Two Alpha Channels as a stereo pair

Two Alpha Channels as a stereo pair Two Alpha Channels as a stereo pair Two Alpha Channels as a stereo pair
Any two or more Alpha Channels have the ability to be linked together. The two phono connections
above the S/PDIF sockets labelled 'LINK' provide access to the side-chain of the Lite Limit circuit.
By simply connecting a phono cable between any 2 alpha channels using the link sockets, the Lite Limit
on each unit will work in sympathy with each other because their side-chains are linked.
As they are a parallel of each other it doesn't matter which of these are used and multiple units can have
their side-chained linked in this manner.
This is essential for correct stereo operation of the two limiters, because each needs to be aware of what
the other is doing to retain a stable stereo image.
