Page 1 ProLiant ML350 Setup and Installation Guide First Edition (September 2000) Part Number 201345-001 Compaq Computer Corporation For use with 1-GHz or greater Intel Pentium III processor-based server models only...
Page 2 Microsoft, MS-DOS, Windows, and Windows NT are trademarks of Microsoft Corporation. Pentium is a trademark of Intel Corporation in the United States. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.
Page 3: Table Of Contents
About This Guide Text Conventions.......................vii Symbols in Text....................... viii Symbols on Equipment.................... viii Important Safety Information ..................ix Getting Help .......................ix Compaq Technical Support ..................x Compaq Website....................x Compaq Authorized Reseller................x Chapter 1 Server Features Standard Hardware Features..................1-2 Front Panel Components .................. 1-3 Rear Panel Connectors..................
Page 4 Compaq ProLiant ML350 Setup and Installation Guide Server Features continued Server Configuration and Management ..............1-12 ROM Based Setup Utility (RBSU) ..............1-12 Compaq SmartStart..................1-13 Compaq Insight Manager................1-13 Diagnostic Features..................1-14 Security Features....................1-14 Chapter 2 Overview of Server Installation Preinstallation Procedures..................
Page 5: Connecting
ROMPaq Utility....................... 5-7 SmartStart and Support Software CD ..............5-7 SmartStart Diskette Builder ..................5-8 Compaq Insight Manager..................5-8 Compaq Survey Utility .................... 5-9 Installing Survey....................5-9 Running Survey ....................5-10 Compaq Diagnostics Utility................... 5-10 Automatic Server Recovery (ASR) ............... 5-10...
Page 6 Compaq ProLiant ML350 Setup and Installation Guide Appendix A Regulatory Compliance Notices Regulatory Compliance Identification Numbers............. A-1 Communications Commission Notice..............A-1 Class A Equipment....................A-2 Class B Equipment....................A-2 Declaration of Conformity for Products Marked with the FCC Logo - United States Only ...................
Page 7: About This Guide
About This Guide This guide is designed to be used as step-by-step instructions for installation and as a reference for operation, troubleshooting, and future upgrades. Text Conventions This document uses the following conventions to distinguish elements of text: Keys Keys appear in boldface. A plus sign (+) between two keys indicates that they should be pressed simultaneously.
Page 8: Symbols In Text
Compaq ProLiant ML350 Setup and Installation Guide Symbols in Text These symbols may be found in the text of this guide. They have the following meanings. WARNING: Text set off in this manner indicates that failure to follow directions in the warning could result in bodily harm or loss of life.
Page 9: Important Safety Information
About This Guide ix This symbol on an RJ-45 receptacle indicates a Network Interface Connection. WARNING: To reduce the risk of electric shock, fire, or damage to the equipment, do not plug telephone or telecommunications connectors into this receptacle. This symbol indicates the presence of a hot surface or hot component. If this surface is contacted, the potential for injury exists.
Page 10: Compaq Technical Support
Compaq Technical Support In North America, call the Compaq Technical Support Phone Center at 1-800-OK-COMPAQ. This service is available 24 hours a day, 7 days a week. For continuous quality improvement, calls may be recorded or monitored. Outside North America, call the nearest Compaq Technical Support Phone Center.
Page 11: Server Features
Whether deployed in either a workgroup setting within a large corporation or as the primary server in a small-to-medium business, the ProLiant ML350 is an ideal server for applications such as file and print services, shared Internet access, and small databases. This business-critical...
Page 12: Standard Hardware Features
1-2 Compaq ProLiant ML350 Setup and Installation Guide Figure 1-1. ProLiant ML350 Standard Hardware Features The features on the following pages are standard on the ProLiant ML350, unless otherwise noted. For use with 1-GHz or greater Intel Pentium III processor-based server models only...
Page 13: Front Panel Components
Server Features 1-3 Front Panel Components Figure 1-2 and Table 1-1 show the components on the front panel of the ProLiant ML350. Figure 1-2. Identifying front panel components with bezel removed: A (non-hot-plug), B (hot-plug) Table 1-1 Front Panel Components – A (Non-Hot-Plug),...
Page 14: Rear Panel Connectors
1-4 Compaq ProLiant ML350 Setup and Installation Guide Rear Panel Connectors WARNING: This equipment is designed for connection to a grounded (earthed) outlet. The grounding type plug is an important safety feature. To reduce the risk of electric shock or damage to your equipment, do not disable this feature.
Page 15: Drive Dimensions
Server Features 1-5 Drive Dimensions The ProLiant ML350 supports a maximum of eight internal drives (four are intended for removable media drives and four are for hard drives). Figure 1-4 and Table 1-3 show the drive configuration. Figure 1-4. Identifying drive dimensions with bezel removed:...
Page 16: System Board Components
1-6 Compaq ProLiant ML350 Setup and Installation Guide System Board Components Figure 1-5 and Table 1-4 show the components and connectors on the system board of the ProLiant ML350. Figure 1-5. Identifying system board components For use with 1-GHz or greater Intel Pentium III processor-based server models only...
Page 17: System Fan
Server Features 1-7 Table 1-4 System Board Components Item Component Item Component Power supply connectors 32-bit PCI slots Processor Power Modules (PPM) Wake On LAN connector Processor sockets 64-bit PCI slots 32-bit PCI slot 1 Primary IDE controller (Server Feature Board) Secondary IDE controller Server Management Information Cable (SMIC) connector...
Page 18: Processors And System Memory
1-8 Compaq ProLiant ML350 Setup and Installation Guide Processors and System Memory Pentium III processor with integrated 256-KB Advanced Transfer Cache and Dual Processor capability Error checking and correcting (ECC) for memory error detection and correction 128-MB PC 133-MHz Registered ECC SDRAM DIMM, system...
Page 19: Network Interface Controller
Server Features 1-9 Network Interface Controller The ProLiant ML350 has an Integrated Compaq Fast Ethernet Network Interface Controller (NIC) 10/100 Autoswitching Network Controller. Ports/Connectors Serial (2) Parallel Keyboard Mouse USB (2) BIOS Compaq ROMPaq™ Utility for BIOS firmware upgrade ROM Based Setup Utility (RBSU) for system configuration...
Page 20: Server Feature Board Components
1-10 Compaq ProLiant ML350 Setup and Installation Guide Server Feature Board Components Figure 1-6 and Table 1-5 show the components on the ProLiant ML350 Server Feature Board. Figure 1-6. Identifying Server Feature Board components Table 1-5 Server Feature Board Components...
Page 21: Power Supply
Supports SVGA, VGA, and EGA graphics resolution Power Supply 300-watt power supply with power factor correction Warranty Three-Year Onsite Limited Worldwide Warranty Compaq Pre-Failure Warranty on processors, hard drives, and memory For use with 1-GHz or greater Intel Pentium III processor-based server models only...
Page 22: Server Configuration And Management
1-12 Compaq ProLiant ML350 Setup and Installation Guide Server Configuration and Management The ProLiant ML350 offers an extensive set of features and optional tools to support effective server management and configuration, including: ROM Based Setup Utility (RBSU) Compaq SmartStart™ Compaq Insight Manager...
Page 23: Compaq Smartstart
Server Features 1-13 Compaq SmartStart Compaq SmartStart, located on the SmartStart and Support Software CD, is the intelligent way to set up your Compaq server. SmartStart includes: ROMPaq Utility Driver updates Assisted operating system installations For information concerning SmartStart, refer to the Server Setup and Management pack included in the shipping box.
Page 24: Diagnostic Features
1-14 Compaq ProLiant ML350 Setup and Installation Guide Diagnostic Features The software and firmware diagnostic features available for your use include: Power-On Self-Test (POST) Diagnostics (DIAGS) ROMPaq utilities to upgrade flash BIOS Automatic Server Recovery (ASR) Security Features Security features include:...
Page 25: Overview Of Server Installation
Overview of Server Installation The following instructions are provided as an overview for first-time installation of your ProLiant ML350. If you have any problems, contact your Compaq authorized reseller. WARNING: To reduce the risk of electric shock or damage to the equipment: Do not disable the power cord grounding plug.
Page 26: Preinstallation Procedures
2-2 Compaq ProLiant ML350 Setup and Installation Guide Preinstallation Procedures Selecting a Site Make sure the installation area you select has the following features: Sturdy, level installation site that includes dedicated and properly grounded (earthed) circuits, air conditioning, and static electricity protection Clearance of 7.6 cm (3 in) at front and back of the server for proper...
Page 27: Locating Materials
Overview of Server Installation 2-3 Locating Materials Locate the following materials that were shipped with your ProLiant ML350: Keyboard Mouse Power cord Documentation label inside the server (most of the option installation and setup instructions are located on the label, which is attached to the...
Page 28: Identifying The Rear Panel Connectors
2-4 Compaq ProLiant ML350 Setup and Installation Guide Identifying the Rear Panel Connectors Install as directed in one of the following two installation sequences. Identify the power cord and peripheral devices to the connectors located on the rear panel of the server as described in Figure 2-1 and Table 2-1.
Page 29: Installation Sequence
If you ordered your server with the factory-installed operating system, everything required to install your operating system is already on the server. Refer to the steps provided in the Compaq Factory-Installed Operating System Software User Guide for more information on using your operating system.
Page 30: Server Configuration
After initialization is complete, the server will automatically go through POST. 6. Install the Compaq Management Agents on the server. Refer to Chapter 5, “Server Configuration and Utilities,” and the Compaq Management CD for information about installing the Compaq Management Agents for your operating system.
Page 31: Operating System Purchased Separately
Overview of Server Installation 2-7 Operating System Purchased Separately If you purchased your operating system separately, install it using the SmartStart and Support Software CD. Refer to the Server Setup and Management pack for instructions on using SmartStart. The first time the server is configured, the SmartStart program automatically creates a necessary partition on your hard drive.
Page 32 Management CD initialization procedures, refer to the Server Setup and Management pack shipped with your server. IMPORTANT: You must install and use Compaq Insight Manager to benefit from the Compaq Pre-Failure Warranties on processors, hard drives, and memory modules. 11. Install any application software needed.
Page 33: Hardware Options Installation
3. Power down the server by pressing the power button on the front of the server. IMPORTANT: The system power in the ProLiant ML350 does not completely power down with the front panel power button. To completely remove all power from the system, you must disconnect the power cord from the server.
Page 34: Opening Or Removing The Bezel
3-2 Compaq ProLiant ML350 Setup and Installation Guide WARNING: To reduce the risk of injury from electric shock or damage to the equipment when installing an upgrade, make sure that the server is powered down. Remove all AC power cords to completely disconnect power from the system.
Page 35: Removing The Access Panel
Hardware Options Installation 3-3 4. To remove the bezel, lift the bezel upward, and pull it away from the chassis. Figure 3-2. Removing the bezel To replace the bezel, reverse the above procedure. NOTE: When replacing the bezel, be sure the bottom hinge points are properly placed in the chassis before rotating the bezel back into its original position.
Page 36 3-4 Compaq ProLiant ML350 Setup and Installation Guide 3. Open the bezel fully to the right. 4. Loosen the two thumbscrews located on the left side of the front chassis. 5. Slide the access panel back about 1.5 cm (0.5 in).
Page 37: Removing The Removable Media Device Blanks
Hardware Options Installation 3-5 Removing the Removable Media Device Blanks NOTE: The blanks must be removed from the chassis to install a storage device in its place. The tray on the blank is used to mount hard drives into removable media device bays.
Page 38: Storage Devices
ProLiant ML350. Drive Dimensions The ProLiant ML350 supports a maximum of eight internal drive bays (four are intended for removable media drives and four are for hard disk drives). Figure 3-5 and Table 3-1 show the drive configuration.
Page 39 Identifying Guide Screws When installing drives, you must install guide screws to ensure the drives correctly align in the drive cage. Compaq has provided extra guide screws. They are located behind the side panel of the server. Some options use 5.25 M3 metric screws and some use HD 6-32 screws.
Page 40: Installation Guidelines For Scsi Hard Drives
3-8 Compaq ProLiant ML350 Setup and Installation Guide Installation Guidelines for SCSI Hard Drives Consider the following guidelines when installing SCSI hard drives: Install drives into the bays in the following order: 0, 1, 2, 3, 4, 5, 6. Assign SCSI device IDs in the following order: 0, 1, 2, 3, 4, 5, 6.
Page 41: Installing A Non-Hot-Plug Hard Drive Into A Non-Hot-Plug Drive Cage
Figure 3-7 for bay numbering. 4. Remove all terminating jumpers from third-party SCSI devices. (Compaq SCSI non-hot-plug hard drive cables are terminated.) 5. Install two guide screws on each side of the drive. Be sure the rear screws are secured in the holes farthest back on the drive and the guide screws line up with the guide slots.
Page 42 3-10 Compaq ProLiant ML350 Setup and Installation Guide 6. Slide the drive into the drive bay until the rear screw clicks into place. Fill the drive bays from right to left. Figure 3-10. Installing a 3.5-inch hard drive NOTE: The interior of the server may look different depending on the model purchased.
Page 43: Removing A Non-Hot-Plug Hard Drive From A Non-Hot-Plug Drive Cage
Hardware Options Installation 3-11 Removing a Non-Hot-Plug Hard Drive from a Non-Hot-Plug Drive Cage To remove a 3.5-inch non-hot-plug hard drive from a non-hot-plug drive cage: CAUTION: Before removing the access panel, make sure that the server is powered down, all cables are disconnected from the server, and the power cord is disconnected from the grounded (earthed) AC outlet.
Page 44 3-12 Compaq ProLiant ML350 Setup and Installation Guide 3. Press inward on the release tab and gently pull the drive out of the drive bay. Figure 3-13. Removing a non-hot-plug hard drive from a non-hot-plug drive 4. Remove the two guide screws from each side of the drive.
Page 45: Installing And Removing A Hot-Plug Hard Drive
Hardware Options Installation 3-13 Installing and Removing a Hot-Plug Hard Drive To install a hot-plug hard drive, first review the installation documentation that came with the drive. 1. Follow the steps in “Opening or Removing the Bezel” to access the hot-plug hard drive bays.
Page 46 3-14 Compaq ProLiant ML350 Setup and Installation Guide 4. Insert the hot-plug hard drive into the lowest available hot-plug drive and close the ejector lever Figure 3-16. Inserting the hot-plug hard drive and closing the ejector lever To remove a hot-plug-hard drive reverse these procedures.
Page 47: Installing A 3.5-Inch Non-Hot-Plug Hard Drive Into A 5.25-Inch Hard Drive Adapter
Hardware Options Installation 3-15 Installing a 3.5-Inch Non-Hot-Plug Hard Drive Into a 5.25-Inch Hard Drive Adapter IMPORTANT: If you are installing a 3.5-inch hard drive into a removable media device bay for the first time, you must use the hard drive adapter found in the removable media device blanks.
Page 48: Installing A Device Into A Removable Media Device Bay
3-16 Compaq ProLiant ML350 Setup and Installation Guide Installing a Device Into a Removable Media Device The ProLiant ML350 includes four removable media device bays. The lower two bays are occupied with a 3.5-inch diskette drive and an IDE CD-ROM drive;...
Page 49 Hardware Options Installation 3-17 Figure 3-18. Installing a device mounted inside a 5.25-inch drive adapter NOTE: The interior of the server may look different depending on the model purchased. 6. Connect the data cable and power cable to the back of the drive. Figure 3-19.
Page 50 Figure 3-20. Installing a tape drive NOTE: The interior of the server may look different depending on the model purchased. NOTE: Compaq recommends installing the tape drive on a separate SCSI cable to avoid a decrease in performance of other SCSI devices.
Page 51: Removing A Device From The Removable Media Bay
Hardware Options Installation 3-19 5. Connect the data cable and power cable to the back of the drive. Figure 3-21. Connecting the tape drive cables Removing a Device from the Removable Media Bay To remove a tape drive or other device: CAUTION: Before removing the access panel, make sure that the server is powered down, all cables are disconnected from the server, and the power cord is disconnected from the grounded (earthed) AC outlet.
Page 52 3-20 Compaq ProLiant ML350 Setup and Installation Guide 2. Disconnect the power cable and data cable from the back of the tape drive. Figure 3-22. Disconnecting the tape drive cables 3. While pushing the drivelock up, pull the drive out of the drive bay.
Page 53: Expansion Slots
Hardware Options Installation 3-21 Expansion Slots Figure 3-24 and Table 3-2 identify the location of expansion slots. Figure 3-24. Locating expansion slots Table 3-2 Expansion Slots Item Slot Type Slot Number 32-bit PCI (Server Feature Board) 64-bit PCI 64-bit PCI 64-bit PCI 64-bit PCI 32-bit PCI...
Page 54: Installing And Removing An Expansion Board
3-22 Compaq ProLiant ML350 Setup and Installation Guide Installing and Removing an Expansion Board To install an expansion board: CAUTION: Before removing the access panel, make sure that the server is powered down, all cables are disconnected from the back of the server, and the power cord is disconnected from the grounded (earthed) AC outlet.
Page 55 Hardware Options Installation 3-23 3. Press on the top of the expansion slot latch and open the latch toward the rear of the chassis. 4. Remove the expansion slot cover Figure 3-26. Removing the expansion slot cover For use with 1-GHz or greater Intel Pentium III processor-based server models only...
Page 56 3-24 Compaq ProLiant ML350 Setup and Installation Guide IMPORTANT: Be sure to insert expansion boards into the appropriate type expansion slot. The 32-bit expansion boards must be inserted into 32-bit slots, and the 64-bit expansion boards must be inserted into 64-bit expansion slots.
Page 57 Hardware Options Installation 3-25 8. If needed, reinstall the expansion board retainer by placing it into the appropriate slot, then tighten the thumbscrews Figure 3-28. Reinstalling the expansion board retainer 9. Reinstall the access panel. To remove an expansion board, reverse the above procedure. For use with 1-GHz or greater Intel Pentium III processor-based server models only...
Page 58: Memory Modules
3-26 Compaq ProLiant ML350 Setup and Installation Guide Memory Modules Technical Information and Important Guidelines for DIMM Installation When installing DIMMs, you must follow these guidelines: Use only 128-, 256-, 512-MB, or 1-GB PC 133-MHz Registered ECC SDRAM DIMMs. DIMMs must be industry-standard 168-pin PC 133-MHz or faster registered SDRAM DIMMs.
Page 59: Installing A Memory Module
Hardware Options Installation 3-27 Installing a Memory Module The ProLiant ML350 supports PC 133-MHz Registered ECC SDRAM DIMMs. Additional DIMMs (128, 256, 512 MB, or 1 GB) are available to upgrade the memory. The server has four DIMM sockets located on the system board.
Page 60 3-28 Compaq ProLiant ML350 Setup and Installation Guide To install a DIMM: 1. Follow the steps in “Removing the Access Panel” at the beginning of this chapter. 2. Insert the DIMM into the socket . Return latches to the upright position.
Page 61: Removing A Memory Module
Hardware Options Installation 3-29 Removing a Memory Module To remove a DIMM: CAUTION: Before removing the access panel, make sure that the server is powered down, all cables are disconnected from the back of the server, and the power cord is disconnected from the grounded (earthed) AC outlet. 1.
Page 62: Installing A Second Processor And Processor Power Module (Ppm)
3-30 Compaq ProLiant ML350 Setup and Installation Guide Installing a Second Processor and Processor Power Module (PPM) To install a second processor and PPM, refer to one of the following installation sources: For text and an illustrated procedure, refer to the installation documentation that came with the option kit.
Page 63: Processor Slots And Processor
Hardware Options Installation 3-31 2. Locate the processor slots and Processor Power Module (PPM) sockets as shown in Figure 3-32 and Table 3-3. Figure 3-32. Locating the processor slots and Processor Power Module (PPM) sockets Table 3-3 Processor Slots and Processor Power Module (PPM) Sockets Item Description...
Page 64 3-32 Compaq ProLiant ML350 Setup and Installation Guide 3. Place the processor into the processor socket. IMPORTANT: The small triangular directional marker should be in the upper left corner of the chip. 4. Lower the lever to lock the processor unit into place.
Page 65: Installing A Second Processor Power Module (Ppm)
Hardware Options Installation 3-33 Installing a Second Processor Power Module (PPM) Each Intel Pentium III processor supplied by Compaq comes with a Processor Power Module (PPM) (DC-to-DC converter). Each PPM must be installed into the slot adjacent to its processor to provide power to that processor. If the processor is installed into processor slot 1, install the PPM into PPM socket 1;...
Page 66: Removing A Second Processor And Processor Power Module (Ppm)
3-34 Compaq ProLiant ML350 Setup and Installation Guide Removing a Second Processor and Processor Power Module (PPM) For an illustrated overview of this procedure, refer to the Quick Start Poster included in the shipping box or to the System Configuration Label located on the inside of the access panel.
Page 67: Locations
Hardware Options Installation 3-35 Table 3-4 Processor and Processor Power Module (PPM) Locations Item Description Processor slot 1 PPM socket 1 Processor slot 2 PPM socket 2 3. Press one side of the heatsink retainer clip to disengage the heatsink from the processor socket.
Page 68: Removing A Second Processor Power Module (Ppm)
Figure 3-37. Removing the Processor Power Module (PPM) Replacing the Battery The ProLiant ML350 has nonvolatile memory that requires a battery to retain system information. There is a battery on the system board and a battery on the Server Feature Board. These batteries are required to maintain certain system data.
Page 69 Hardware Options Installation 3-37 To replace the lithium battery: CAUTION: Before removing the access panel, make sure that the server is powered down, all cables are disconnected from the back of the server, and the power cord is disconnected from the grounded (earthed) AC outlet. CAUTION: Static electricity can damage electronic components of the server.
Page 70: Replacing The Battery On The Server Feature Board
3-38 Compaq ProLiant ML350 Setup and Installation Guide 3. Slide the battery out of the holder. Lift the battery away from the holder. Figure 3-39. Removing the battery from the system board 4. Slide the replacement battery into the holder in the proper position.
Page 71 Hardware Options Installation 3-39 To install the new battery: NOTE: It may be necessary to remove the Server Feature Board from the unit to replace the battery. Refer to “Expansion Slots” earlier in this chapter for instructions on removing and installing expansion boards (including the Server Feature Board). 1.
Page 72: Cabling Guidelines
Storage Device Installation Guidelines This chapter provides an overview of the internal cabling of the ProLiant ML350 chassis. It also includes information on how to cable SCSI, IDE, and removable media devices in the system, as well as information about all critical system cabling.
Page 73: Identifying The Internal Scsi Components
4-2 Compaq ProLiant ML350 Setup and Installation Guide Identifying the Internal SCSI Components Non-Hot-Plug Hard Drive SCSI Cable The SCSI cable shown in Figure 4-1 is included with the non-hot-plug hard drive server. The SCSI cable shown in this illustration supports up to four SCSI devices and includes a terminator on the end.
Page 74 Cabling Guidelines 4-3 Hot-Plug Hard Drive SCSI Cable The SCSI cable shown in Figure 4-2 is included with the hot-plug hard drive server. The SCSI cable shown in this illustration connects the hot-plug drive cage to the SCSI controller. The hot-plug hard drive cage has built-in termination.
Page 75: Internal Scsi Component
4-4 Compaq ProLiant ML350 Setup and Installation Guide Internal SCSI Component Location Before cabling the server, note the removable media and hard drive cage locations as shown in Figure 4-3 and Table 4-1. For additional information about installing optional SCSI devices, refer to the documentation included with the SCSI devices.
Page 76: Identifying And Connecting A Fast Scsi-2 Device (Narrow)
Cabling Guidelines 4-5 Identifying and Connecting a Fast SCSI-2 Device (Narrow) Some SCSI devices require a special adapter to connect with the SCSI cable included with your server. Figure 4-4. 68-to-50 pin (wide-to-narrow) SCSI adapter If you are installing a device that uses a Fast SCSI-2 interface, you must use a 68-to-50 pin SCSI adapter (spare part number 199618-001) shown in Figure 4-4.
Page 77: Connecting An Integrated Wide-Ultra3 Scsi Controller To An Internal Non-Hot-Plug Hard Drive
4-6 Compaq ProLiant ML350 Setup and Installation Guide Connecting an Integrated Wide-Ultra3 SCSI Controller to an Internal Non-Hot-Plug Hard Drive The following steps detail the procedure for cabling an integrated Wide-Ultra3 SCSI controller (channel A) to an internal non-hot-plug hard drive: 1.
Page 78: Connecting An Integrated Wide-Ultra3 Scsi Controller To A Removable Media Or Other Device
Cabling Guidelines 4-7 Connecting an Integrated Wide-Ultra3 SCSI Controller to a Removable Media or Other Device The following steps detail the procedure for cabling an integrated Wide-Ultra3 SCSI controller (channel B) to a removable media or other device: 1. Follow the steps in the sections following “Installing a Device in a Removable Media Device Bay”...
Page 79: Connecting Internal Hard Drives To A Scsi Controller Option Or Smart Array Controller
4-8 Compaq ProLiant ML350 Setup and Installation Guide Connecting Internal Hard Drives to a SCSI Controller Option or Smart Array Controller Many configurations are possible when adding SCSI controllers. This section outlines the procedure for connecting internal hard drives to a SCSI controller option or a Smart Array Controller and assumes that the controller option or Smart Array Controller is already installed.
Page 80 Cabling Guidelines 4-9 3. Remove the SCSI cable from the SCSI channel A connector on the system board. 4. Reconnect the SCSI cable to either the SCSI Controller option or Smart Array Controller. Figure 4-8. Connecting a SCSI cable to a SCSI controller option or Smart Array Controller NOTE: Both SCSI channels on the Server Feature Board are self-terminating.
Page 81: Installing An Internal To External Scsi Connector
4-10 Compaq ProLiant ML350 Setup and Installation Guide Installing an Internal to External SCSI Connector If you are not using one or both SCSI channels (A or B) internally, you may install an internal to external SCSI connector in the SCSI knockout locations on the rear of the chassis.
Page 82: Connecting Ide Devices To The Integrated Ide Controller
Drive 0. All IDE devices in the system should have their configuration jumpers set to “Cable Select” or “CS.” IMPORTANT: If your network operating system is Novell NetWare, Compaq recommends that you connect your CD-ROM to the primary IDE channel and to the Drive 0 connector on the IDE cable.
Page 83: Connecting The Server Management Information Cable (Smic)
4-12 Compaq ProLiant ML350 Setup and Installation Guide Connecting the Server Management Information Cable (SMIC) The Server Management Information Cable (SMIC) provides system critical management information to the operating system. Proper SMIC cabling helps to avoid potential system failure and BIOS error messages. Figure 4-11 illustrates the proper SMIC connection between the system board and the Server Feature Board.
Page 84: Connecting The System Fan
Cabling Guidelines 4-13 Connecting the System Fan The system fan is an integral part of the ProLiant ML350 system design. Proper cabling of the fan helps to avoid potential system failure and operating system error messages. Connect the system fan to the system board as illustrated in Figure 4-12.
Page 85: Server Configuration And Utilities
Chapter Server Configuration and Utilities This chapter provides information about the utilities and tools provided with the ProLiant ML350. The following tools and utilities are described: ROM Based Setup Utility (RBSU) ROMPaq Utility SmartStart and Support Software CD SmartStart Diskette Builder...
Page 86: Rom Based Setup Utility (Rbsu)
5-2 Compaq ProLiant ML350 Setup and Installation Guide ROM Based Setup Utility (RBSU) RBSU performs a wide range of configuration activities including the following: Configuring system devices and installed options Viewing system information Selecting the operating system Selecting the primary boot controller Managing storage options In addition, RBSU includes other features, which are outlined in “Using the...
Page 87: Using The Rom Based Setup Utility (Rbsu)
Server Configuration and Utilities 5-3 Using the ROM Based Setup Utility (RBSU) NOTE: Most of the features in RBSU are not required in the setup of your server. The options in this utility are designed to assist with specific server configuration issues. RBSU is separated into a series of menu selections designed to configure specific areas of the system.
Page 88 5-4 Compaq ProLiant ML350 Setup and Installation Guide System Options The System Options menu is used for overall system configuration settings. The following is a list of selections found in this menu with an explanation of each option: OS Selection allows the selection of the operating system. This option automatically selects appropriate advanced settings for the operating system selected and should be set before the operating system installation.
Page 89 Server Configuration and Utilities 5-5 System Passwords The System Passwords menu is used to set up passwords to limit access to the system and its setup options. The following is a list of selections found in this menu with an explanation of each option: Setup Password allows a setup password to be set.
Page 90 5-6 Compaq ProLiant ML350 Setup and Installation Guide Secondary IDE Controller allows the user to enable or disable the secondary IDE controller. Processor Serial Number allows the user to enable or disable the ability of applications to read the processor serial number.
Page 91: Rompaq Utility
Server Configuration and Utilities 5-7 ROMPaq Utility Using Flash ROM in Compaq servers allows the firmware (BIOS) to be upgraded with system or option ROMPaq utilities. To upgrade the BIOS, insert a ROMPaq diskette into drive A and power up the system.
Page 92: Smartstart Diskette Builder
Compaq Insight Manager is available on the Compaq Management CD in [CD-ROM DRIVE]:\OVERVIEW.HLP. IMPORTANT: You must install and use Compaq Insight Manager to benefit from the Compaq pre-failure warranties on processors, hard drives, and memory modules. For use with 1-GHz or greater Intel Pentium III processor-based server models only...
Page 93: Compaq Survey Utility
To install the Compaq Survey Utility through the SmartStart Setup process, refer to the SmartStart Installation poster. This method installs an operating system and Compaq products on a server. Do not use this method to add the Compaq Survey Utility to an existing system.
Page 94: Running Survey
ASR is a feature in ProLiant servers that causes the system to restart in the event of a catastrophic OS error like a blue-screen, ABEND (abnormal end), or panic. A system fail-safe timer, the ASR timer, is started when the Compaq System Management driver, also known as the health driver, is loaded. The timer is periodically reset during normal OS operation, but in the event of OS failure, the timer expires and restarts the server.
Page 95: Regulatory Compliance Notices
For the purpose of regulatory compliance certifications and identification, your server is assigned a Compaq series number. The Compaq series number for the ProLiant ML350 is Series ES1007. The series number can be found on the product label, along with the required approval markings and information.
Page 96: Class A Equipment
A-2 Compaq ProLiant ML350 Setup and Installation Guide The rating label on the device shows which class (A or B) the equipment falls into. Class B devices have an FCC logo or FCC ID on the label. Class A devices do not have an FCC logo or FCC ID on the label. Once the class of the device is determined, refer to the following corresponding statement.
Page 97: Declaration Of Conformity For Products Marked With The Fcc Logo - United States Only
Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user's authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC Rules and Regulations.
Page 98: Canadian Notice (Avis Canadien
A-4 Compaq ProLiant ML350 Setup and Installation Guide Canadian Notice (Avis Canadien) Class A Equipment This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Page 99: Japanese Notice
For more information about battery replacement or proper disposal, contact your Compaq authorized reseller or authorized service provider. For use with 1-GHz or greater Intel Pentium III processor-based server models only...
Page 100: Laser Compliance
Laser Compliance The CD-ROM drive contains a laser diode of gallium aluminum arsenide (GaAlAs) emitting in the wavelength range of 780 +/- 35 nm. All Compaq systems equipped with a laser device comply with safety standards, including International Electrotechnical Commission (IEC) 825. With specific regard to the laser, the equipment complies with laser product performance standards set by government agencies as a Class 1 laser product.
Page 101: Power Cords
18AWG, and the length of the cord must be between 1.8 m (6 ft) and 3.6 m (12 ft). If you have questions about the type of power cord to use, contact your Compaq authorized service provider. A power cord should be routed so that it is not likely to be walked on or pinched by items placed upon it or against it.
Page 102: Electrostatic Discharge (Esd)
Appendix Electrostatic Discharge (ESD) To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. An electrostatic discharge (ESD) from a finger or other conductor may damage system boards or other static-sensitive devices.
Page 103: Grounding Methods
B-2 Compaq ProLiant ML350 Setup and Installation Guide Grounding Methods There are several methods for grounding. Use one or more of the following methods when handling or installing electrostatic-sensitive parts: Use a wrist strap connected by a ground cord to a grounded (earthed) workstation or computer chassis.
Page 104: Switches And Jumpers
RBSU. Setting System Board Switches The ProLiant ML350 system board has a four-position switch (SW1) that is used to set configuration settings on your server. For information on settings, refer to the access panel labels, to the Compaq ProLiant ML350 Quick Start Poster, or to Table C-1 and Table C-2.
Page 105: System Board Configuration Switch Settings (Sw1
C-2 Compaq ProLiant ML350 Setup and Installation Guide System Board Configuration Switch Settings (SW1) The following table defines the function for each system board configuration switch setting (SW1): Table C-1 System Board Configuration Switch Settings (SW1) Switch Function Default Position...
Page 106: Server Feature Board Configuration Switch Settings (Sw3
Switches and Jumpers C-3 Server Feature Board Configuration Switch Settings (SW3) The following table defines the function for each Server Feature Board configuration switch setting (SW3): Table C-2 Server Feature Board Configuration Switch Settings (SW3) Switch Function Default Position On = Disable video Reserved Reserved Reserved...
Page 107: Scsi Device Jumper Settings
C-4 Compaq ProLiant ML350 Setup and Installation Guide SCSI Device Jumper Settings No two SCSI devices connected to the same SCSI controller can have the same SCSI ID. If another SCSI device is connected to the same controller, check its SCSI ID before beginning the installation procedure for the additional device.
Page 108 Index access panel cables, disconnecting tape drive, removing 3-3 illustrated 3-20 removing, illustrated 3-4 cabling replacing 3-4 connecting an integrated additional items for Wide-Ultra3 SCSI installation 2-3 controller to internal hard ASR, disabling 5-10 drives 4-6 Automatic Server Recovery See drives, illustrated 3-10 external SCSI controller 4-10 FCC Rules and...
Page 109 2 Compaq ProLiant ML350 Setup and Installation Guide cautions Compaq recommendations before removing bezel 3-2, NetWare 4-11 Compaq Server Profile Diskette, cables, disconnecting 3-2 registration 2-8 Compaq Survey Utility data loss 3-3 electronic component changing data gathering 5-10 damage 3-37, 3-38...
Page 110 Index 3 DAT tape drive, bays supported ejector lever in 1-5 closing, illustrated 3-14 data back up 3-1 opening, illustrated 3-13 device installation mounted inside electric shock symbol viii 5.25-inch drive adapter, electrostatic discharge See ESD illustrated 3-17 diagnostic tools, configuring and damage caused by B-1 managing server with 1-14 parts...
Page 111 4 Compaq ProLiant ML350 Setup and Installation Guide hard drives installation 3-9, 3-13 installation, illustrated 3-10 cable requirements A-3 installing 3-15 Class A devices A-1 number supported 1-5 Class A notice A-2 removal 3-11 Class B devices A-1 Smart Array controller...
Page 112 B 4-11 processor and PPM cabling the drives 3-10 closing ejector lever 3-14 location 3-31, 3-34 ProLiant ML350 1-2 rear panel connectors 1-4, 2-4 reinstalling expansion board retainer 3-25 releasing the tape drive 3-20 For use with 1-GHz or greater Intel Pentium III processor-based server models only...
Page 113 6 Compaq ProLiant ML350 Setup and Installation Guide removing internal to external SCSI access panel 3-4 connector 4-10 battery 3-38 memory modules 3-28 DIMMs 3-29 operating system 2-7 PPM 3-33 drive cage door 3-9 drives from drive bay 3-12 second PPM 3-30...
Page 114 Index 7 powering down server 3-1 powering up, illustrated 2-5 materials shipped with server 2-3 memory modules installation 3-33 removing 3-29 location, illustrated 3-34 removing, illustrated 3-29 removal 3-36 mouse, FCC compliance A-7 removal, illustrated 3-36 socket location, illustrated 3-31 preconfigured operating system, navigation, RBSU 5-2 installation instructions 2-5...
Page 115 8 Compaq ProLiant ML350 Setup and Installation Guide registration, online 2-8 Regulatory Compliance safety information, document ix Identification Numbers A-1 safety standards removable media device blanks, IEC 825 A-6 removing 3-5 laser compliance A-6 removable media drives, number screwdriver symbol viii...
Page 116 Index 9 server preinstalling hardware BIOS 1-9 options 3-1 cabling guidelines 4-1 processors and system Compaq series number A-1 memory 1-8 rear panel connectors 1-4 complete power down 3-1 configuration 5-1 reconfiguration C-1 configuration and management registration 2-8 tools 1-12...
Page 117 10 Compaq ProLiant ML350 Setup and Installation Guide SMIC Processor Slots and Processor connecting 4-12 Power Module (PPM) connection, illustrated 4-12 Sockets 3-31 standard hardware, features 1-2 Rear Panel Connectors 1-4, storage devices, removing and replacing procedures 3-6 Server Feature Board...
Page 118 1-4, 2-1 wattage, power supply 1-11 hazardous radiation A-6 wrist strap, using B-2 hot surface 3-3, 3-30, 3-34 www.compaq.com x hot surfaces ix multiple sources of power ix For use with 1-GHz or greater Intel Pentium III processor-based server models only...

Compaq ProLiant ML350 Setup And Installation Manual

Table of Contents

Chapter 1 Server Features

Chapter 2 Overview of Server Installation

Chapter 3 Hardware Options Installation

Chapter 4 Cabling Guidelines

Chapter 5 Server Configuration and Utilities

Appendix A Regulatory Compliance Notices

Appendix B Electrostatic Discharge (ESD)

Appendix C Switches and Jumpers

Technical Support

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Compaq ProLiant ML350

Summary of Contents for Compaq ProLiant ML350

Table of Contents
