15 VFR800X-32MJM8000.book 1 ページ ２０１４年１２月１９日　金曜日　午後１時４０分
This manual should be considered a permanent part of the motorcycle
and should remain with the motorcycle when it is resold.
This publication includes the latest production information available
before printing. Honda Motor Co., Ltd. reserves the right to make
changes at any time without notice and without incurring any obligation.
No part of this publication may be reproduced without written
permission.
The vehicle pictured in this owner's manual may not match your actual
vehicle.
© 2014 Honda Motor Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the vfr800x and is the answer not in the manual?

Questions and answers

Related Manuals for Honda vfr800x

Summary of Contents for Honda vfr800x

  • Page 1 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 2 Honda motorcycle. Your selection of a ● The illustrations here in are based on the Honda makes you part of a worldwide family VFR800X II ED type. of satisfied customers who appreciate Honda’s reputation for building quality into Country Codes every product.
  • Page 3 15 VFR800X-32MJM8000.book 3 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 A Few Words About Safety Your safety, and the safety of others, is very DANGER important. Operating this motorcycle safely is You WILL be KILLED or SERIOUSLY an important responsibility. HURT if you don’t follow instructions.

  • Page 4: Table Of Contents

    15 VFR800X-32MJM8000.book 4 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Contents Motorcycle Safety P. 2 Operation Guide P. 18 Maintenance P. 51 Troubleshooting P. 97 Information P. 116 Specifications P. 130 Index P. 133...

  • Page 5: Motorcycle Safety

    15 VFR800X-32MJM8000.book 2 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Motorcycle Safety This section contains important information for safe riding of your motorcycle. Please read this section carefully. Safety Guidelines .........P. 3 Image Labels..........P. 6 Safety Precautions ........P. 11 Riding Precautions ........P. 12 Accessories & Modifications......P. 16...

  • Page 6: Safety Guidelines

    15 VFR800X-32MJM8000.book 3 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Safety Guidelines Safety Guidelines that you and your passenger are both wearing an approved motorcycle helmet and protective Follow these guidelines to enhance your safety: apparel. Instruct your passenger on holding ● Perform all routine and regular inspections onto the grab rails, leaning with you in turns, specified in this manual.
  • Page 7 15 VFR800X-32MJM8000.book 4 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Safety Guidelines Make Yourself Easy to See Keep Your Honda in Safe Condition Make yourself more visible, especially at night, It’s important to keep your motorcycle properly by wearing bright reflective clothing, maintained and in safe riding condition.
  • Page 8 15 VFR800X-32MJM8000.book 5 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Safety Guidelines check the tightness of critical nuts and bolts, WARNING and check the handlebar, control levers, brakes, and wheels. Ride slowly and cautiously. Carbon monoxide gas is toxic. Your motorcycle may have suffered damage Breathing it can cause that is not immediately apparent.

  • Page 9: Image Labels

    15 VFR800X-32MJM8000.book 6 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Image Labels Image Labels Read instructions contained in Owner’s Manual carefully. The following pages describe the label meanings. Some labels warn you of Read instructions contained in Shop Manual potential hazards that could cause serious carefully.
  • Page 10 15 VFR800X-32MJM8000.book 7 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Image Labels BATTERY LABEL DANGER • Keep flame and spark away from the battery. Battery produce explosive gas that can cause explosion. • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.
  • Page 11 15 VFR800X-32MJM8000.book 8 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Image Labels RADIATOR CAP LABEL DANGER NEVER OPEN WHEN HOT. Hot coolant will scald you. Relief pressure valve begins to open at 108 kPa. ACCESSORIES AND LOADING WARNING LABEL WARNING ACCESSORIES AND LOADING • The safety stability and handling of this motorcycle may be affected by the addition of accessories and luggage.
  • Page 12 15 VFR800X-32MJM8000.book 9 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Image Labels REAR CUSHION LABEL GAS FILLED Do not open. Do not heat. TYRE INFORMATION LABEL Cold tyre pressure: [Driver only] Front 250 kPa (2.50 kgf/cm , 36 psi) Rear 290 kPa (2.90 kgf/cm , 42 psi)
  • Page 13 15 VFR800X-32MJM8000.book 10 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Image Labels SAFETY REMINDER LABEL For your protection, always wear helmet, protective apparel. FUEL LABEL Unleaded petrol only DRIVE CHAIN LABEL Keep chain adjusted and lubricated. 30 to 40 mm (1.2 to 1.6 in) Freeplay...

  • Page 14: Safety Precautions

    15 VFR800X-32MJM8000.book 11 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Safety Precautions Safety Precautions ● Face shield with unobstructed field of vision or other approved eye protection. ● Ride cautiously and keep your hands on the WARNING handlebar and feet on the footpegs. ● Keep passenger’s hands onto the grab rails, Not wearing a helmet increases the passenger’s feet on the footpegs while...

  • Page 15: Riding Precautions

    15 VFR800X-32MJM8000.book 12 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Riding Precautions Riding Precautions Brakes Observe the following guidelines: Running-in Period ● Avoid excessively hard braking and down- shifts. During the first 500 km (300 miles) of running, Sudden braking can reduce the follow these guidelines to ensure your motorcycle’s stability.
  • Page 16 15 VFR800X-32MJM8000.book 13 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Riding Precautions ❙ ❙ Anti-lock Brake System (ABS) Engine Braking This model is equipped with an Anti-lock Brake Engine braking helps slow your motorcycle System (ABS) designed to help prevent the down when you release the throttle. For further brakes from locking up during hard braking.
  • Page 17 15 VFR800X-32MJM8000.book 14 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Riding Precautions 4. Turn the handlebar fully to the left. Parking Turning the handlebar to the right reduces ● Park on a firm, level paved surface. stability and may cause the motorcycle to ● If you must park on a slight incline or loose fall.
  • Page 18 15 VFR800X-32MJM8000.book 15 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Riding Precautions Torque Control will allow some wheel spin Refuelling and Fuel Guidelines during acceleration at the lower Torque Control Follow these guidelines to protect the engine levels settings. Select a level that is appropriate and catalytic converter: for your skill and riding conditions.

  • Page 19: Accessories & Modifications

    We strongly advise that you do not add any accessories that were not specifically designed seriously hurt or killed. for your motorcycle by Honda or make modifications to your motorcycle from its Follow all instructions in this owner’s original design. Doing so can make it unsafe.

  • Page 20: Loading

    15 VFR800X-32MJM8000.book 17 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Loading Loading WARNING ● Carrying extra weight affects your Overloading or improper loading can motorcycle’s handling, braking and stability. cause a crash and you can be seriously Always ride at a safe speed for the load you hurt or killed.

  • Page 21: Operation Guide

    Operation Guide 15 VFR800X-32MJM8000.book 18 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Parts Location (P68) Rear seat Front seat (P69) Main fuse & FI fuse (P115) (P74) Battery (P72) Battery cover Front brake fluid reservoir (P81) (P89) Front brake lever (P88) Throttle grip Coolant reserve tank...
  • Page 22 15 VFR800X-32MJM8000.book 19 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Clutch lever (P89) Clutch fluid reservoir (P83) (P90) Front suspension spring preload/rebound damping adjuster (P47) Fuel fill cap (P114) Fuse boxes (P49) Document bag Tool kit (P49) Rear suspension spring preload adjuster knob (P92) Drive chain...

  • Page 23: Instruments

    15 VFR800X-32MJM8000.book 20 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments Tachometer NOTICE Do not operate the engine in the tachometer red zone. Excessive engine speed can adversely affect engine life. Tachometer red zone (excessive engine rpm range) button button Display Check When the ignition switch is turned on, all the mode and digital segments will show. If any part of these displays does not come on when it should, have your dealer check for problems.
  • Page 24 15 VFR800X-32MJM8000.book 21 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Fuel gauge Remaining fuel when only 1st Speedometer (E) segment starts flashing: approximately 3.5 litres (0.92 US gal, 0.77 Imp gal) If the fuel gauge indicators repeat (P103) flashing or turned off: Handle grip heater status icon The handle grip heater status icon will appear while the handle grip heater is on.
  • Page 25 15 VFR800X-32MJM8000.book 22 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments Torque Control level (P43) Coolant temperature gauge ( • Above 122 ºC: - High coolant temperature indicator lights - 6th (H) segment flashes Even if the engine coolant temperature is low, the cooling fan may start running when you rev up the engine.
  • Page 26 15 VFR800X-32MJM8000.book 23 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 ❙ Odometer [TOTAL] & Tripmeter [TRIP A/ Odometer B] & Mileage countdown Total distance ridden. When “------” is displayed, go to your dealer for service. ❙ Tripmeter Distance ridden since tripmeter was reset. When “----.-” is displayed, go to your dealer for service.
  • Page 27 15 VFR800X-32MJM8000.book 24 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments If an indication other than the mileage Gear position indicator countdown is displayed, the indication Shows 1st to 6th gear position. automatically switches to the mileage When the ignition switch is turned on with countdown and flashes “0.0”...
  • Page 28 15 VFR800X-32MJM8000.book 25 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 ❙ Fuel mileage meter & Average speed Current fuel mileage Displays the current or instant fuel mileage. Display range: 0.1 to 99.9 km/L (L/100km, mile/L or mile/gal) • When your speed is less than 7 km/h (5 mph): “--.-”...
  • Page 29 15 VFR800X-32MJM8000.book 26 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments ❙ Average fuel mileage When “--.-” is displayed except for the Displays the average fuel mileage since the above-mentioned case, go to your dealer for selected tripmeter was reset. service. The average fuel mileage will be calculated...
  • Page 30 15 VFR800X-32MJM8000.book 27 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 ❙ Average speed Displays the average speed since the selected tripmeter was reset. The average speed will be calculated based on value displayed on the tripmeter (A or B) selected. Also, the average speed for...
  • Page 31 15 VFR800X-32MJM8000.book 28 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments ❙ To reset the tripmeter, average fuel To reset tripmeter B, average fuel mileage mileage and average speed and average speed (these are based on To reset tripmeter A, average fuel mileage tripmeter B) together, press and hold and average speed (these are based on button while tripmeter B is displayed.
  • Page 32 15 VFR800X-32MJM8000.book 29 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 ❙ Clock (12-hour display) & Trip time & Clock (P31) Handle grip heater level To set the clock: ❙ Trip time Displays the time elapsed since the engine was started. Display range: 0:00 to 19:59 (hours:minutes) Clock (12-hour display) &...
  • Page 33 15 VFR800X-32MJM8000.book 30 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments Display Setting Ordinary display Following items to change sequentially. • Clock setting • Backlight brightness adjustment Clock setting • HISS indicator setting • Changing the speed and mileage unit Backlight brightness adjustment • Changing the fuel mileage meter unit •...
  • Page 34 15 VFR800X-32MJM8000.book 31 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 If the ignition switch is turned off, the button 1 Clock setting: is not pressed for about 30 seconds, or the Turn the ignition switch ON. handle grip heater level is changed, the Press and hold...
  • Page 35 15 VFR800X-32MJM8000.book 32 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments 2 Backlight brightness adjustment: Press button until the desired minute is You can adjust the brightness to one of five displayed. levels. Press and hold button to advance the minute fast. Press button. The brightness is switched.
  • Page 36 15 VFR800X-32MJM8000.book 33 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 3 HISS indicator setting: 4 Changing the speed and mileage unit: You can select the blink or off the HISS “km/h” & Press button to select either indicator. “km” or “mph” & “mile”. “ ” (blinks)
  • Page 37 15 VFR800X-32MJM8000.book 34 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments 5 Changing the fuel mileage meter unit: 6 Setting the mileage countdown: “L/100km” or Press button to select The preset figure is displayed and the third “km/L”. digit will be flashing. To set the third digit, press button until If the “mph”...
  • Page 38 15 VFR800X-32MJM8000.book 35 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Press button. The trip distance is set, and then the display will return to the ordinary display. The trip distance will not be reset when you complete setting of the mileage countdown by pressing button only or when you set the trip distance to the same as the current distance.
  • Page 39 15 VFR800X-32MJM8000.book 36 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Indicators Left turn signal indicator Low oil pressure indicator Comes on when the ignition switch is turned on. Goes off when the engine starts. (P100) If it comes on while engine is running: Neutral indicator Comes on when the transmission is in Neutral.
  • Page 40 15 VFR800X-32MJM8000.book 37 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Torque Control indicator (P118) HISS indicator • Comes on when the ignition switch is turned • Comes on briefly when the ignition on. Goes off when your speed reaches switch is turned on with the engine...
  • Page 41 15 VFR800X-32MJM8000.book 38 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Switches Torque Control switch Torque Control level setting and Torque Control on/off. (P43) Passing light control switch Flashes the high beam headlight. Headlight dimmer switch • : High beam • : Low beam Handle grip heater switch...
  • Page 42 15 VFR800X-32MJM8000.book 39 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Ignition Switch Switches the electrical system on/off, locks the steering. Key can be removed when in the OFF or LOCK position. Engine stop switch Should normally remain in the (Run) position. In an emergency, switch to the (Off) position to stop the engine.
  • Page 43 15 VFR800X-32MJM8000.book 40 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Switches Steering Lock Lock the steering when parking to help Turns electrical system on for starting/riding. prevent theft. A U-shaped wheel lock or similar device is also recommended. Turns engine off. LOCK Ignition key Locks steering.
  • Page 44 15 VFR800X-32MJM8000.book 41 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Handle Grip Heater VFR800X is equipped with a handle grip Handle grip heater indicator: heater that warms up your hands during ride. Displayed when the handle grip heater is on. Wear gloves to protect your hands from the The selected heater level is indicated by the heated grips.
  • Page 45 15 VFR800X-32MJM8000.book 42 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Handle Grip Heater ❙ To operate the handle grip heater a low (or dead) battery. Maintains the selected level when the Start the engine. P. 45 ignition switch is turned off. Press the handle grip heater switch. The The heater level is not changed if the ignition handle grip heater is on.
  • Page 46 15 VFR800X-32MJM8000.book 43 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Honda selectable torque control (Torque Control) Torque Control level (engine power control) Torque Control level setting can be selected or turned on/off. The level can be selected by pressing the Torque Control switch. Do not operate the Torque Control switch while riding.
  • Page 47 15 VFR800X-32MJM8000.book 44 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Honda selectable torque control (Torque Control) Level 2 Level 1 Torque Control Torque Control level: level: maximum minimum Press the Torque Control switch Press and hold the Torque Control switch No Torque Control...

  • Page 48: Starting The Engine

    15 VFR800X-32MJM8000.book 45 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Starting the Engine Start your engine using the following Make sure the engine stop switch is in the (Run) position. procedure, regardless of whether the engine is cold or warm. Turn the ignition switch to the ON position.

  • Page 49: Shifting Gears

    15 VFR800X-32MJM8000.book 46 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Shifting Gears Your motorcycle transmission has six forward gears in a one-down, five-up shift pattern. If you put the motorcycle in gear with the side stand down, the engine will shut off.
  • Page 50 15 VFR800X-32MJM8000.book 47 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Refuelling Opening the Fuel Fill Cap Ignition key Lock cover Open the lock cover, insert the ignition key, and turn it clockwise to open the fuel fill cap. Level plate Closing the Fuel Fill Cap After refuelling, push the fuel fill cap closed until it locks.
  • Page 51 15 VFR800X-32MJM8000.book 48 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Storage Equipment Helmet Holder Use the helmet holder only when parked. The helmet holders is located under the rear ❙ (P68) Removing the Rear Seat seat. The helmet set wire is stored in the tool kit.
  • Page 52 15 VFR800X-32MJM8000.book 49 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Tool Kit/Document Bag U-shaped Lock The tool kit is located under the rear seat. A U-shaped lock is held in place above the Secure the tool kit with the rubber strap A rear fender. (large-diameter) as shown in the illustration.
  • Page 53 15 VFR800X-32MJM8000.book 50 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Storage Equipment U-shaped lock, Place the tool kit onto the then secure the tool kit and U-shaped lock by hooking the rubber A at the strap two points as shown in the illustration. Tool kit...

  • Page 54: Maintenance

    15 VFR800X-32MJM8000.book 51 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. Importance of Maintenance ..... P. 52 Brakes/Clutch ..........P. 81 Maintenance Schedule ......P. 53 Side Stand...........P. 84 Maintenance Fundamentals .....

  • Page 55: Importance Of Maintenance

    15 VFR800X-32MJM8000.book 52 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your motorcycle well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task, and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required.

  • Page 56: Maintenance Schedule

    15 VFR800X-32MJM8000.book 53 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Schedule The maintenance schedule specifies the All scheduled maintenance is considered a maintenance requirements necessary to normal owner operating cost and will be ensure safe, dependable performance, and charged for by your dealer. Retain all proper emission control.
  • Page 57 : Inspect (clean, adjust, lubricate, or replace, if necessary) you have the necessary tools and are mechanically skilled. : Lubricate Procedures are provided in an official Honda Shop Manual. : Replace : Technical. In the interest of safety, have your motorcycle...
  • Page 58 15 VFR800X-32MJM8000.book 55 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 56 × 1,000 mi Drive Chain Every 1,000 km (600 mi): Drive Chain Slider Brake Fluid 2 Years...

  • Page 59: Maintenance Fundamentals

    15 VFR800X-32MJM8000.book 56 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Fundamentals ● Drive chain-Check condition and slack, Pre-ride Inspection adjust and lubricate if necessary. P. 61, To ensure safety, it is your responsibility to perform a pre-ride inspection and make sure ● Brakes-Check operation;...
  • Page 60 15 VFR800X-32MJM8000.book 57 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Fundamentals Replacing Parts Colour label Always use Honda Genuine Parts or their equivalents to ensure reliability and safety. When ordering coloured components, specify the model name, colour, and code mentioned on the colour label. The colour label is attached to the rear fender under the rear seat.
  • Page 61 15 VFR800X-32MJM8000.book 58 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Fundamentals Battery WARNING Your motorcycle has a maintenance-free type The battery gives off explosive battery. You do not have to check the battery hydrogen gas during normal electrolyte level or add distilled water. Clean the operation.
  • Page 62 15 VFR800X-32MJM8000.book 59 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Fundamentals 3. If the terminals are heavily corroded, clean Fuses and polish the terminals with a wire brush or Fuses protect the electrical circuits on your sandpaper. Wear safety glasses. motorcycle. If something electrical on your motorcycle stops working, check for and replace any blown fuses.
  • Page 63 Selecting the Engine Oil circular API service symbol. For recommended engine oil, see “Specifications”. P. 131 If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: ● JASO T 903 standard...
  • Page 64 If either has worn or damaged teeth, NOTICE have the sprocket replaced by your dealer. Brake fluid can damage plastic and painted surfaces. Wipe up spills immediately and wash thoroughly. Recommended brake fluid: Honda DOT 4 Brake Fluid or equivalent Normal Worn Damaged (GOOD) (REPLACE)
  • Page 65 Recommended lubricant: Drive chain lubricant designed specifically Recommended Coolant for O-ring chains. Pro Honda HP coolant is a pre-mixed solution of If not available, use SAE 80 or 90 gear oil. antifreeze and distilled water. Concentration: 50 % antifreeze and 50 % distilled water...
  • Page 66 15 VFR800X-32MJM8000.book 63 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Fundamentals A concentration of antifreeze below 40 % will Air Cleaner not provide proper corrosion and cold This motorcycle is equipped with a viscous type temperature protection. A concentration of up air cleaner element.
  • Page 67 15 VFR800X-32MJM8000.book 64 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Fundamentals ❙ Inspecting for Abnormal Wear Tyres (Inspecting/Replacing) Inspect the tyres for ❙ Checking the Air Pressure signs of abnormal Visually inspect your tyres and use an air wear on the contact pressure gauge to measure the air pressure at surface.
  • Page 68 15 VFR800X-32MJM8000.book 65 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Fundamentals ❙ Inspecting Tread Depth WARNING Inspect the tread wear indicators. If they become visible, replace the tyres immediately. Riding on tyres that are excessively For safe riding, you should replace the tyres worn or improperly inflated can cause when the minimum tread depth is reached.
  • Page 69 15 VFR800X-32MJM8000.book 66 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Maintenance Fundamentals Have your tyres replaced by your dealer. WARNING For recommended tyres, air pressure and minimum tread depth, see “Specifications”. Installing improper tyres on your P. 131 motorcycle can adversely affect Follow these guidelines whenever you replace handling and stability, and can cause a tyres.

  • Page 70: Tool Kit

    15 VFR800X-32MJM8000.book 67 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Tool kit The tool kit is stored under the raer seat. P. 68 You can perform some roadside repairs, minor adjustments and parts replacement with the tools contained in the kit. ● Standard/Phillips screwdriver ●...

  • Page 71: Removing & Installing Body Components

    15 VFR800X-32MJM8000.book 68 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Removing & Installing Body Components ❙ Rear Seat Removal 1. Insert the ignition key into the seat lock. 2. Turn it clockwise, then pull the rear seat Prongs Rear seat up and back. Seat lock ❙...

  • Page 72: Front Seat

    15 VFR800X-32MJM8000.book 69 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Removing & Installing Body Components Front Seat ❙ Front Seat Installation When setting the high seat position: ❙ Removal Install the front seat by aligning its recesses with the front side stays and Mounting bolts placing its prong on the front centre stay.
  • Page 73 15 VFR800X-32MJM8000.book 70 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Removing & Installing Body Components Front Seat When setting the low seat position: Mounting bolts Install the front seat by aligning its recesses with the front side stays and its prong with the front centre stay.

  • Page 74: Right Under Cover

    15 VFR800X-32MJM8000.book 71 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Removing & Installing Body Components Right Under Cover Right Under Cover The right under cover must be removed to replace the engine oil filter. ❙ Right under cover Removal Collars 1. Remove the bolts and collars.

  • Page 75: Battery Cover

    15 VFR800X-32MJM8000.book 72 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Removing & Installing Body Components Battery Cover Battery Cover Clips Battery cover The battery cover must be removed to Clip remove the battery, to service the main and fuse box fuses. ❙ Removal When setting the high seat position: 1.
  • Page 76 15 VFR800X-32MJM8000.book 73 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Removing & Installing Body Components Battery Cover When setting the low seat position: 4. While pressing down the rear left part of 1. Remove the front seat. P. 69 the battery cover (!b), pull up the right 2.

  • Page 77: Battery

    15 VFR800X-32MJM8000.book 74 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Removing & Installing Body Components Battery Battery 3. Disconnect the negative terminal from the battery. 4. Disconnect the positive terminal from Rubber strap Positive terminal the battery. 5. Remove the battery taking care not to drop the terminal nuts.

  • Page 78: Engine Oil

    15 VFR800X-32MJM8000.book 75 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Engine Oil Checking the Engine Oil Oil fill cap Oil level 1. If the engine is cold, idle the engine for 3 inspection window to 5 minutes. 2. Turn the ignition switch off, and wait for Upper level 2 to 3 minutes.

  • Page 79: Adding Engine Oil

    15 VFR800X-32MJM8000.book 76 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Engine Oil Adding Engine Oil Adding Engine Oil 2. Securely reinstall the oil fill cap. NOTICE If the engine oil is below or near the lower Overfilling with oil or operating with insufficient oil can level mark, add the recommended engine oil.
  • Page 80 Changing the oil and filter requires special Sealing washer tools. We recommend that you have your motorcycle serviced by your dealer. Use a new Honda Genuine oil filter or equivalent specified for your model. NOTICE Using the wrong oil filter can result in serious damage to the engine.
  • Page 81 15 VFR800X-32MJM8000.book 78 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Engine Oil Changing Engine Oil & Filter 7. Remove the oil filter with a filter wrench 8. Apply a thin coat of engine oil to the from the right side and let the remaining rubber seal of a new oil filter.

  • Page 82: Coolant

    15 VFR800X-32MJM8000.book 79 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Coolant Checking the Coolant If the coolant level is dropping noticeably or the reserve tank is empty, you likely have a 1. Place your motorcycle on a firm, level serious leak. Have your motorcycle inspected surface.

  • Page 83: Changing Coolant

    15 VFR800X-32MJM8000.book 80 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Coolant Changing Coolant 2. Remove the reserve tank cap and add Reserve tank cap fluid while monitoring the coolant level. Do not overfill above the UPPER level mark. Make sure no foreign objects enter the reserve tank opening.

  • Page 84: Brakes/Clutch

    15 VFR800X-32MJM8000.book 81 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Brakes/Clutch Checking Brake Fluid If the brake fluid level in either reservoir is below the LOWER level mark or the brake 1. Place your motorcycle in an upright lever and pedal freeplay becomes excessive, position on a firm, level surface.
  • Page 85 15 VFR800X-32MJM8000.book 82 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Brakes/Clutch Inspecting the Brake Pads Inspecting the Brake Pads Front Inspect the brake pads from in front of the brake caliper. Check the condition of the brake pad wear Always inspect both left and right indicators.
  • Page 86 15 VFR800X-32MJM8000.book 83 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Brakes/Clutch Adjusting the Brakelight Switch Adjusting the Brakelight Checking the Clutch Fluid Switch Clutch fluid reservoir Check the operation of the brakelight switch. Hold the brake light switch and turn the adjusting nut in the direction A if the switch operates too late, or turn the nut in the direction B if the switch operates too soon.

  • Page 87: Side Stand

    15 VFR800X-32MJM8000.book 84 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Side Stand 4. Start the engine, pull the clutch lever in, and shift the transmission into gear. 5. Lower the side stand all the way. The engine should stop as you lower the side stand. If the engine doesn’t stop, have your motorcycle inspected by your dealer.

  • Page 88: Drive Chain

    15 VFR800X-32MJM8000.book 85 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Drive Chain Inspecting the Drive Chain 3. Check the slack in the lower half of the drive chain midway between the Slack sprockets. Check the drive chain slack at several points Drive chain slack: along the chain. If the slack is not constant at 30 to 40 mm (1.2 to 1.6 in)

  • Page 89: Adjusting The Drive Chain Slack

    15 VFR800X-32MJM8000.book 86 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Drive Chain Adjusting the Drive Chain Slack 5. Inspect the sprockets. P. 61 5. Tighten the bearing holder pinch bolt to 6. Clean and lubricate the drive chain. the specified torque. P. 62 Torque: 74 N·m (7.5 kgf·m, 55 lbf·ft).
  • Page 90 15 VFR800X-32MJM8000.book 87 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Drive Chain Checking the Drive Chain Slider ❙ Checking the Drive Chain Slider Checking the Drive Chain Wear Check the chain wear label when adjusting Check the condition of the drive chain the drive chain. If the red zone on the label slider.The drive chain slider need to be...

  • Page 91: Throttle

    15 VFR800X-32MJM8000.book 88 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle freeplay is correct. If the throttle does not move smoothly, close automatically, or if the cable is damaged, have the motorcycle inspected by your dealer.

  • Page 92: Other Adjustments

    15 VFR800X-32MJM8000.book 89 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Other Adjustments ❙ Adjusting the Clutch and Brake Adjustment method Levers Turn the adjuster until the numbers aligns with the index mark while pushing the lever You can adjust the distances between the tip forward in the desired position.

  • Page 93: Adjusting The Front Suspension

    15 VFR800X-32MJM8000.book 90 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Other Adjustments Adjusting the Front Suspension Adjusting the Front Suspension Fork bolt ❙ Spring Preload You can adjust the spring preload by the adjuster to suit the load or the road surface. Turn the adjuster using the preload spanner provided in the tool kit.
  • Page 94 15 VFR800X-32MJM8000.book 91 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Other Adjustments Adjusting the Front Suspension ❙ Rebound Damping Reference You can adjust the rebound damping by the mark adjuster to suit the load or the road surface. Turn clockwise to increase rebound damping (hard), or turn counterclockwise to decrease rebound damping (soft).

  • Page 95: Adjusting The Rear Suspension

    15 VFR800X-32MJM8000.book 92 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Other Adjustments Adjusting the Rear Suspension ❙ Adjusting the Rear Suspension Rebound Damping You can adjust the rebound damping by the ❙ Spring Preload adjuster to suit the load or the road surface. You can adjust the spring preload by the...

  • Page 96: Headlight Aim

    15 VFR800X-32MJM8000.book 93 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Other Adjustments Adjusting the Headlight Aim Adjusting the Headlight Aim NOTICE Do not turn the adjuster beyond its limits. You can adjust vertical aim of the headlight NOTICE for proper alignment. Turn the knob in or out The rear shock absorber damper unit contains high as necessary.

  • Page 97: Front Seat Height

    15 VFR800X-32MJM8000.book 94 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Other Adjustments Changing the Front Seat Height Changing the Front Seat Height 4. If you change the front seat height from high position to low position, remove the The front seat can be changed to one of two socket bolts B/set collars A and socket bolt positions according to your preference.
  • Page 98 15 VFR800X-32MJM8000.book 95 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Other Adjustments Changing the Front Seat Height 5. Install the front seat. P. 69 Socket bolts B/ Socket bolt C/ When setting the high seat position: set collars A set collar B High Install the front seat by aligning its...
  • Page 99 15 VFR800X-32MJM8000.book 96 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Other Adjustments Changing the Front Seat Height When setting the low seat position: 6. Make sure that the mount positions of the Install the front seat by aligning its front seat prong and the adjust plates are recesses with the front side stays and its the same seat position.

  • Page 100: Troubleshooting

    15 VFR800X-32MJM8000.book 97 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Troubleshooting Engine Will Not Start (HISS indicator stays Other Warning Indications ......P. 103 ............P. 98 Fuel Gauge Failure Indications ....P. 103 Overheating (High coolant temperature Handle Grip Heater Failure Indication..P. 103 indicator is on) ......... P. 99 Tyre Puncture ...........P.

  • Page 101: Engine Will Not Start (Hiss Indicator Stays On)

    15 VFR800X-32MJM8000.book 98 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Engine Will Not Start (HISS indicator stays on) ❙ Starter Motor Operates But Engine Check if there are no any metallic seals Does Not Start or stickers on the key. If the HISS indicator still stays on, have...

  • Page 102: Overheating (High Coolant Temperature Indicator Is On)

    15 VFR800X-32MJM8000.book 99 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Overheating (High coolant temperature indicator is on) The engine is overheating when the 2. Check that the radiator fan is operating, following occurs: and then turn the ignition switch to the ● High coolant temperature indicator comes OFF position.

  • Page 103: Warning Indicators On Or Flashing

    15 VFR800X-32MJM8000.book 100 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Warning Indicators On or Flashing Low Oil Pressure Indicator If the engine oil level goes down rapidly, your motorcycle may have a leak or another If the low oil pressure indicator comes on, serious problem. Have your motorcycle pull safely to the side of the road and stop inspected by your dealer.

  • Page 104: Abs (Anti-Lock Brake System) Indicator

    15 VFR800X-32MJM8000.book 101 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Warning Indicators On or Flashing ABS (Anti-lock Brake System) Indicator ABS (Anti-lock Brake System) If the ABS indicator stays on, your brakes will continue to work as a conventional system, Indicator but without the anti-locking function.

  • Page 105: Torque Control Indicator

    15 VFR800X-32MJM8000.book 102 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Warning Indicators On or Flashing Torque Control Indicator Torque Control Indicator Even when the Torque Control indicator is on, your motorcycle will have normal riding If the indicator operates in one of the ability without Torque Control function.

  • Page 106: Other Warning Indications

    15 VFR800X-32MJM8000.book 103 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Other Warning Indications Fuel Gauge Failure Indications Handle Grip Heater Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the If the handle grip heater system has an error, illustration.

  • Page 107: Tyre Puncture

    15 VFR800X-32MJM8000.book 104 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Tyre Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. We recommend you have this type of service Riding your motorcycle with a performed by your dealer. temporary tyre repair can be risky. If...
  • Page 108 15 VFR800X-32MJM8000.book 105 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Tyre Puncture Removing Wheels When removing and installing the wheel, be 3. Remove the wheel speed sensor by careful not to damage the wheel speed removing the bolts. sensor and pulser ring. 4. On the right side, remove the mounting bolts and remove the brake caliper.
  • Page 109 15 VFR800X-32MJM8000.book 106 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Tyre Puncture Removing Wheels 6. Remove the front axle bolt. 9. Loosen the left axle pinch bolts. 7. Loosen the right axle pinch bolts. 10. On the left side, withdraw the front axle 8. Support your motorcycle securely and...
  • Page 110 15 VFR800X-32MJM8000.book 107 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Tyre Puncture Removing Wheels Installation 4. Tighten the left axle pinch bolts to hold 1. Attach the side collars to the wheel. the axle. 2. On the left side, place the wheel 5. Tighten the axle bolt.
  • Page 111 15 VFR800X-32MJM8000.book 108 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Tyre Puncture Removing Wheels 9. Install the left brake caliper and tighten 13. Raise the front wheel off the ground the mounting bolts. again, and check that the wheel rotates freely after you release the brake.
  • Page 112 15 VFR800X-32MJM8000.book 109 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Tyre Puncture Removing Wheels ❙ Rear Wheel 4. Move the muffler outward. 5. Remove the rear wheel nuts, and remove Removal the rear wheel. 1. Support your motorcycle securely and Rear wheel nuts Muffler raise the rear wheel off the ground using a maintenance stand or a hoist.
  • Page 113 15 VFR800X-32MJM8000.book 110 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Tyre Puncture Removing Wheels Installation 1. To install the rear wheel, reverse the removal procedure. 2. Tighten the rear wheel nuts equally. Torque: 108 N·m (11.0 kgf·m, 80 lbf·ft). 3. Hold the muffler mounting bolt and tighten the mounting nut.

  • Page 114: Electrical Trouble

    15 VFR800X-32MJM8000.book 111 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the motorcycle Turn the ignition switch to the OFF or LOCK before charging.
  • Page 115 15 VFR800X-32MJM8000.book 112 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Electrical Trouble Burned-out Light Bulb ❙ ❙ Headlight Brake/Tail light Brake/Tail light Headlight The brake and tail light uses several LEDs. If there is a LED which is not turned on, see The headlight uses several LEDs.
  • Page 116 15 VFR800X-32MJM8000.book 113 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Electrical Trouble Burned-out Light Bulb ❙ ❙ Front/Rear Turn Signal Light License Plate Light 1. Remove the screws. 2. Remove the license light cover and license light cover packing. 3. Pull out the bulb without turning.

  • Page 117: Blown Fuse

    15 VFR800X-32MJM8000.book 114 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Electrical Trouble Blown Fuse Blown Fuse 1. Remove the battery cover. P. 72 2. Open the fuse box covers. Before handling fuses, see “Inspecting and 3. Pull the fuses out with the fuse puller in Replacing Fuses”.
  • Page 118 15 VFR800X-32MJM8000.book 115 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Electrical Trouble Blown Fuse ❙ Main Fuse & FI Fuse 3. Pull the main fuse and FI fuse out with the fuse puller in the tool kit and check for a Starter magnetic switch cover blown fuse.

  • Page 119: Information

    15 VFR800X-32MJM8000.book 116 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Information Keys............P. 117 Instruments, Controls, & Other Features ..P. 118 Fuels Containing Alcohol......P. 121 Catalytic Converter ........P. 122 Caring for Your Motorcycle.....P. 123 Storing Your Motorcycle ......P. 126 Transporting Your Motorcycle ....P. 127 You & the Environment ......P. 128...

  • Page 120: Keys

    15 VFR800X-32MJM8000.book 117 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Keys Keys key. If you lose a key, make another duplicate key immediately. Ignition key This motorcycle has two ignition keys and a key To make a duplicate key and register it with tag with a key number and a bar code.

  • Page 121: Instruments, Controls, & Other Features

    15 VFR800X-32MJM8000.book 118 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments, Controls, & Other Features Instruments, Controls, & Tripmeter Other Features The tripmeter A, B returns to 0.0 when the readout exceeds 9,999.9. Ignition Switch HISS The headlight is always on when the ignition The Honda Ignition Security System (HISS) switch is ON.
  • Page 122 15 VFR800X-32MJM8000.book 119 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments, Controls, & Other Features The HISS indicator starts flashing every 2 seconds for 24 hours after the ignition switch is turned off. You can turn this feature on or off. The declaration of conformity to R & TTE P.
  • Page 123 15 VFR800X-32MJM8000.book 120 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Instruments, Controls, & Other Features Document Bag The owner’s manual, registration, and insurance information can be stored in the plastic document bag located under the front seat. Ignition Cut-off System A banking (lean angle) sensor automatically stops the engine and fuel pump if the motorcycle falls over.

  • Page 124: Fuels Containing Alcohol

    15 VFR800X-32MJM8000.book 121 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Fuels Containing Alcohol Fuels Containing Alcohol The use of petrol containing more than 10 % ethanol may: ● Some conventional fuels blended with alcohol Damage the painting of the fuel tank. ● are available in some locales to help reduce Damage the rubber tubes of the fuel line.

  • Page 125: Catalytic Converter

    15 VFR800X-32MJM8000.book 122 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Catalytic Converter Catalytic Converter Follow these guidelines to protect your motorcycle’s catalytic converter. ● This motorcycle is equipped with a three-way Always use unleaded petrol. Leaded petrol catalytic converter. The catalytic converter will damage the catalytic converter.

  • Page 126: Caring For Your Motorcycle

    Frequent cleaning and polishing is important to 3. Thoroughly rinse your motorcycle with plenty ensure the life of your Honda. A clean of clean water and dry with a soft, clean motorcycle makes it easier to spot potential cloth.
  • Page 127 15 VFR800X-32MJM8000.book 124 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Caring for Your Motorcycle ● If your motorcycle has any mat painted Do not direct water at the air cleaner: parts, do not apply a coat of wax to the Water in the air cleaner can prevent the mat painted surface.
  • Page 128 15 VFR800X-32MJM8000.book 125 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Caring for Your Motorcycle Aluminium Components Windscreen Aluminium will corrode from contact with dirt, Using plenty of water, clean the windscreen mud, or road salt. Clean aluminium parts with a soft cloth or sponge. (Avoid using...

  • Page 129: Storing Your Motorcycle

    15 VFR800X-32MJM8000.book 126 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Storing Your Motorcycle Storing Your Motorcycle Exhaust Pipe and Muffler The exhaust pipe and muffler are stainless steel If you store your motorcycle outdoors, you but may become stained by mud or dust. should consider using a full-body motorcycle To remove mud or dust, use a wet sponge and cover.

  • Page 130: Transporting Your Motorcycle

    15 VFR800X-32MJM8000.book 127 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Transporting Your Motorcycle Transporting Your After removing your motorcycle from storage, inspect all maintenance items required by the Motorcycle Maintenance Schedule. If your motorcycle needs to be transported, it should be carried on a motorcycle trailer or a...

  • Page 131: You & The Environment

    15 VFR800X-32MJM8000.book 128 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 You & the Environment You & the Environment drain or on the ground. Used oil, petrol, coolant, and cleaning solvents contain poisons Owning and riding a motorcycle can be that can hurt refuse workers and contaminate enjoyable, but you must do your part to protect drinking water, lakes, rivers, and oceans.

  • Page 132: Serial Numbers

    15 VFR800X-32MJM8000.book 129 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Serial Numbers Serial Numbers The frame and engine serial numbers uniquely identify your motorcycle and are required in order to register your motorcycle. They may also be required when ordering replacement parts. The frame number is stamped on the right side of the steering head.

  • Page 133: Specifications

    15 VFR800X-32MJM8000.book 130 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Specifications Specifications ■ Main Components Displacement 782 cm (47.7 cu-in) Type RC80 Bore × stroke 72.0 x 48.0 mm (2.83 x 1.89 in) Overall length 2,190 mm (86.2 in) Compression ratio 11.8 : 1 Overall width 870 mm (34.3 in)
  • Page 134 15 VFR800X-32MJM8000.book 131 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Specifications ■ Service Data 2.9 litres (3.1 US qt, 2.6 After draining Front 120/70R17M/C 58V Imp qt) Tyre size Rear 180/55R17M/C 73V After draining & Engine oil 3.1 litres (3.3 US qt, 2.7 engine oil filter...

  • Page 135: Torque Specifications

    15 VFR800X-32MJM8000.book 132 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Specifications ■ Torque Specifications Recommended Drive chain lubricant designed specifically for drive chain O-ring chains. If not available, use SAE 80 or Engine oil drain bolt 30 N·m (3.1 kgf·m, 22 lbf·ft) lubricant 90 gear oil.

  • Page 136: Index

    15 VFR800X-32MJM8000.book 133 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Index Index ABS (Anti-lock Brake System) Caring for Your Motorcycle....123 Indicator .......... 37, 101 Clutch Accessories..........16 Fluid ........... 61, 83 Anti-lock Brake System (ABS)....13 Lever Adjustment ........89 Colour Label ..........57 Compartment Battery ..........
  • Page 137 15 VFR800X-32MJM8000.book 134 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Fuel Electrical Trouble........111 Gauge ............21 Engine Mileage Meter ..........25 Number..........129 Recommended..........47 Oil ............60, 75 Remaining ..........21 Oil Filter............ 77 Tank Capacity ...........47 Fuels Containing Alcohol ......121 Overheats..........99 Starting ............ 45 Fuses ...........59, 114 Stop Switch ........
  • Page 138 15 VFR800X-32MJM8000.book 135 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 HISS Indicator ........ 30, 37, 98 Importance..........52 Horn Button ..........39 Safety............52 Schedule ..........53 Maximum Weight Limit ......17 Ignition Cut-off System Modifications..........16 Banking Sensor ........120 Side Stand..........84 Ignition key ..........117 Neutral Indicator ........
  • Page 139 15 VFR800X-32MJM8000.book 136 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Specifications ...........130 Rear Seat............ 68 Speedometer..........21 Recommended Start Button .........39, 45 Coolant ............ 62 Starting the Engine ........45 Fuel ............47 Steering Lock ..........40 Oil ............60 Stopping Engine ........118 Storage Refuelling ..........47 Removal Document Bag..........49...
  • Page 140 15 VFR800X-32MJM8000.book 137 ページ ２０１４年１２月１９日　金曜日　午後１時４０分 Transporting Your Motorcycle....127 Tripmeter........... 23 Troubleshooting ........97 Turn Signal Indicators......36, 37 Turn signal switich ........38 Tyres Air Pressure..........64 Puncture ..........104 Replacing ......... 64, 104 Warning Indicators On ..... 99, 100 Washing Your Motorcycle......
  • Page 141 15 VFR800X-32MJM8000.book 138 ページ ２０１４年１２月１９日　金曜日　午後１時４０分...

Table of Contents

Save PDF
