- Page 1 Quick Installation Guide DVG-5402SP VoIP Router Package Contents DVG-5402SP CD-ROM Phone Cord Ether Power VoIP Router which (CAT5 Adapter includes UTP) the User Cable Manual Using a power adapter with a different voltage rating will damage this product and void the warranty.
-
Page 2: Hardware Overview
LED will turn off. The LED will light solid red if the self-test or boot-up fails. Register The Register LED will turn on when DVG-5402SP is connected to a VoIP service provider. The LED will turn off if not connected to a service provider. -
Page 3: Rear Panel
Hardware Overview (continued) Rear Panel Line: Connect to your original telephone line on the wall jack with RJ-11 cable. Phone Port (1-2): Connect to your phones using standard phone cabling (RJ-11). LAN: Connect to your Ethernet enabled computers using Ethernet cabling. -
Page 4: Installing The Hardware
Installing the Hardware A. Insert one end of the Ethernet cable into the Ethernet (LAN) port on the back panel of the DVG-5402SP and the other end of the cable to an Ethernet Adapter or available Ethernet port on your computer. - Page 5 E. Connect the power adapter to the power input at the back panel of the DVG-5402SP and then plug the other end of the power adapter to a wall outlet or power strip. On the front of the device, the Power LED will turn On to indicate proper operation.
- Page 6 Installing the Hardware (continued) After the installations are completed, your network should look similar to the diagram below. Hardware configuration is complete! If your VoIP service is already activated, you can make phone calls now.
- Page 7 Configuration To access the web-based configuration utility, open a web browser such as Internet Explorer and enter the IP address of the DVG-5402SP. Open your Web browser and type http://192.168.8.254 into the URL address box. Press the Enter or Return Key.
- Page 8 Configuration (continued) Click Next. The username of ADMIN and USER have been defined and locked by default. It is highly recommended to create a login password to keep your router secure. Click Next. Enter a NTP server or use the default server.
- Page 9 Configuration (continued) Select your Internet connection type: DHCP – Most Cable ISPs or if you are connecting the DVG-5402SP behind a router. Static IP – Select if your ISP supplied you with your IP settings. PPPoE – Most DSL ISPs.
- Page 10 Configuration (continued) Setup is finished. Check the summary of your settings. To make new settings effective, you must click on the Restart button to reboot the DVG-5402SP. Click Restart.
