Summary of Contents for Zenoah BCZ3200DL
- Page 1 BCZ3200DL BCZ3200DW BCZ3200DL / BCZ3200DW OWNER’S MANUAL BRUSHCUTTERS GB-1...
-
Page 2: Explanation Of Symbols And Safety Warnings
BCZ3200DL / BCZ3200DW EXPLANATION OF SYMBOLS AND SAFETY WARNINGS MAY INVOLVE A DAILY LEVEL OF PERSONAL EXPOSURE TO NOISE FOR THE OPERATOR EQUAL TO OR GREATER THAN MODEL 29.5 cm BCZ3200DL BCZ3200DW 29.5 cm APPROVAL NUMBER OF CE EXHAUST EMISSION REGULATION... -
Page 3: Table Of Contents
5. For safe operation ... 5 6. Set up ... 8 7. Fuel ... 9 8. Operation ... 10 9. Maintenance ... 13 10. Storage ... 15 11. Troubleshooting guide ... 16 BCZ3200DL BCZ3000DL BCZ3200DL / BCZ3200DW BCZ3200DW BCZ3000DW GB-3... -
Page 4: Specifications
BCZ3200DL / BCZ3200DW 2. Specification BCZ3200DL / BCZ3200DW Overall size (L H) ... 1860 x 395 x 325 / 1860 x 610 x 520 mm Dry weight ... 5.7 / 6.1 kg Engine Model ... Zenoah GZ30N Displacement ... 29.5 cm Fuel ... -
Page 5: Blade
2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. BCZ3200DL / BCZ3200DW b. At night, at times of heavy fog, or at any other times when your field of vision might be... - Page 6 BCZ3200DL / BCZ3200DW 5. For safe operation BEFORE STARTING THE ENGINE 1. The area within a perimeter of 15 m (50 ft) of the person using the product should be considered a hazardous area into which no one should enter. If necessary,...
-
Page 7: If Someone Comes
BCZ3200DL / BCZ3200DW HANDLING FUEL 1. The engine of the KOMATSU ZENOAH product is designed to run on a mixed fuel, which con- tains highly flammable gasoline. -
Page 8: Gear Case
2. Put the handle assembly into the bracket and put the upper cap over it. Tighten the cap securely. CONNECTING THROTTLE WIRE (BCZ3200DL/DW) 1. Remove the air cleaner cover. 2. Connect the end of the throttle wire to the joint on the top of the carburetor. -
Page 9: Fuel
2. Put some of the gasoline into a clean, approved fuel container. 3. Pour in all of the oil and agitate well. BCZ3200DL / BCZ3200DW 4. Pour in the rest of gasoline and agitate again for at least one minute. As some oils may be difficult to agitate depending on oil ingredients, sufficient agi- tation is necessary for the engine to last long. -
Page 10: Operation
BCZ3200DL / BCZ3200DW 8. Operation STARTING ENGINE WARNING The cutting head will start rotating upon the engine starts. 1. Feed fuel into the fuel tank and tighten the cap se- curely. 2. Rest the unit on a flat, firm place. Keep the cutting head off the ground and clear of surrounding objects, as it will start rotating upon starting of the engine. - Page 11 T3189-15102 BCZ3200DL / BCZ3200DW METAL BLADE USAGE 1. Check the nut to fasten the blade and be sure the nut has no fault, and no abrasion.
-
Page 12: Cutting Method
BCZ3200DL / BCZ3200DW 8. Operation CUTTING METHOD (a) Use the front left side cutting. (b) Guide the blade from your right to left with it tilted slightly to your left. (c) When mowing a wide area, start working from your left end to avoid interference of cut grass. -
Page 13: Maintenance
3. Do not use water when using a grinder. • It is recommended that filing should be done by pro- fessionals. • Especially regarding filing the saw blade, Leave it to the professionals. BCZ3200DL / BCZ3200DW Note after after replace, if necessary... - Page 14 BCZ3200DL / BCZ3200DW 9. Maintenance REFILLING TRIMMING LINE 1. For replacement line, use a diameter of 2.4mm(.095in). The spool is capable for a line upto 6m(20ft) on the 10cm(4”) head. Avoid using a larger line as it may cut down the trimming performance.
-
Page 15: Storage
Before storing the unit, empty the fuel tank and run the engine until it uses all the fuel left in the fuel line and the carburetor. Store the unit indoor taking necessary measures for rust prevention. BCZ3200DL / BCZ3200DW GB-15... -
Page 16: Troubleshooting Guide
BCZ3200DL / BCZ3200DW 11. Troubleshooting guide Case 1. Starting failure CHECK fuel tank fuel filter carburetor adjustment screw sparking (no spark) spark plug Case 2. Engine starts but does not keep running/hard re-starting CHECK fuel tank carburetor adjustment screw muffler, cylinder (exhaust port) - Page 17 Leaf Vacuums Ride on Mowers Ride on Mowers Scarifiers Scarifiers Westwood Westwood Tractors Tractors Petrol Lawn Petrol Lawn Mowers Mowers Husqvarna Petrol Husqvarna Petrol Chainsaws Chainsaws Kawasaki Kawasaki Hedgecutters Hedgecutters Echo Petrol Echo Petrol Chainsaws Chainsaws Leaf Hoovers Leaf Hoovers...
