Summary of Contents for NTI SM-8X8-C6HDR-HDBT
- Page 2 System Application Connection Diagram SAFETY Operation: 1.Connect the signal source (such as HD-DVD,PS3,STB) to HDMI input interfaces ; 2.Connect the display devices(such as HD-LCD,DH-DLP) to HDBase-T receiver’s HDMI output interfaces; 3.Connect the EIA/TIA 568B one long CAT5e/6 cable to the sender output socket; 4.Connect the EIA/TIA 568B one long CAT5e/6 cable to the receiver input socket;...
