How do I view instrument data?

Your SmartController can display up to 8 pages of boat information.
Each page can be set to show 1,2 or 4 data items, or, to view
information graphically. When the autopilot is enabled, an extra "P"
page is added to the favourites, showing autopilot specific information.
view previous page
view next page
Example Screens
2 Data items
1
DEPTH
4.7FT
SPEED
11KTS
If you only ever use a few favourite pages, use
Quick Tip
the PAGE ON/OFF feature to turn off the rest.
User Guide
1 2
3
From the main instrument display:
1. Press the up/down key to
move to the previous or next
page.
2. The number of the page
currently being displayed will
be shown in the upper left
hand corner.
3. Press the MENU softkey to
access SmartController settings
Graphcal data
4
XTE
BTW
002º
MENU
0.35NM
DTW
2.5NM
MENU
9
