WARNING:
Do not install or use this infant
restraint
until
you
understand all instructions in this
manual. To avoid serious injuries to
your baby, follow the instructions
carefully and be sure to buckle your
baby using the 5-point harness.
Weight limits in
read
and
rear-facing mode:
5-45 lbs (2.3 - 20.4 kg)
maximum height:
35 inches (89 cm)
USA
Instructions for use EN
FIUS1001I141
Weight limits in
forward-facing mode:
22-70 lbs (10 - 31.8 kg)
maximum height:
49 inches (125 cm)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Primo Viaggio SIP Convertible and is the answer not in the manual?

Questions and answers

Related Manuals for Peg-Perego Primo Viaggio SIP Convertible

Summary of Contents for Peg-Perego Primo Viaggio SIP Convertible

  • Page 1 Instructions for use EN FIUS1001I141 WARNING: Weight limits in Weight limits in Do not install or use this infant restraint until read rear-facing mode: forward-facing mode: understand all instructions in this 5-45 lbs (2.3 - 20.4 kg) 22-70 lbs (10 - 31.8 kg) manual.

  • Page 2: Table Of Contents

    3 - Forward facing mode using lap belt (Type I) ............ 34 Installing your car seat in an aircraft ....................36 Securing your baby in Primo Viaggio SIP Convertible ..............38 Securing your baby in Primo Viaggio SIP Convertible (Crotch strap adjustment)....43 Cleaning and maintenance ........................45 Replacement Parts............................ 49 - 2 - ©...

  • Page 3: Introduction

    Introduction Thank you for choosing a PegPerego Primo necessary time and making fitting trials before Viaggio SIP Convertible. As with any other using it with your child. Once you have read PegPerego product, your Convertible has been the manual, store it again in its proper pocket. designed and certified by a dedicated team This will make you sure that everybody looking of engineers inside Peg Perego Research and...
  • Page 4 Peg Perego Customer Service @ 1-800-671- 1701 for help. Now that you know your new Primo Viaggio SIP Convertible, you are ready to enjoy safe and happy journeys with your family and your children.

  • Page 5: Warning

    • Primo Viaggio SIP Convertible can besecured sure that the belts are in the correct position. to your vehicle by means of lower universal • Primo Viaggio SIP Convertible can be used in anchorage system (LATCH) inconjunction with two main modes: rear facing, when baby sitting a top tether, both provided with this product.
  • Page 6 Warning seats equipped with an active air bag or next accident, it may be no longer safe for use. You to airbags located in other parts of the vehicle. may need to get a new unit. Call customer Death or serious injuries can occur if an air bag service @ 1-800-671-1701 for help.

  • Page 7: Safety Information

    Safety information • Use only with children who weigh between 5 • Do not place this car seat on countertops, and 70 lbs (2.3 and 31.8 kg). tables or soft surfaces. Do not use this unit after • When placing your child in the seat, make seven (7) years from the date of production sure that bulky jackets or covers are removed.

  • Page 8: Registration Form

    Registration form Important! Child restraints could be recalled Registration form is attached to the product for safety reasons. You must register this re- cover. Detach the form, fill in and mail to straint to be reached in a recall. Send your PegPerego.
  • Page 9 Registration form Harness serial number is also indelibly printed on the buckle and the webbing and could provide useful information in case of accident or defects. See picture below for location explanation. - 9 -...

  • Page 10: Your Car Seat

    Your car seat Headpad adjustment strap Newborn EPS padded head panel ller cushion 5 point harness Shoulder pads Chest clip Buckle Locko clip Harness release button Base Recline handle Latch Instruction Top tether connector manual pocket strap Adjuster strap - 10 -...

  • Page 11: Installing Your Car Seat In A Vehicle

    Installing your car seat in the vehicle VEHICLE SEATBELTS DESIGN AND COMPATIBILITY Primo Viaggio SIP Convertible is designed to be installed with vehicle belts commonly fitted on most of the available cars. However, in the market there are several different types of vehicles manufactured in different periods.
  • Page 12 Installing your car seat in the vehicle Lap/shoulder belt (3-point) with Emergency Locking Retractor (ELR) and free sliding latch plate. This type of seat belt has a latch plate that moves freely along the belt; it will only lock in an emergency (sudden stop or crash) so you must use the lock off clips when available to enhance stability during normal use.
  • Page 13 Installing your car seat in the vehicle Lap/shoulder belt (3-point) with Emergency Locking Retractor (ELR) and with a locking latch plate. This type of belt can be adjusted by pulling/releasing the strap at the latch plate adjuster. This type of belt belong to older vehicle models and can result in a very difficult or poor installation of Primo Viaggio SIP Convertible due to the specific design of its...
  • Page 14 Locking Retractor (ELR). This type of seat belt has a latch plate sewn at the end of the belt; it will only lock in an emergency (sudden stop or crash). Important note: DO NOT USE Primo Viaggio SIP Convertible with these belts. - 14 -...
  • Page 15 This type of belt belong to older vehicle models and can result in a very difficult or poor installation of Primo Viaggio SIP Convertible due to the specific design of its structure. Please refer to your vehicle owner’s manual for details.

  • Page 16: Non Compatible Vehicle Belt Designs

    Installing your car seat in the vehicle 2. Side facing seats NON COMPATIBLE VEHICLE BELT DESIGNS WARNING: do not use Primo Viaggio SIP Convertible with the following vehicle belt design: 1. Lap/motorized shoulder belts. Belts mounted on the door 3. Rear facing seats or seats that rotate in different positions For your child’s safety, always read your vehicle owner’s manual for further informations.

  • Page 17: Proper Levelling Of Child Seat In Rearward Facing Mode

    Installing your car seat in the vehicle PROPER LEVELLING OF CHILD SEAT IN REARWARD FACING MODE When properly installed according to the following sections, a child seat used in rear facing mode should have a backrest angle of 40° - 45° from vertical. If it is not possible to reach such angle, use a pool noodle or a rolled towel to further recline the seat.

  • Page 18: Use Of Top Tether Strap

    Installing your car seat in the vehicle USE OF TOP TETHER STRAP 1. The top tether is an additional strap attached at the top of the Primo Viaggio SIP Convertible shell equipped with a hook and an adjuster. Your Primo Viaggio SIP Convertible is certified for use without a top tether.
  • Page 19 Installing your car seat in the vehicle 2. To use the tether, detach it from its rear panel hook pressing on adjuster button in order to lengthen the strap to the required length. - 19 -...
  • Page 20 3. Tether can be used to prevent excessive rotation in an impact in forward facing mode, thus reducing the risk for the occupant to impact objects in front of him. Attach the tether to the designed tether anchor and pull the free strap until the tether is fully tensioned and free of any slack.
  • Page 21 Installing your car seat in the vehicle 4. Attach the tether to the designed tether anchor and pull the free strap until the tether is fully tensioned and free of any slack. Picture shows the tether anchor located on the back of the seat.

  • Page 22: Rear Facing Mode Using Latch System

    Installing your car seat in the vehicle REAR FACING MODE USING LATCH SYSTEM 1. Recline the child seat to the rearfacing position as shown in the picture. To recline the seat, pull the handle located below the front edge of the shell as shown in detail.
  • Page 23 Installing your car seat in the vehicle 5. Attach the lower connectors to the lower anchors of your vehicle located at the joint line between seat and backrest. Check your vehicle owner’s manual to learn what is the best place for your car seat. When the LATCH straps are connected to the lower anchors, an audible click will be heard.
  • Page 24 Installing your car seat in the vehicle IMPORTANT NOTE : Unless where specified differently, lower (latch) should be used for a child whose weight is less than 30 lbs. However most car lower anchors can withstand much greater forces. Please, check your vehicle owner’s manual or contact the vehicle manufacturer in order to determine which is the limit weight for the use of lower anchors.

  • Page 25: Rear Facing Mode Using Lap/Shoulder Belt (Type Ii)

    Installing your car seat in the vehicle REAR FACING MODE USING LAP/ SHOUER BELT (TYPE II) 1. Recline the child seat to the rearfacing position as shown in the picture. To recline the seat, pull the handle located below the front edge of the shell as shown in detail.
  • Page 26 Installing your car seat in the vehicle 4. Buckle the vehicle belt and check that the vehicle belt portions are both threaded below the integral harness crotch strap and free of any entrapment. 5. Push the seat firmly into the vehicle seat (1) and pull the vehicle belt (2) in order to tighten the seat at the most, eliminating any slack (3).

  • Page 27: Rear Facing Mode Using Lap Belt (Type I)

    Installing your car seat in the vehicle REAR FACING MODE USING LAP BELT (TYPE I) 1. Recline the child seat to the rearfacing position as shown in the picture. To recline the seat, pull the handle located below the front edge of the shell as shown in detail. An audible "click"...
  • Page 28 Installing your car seat in the vehicle 4. Buckle the vehicle belt and check that the vehicle belt is threaded below the integral harness crotch strap and free of any entrapment. 5. Push the seat firmly into the vehicle seat (1) and pull the vehicle belt in order to tighten the seat at the most, eliminating any slack (2).

  • Page 29: Forward Facing Mode Using Latch System

    Installing your car seat in the vehicle FORWARD FACING MODE USING LATCH SYSTEM 1. Recline the child seat pulling the handle located below the front edge of the shell as shown in detail. This will make access to the latch storage area easier. 2.
  • Page 30 Installing your car seat in the vehicle 4. Attach the lower connectors to the lower anchors of your vehicle located at the joint line between seat and backrest. Check your vehicle owner’s manual to learn what is the best place for your car . When the LATCH straps are connected to the lower anchors, an audible click will be heard.
  • Page 31 Installing your car seat in the vehicle IMPORTANT NOTE : Unless where specified differently, lower anchors should be used for a child whose weight is less than 30 lbs. However most car lower anchors can withstand much greater forces. Please, check your vehicle owner’s manual or contact the vehicle manufacturer in order to determine which is the limit weight for the use of lower anchors.

  • Page 32: Forward Facing Mode Using Lap/Shoulder Belt (Type Ii)

    Installing your car seat in the vehicle FORWARD FACING MODE USING LAP/SHOULDER BELT (TYPE II) 1. Before installing the seat in the vehicle, make sure that the backrest is in the upright position or adjust it using the handle located below the front edge of the shell as shown in detail.
  • Page 33 Installing your car seat in the vehicle 5. Push the seat firmly into the vehicle seat (1) and pull the vehicle belt in order to tighten (2) the seat at the most, eliminating any slack. Follow the procedure shown in the picture making sure that while the seat is pushed down (1), the lap portion of the belt is pulled from the fixed point toward the buckle.

  • Page 34: Forward Facing Mode Using Lap Belt (Type I)

    Installing your car seat in the vehicle FORWARD FACING MODE USING LAP BELT (TYPE I) 1. Before installing the seat in the vehicle, make sure that the backrest is in the upright position or adjust it using the handle located below the front edge of the shell as shown in detail.
  • Page 35 Installing your car seat in the vehicle 5. Push the seat firmly into the vehicle seat (1) and pull the vehicle belt in order to tighten (2) the seat at the most, eliminating any slack. 6. Make sure that the belt passes through the opened lockoff clips and then close these following the procedure shown in picture.

  • Page 36: Installing Your Car Seat In An Aircraft

    FAA regulations. However, due to the size and weight of Primo Viaggio SIP Convertible, it is recommended that airline is contacted for further information prior to booking or flight.
  • Page 37 Installing your car seat in an aircraft 2. Installation in forward facing mode: please refer to section page 29 for proper belt fit. Keep lock off closed due to large aircraft buckles. After installation make sure that the seat is properly levelled and safely firm on the aircraft seat.

  • Page 38: Securing Your Baby In Primo Viaggio Sip Convertible

    Strapping your baby into the car seat 1. This restraint uses a 5 point harness system to secure your baby . Before placing the occupant in the seat, push the release button and pull the shoulder straps as shown in the picture. 2.
  • Page 39 Strapping your baby into the car seat 4. Put your baby in the car seat with bottom and back flat against the child restraint. Bring the two shoulder straps over your baby’s shoulders. Make sure that the straps are not twisted behind the backrest or over your baby’s chest.
  • Page 40 Strapping your baby into the car seat 6. To adjust the harness shoulder level, from bottom to top, pull the arrow strap located on top of headrest until the panel is disengaged and able to move. Once the desired position is reached, make sure that the panel is properly latched.
  • Page 41 Strapping your baby into the car seat 8. The harness is equipped with a chest clip. This device is used in order to guarantee that the shoulder harness is positioned correctly on the shoulder, preventing the risk of the straps falling down the shoulder in an accident.
  • Page 42 Strapping your baby into the car seat 10. When the harness is tightened, check that the chest clip is levelled at arm pit level. If necessary remove the shoulder pads (Vel- cro straps) as they are not considered as safety features.

  • Page 43: Securing Your Baby In Primo Viaggio Sip Convertible (Crotch Strap Adjustment)

    Strapping your baby into the car seat CROTCH STRAP ADJUSTMENT 12. Your Primo Viaggio SIP Convertible is equip- ped with a repositionable crotch strap. The product is assembled with the crotch located in the forward position (A). However, for children up to 22 lbs, the crotch strap must be relocated in the rear position (B).
  • Page 44 Strapping your baby into the car seat 13. To complete the operation, put the soft cover on the crotch in the new position by sli- ding the buckle through the openings in the upholstery and in the croch protection 14. Important! The seat is supplied with a specifically designed filler cushion for This cushion...

  • Page 45: Cleaning And Maintenance

    Cleaning and maintenance Your product requires a minimum of cleaning and maintenance. Do not clean with harsh products or solvents. Keep moving parts clean; in case, clean plastic parts with a damp cloth. Do not use water with harness and latching mechanisms. Protect the product from extreme cold, water, rain and sun exposure.
  • Page 46 Cleaning and maintenance 2. Remove head panel padding following the procedure (1, then 2). Take care of the soft white EPS insert. 3. Undo the lower part of upholstery and remove it from the crotch strap. The crotch portion of the harness does not need to be removed.
  • Page 47 Cleaning and maintenance 5. Remove the padding from backrest starting from the lower part of the opening 6. Remove the padding from bottom to top making sure that the side impact wings white EPS are not bent or broken in the process. - 47 -...
  • Page 48 Cleaning and maintenance 7. When the product has to be reassembled after cleaning put the uphostery on, starting from the head panel opening as shown in the sequence. Then put the head panel cover on. Pull shoulder straps up throught slots in bottom of upholstery.

  • Page 49: Replacement Parts

    Replacement Parts 1) BSACOB* NOTE: Spare parts available in different 2) BRICOB* colors* to be specified when ordering. 3) MUCI0076GR 4) BAKCOB* - 49 -...
  • Page 50 - 50 -...
  • Page 51 - 51 -...
  • Page 52 Instructions for use EN FIUS1001I141 WARNING: Weight limits in Weight limits in Do not install or use this infant restraint until read rear-facing mode: forward-facing mode: understand all instructions in this 5-45 lbs (2.3 - 20.4 kg) 22-70 lbs (10 - 31.8 kg) manual.
