Step 3: Unlocking the Scanner

1. Remove the yellow "Step 3" sticker from your scanner.
2. When the scanner is powered off, tilt the front right corner of the scanner to
3. Push the locking switch to the position as indicated in the graphic, with the
Note: To lock the scanner (for shipping and other purposes), follow the steps
below:
1. Turn off the scanner.
2. Tilt the front right corner of the scanner to see the locking switch at the
3. Push the locking switch to the position as indicated in the graphic, with the

Step 4: Connecting the Scanner

To the ADF

Make the Automatic Document Feeder (ADF)
is properly installed, with its connector
securely connected to the scanner's 15-pin
accessory port.

To the Power Adapter

1. Remove the yellow "Step 4" sticker
2. Connect the power adapter to the back of the scanner.
3. Plug one end of the power cord into the power adapter, and plug the other
14 ArtixScan 1200DF User's Manual
see the locking switch at the bottom.
icon on the lock showing as "unlocked".
bottom.
icon on the lock showing as "locked".
from your scanner.
end of the power cord into a wall outlet or other power source.
Unlocked Locked
