Before connecting any external equipment, remove the mains plug from the
(*) Number of these inputs may change according to the model of your TV.
Aerial cable:.....................................................
Connect the aerial to the ANT. socket on the rear of
the TV.
SCART lead:....................................................
If you use a decoder* or a media recorder, it is
essential that the scart cable is connected to the TV.
Before running first time installation, any connected
devices need to be set to standby mode.
The DIGITAL AUDIO socket enables the connection
of a suitable surround sound system.
HDMI
(High-Definition Multimedia Interface) is for
®
using with a DVD decoder or other equipment with
digital audio and video output. It is designed for best
performance with 1080i and 1080p high-definition
video signals but will also accept and display VGA,
480i, 480p, 576i, 576p and 720p signals. PC format
signals will also be displayed.
NOTE: Although this TV is able to connect to HDMI
equipment, it is possible that some equipment may
not operate correctly.
When connecting a device via the Side AV input, you
must use the supplied connection cable to enable
connection.

Connecting External Equipment

When connecting a device via YPbPr input, you
must use the supplied connection cable to enable
connection.
A wide
variety of external equipment can be connected
to the TV; therefore, the relevant owner's manuals
for all additional equipment must be referred to for
exact instructions.
If the TV automatically switches over to monitor
external equipment, return to normal TV by pressing
the desired programme position button. To recall
external equipment, press SOURCE button repeatedly
to switch between sources.
Regardless of source's property, audio output from the
DIGITAL AUDIO socket cannot be copied.
English - 8 -
wall socket.
