner’s manual storage compartment Servicing Your Honda...

  • Page 99: Seat Removal

    Push forward and then down on the rear of the seat. Be sure to securely lock the seat after reinstalling it. (1) seat (4) front prongs (2) ignition key (5) front stays (3) seat lock (6) rear prongs (7) rear stays Servicing Your Honda...

  • Page 100: Rear Seat Cover

    Install the grab rail covers (5). when riding in tandem. (2) (1) (1) caps (3) washers (6) rear seat cover (2) grab rail (4) grab rails (7) stopper holes mounting bolts (5) grab rail covers (8) pins Servicing Your Honda...
  • Page 101 16 lbf·ft (22 N·m , 2.2 kgf·m) If a torque wrench was not used for installation, see your Honda dealer as soon as possible to verify proper assembly. The grab rails could come off easily and result in serious injury if the assembly is not done properly.

  • Page 102: Lower Fairing Removal

    Saf ety Precautions on page RIGHT SIDE The lower fairing must be removed to service the coolant reserve tank or to remove the inner fairing. (1) A clips (3) B bolts (2) A bolts (4) C bolts Servicing Your Honda...
  • Page 103 Remove the A bolts (2). Remove the B bolts (3). Remove the C bolts (4). Installation Installation can be done in the reverse order of removal. (1) A clips (3) B bolts (2) A bolts (4) C bolts Servicing Your Honda...
  • Page 104 Press down on the center pin to release Insert the clip into the hole. the lock. Lightly press down on the center pin to Pull out the clip from the hole. lock the clip. Servicing Your Honda...

  • Page 105: Inner Fairing Removal

    The inner fairing must be removed to service the engine oil filter. Removal Remove the lower fairing (page 93). Remove the A clips (1). Installation Installation can be done in the reverse order of removal. (1) A clips (2) inner fairing Servicing Your Honda...

  • Page 106: Inner Panel Removal

    Remove the A bolt (1) and B bolt (2). Remove the A clip (3). Remove the inner panel (4). Installation Installation can be done in the reverse order of removal. (1) A bolt (3) A clip (2) B bolt (4) inner panel Servicing Your Honda...

  • Page 107: Raising The Fuel Tank

    Check that the fuel fill cap is closed. Remove the seat (page 90). Remove the two bolts (1) with washers (2) and the collars (3). (1) bolts (2) washers (3) collars Servicing Your Honda...

  • Page 108: Servicing Your Honda (Cont'd)

    When raising the fuel tank, be careful not to allow the collars fall down. (4) fuel tank (5) stopper cable (6) pin spanner (7) extension bar Servicing Your Honda...

  • Page 109: Fuel

    We recommend that you use unleaded fuel because it produces fewer engine deposits and extends the life of exhaust system components. The use of leaded gas will damage the catalytic converter. Servicing Your Honda...
  • Page 110 If pinging or spark knock occurs at a steady engine speed under normal load, change brands of gasoline. If pinging or spark knock persists, consult your Honda dealer. Servicing Your Honda...
  • Page 111 Fuel Capacity Fuel tank capacity: 5.81 US gal (22.0 ) (1) ignition key (3) filler neck (2) fuel fill cap Insert the ignition key ( ) in the fuel fill cap ( ) and turn it clockwise. Servicing Your Honda...
  • Page 112 Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. Stop the engine and keep heat, sparks and flame away. Handle fuel only outdoors. Wipe up spills immediately. Servicing Your Honda...

  • Page 113: Engine Oil & Filter

    Running the engine with insufficient oil can cause serious damage to the engine and transmission. Change the engine oil as specified in the maintenance schedule on page Servicing Your Honda...
  • Page 114 Engine Oil & Filter Oil Recommendation suggested oil Pro Honda GN4 or HP4 (without SG or higher molybdenum additives) 4-stroke classification except oils oil (USA & Canada), or Honda labeled as energy 4-stroke oil (Canada only), or an conserving on the equivalent motorcycle oil.
  • Page 115 Do not use API SH or higher oils displaying a circular API ‘‘energy conserving’’ service label on the container. They may affect lubrication and clutch performance. NOT RECOMMENDED Do not use non-detergent, vegetable, or castor based racing oils. Servicing Your Honda...
  • Page 116 4-stroke motorcycle engines. There are two classes: MA and MB. Oil conforming to the standard has the following classification on the oil container. (1) code number of the sales company of the oil (2) oil classification Servicing Your Honda...
  • Page 117 ( ) –– remove the oil (1) oil inspection window filler cap ( ) and add the (2) upper level mark recommended oil until it reaches the (3) lower level mark upper level mark. (Do not overfill.) (4) oil filler cap Servicing Your Honda...
  • Page 118 Your motorcycle’s oil filter has very specific performance requirements. Use a new genuine Honda oil filter or a filter of equal quality specified for your model. Using the wrong oil f ilter may result in leaks or premature engine damage.
  • Page 119 (page ). If you do not have the skills washer ( ). or the tools, see your Honda dealer. LEFT SIDE Drain the Engine Oil: Park your motorcycle on its center stand on a firm, level surface.
  • Page 120 Discard the oil filter in an approved manner (page Pour the drained oil into a suitable container and dispose of it in an approved manner (page Improper disposal of drained f luids is harmf ul to the environment. (3) oil filter (cont’d) Servicing Your Honda...
  • Page 121 Install the new oil filter and tighten it by Install the oil filler cap. hand. Using an oil filter wrench attachment and a torque wrench, tighten the new oil filter to the specified torque: 20 lbf·ft (26 N·m , 2.7 kgf·m) Servicing Your Honda...
  • Page 122 (page Check that there are no oil leaks. Install the lower fairings and inner fairing. If a torque wrench is not used for installation, see your Honda dealer as soon as possible to verify proper assembly. Servicing Your Honda...

  • Page 123: Coolant

    Using tap water may cause engine damage. Coolant Recommendation The factory provides a 50/50 solution of Use Pro Honda HP coolant or an antifreeze and water in this motorcycle. equivalent high quality ethylene glycol This coolant solution is recommended for...
  • Page 124 Saf ety Precautions on page should only be used to provide additional LEFT SIDE protection against freezing. Check the cooling system frequently during freezing weather. (1) UPPER level mark (2) LOWER level mark (3) reserve tank cap Servicing Your Honda...
  • Page 125 Saf ety Precautions on page marks. If the reserve tank is empty, or if Coolant should be replaced by your Honda coolant loss is excessive, check for dealer, unless you have the proper tools leaks and see your Honda dealer for and service data and are mechanically repair.
  • Page 126 Always let the engine and radiator cool down before removing the radiator cap. To properly dispose of drained coolant, refer to You & the Environment, page Servicing Your Honda...

  • Page 127: Air Cleaner

    Your Honda dealer can help you determine the correct service interval for your riding conditions. Improper or lack of proper air cleaner maintenance can cause poor perf ormance Your motorcycle’s air cleaner has very...
  • Page 128 Raise the fuel tank (page 98). Install a new air cleaner. Disconnect the vacuum tube (1). Install the removed parts in reverse Remove the screws (2) that secure the order of removal. air cleaner housing cover (3). Remove the cover. Servicing Your Honda...

  • Page 129: Throttle

    Loosen the lock nut ( ). Turn the adjuster ( ). After adjustment, check for smooth rotation of the throttle grip from fully closed to fully open in all steering positions. (1) lock nut ( ) increase ( ) decrease (2) adjuster Servicing Your Honda...

  • Page 130: Throttle Inspection

    Check that the throttle assembly is positioned properly and the securing bolts are tight. Check for smooth rotation of the throttle from fully open to fully closed in all steering positions. If there is a problem, see your Honda dealer. Servicing Your Honda...

  • Page 131: Clutch System

    See your Honda dealer to have the air bled out of the system. (1) adjuster...
  • Page 132 (1) LOWER level mark Check that the fluid level is above the LOWER level mark. If the fluid level is below the LOWER level mark, it indicates fluid leakage. See your Honda dealer for repair. Servicing Your Honda...
  • Page 133 Clutch System Other Inspections Make sure there are no fluid leaks. Check for deterioration or cracks in the hose and fittings. Check that the clutch lever assembly is positioned properly and the securing bolts are tight. Servicing Your Honda...

  • Page 134: Engine Idle Speed

    (1) throttle stop ( ) increase screw ( ) decrease If the engine is cold, start it and warm it up with ten minutes of stop-and-go riding. Stop the engine. (cont’d) Servicing Your Honda...
  • Page 135 Engine Idle Speed Place your motorcycle on its center stand on a firm, level surface. Shift into neutral. Start the engine. Adjust idle speed with the throttle stop screw ( ). Idle speed (in neutral): 1,200 100 rpm Servicing Your Honda...

  • Page 136: Spark Plugs

    ‘‘leaf-type feeler gauge.’’ Do not adjust the spark plug gap. If the gap is out of specification, replace the Using spark plugs with an improper heat spark plug with a new one. range can cause engine damage. Servicing Your Honda...
  • Page 137 To access the rear cylinder spark plugs: Raise the fuel tank (page Remove the bolts ( ). Disconnect the ignition coil connectors Disconnect the ignition coils ( ) from the spark plugs. (1) bolts (2) ignition coil connectors (3) ignition coils Servicing Your Honda...
  • Page 138 LEFT SIDE (right side similar) (rear cylinder) plug bases. Using the spark plug wrench ( provided in the tool kit, remove the spark plugs. Be careful not to damage the hoses and the wire harness. (4) spark plug wrench Servicing Your Honda...
  • Page 139 Remove the bolts ( ) and wire harness holder ( ). Disconnect the ignition coil connectors Disconnect the ignition coils ( ) from the spark plugs. (5) bolts (6) wire harness holder (7) ignition coil connectors (8) ignition coils Servicing Your Honda...
  • Page 140 ( ). If the gauge (front cylinder) fits in the gap, replace the plug with a new one. Make sure the plug washer is in good condition. (4) spark plug wrench (9) spark plug gap (cont’d) Servicing Your Honda...
  • Page 141 1/8 turn after it seats. install and tighten the bolts. Install the remaining parts in the reverse order of removal. Hold the ignition coils wire harness ) in the right side of front cylinder with the wire harness holder ( Servicing Your Honda...
  • Page 142 Spark Plugs RIGHT FRONT (front cylinder) (12) (10) (13) (11) (10) ignition coils (11) ignition coil connectors (12) wire harness holder (13) wire harness Servicing Your Honda...

  • Page 143: Suspension

    The oil damper systems hydraulically both suspension systems. You may also control the rebound of the suspension adjust the rebound damping of the rear springs so that traction and comfort are suspension system. maintained as the wheels ride over road surfaces. Servicing Your Honda...
  • Page 144 Front Suspension Adjustment The front suspension can be adjusted for rider (and passenger) weight and riding conditions by changing the spring pre-load. Servicing Your Honda...
  • Page 145 STANDARD POSITION For a light load and smooth road conditions, turn the adjuster counterclockwise toward SOFT. To Increase Spring Pre-load (HARD): For a firmer ride and rough road conditions, turn the adjuster clockwise toward HARD. (1) pre-load adjuster Servicing Your Honda...
  • Page 146 Do not attempt to disassemble, service, or dispose of the damper; see your Honda dealer. The instructions found in this owner’s manual are limited to adjustments of the shock assembly only. Servicing Your Honda...
  • Page 147 Always adjust the shock absorber position in sequence (1-2-3-4-5-6-7 or 7-6-5-4-3-2- 1). Attempting to adjust directly from 1 to 7 or 7 to 1 may damage the shock absorber. (1) spring pre-load adjuster (2) pin spanner (3) extension bar Servicing Your Honda...
  • Page 148 Turn the adjuster clockwise by clicks. At that position, the end of the adjuster knob ( ) should be aligned with the indicator line ( ). (1) adjuster knob (2) end of the adjuster knob (3) indicator line Servicing Your Honda...
  • Page 149 SOFT (S). To Increase Rebound Damping (HARD): (1) damping adjuster For a firmer ride and rough road (2) punch mark conditions, turn the adjuster clockwise (3) reference punch mark toward HARD (H). To adjust to the standard position: Servicing Your Honda...

  • Page 150: Brakes

    Brakes The hydraulic braking systems on your air in the brake system. See your Honda motorcycle dissipate the heat generated by dealer to have the air bled from the system. the friction of the brake pads on the brake Front Brake Lever Adjustment discs as the wheels are slowed.
  • Page 151 Apply the brake, release it, then spin the wheel and check that it rotates freely. The recommended brake fluid is Honda Repeat this procedure several times. DOT 4 Brake Fluid, or any brake fluid of equal quality and performance. Use fresh brake fluid from a sealed container.
  • Page 152 RIGHT HANDLEBAR If your inspection indicates a low fluid level, have your Honda dealer add the (front brake) recommended brake fluid. Do not add or replace brake fluid, except in an emergency. If you do add fluid, have your Honda dealer check the system as soon as possible.
  • Page 153 Make sure there are no fluid leaks. (2) LOWER level mark Check for deterioration or cracks in the hoses and fittings. Place your motorcycle on its center stand on a firm, level surface. Remove the seat (page Servicing Your Honda...

  • Page 154: Brake Pad Wear

    Always inspect both pads in both the right and left front brake calipers. Check the cutouts ( ) in each pad. If either pad is worn to the cutout, replace both pads as a set. See your Honda dealer for this service. (1) cutouts Servicing Your Honda...
  • Page 155 Move the left caliper assembly ( ) upward while slowly rotating the rear wheel. The brake system is normal if the rear wheel stops. If the rear wheel does not stop, see your Honda dealer. (1) left caliper assembly Servicing Your Honda...

  • Page 156: Tires

    Overinflated tires make inflation and maintenance. your motorcycle ride more harshly, are more prone to damage from road hazards, and wear unevenly. The following pages give detailed information on how and when to check Servicing Your Honda...
  • Page 157 Always check air pressure when your tires are ‘‘cold’’ –– after the motorcycle has been parked for at least three hours. If you check air pressure when your tires are Servicing Your Honda...
  • Page 158 Cuts, slits, or cracks in the tires. Replace the tire if you can see fabric or cord. Nails or other foreign objects embedded in the side of the tire or tread. Excessive tread wear. (1) wear indicator (2) wear indicator location mark Servicing Your Honda...

  • Page 159: Tire Repair

    We strongly recommend that you replace, not repair, any tire that is punctured or damaged. As discussed below, a tire that is repaired, either temporarily or permanently, will have lower speed and performance limits than a new or undamaged tire. Servicing Your Honda...

  • Page 160: Tire Replacement

    If you have a tire professionally repaired at a non-Honda facility, we recommend that you have the work checked by your Honda dealer. Servicing Your Honda...
  • Page 161 METZELER MEZ4A radial ply, tubeless tires recommended in this owner’s type manual. Whenever you replace a tire, remember: Have the wheel balanced after the tire is installed. Have the tire replaced by your Honda dealer if possible. Servicing Your Honda...
  • Page 162 Tires If you have a tire professionally replaced at a non-Honda facility, we recommend that you have the work checked by your Honda dealer. Important Safety Reminders Do not install a tube inside a tubeless tire on this motorcycle. Excessive heat build-up can cause the tube to burst.

  • Page 163: Side Stand

    The engine should stop as you lower the side stand. If the engine doesn’t stop, Check that the side stand assembly is see your Honda dealer for service. working properly. If the side stand is stiff or squeaky, clean the pivot area and lubricate the pivot bolt with clean grease.

  • Page 164: Drive Chain

    It is not necessary to remove or replace the damage to the drive chain or sprockets. drive chain to perform the recommended service in the Maintenance Schedule. The drive chain should be checked, adjusted, and lubricated as part of the pre- ride inspection (page Servicing Your Honda...
  • Page 165 Drive chain slack should allow the damaged rollers following vertical movement by hand: dry or rusted links 1 1 3/8 in (25 35 mm) kinked or binding links excessive wear LEFT SIDE improper adjustment damaged or missing O-rings (1) drive chain Servicing Your Honda...
  • Page 166 Adjust chain slack if needed. Inspect the front and rear sprocket teeth for excessive wear or damage. If necessary, have your Honda dealer normal sprocket teeth replace a worn sprocket. GOOD Use of a new chain with worn sprockets will cause rapid chain wear.
  • Page 167 ( ) after the chain has been adjusted to the proper slack, the chain is excessively worn and must be replaced. The proper slack is: 1 1 3/8 in (25 35 mm) Servicing Your Honda...
  • Page 168 Torque the bearing holder pinch bolt to: 54 lbf·ft (74 N·m , 7.5 kgf·m) If a torque wrench is not used for this installation, see your Honda dealer as soon as possible to verify proper assembly. Improper assembly may lead to a loss of braking capacity.
  • Page 169 Lubricate every 500 miles (800 km) or sooner if chain appears dry. Lubricant: SAE 80 or 90 gear oil Lubricate only with SAE 80 or 90 gear oil. Commercial chain lubricants may contain solvents which could damage the rubber O-rings. Servicing Your Honda...
  • Page 170 O-rings. master link) type chain. It should only be Inspect the drive chain for possible removed or replaced by your Honda dealer. wear or damage. The O-rings can be damaged by steam Replace the drive chain if it has damaged...

  • Page 171: Battery

    Battery posts, terminals accessories on your motorcycle –– or do and related accessories contain lead and not ride frequently, we recommend that lead compounds. Wash hands after you charge the battery frequently (see handling. Battery Charging, page Servicing Your Honda...
  • Page 172 You will get the best storage results from Wear protective clothing and a removing the battery and slow (trickle) charging it every 30 days (see Battery face shield, or have a skilled Charging, page mechanic do the battery maintenance. Servicing Your Honda...
  • Page 173 ( ). Pull the battery ( ) out of the battery box. (1) battery cover clips (2) battery cover (3) rubber band (4) negative ( ) terminal lead (5) positive ( ) terminal lead (6) battery Servicing Your Honda...

  • Page 174: Battery Charging

    Slow charge the battery (see following (1) ‘‘trickle’’ charger section) once every 30 days. Be sure to read the information that came with your battery charger and follow the instructions on the battery. Improper charging may damage the battery. Servicing Your Honda...
  • Page 175 However, do not intentionally leave the charger connected longer than the time period recommended in the charger’s instructions. Avoid using an automotive-type battery charger. An automotive charger can overheat a motorcycle battery and cause permanent damage. Servicing Your Honda...

  • Page 176: Appearance Care

    Appearance Care Frequent cleaning and polishing will keep Avoid products that contain harsh your Honda looking newer longer. detergents or chemical solvents that Frequent cleaning also identifies you as an could damage the metal, paint, and owner who values your motorcycle. A plastic on your motorcycle.
  • Page 177 High pressure water (or air) can damage certain parts of your motorcycle. After cleaning, inspect for damage, wear, and leaks (fuel, oil, coolant, brake, and clutch fluid). Servicing Your Honda...
  • Page 178 Clean the windscreen with a soft cloth washing, it should clear after a few or sponge and plenty of water. Dry with minutes of riding. a soft clean cloth. Remove minor (cont’d) Servicing Your Honda...
  • Page 179 The engine heat will help dry moist areas. As a precaution, ride your motorcycle at a slow speed and apply the brakes several times. This will help dry the brakes and restore normal braking performance. Servicing Your Honda...
  • Page 180 If necessary, rub with a sponge. Rinse and dry. Apply a spray cleaner/polish and wipe with a non-abrasive cloth. Dull, corroded chrome or Apply a high quality chrome/aluminum aluminum. polish and wipe with a non-abrasive cloth. Servicing Your Honda...
  • Page 181 Use a wet sponge and mild detergent. Avoid stiff brushes, steel wool, or cleaners containing abrasives or chemical compounds. After washing, rinse with plenty of water and dry with a clean cloth. If the paint is chipped, apply touch-up paint. Servicing Your Honda...
  • Page 182 If a surface on your motorcycle is chipped or scratched, your Honda dealer has touch- up paint to match your motorcycle’s color. Be sure to use your motorcycle’s color code (page ) when you buy touch-up paint.
  • Page 183 Servicing Your Honda...

  • Page 184: Tips

    Tips Here’s a few helpful tips on how to store Storing Your Honda ......176 and transport your Honda, and how to be Transporting Your Motorcycle ... . 179 an environmentally responsible You & the Environment ...... . 180 motorcycle owner.

  • Page 185: Storing Your Honda

    For more information about storage, refer with a 50/50% antifreeze solution (page to the Honda Motorcycle Winter Storage Guide, available from your Honda dealer Fill the fuel tank. Make sure the fuel fill (USA only). cap is properly installed. We suggest you perform the following procedures to keep your motorcycle in top condition.

  • Page 186: Tips

    Storing Your Honda To prevent rusting in the cylinders, Reinstall the spark plugs, ignition perform the following: coils and ignition coil connectors. Remove the ignition coil connectors Remove the battery and charge it fully. and ignition coils from the spark Store it in an area protected from plugs.
  • Page 187 If your motorcycle has been stored for raise the front tire off the floor. more than two months –– ask your Cover your motorcycle with a porous Honda dealer to drain and replace the material. Avoid using plastic or similar fuel. non-breathing, coated materials that...

  • Page 188: Transporting Your Motorcycle

    Transporting Your Motorcycle If your motorcycle needs to be transported, it should be carried on a motorcycle trailer, or a truck or trailer with a flatbed area. For information about 24-hour emergency assistance, see page (USA only). Do not tow your motorcycle, as towing can seriously damage the transmission.

  • Page 189: You & The Environment

    You & the Environment Owning and riding a motorcycle can be Recycle Wastes. It’s illegal and enjoyable, but you must do your part to thoughtless to put used engine oil in the protect nature. trash, down a drain, or on the ground. Used oil, gasoline, coolant, and Following are tips on how you can be an cleaning solvents contain poisons that...

  • Page 190: Taking Care Of The Unexpected

    Taking Care of the Unexpected This section discusses the more common General Guidelines ....... 182 problems that can occur with your If Your Engine Quits or motorcycle while you’re riding. It tells Won’t Start .......... . 183 you how to evaluate each problem and If You Have a Flat Tire .......

  • Page 191: General Guidelines

    (USA only: For information possible. about the Honda Rider’s Club of America, Do not continue riding if you are hurt or see page your motorcycle is not in safe riding condition.

  • Page 192: If Your Engine Quits Or Won't Start

    If you have a problem starting the but the engine won’t start symptom. engine or experience poor engine performance the following information may help you. If you can’t correct the problem, see your Honda dealer. Taking Care of the Unexpected...
  • Page 193 Tighten the battery lead. dead battery Charge the battery (page ). If charging doesn’t help, see your Honda dealer. faulty starter motor If all possible causes are negative, the starter motor may be faulty. See your Honda dealer. Taking Care of the Unexpected...
  • Page 194 If the engine still won’t start, see your ignition coils Honda dealer. loose battery cables Tighten the battery terminal bolts. weak battery Charge the battery (page ). If charging doesn’t help, see your Honda dealer. Taking Care of the Unexpected...
  • Page 195 POSSIBLE CAUSE WHAT TO DO idles roughly, too fast, stalls Check engine idle adjustment (page ). If the problem persists, see your Honda dealer. overheating Check the coolant temperature meter. Refer to Y our Engine Overheats, page low oil pressure Check the low oil pressure indicator.
  • Page 196 If applicable, switch to the recommended octane load gasoline (page ) or change your brand of gasoline. If the problem persists, see your Honda dealer. afterfires (backfires) See your Honda dealer. pre-ignition (runs on after See your Honda dealer.

  • Page 197: If You Have A Flat Tire

    If a tire has a major puncture or a cut in repaired. the tread or sidewall, or the bead has come loose from the rim, there is probably not much you can do except have your motorcycle transported to a Honda dealer Taking Care of the Unexpected...
  • Page 198 If You Have a Flat Tire repaired. Stop frequently and check the air pressure. If the tire is losing pressure, it Riding your motorcycle with a may be unsafe to continue riding. As the temporary tire repair can be risky. tire gets low, it will affect the handling of If the temporary repair fails, you your motorcycle (especially with a...
  • Page 199 If You Have a Flat Tire Inflate the tire: Tubeless tires have Should You Repair or Replace a some self-sealing ability if they are Tire? punctured and the result is usually just a slow leak. If this is the case, you can try inflating the tire to see if it will hold air We strongly recommend that you replace, pressure.
  • Page 200 Saf ety Precautions on page fairing. We recommend wheel removal be done LEFT SIDE only by your Honda dealer or another qualified mechanic. Do not attempt to remove the wheel on your own. Wheel removal requires mechanical skill and professional tools.
  • Page 201 If You Have a Flat Tire LEFT SIDE RIGHT SIDE (2) A socket bolt (5) fixing bolts (3) B socket bolt (6) right caliper assembly (4) left caliper assembly Remove the A ( ) and B ( ) socket bolts and remove the left caliper assembly ( ) from the fork leg.
  • Page 202 If You Have a Flat Tire Remove the fixing bolts ( ) and Remove the axle bolt ( ), and then remove the right caliper assembly ( ). loosen the right and left axle pinch bolts To avoid damage to the brake hose ( ).
  • Page 203 If this occurs, the left side, through the left fork leg and brake system will require service. See wheel hub. your Honda dealer for this service. To avoid damaging the brake pads, carefully fit both brake discs between LEFT FRONT the pads.
  • Page 204 If You Have a Flat Tire Tighten the axle pinch bolt on the right (10) fork leg to the specified torque: (12) 16 lbf·ft (22 N·m , 2.2 kgf·m) Fit the brake disc carefully between the (11) brake pads to avoid damaging the pads. Install the right caliper fixing bolts and tighten to the specified torque: 23 lbf·ft (31 N·m , 3.2 kgf·m)
  • Page 205 If You Have a Flat Tire If the feeler gauge inserts easily, Check for free wheel rotation after remove it and tighten the left axle pinch the brake lever and brake pedal are bolt to the specified torque: released. Recheck the wheel if the 16 lbf·ft (22 N·m , 2.2 kgf·m) brake drags or if the wheel does not If the feeler gauge cannot be inserted...

  • Page 206: Emergency Rear Wheel Removal/Installation

    If You Have a Flat Tire If a torque wrench was not used for Remove the four rear wheel nuts ( ). installation, see your Honda dealer as soon RIGHT REAR as possible to verify proper assembly. Improper assembly may lead to loss of braking capability.
  • Page 207 If You Have a Flat Tire Installation If a torque wrench was not used for Position the rear wheel and install the installation, see your Honda dealer as soon rear wheel nuts. as possible to verify proper assembly. Avoid getting grease, oil, or dirt on Improper assembly may lead to loss of the disc or pad surfaces.

  • Page 208: If Your Engine Overheats

    If Your Engine Overheats Normally, the coolant temperature on your temperature meter will rise and then level off. Hot weather may cause the Continuing to ride with an overheated temperature to rise higher than normal. So engine can cause serious engine damage. will temporary stress such as climbing a hill.
  • Page 209 If the fan is not working, turn the ride. The engine needs repair. Transport engine off. Open the fuse box (page your motorcycle to a Honda dealer ) and check the radiator fan fuse. (page If the fuse is blown, replace it with the If the temperature drops to normal, proper (same rating) spare fuse.

  • Page 210: If The Low Oil Pressure Indicator Lights

    If the indicator goes off and there is no leak –– resume riding. If there is a leak –– do not ride the motorcycle until the leak is repaired by a Honda dealer. Taking Care of the Unexpected...

  • Page 211: If A Fuse Blows

    If a Fuse Blows All of the electrical circuits on your (INTERCEPTOR) motorcycle have fuses to protect them The circuit fuse box (including spare from damage caused by excess current fuse) is located under the right inner flow (short circuit or overload). panel.
  • Page 212 If a Fuse Blows To prevent an accidental short circuit, Main Fuse Access: turn the ignition switch OFF before To access the main fuse A ( ), checking or replacing the fuses. disconnect the wire connector ( ) of Remove the seat (page the starter magnetic switch ( ).
  • Page 213 If a Fuse Blows Reconnect the wire connector. Circuit Fuse Access: To access main fuse B ( ), open the Remove the inner panel (page main fuse B cover ( ). Open the fuse box cover ( Pull main fuse B out. RIGHT FRONT If it is blown, install a new main fuse B.
  • Page 214 If a Fuse Blows LEFT FRONT CIRCUIT FUSE (INTERCEPTOR ABS only) (10) (10) blown fuse Close the fuse box cover. Install the inner panel. (8) cover If you do not have a replacement fuse with (9) spare fuses the proper rating for the circuit, install one with a lower rating.
  • Page 215 If the replacement fuse of the same rating burns out in a short time, there is probably a serious electrical problem on your motorcycle. Leave the blown fuse in that circuit and have your motorcycle checked by your Honda dealer. Taking Care of the Unexpected...

  • Page 216: If You Crash

    Also, be sure another person or vehicle is involved in to have your Honda dealer check the the accident. frame and suspension after any serious crash.

  • Page 217: If You Lose Your Key

    If you don’t know your key duplicate key made. number, call the dealer you purchased your Honda from. They may have it listed A lost key won’t be a problem if you take in their records. If they don’t, transport preventative action.

  • Page 218: If Your Battery Is Low (Or Dead)

    Bump starting is also not recommended. If you can’t charge the battery or it appears unable to hold a charge, contact your Honda dealer. Taking Care of the Unexpected...
  • Page 219 Taking Care of the Unexpected...

  • Page 220: Technical Information

    Technical Information This section contains dimensions, Vehicle Identification ......212 capacities, and other technical data, plus Specifications ........215 information on government requirements Break-in Guidelines ......222 and how to break-in your motorcycle. Emission Control Systems ....

  • Page 221: Vehicle Identification

    Vehicle Identification The VIN (vehicle identification number) Serial Numbers appears on the Safety Certification Label attached to the left side of the frame. The frame, VIN, and engine serial LEFT SIDE numbers are required when you register your motorcycle. They may also be required when ordering replacement parts.

  • Page 222: Technical Information

    Vehicle Identification The frame number ( ) is stamped on the The engine number ( ) is stamped on the right side of the steering head. top of the crankcase. RIGHT SIDE LEFT SIDE (2) frame number (3) engine number Technical Information...
  • Page 223 Vehicle Identification Color Label & Code The color label is attached to the frame under the seat. Remove the seat (page to check the label. The color code is helpful when ordering replacement parts. You may record the color and code in the Quick Reference section at the rear of this manual.

  • Page 224: Specifications

    Specifications Dimensions 83.5 in (2,120 mm) overall length 28.9 in (735 mm) overall width 47.0 in (1,195 mm) overall height 57.5 in (1,460 mm) wheelbase 4.9 in (125 mm) ground clearance Weight INTERCEPTOR: dry weight 472 lbs (214 kg) 470 lbs (213 kg) Canada INTERCEPTOR ABS: 483 lbs (219 kg)
  • Page 225 SAE 10W-40, JASO T 903 standard MA, Pro Honda GN4 or HP4 (without molybdenum additives) 4-stroke oil (USA & Canada) or Honda 4-stroke oil (Canada only), or an equivalent motorcycle oil SAE 80 or 90 gear oil drive chain lubricant...
  • Page 226 Specifications Capacities Operator and one passenger passenger capacity USA: 399 lbs (181 kg) maximum weight Canada: 408 lbs (185 kg) capacity rider, passenger, all cargo and accessories Engine Specifications 47.7 cu-in (782 cm ) displacement 2.83 x 1.89 in (72.0 x 48.0 mm) bore &...
  • Page 227 Specifications Power Transmission 1.939 primary reduction 2.846 gear ratio, 1st 2.062 1.578 1.291 1.111 0.965 2.687 final reduction drive (engine) sprocket: standard driven (rear wheel) sprocket: sprocket sizes chain final drive DID50VA8 RK50HFOZ5 Technical Information...
  • Page 228 Specifications Chassis & Suspension 25°30’ caster 3.7 in (95 mm) trail 120/70ZR17M/C (58W) tire size, front 180/55ZR17M/C (73W) tire size, rear radial ply, tubeless tire type 36 psi (250 kPa , 2.50 kgf/cm ) tire pressure, front (cold) 42 psi (290 kPa , 2.90 kgf/cm ) tire pressure, rear (cold) Electrical...
  • Page 229 Specifications Lights 12V 55W (4 bulbs) headlight 12V 21/5W (2 bulbs) brake/tail light 12V 21W (front) turn signal lights 12V 21W (rear) 12V 8W license light Technical Information...
  • Page 230 Specifications Fuses main A main B 10A, 20A, 30A (INTERCEPTOR ABS ONLY) other fuses Torque Specifications 22 lbf·ft (29 N·m , 3.0 kgf·m) oil drain bolt 20 lbf·ft (26 N·m , 2.7 kgf·m) oil filter 43 lbf·ft (59 N·m , 6.0 kgf·m) front wheel axle bolt 23 lbf·ft (31 N·m , 3.2 kgf·m)

  • Page 231: Break-In Guidelines

    Break-in Guidelines Help assure your motorcycle’s future reliability and performance by paying extra attention to how you ride during the first 300 miles (500 km). During this period, avoid full-throttle starts and rapid acceleration. Technical Information...

  • Page 232: Emission Control Systems

    Warranty Compliance The U.S. Environmental Protection Compliance with the terms of the Agency (EPA), the California Air Distributor’s Warranties for Honda Resources Board (CARB), and Motorcycle Emission Control Systems is Environment Canada require that your necessary in order to keep the emissions motorcycle comply with applicable system warranty in effect.
  • Page 233 Carbon monoxide does not react in the same way, but it is toxic. Honda Motor Co., Ltd. utilizes various systems to reduce carbon monoxide, oxides of nitrogen and hydrocarbons. Technical Information...
  • Page 234 Emission Control Systems Exhaust Emission Control System PGM-FI System The exhaust emission control system The PGM-FI system uses sequential includes a secondary air injection system, multiport fuel injection. It has four PGM-FI system, two three-way catalytic subsystems: Air Intake, Engine Control, converters, and two heated oxygen sensors.
  • Page 235 Emission Control Systems Secondary Air Injection System Evaporative Emission Control System The secondary air injection system (USA only) introduces filtered air into the exhaust This motorcycle complies with the gases in the exhaust port. The secondary requirements of the California Air air injection system helps improve Resources Board (CARB) evaporative emission performance.
  • Page 236 If you are aware of any of the following crankcase emissions into the atmosphere. symptoms, have the vehicle inspected and Blow-by gas is returned to the combustion repaired by your authorized Honda chamber through the air cleaner and the motorcycle dealer. intake manifold.
  • Page 237 Emission Control Systems Noise Emission Control System AMONG THOSE ACTS PRESUMED TAMPERING WITH THE NOISE TO CONSTITUTE TAMPERING ARE CONTROL SYSTEM IS PROHIBITED: THE FOLLOWING ACTS: U. S. federal law prohibits, or Canadian Removal of, or puncturing the muffler, provincial laws may prohibit the following baffles, header pipes or any other acts or the causing thereof: ( ) The component which conducts exhaust...

  • Page 238: Catalytic Converter

    NOx. A replacement unit must be an contaminate the catalyst metals, making original Honda part or its equivalent. the catalytic converter ineffective. The catalytic converters must operate at a Keep the engine tuned-up.

  • Page 239: Oxygenated Fuels

    Oxygenated Fuels Some conventional gasolines are being The following are the EPA-approved blended with alcohol or an ether percentages of oxygenates: compound. These gasolines are collectively referred to as oxygenated ETHANOL (ethyl or grain alcohol) 10% fuels. To meet clean air standards, some by Volume areas of the United States and Canada use You may use gasoline containing up to...
  • Page 240 Oxygenated Fuels METHANOL (methyl or wood alcohol) Fuel system damage or performance 5% by Volume problems resulting from the use of an You may use gasoline containing oxygenated fuel containing more than the methanol containing up to 5% methanol percentages of oxygenates mentioned by volume as long as it also contains above are not covered under warranty.
  • Page 241 Technical Information...

  • Page 242: Consumer Information

    Consumer Information This section contains information on your Authorized Manuals ......234 warranty and how to get an official Honda Warranty Coverage ......237 service manual. Warranty Service ........238 Contacting Honda ........ . 239 Your Honda Dealer ......

  • Page 243: Authorized Manuals

    Authorized Manuals The Service Manual used by your authorized Honda dealer is available from Helm, Inc. (USA only, Canada: See your Honda dealer to order authorized manuals.) Also available, but not necessary, to service your model is the Honda Common Service Manual which explains theory of operation and basic service information for various systems common to all Honda motorcycles, motor scooters and ATVs.

  • Page 244: Consumer Information

    By completing this form you can order the materials desired. You can pay by check or money order, or charge to your credit card. Mail to Helm, Inc. at the address shown on the back of this order form (USA only). Canada: See your Honda dealer to order authorized manuals. Publication Item Description Qty.

  • Page 245: Consumer Information

    NOTE: Dealers and Companies please provide dealer or company name, and also the name of the person to whose attention the shipment should be sent. Customer Name Attention Street Address - No P. O. Box Number Apartment Number City State Zip Code Daytime Telephone Number Check or money order enclosed payable to Helm Inc.

  • Page 246: Warranty Coverage

    Please read the Warranties Booklet given Almost all of your warranty coverage can to you by your Honda dealer at the time of be extended through the Honda Protection purchase. Be sure to keep your Honda Plan (USA only).

  • Page 247: Warranty Service

    If you aren’t satisfied with your your motorcycle, call the service dealer’s handling of the situation, we department of your Honda dealer. Make suggest you discuss your problem with the an appointment for an inspection and appropriate member of the dealership’s diagnosis.

  • Page 248: Contacting Honda

    If you wish to comment on your experiences with your Honda or with your We will likely ask your Honda dealer to dealer, please send your comments to the respond, or possibly acknowledge your following address (USA only): comments directly.

  • Page 249: Your Honda Dealer

    Once you purchase your new Honda, get products available from the parts familiar with the organization of your department. Honda dealer so you can utilize the full range of services available. The sales department offers the Honda Protection Plan to extend almost all of The service department is there to perform your warranty coverage (USA only).

  • Page 250: The Honda Rider's Club (Usa Only)

    Honda (includes roadside HRCA’s insurance partner. assistance for your transport vehicle as Racing contingency programs and long as your Honda is aboard or in tow). assistance at selected dual-sport, off- Vehicle transport to the nearest Honda road, and motocross events.

  • Page 251: Reporting Safety Defects (Usa Only)

    National Highway Washington, D.C. area) or write to: Traffic Safety Administration (NHTSA) NHTSA, U.S. Department of in addition to notifying American Honda Transportation, Washington, D.C. 20590. Motor Co., Inc. You can also obtain other information If NHTSA receives similar complaints, it...
  • Page 252 Consumer Information...

  • Page 253: Table Of Contents

    Table of Contents The following presents the contents of Controls & Features each section of your owner’s manual. Ignition Switch ........35 Start Button ......... 36 MOTORCYCLE SAFETY ....Engine Stop Switch ......36 Important Safety Information ....
  • Page 254 Table of Contents Loading Guidelines ......49 SERVICING YOUR HONDA ... . 69 Bef ore You Service Your Honda BASIC OPERATION & RIDING ..51 The Importance of Maintenance ... . 72 Safe Riding Precautions ......52 Maintenance Safety .......
  • Page 255 Table of Contents SERVICING YOUR HONDA (cont’d) Drive Chain .......... . 155 Service Procedures Electrical Fluids & Filters Battery ........... 162 Fuel ............100 Engine Oil & Filter ....... 104 Appearance Care ........167 Coolant ..........
  • Page 256 ........ . 239 If Your Engine Overheats ....199 Your Honda Dealer ......240 If the Low Oil Pressure Indicator The Honda Rider’s Club Lights ........... . 201 (USA only) .......... . 241 If a Fuse Blows ........

  • Page 257: Index

    . 39 air pressure, tires ........147 SELECT ..........39 air temperature meter ......28 American Honda, contacting ....239 anti-lock brake system (ABS) (INTERCEPTOR ABS) ......61 capacity, fuel ........102 apparel, protective .........
  • Page 258 Index compartment, multi-function ........24 owner s manual ....... . 89 drive chain ..........155 tool kit ..........88 component locations, indicators and controls ...... . 11 maintenance ........85 emission control systems ..... . 223 consumer information ......

  • Page 259: Index

    Rider’s Club ........241 tank raising ......... 98 dealer ..........240 tank capacity ........102 Honda service manual ......234 fuses ............202 horn button ..........39 gap, spark plug ........131 identification, vehicle ......
  • Page 260 Index idle speed, engine ........ . 125 load limits ..........49 ignition cutoff system, loading guidelines ........49 bank angle .......... . 55 location, components, side stand ..........53 indicators & controls ......11 ignition switch ........
  • Page 261 ........91 seat ............90 reporting safety defects ......242 RESET button ......... 39 parking ........... . 63 rider training ........2, 44 pinging, engine ........101 Rider’s Club, Honda ......241 Index...
  • Page 262 Index riding, service, basic operation ........51 customer ..........239 clothing ..........42 manuals ..........234 precautions ......... . 52 warranty ..........238 safety ............ shifting gears ......... . 57 safety precautions ....... 52 side stand ..........
  • Page 263 Index stopping engine ........56 storage, motorcycle ........176 owner’s manual ........89 tachometer ........14, 18 suspension, temperature meter, front suspension adjustment .... . 135 ............28 front suspension spring pre-load ..136 coolant ..........
  • Page 264 Index vehicle identification no. (VIN) ... 212 warranty, coverage ..........237 extended ..........237 service ..........238 washing your motorcycle ..... 169 weight limit ..........49 wheels, front removal ........191 rear removal ........
  • Page 265 Memo...

  • Page 266: Quick Reference

    Honda. You’ll also find space to record important notes. The engine of your Honda can be the most expensive component to repair. Proper maintenance, especially the use of the recommended fluids and filters, prevents premature wear and damage.
  • Page 267 Quick Reference VIN/Frame No. Engine No. Frame No. Ignition Key No. Color Label Owner’s Name Address City/State Phone Dealer’s Name Address City/State Phone Service Mgr. Quick Reference...
  • Page 268 API Service Classification SG or higher except oils labeled as energy conserving on the circular API service label, SAE 10W-40, JASO T 903 standard MA, Pro Honda GN4 or HP4 (without molybdenum additives) 4-stroke oil or equivalent 399 lbs (181 kg)
  • Page 269 VNH27Z (DENSO) cold climate: IMR8B 9H (NGK) VNH24Z (DENSO) Coolant ethylene glycol antifreeze (silicate-free) for aluminum engines in 50/50 solution with Pro Honda HP Coolant or an equivalent distilled water Fuses main A: main B: other: 10A, 20A, 30A (INTERCEPTOR ABS ONLY)

This manual is also suitable for:

Vfr800 2005Interceptor 2005Interceptor abs 2005

Table of Contents
