- Page 1 ® VEEMUX Series SM-4X4-DVI SM-8X8-DVI DVI Video Matrix Switch Installation and Operation Manual MAN114 Rev Date 10/7/2009...
- Page 2 TRADEMARK VEEMUX is a registered trademark of Network Technologies Inc in the U.S. and other countries. COPYRIGHT Copyright © 2009 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
-
Page 3: Table Of Contents
Operating the sm-4x4-dvi ..............................5 Learn Mode.................................. 5 Enter Learn Mode ..............................5 Change Connections Manually............................ 5 Operating the sm-8x8-dvi ..............................6 Accessing the Setup Menu ............................6 Change Connections via RS232 ..........................7 Setup Control Computer ............................7 RS232 Protocol................................. 9 Embedded Commands ............................. -
Page 4: Introduction
Locate computers up to 19 feet away from displays, enabling easy access to multiple servers in various locations. Also available: SM-8X8-DVI- provides non-blocking access to 8 single link digital DVI video sources from 8 eight displays Features: •... -
Page 5: Materials
NTI VEEMUX DVI VIDEO MATRIX SWITCH MATERIALS Materials supplied with this kit • NTI SM-4X4-DVI or SM-8X8-DVI DVI Video Matrix Switch • 100-240VAC at 50 or 60Hz-5VDC/3.0A (4x4) or 4.0A (8x8) AC Adapter • CD containing pdf of this manual and control software Materials Not supplied but REQUIRED: •... - Page 6 NTI VEEMUX DVI VIDEO MATRIX SWITCH FRONT VIEW OF SM-8X8-DVI VEEMUX Network Technologies Inc Scroll Enter NETWORK TECHNOLOGIES INC 1275 Danner Dr, Aurora, OH 44202 Tel:330-562-7070 www.networktechinc.com RS232 INPUT 1 INPUT 3 INPUT 5 INPUT 7 OUTPUT 1 OUTPUT 3...
-
Page 7: Connect Cables
NTI VEEMUX DVI VIDEO MATRIX SWITCH CONNECT CABLES 1. Connect a DVI male cable between each video source and an “Input” connector on the rear of the VEEMUX. 2. Connect a DVI male cable between each display device and an “Output” connector on the rear of the VEEMUX. -
Page 8: Operating The Sm-4X4-Dvi
NTI VEEMUX DVI VIDEO MATRIX SWITCH OPERATING THE SM-4X4-DVI Learn Mode The VEEMUX is able to emulate a monitor for a connected video source, whether a monitor is actually connected or not. To do this, the VEEMUX must first learn the specifications of a display device. To make the VEEMUX learn the specifications, use “Learn Mode”. -
Page 9: Operating The Sm-8X8-Dvi
NTI VEEMUX DVI VIDEO MATRIX SWITCH OPERATING THE SM-8X8-DVI Accessing the Setup Menu Simultaneously press and hold both front panel buttons for at least three (3) seconds, then release. The LCD should display: SETUP MENU V: x.x DDC <n> : yy Where: x.x is the version number,... -
Page 10: Change Connections Via Rs232
NTI VEEMUX DVI VIDEO MATRIX SWITCH CHANGE CONNECTIONS VIA RS232 Connections can be changed from a terminal located away from the VEEMUX, connected serially using RS232. To change connections using the RS232 port, a control computer must first be setup. -
Page 11: Figure 3- Smart Control Connection Display
NTI VEEMUX DVI VIDEO MATRIX SWITCH 4. Click the “OK” button. The following image (or one similar) will appear. Blue dots will appear wherever the connections have been made between outputs (top row) and inputs (left column). Figure 3- VEEMUX-DVI-Control Connection Display 5. -
Page 12: Rs232 Protocol
NTI VEEMUX DVI VIDEO MATRIX SWITCH RS232 Protocol Commands can alternatively be sent using a terminal emulator program that supports macros. The following section lists the available commands. Embedded Commands The VEEMUX can be controlled using connection commands embedded in serial programs. Applicable RS232 commands are... - Page 13 NTI VEEMUX DVI VIDEO MATRIX SWITCH Continued) TABLE OF COMMANDS FOR SM-8X8-DVI ( Command: ASCII input_4_output_3 / F 0 0 M 0 3 I 0 4 <CHK> <CR> 2F 2F 46 30 30 4D 30 33 49 30 34 45 0D input_5_output_3 / F 0 0 M 0 3 I 0 5 <CHK>...
-
Page 14: Technical Specifications
NTI VEEMUX DVI VIDEO MATRIX SWITCH TECHNICAL SPECIFICATIONS Video Video Amplifier Bandwidth 165MHz Input Video Signal 1.2 volts p-p Input DDC Signal 5 volts p-p (TTL) Single Link Range 1080p/1920 x 1200 DVI Connector DVI-I 29 pin female Control Serial Controls...
