Item Label
Indicators Power
LAN1-4
Internet Blinking green: PPP/DHCP negotiation
DSL
Wi-Fi
3G
VoIP
Interface 1
Power
LAN1-4
VoIP
DSL
Interface 2 WiFi
WPS
Reset
2.1.2

Package Contents

Item
Power Adapter 1
Phone Line
RJ-45 Cable
Modem
User Manual
Splitter
2.1.3 Connection Topological Diagram
Description
On: Modem power up
Off: Modem Power off
On: Ethernet is connected
Blinking green: Ethernet Traffic flows
Off: Ethernet is disconnected
Solid green: PPP/DHCP up
Quick blinking green: Tx/Rx traffic on line
On: Modem synchronized to the DSLAM
Quick blinking green: Modem training, but not synchronized
Slow blinking green: Modem Idle
On: Wi-Fi connection is available
Blinking green: Negotiation or traffic on line
Off: Wi-Fi connection is not available
Blinking green: Negotiation or traffic on line
Solid green: Up
Quick blinking green: Tx/Rx traffic on line
Solid red: Authentication failed
Off: Traffic through DSL interface
On: The analog phone connected to VoIP off-hook
Off: The analog phone connected to VoIP on-hook
Power switch
For 12V DC power adapter
LAN interface for connecting to computers
Connecting to analog telephones
Connecting to ADSL enabled telephone line
WiFi switch
WPS switch
Restore to factory default settings
Quantity
2
1
1
1
1
4
