Instruction Manual
UNITY4000ª
AUDIO INTEGRATED
RECEIVER DECODER
WEGENER
COMMUNICATIONS
TECHNOLOGY PARK / JOHNS CREEK
11350 TECHNOLOGY CIRCLE
DULUTH, GEORGIA 30097-1502
(770) 814-4000 FAX (770) 623-0698
R
Advertisement
Table of Contents
Related Manuals for Wegener UNITY4000
Summary of Contents for Wegener UNITY4000
- Page 1 AUDIO INTEGRATED RECEIVER DECODER Data, drawings, and other material contained herein are proprietary to Wegener Communications, Inc., and may not be reproduced or duplicated in any form without the prior permission of Wegener Communications, Inc. When ordering parts from Wegener Communications, Inc., be sure to include...
- Page 2 Page 2 This Page Intentionally Left Blank UTY4000-011 Page 2 of 75...
-
Page 3: Uty4000
The following warranty applies to all Wegener Communications products. All Wegener Communications products are warranted against defective materials and workmanship for a period of one year after shipment to customer. Wegener Communications' obligation under this warranty is limited to repairing or, at Wegener Communications' option, replacing parts, subassemblies, or entire assemblies. - Page 4 Page 4 This Page Intentionally Left Blank UTY4000-011 Page 4 of 75...
-
Page 5: Table Of Contents
Page 5 TABLE OF CONTENTS SECTION 1 GENERAL INFORMATION..............10 GENERAL........................10 INTRODUCTION ......................10 UNPACKING AND INSPECTION................10 PHYSICAL ENVIRONMENT ..................10 SECURITY LABELS ......................11 PHYSICAL SPECIFICATIONS ...................11 TECHNICAL SUPPORT ....................11 MANUALS........................12 SECTION 2 SYSTEM CONFIGURATION ...............14 UNIT OVERVIEW......................14 BLOCK DIAGRAM DISCUSSION ................14 SPECIFICATIONS ......................16 2.3.1 ......................16 UNER... - Page 6 Page 6 2.4.2.2 Standard DVB Synchronous Interface..............22 EXTERNAL INPUTS AND OUTPUTS ................23 2.5.1 ..................23 ALANCED UDIO UTPUTS 2.5.2 FCC-M ..........23 ANDATED UPPRESSION OF ADIATED MISSIONS 2.5.3 ...........24 LARM ELAY AND DDRESSABLE ONTACT LOSURES EXPANSION CARD CONFIGURATION ..............27 2.6.1 .................27 ALANCED UDIO XPANSION 2.6.1.1 Audio Card Jumper Configuration................27...
- Page 7 Page 7 3.8.4 ....................40 REQUENCY AGGING DISPLAY / PUSH BUTTONS..................41 3.9.1 ........................41 VERVIEW 3.9.1.1 LCD Menu Timeout....................41 3.9.2 ...................42 UTTON UNCTIONS 3.9.3 ..............E MAIL RROR OOKMARK NOT DEFINED APPENDIX A TERMINAL/MODEM COMMANDS...........50 STATUS COMMANDS ....................50 A.1.1 ]......................50 COMMAND A.1.2 ] ......................51 TYPE PAGE...
- Page 8 VERSION ........................70 NAVIGATION HELP......................71 APPENDIX C GLOSSARY OF TERMS ..............74 LIST OF ILLUSTRATIONS Figure 1. UNITY4000 Block Diagram ..................15 Figure 2. Ferrite Bead Installation....................25 Figure 3. UNITY4000 Front Panel ....................26 Figure 4. UNITY4000 Rear Panel....................26 LIST OF TABLES Table 1. Physical Specifications....................11 Table 2.
- Page 9 Page 9 Table 19. Settings Types ......................39 Table 20. IRD Signal Quality......................40 Table 21. Display Modes ......................41 Table 22. Push Button Functions ....................42 Table 23. LC Display Menus .......................44 Page 9 of 77 UTY4000-003...
-
Page 10: General Information
PHYSICAL ENVIRONMENT Mount the UNITY4000 IRD in a standard EIA 19-inch equipment rack located in a clean, dry environment, and do not place unsupported equipment on the unit. Make sure that total rack power consumption does not exceed the limits of the AC branch circuit, and that a reliable earth safety ground is maintained. -
Page 11: Security Labels
Please note the maximum per-unit power dissipation of 45 watts. SECURITY LABELS The UNITY4000 uses security labels over some of the screws. There are no user serviceable components within the unit, and tampering with the security labels or opening the units will void your warranty. -
Page 12: Manuals
Thank you. Return the product, freight prepaid, to the address below: Service Department RMA# ________ Wegener Communications, Inc. 11350 Technology Circle Duluth, GA 30097 NOTE: All returned material must be shipped freight prepaid. C.O.D. - Page 13 Page 13 This Page Intentionally Left Blank Page 13 of 77 UTY4000-003...
-
Page 14: Section 2 2.1 Unit Overview
Page 14 SECTION 2 SYSTEM CONFIGURATION UNIT OVERVIEW The UNITY 4000 IRD features several separate hardware components, including the DC switching power supply, the main motherboard, an L-band DVB receiver, front-panel keypad controller card, a front-panel LCD assembly, and the L-band RF switch. The DC switching power supply provides all internal regulated DC power. -
Page 15: Figure 1. Unity4000 Block Diagram
Page 15 Figure 1. UNITY4000 Block Diagram Page 15 of 77 UTY4000-003... -
Page 16: Specifications
Page 16 The control system on the main board is run by the main host processor. This processor interfaces with the COMPELª network as well as local users and then controls and monitors the unitÕs operations. To do its job, this processor accesses the control data streams recovered from the main transport demultiplexer. -
Page 17: Qpsk Demodulator
Page 17 2.3.2 QPSK Demodulator The QPSK demodulatorÕs input data rate is variable over the range shown in Table 3 (Page 17), with a minimum transport-rate step size of 1 kbps. In Table 3, Òthreshold Eb/NoÓ is that value of Eb/No at which the average number of uncorrected FEC frames exceeds one per minute. Table 3. -
Page 18: Video Specifications
Page 18 544H x 480V (3/4 Resolution) 544H x 576V 480H x 480V 480H x 576V 352H x 480V (1/2 Resolution) 352H x 576V 352H x 240V 352H x 288V 2.3.7 Video Specifications NTSC video performance is specified below at a 9 Mbps video PES rate, maximum resolution. Table 5. -
Page 19: Serial Async Data, Monitor And Control Of Ird
Page 19 50 Hz to 15 kHz, ≤ ± 2° from linear phase Phase accuracy ≤0.5 % Harmonic Distortion (1 kHz test-tone, 1 Db below PPL) ≥ 80 Db (22 Hz to 20 KHz) unweighted S/N Ratio Dynamic Range 16 bits ≤... -
Page 20: Encryption
Page 20 2.3.10 Encryption The WCI decryption option includes a secure microprocessor and a decryption ASIC. Different levels of security may be implemented with software and ASIC changes. 2.3.11 Transport Output The TRANSPORT output supplies the original received MPEG2 transport stream in Synchronous Parallel format. -
Page 21: 2.3.15.2 Electrical Characteristics
Page 21 No user-accessible controls or indicators are located on the module. 2.3.15.2 Electrical Characteristics The characteristics described in Table 9 are measured at a Ð25 dBm input level. Table 9. RF Switch Characteristics Parameter Specification > 35 Db, 950-1450 MHz Input Isolation, Port to Port (all ports terminated) ≥... -
Page 22: Rear Panel
Page 22 MPEG Main MPEG mux indication Green Contact-closure activation Green AUTH Authorized to receive KMS program Green Signal Level Warning Green COMPELª Network control indication Green WARNING General warning indication Yellow ALARM Link lost or other major alarm indication *For an explanation of the Front Panel LEDÕs , see Section 3.2. -
Page 23: External Inputs And Outputs
THAT IS USED, a single ferrite core must be used for EMI emission suppression. The ferrite cores are supplied in the shipping container along with the Unity4000 IRD. Details on assembly of the ferrite cores on the wiring are shown in Figure 2. -
Page 24: Alarm Relay And Addressable Contact Closures
Page 24 2.5.3 Alarm Relay and Addressable Contact Closures The rear panel has an alarm relay and two network-controlled solid-state contact closures addressable from the COMPELª uplink computer. The alarm relayÕs ÒalarmÓ conditions are the same as the front-panel ALARM LED. The alarm relay is factory-set so that an alarm condition or the loss of unit power will cause the rear panel alarm outputs to short together (alarm relay closed). -
Page 25: Figure 2. Ferrite Bead Installation
Page 25 Figure 2. Ferrite Bead Installation BALANCED AUDIO 2 5 0 mA CH 2 CH 1 ALA RM CLOSURE MO DE * * * CAUTION * * * To meet FCC requirements, the alarm and contact closures must have a ferrite bead installed on each pair of wires leading from them. -
Page 26: Figure 3. Unity4000 Front Panel
Page 26 Figure 3. UNITY4000 Front Panel Figure 4. UNITY4000 Rear Panel With Optional RF Switch UTY4000-011 Page 26 of 75... -
Page 27: Expansion Card Configuration
Page 27 EXPANSION CARD CONFIGURATION The purpose of this section is to detail the jumper settings and labeling instructions for the Unity Expansion Cards. For more complete explanations of setup and operation of the expansion cards, see the individual manuals which accompany the cards. 2.6.1 Balanced Audio Expansion Card 2.6.1.1... -
Page 28: Sync Or Asi Data Card Jumper Configuration
Page 28 When a second balanced audio expansion card is installed, channels 5 and 6 are used. The second card is installed in the vacant module slot and connected to the first card and the motherboard by a 3-connector cable, rather than the 2-connector cable used with a single card. The second card enables Channels 5 &... -
Page 29: Operation
OPERATION MODES OF OPERATION This UNITY4000 has the capability of operating as an Audio-Only Integrated Receiver Decoder. It can also receive and process video signals, but is not normally used this way. The Audio-Only capability is accomplished by setting a software flag at the factory. This being the case, unit specifications are not changed from one mode to the other, but menus and displays are presented differently from those in an Audio-Visual UNITY4000 to accommodate this duality. -
Page 30: Led & Alarm / Warning Conditions
ON for 50 Ms, OFF for 50 Ms. AMBER RED and GREEN turned ON at the same time. The UNITY4000 has eight front panel LEDÕs, each of which is described below. 3.2.1 Carrier (Green) ON if receiver board is tracking (IRD not necessarily in tracking mode). Otherwise FLASH. -
Page 31: Authorized (Green)
Page 31 COMPEL is not required or unit is not in Tracking mode. Otherwise, FLASH (unit is in Tracking and no COMPEL within last 2 minutes). 3.2.6 Authorized (Green) ON if authorized for current program and have MPEG sync. FLASH if not authorized for current program. -
Page 32: Warning (Amber)
Page 32 Note that the Alarm LED is only ON when the unit is either overheating or unable to produce video, or if a secondary output has failed (and if control mask allows for alarm or warning display). 3.2.8 Warning (Amber) ON if any of following: 1. -
Page 33: Pulse Command For Relay Closures
Page 33 Warning Energized User Controlled Alarm De-energized User Controlled Boot Fail De-energized Open Power Off De-energized Open Note that the alarm relay is de-energized when the IRDÕs power is off. Power loss will look like any other alarm. 3.3.1 Pulse Command For Relay Closures A command may be issued via COMPEL which sets the state of a relay for a set time period. -
Page 34: Duplicating Audio Service
Page 34 4. Then press the ÔÕÕ or Ô®Õ key several times to scroll through the available services. 5. Press <ENTER> to set the Port to the currently displayed service. The audio settings discussed above are contained in an Audio Configurations Table, which is factory set in an EEPROM. -
Page 35: Unit Control
Page 35 * Originally, left ÒchannelsÓ were designated Ò1Ó and right as Ò2Ó. Now ÒchannelÓ designates the selected audio program by PID. UNIT CONTROL The IRD can be controlled via COMPELª, terminal, modem, DIP switches, and Display / Push buttons. Each of these methods of control is explained in the following sections, but you should read the COMPEL manual for a complete explanation of the COMPEL system. -
Page 36: Display / Push Buttons
LCD menus. SERIAL PORTS The UNITY4000 contains two serial ports. Any of four ÒdevicesÓ may be assigned to either serial port, though higher-speed processes should prefer port 1 because it has more buffering. Also, any device may only be assigned once, with the additional restriction that if either the terminal or modem is assigned, the other cannot. -
Page 37: Printer Device Handling
Page 37 3.7.1 Printer Device Handling For the Printer device, there are three legal output types: COMPEL E-mail, COMPEL Requested Reports, and Raw COMPEL (binary) data. If allowed, then the uplink, through COMPEL, may elect to send E-mail or request report dumps. (See the COMPEL Manual about COMPEL E-mail.) The report dumps are the same as those the local user may select using the ÔRÕ... - Page 38 Page 38 video channel and associated audio signals). The IRD is acting on one of three groups of settings at any given time, each of which is described in the following table: UTY4000-011 Page 38 of 75...
-
Page 39: Settings Table (Or Search Table)
Page 39 Table 19. Settings Types Settings Description Group Temp These settings are entered via COMPEL or the TEMP / TEMPCH terminal commands. The unit is said to be inserting when it is configured to the temp_settings. The maximum length of an insert is approximately 18 hours (65535 seconds). -
Page 40: Signal Quality Monitoring
Page 40 3.8.3 Signal Quality Monitoring The IRD provides the following signal quality information: Table 20. IRD Signal Quality Eb/No An average Eb/No reading. An Eb/No is taken approximately every 500 Ms, and the Average Eb/No is a 10 second running average of these readings. Display of Eb/No is based on readings from the OEM DVB receiver daughtercard. -
Page 41: Display / Push Buttons
Page 41 Exceptions to the normal operation with respect to Carrier ID Tagging are: If the IRD is in the nonvolatile ÔISOG EÕ state (see ÔISOGÕ terminal command), the Carrier Tags are not required. When in the GET CARRIER submode, and Carrier Lock is achieved, then the unit state transitions directly to TRACKING (passes through GET TAG). -
Page 42: Push Button Functions
Page 42 However, there may be times when you want to leave a screen displayed for more than five minutes. To do this, display the screen you wish to ÒPark,Ó press and hold the <ENTER> key, and press the < ° > (left arrow) key. This will leave the current screen displayed until you press any other key on the front panel. - Page 43 Page 43 ∨ (DOWN) Decreases value of number in edit field or scrolls down to next choice in list. In number field, button decrements once per button push or can be held to scroll. Button acceleration occurs when push-button is depressed for more than 5 seconds. >...
-
Page 44: Table 23. Lc Display Menus
Page 44 Table 23. LC Display Menus Note: Screens marked by Ô*Õ are not shown if local control is disabled (either programmed into non-volatile memory at factory or set by COMPEL command). Exception: ÒAudio SettingsÓ screen is shown but only ÒAttenuationÓ may be changed by local user. MAIN LEVEL SECOND LEVEL THIRD LEVEL... - Page 45 Page 45 MAIN LEVEL SECOND LEVEL THIRD LEVEL To Reset Unit Press <ENTER> Return Press <SELECT> Status Reports Settings Status Freq Mode Press <SELECT> Press <SELECT> Data Rate FEC Rate Tag:tt Mode Prog:ppppp Return Press <SELECT> Carrier Status Mode: Press <SELECT> Duration: hh:mm:ss Freq Data Rate...
- Page 46 Page 46 MAIN LEVEL SECOND LEVEL THIRD LEVEL History:hh:mm:ss Totl Processd: Return Press <SELECT> Parameter Status LNB LO:fffff.ff Press <SELECT> SNR Alarm Level:xx.x SNR Marg Offset:xx.x Fade: hh:mm:ss Install: hh:mm:ss Search: hh:mm:ss No Compel hh:mm:ss Cmpl Seek: hh:mm:ss Hdr Srch: hh:mm:ss Aud Demux: Installed/Not Instl Audio Ports: (1or 2)
-
Page 47: E-Mail
APPENDIX B (Page 56) along with explanations as to the conditions that generated them. 3.9.3 E-mail messages may be sent from the uplink to the Unity4000 and displayed on the LC Display. E-mail To view messages, follow these steps: E-mail 1. - Page 48 Page 48 E M A I L P R E S E N T ¯ ° Press < > or < > to scroll through the top level menu until you see the E-mail menu display similar to the one shown in Step 2. NOTE: If the ÒWarningÓ...
- Page 49 Page 49 If you press <SELECT> you can scroll through the message again. If you stop at this point, the message remains in the buffer. If you press <ENTER> you will erase the E-mail message and remain at the top level menu. The following message will be displayed: E M A I L : N O N E ¯...
-
Page 50: Appendix Aterminal/Modem Commands
Page 50 APPENDIX A TERMINAL/MODEM COMMANDS * * * CAUTION * * * Terminal / modem commands fall into two categories, Status Commands and Control Commands. If Local Control is disabled, only Status Commands will be accepted by the unit. No Control Commands will be accepted until Local Control is enabled. -
Page 51: R Type [Page]
Page 51 A.1.2 R type [page] Indicates the type of report as follows: type: C - Carrier Status CFG Ð Configurations Table P - Parameters G - Group Status NC - Network Controller Status M - MPEG R - Relay Status S - Settings Status ST - Settings Table SP - Serial Port Configuration... -
Page 52: Csel Port Location
Page 52 attenuation: 0-14 Db attenuation level This command assigns a ÔLabelÕ to an audio configuration and places that label and configuration into the Audio Configurations Table. The Audio Configurations Table entry in location (1-30) is set to service (XXX) with route (S,R,1,2) and attenuation (0-14). A.2.5 CSEL port location Select Table Entry. -
Page 53: Permch Location
Page 53 A.2.10 PERMCH location location: Value from 1 Ð 48 indicating location in settings_table. Unit sets its perm_settings to those retrieved from the settings_table according to location. A.2.11 PW password password: One to six alphanumeric characters. Changes the modem_password to password. A.2.12 RE state [number] state: O or C, to Open or Close, respectively. -
Page 54: Snr Alarm Level Margin Offset
Page 54 6 Ð Header Search time: Time-out value in HH:MM:SS format. Valid range up to 4660 hours (except 30 seconds for fade). Timeout.source is set to time. The timeout sources are defined as follows: (1) FADE timeout: The amount of time that the unit software will allow the receiver card to re-acquire a faded carrier Òon its ownÓ... - Page 55 Page 55 This Page Intentionally Left Blank Page 55 of 77 UTY4000-003...
-
Page 56: Appendix Bfront Panel Display
Page 56 APPENDIX B FRONT PANEL DISPLAY HOME SCREEN U N I T L A B E L P R O G : p p p p p E B N O : x x . x where UNIT LABEL is a (1-20)-alphanumeric-character string identifying the unit for local purposes. -
Page 57: E-Mail
Page 57 P O R T R O U T E : S R V C : y y y A T T E N : Where n is the audio port, x is the routing, either ÒSÓ for normal stereo, ÒRÓ for reversed stereo, Ò1Ó... -
Page 58: Hardware Setup
Page 58 < - E N D E M A I - > Q U I C K B R O W N F O X After pressing <ENTER> the exit screen appears: R E T U R N : P r e s s <... -
Page 59: Channel Selection
Page 59 S A V E : < E N T E R > C A N C E L : < S E L E C T > <ENTER> saves the entry (new setting) and returns to 2 level screens under ÒHARDWARE SETUP>. -
Page 60: Lnb Los
Page 60 Where ÒxxÉxxÓ is Serial Port 1 device assignment and ÒyyÉyyÓ is the same for Port 2. Either may be assigned the PRINTER, TERMINAL, MODEM, or AUX DATA devices. See Section 3.7 for other limitations. M O D E M P A S S W O R D x x x x x x Where ÒxxÉxxÓ... -
Page 61: Unit Label
Page 61 Where fffff.ff is the frequency presumed for the LNB LO (in MHz). orÉ if optional RF Switch installed, two screens are shown, each as below: L N B L O : x x x x x . x x L N B L O : y y y y y . -
Page 62: Carrier Status
Page 62 Otherwise: a a a a . d d d Where n is the number of the RF Switch output currently being selected. fffff.ff is the Carrier Downlink frequency in MHz. aaaa is the Mode, as TEMP, PERM, or SEARCH. dd.ddd is the Data Rate in Mbps. - Page 63 Page 63 DURATION hh:mm:ss is Time Since Last Acquired (the carrier, for whatever reason) in hours, minutes, seconds. I N : 1 . d d d RF IN: n is only shown if optional RF switch is installed. Otherwise, this is omitted and fffff.ff fills to left.
- Page 64 Page 64 R E T U R N P r e s s < S E L E C T > If NOT CURRENTLY TRACKING CARRIER: M O D E : X X X X X X X X X X X X D U R A T I O N : h h h : m m : s s...
-
Page 65: Mpeg Status
Page 65 R E T U R N P r e s s < S E L E C T > B.5.3 MPEG Status M P E G S T A T U S P r e s s < S E L E C T > Moves user to 3 level screens. -
Page 66: Settings Table
Page 66 R E T U R N P r e s s < S E L E C T > B.5.4 Settings Table S E T T I N G S T A B L E P r e s s <... - Page 67 Page 67 S / N : s s s s s s x x x x x x x x C O M P E L : y y y y y y y y y y Where ssÉss is unit serial number, xxÉxx is COMPEL lock status (LOCKED or UNLOCKED), and yyÉyy is COMPEL required status (REQUIRED or NOT REQUIRED).
-
Page 68: Parameter Status
Page 68 R E T U R N e s s < S E L E C T > B.5.6 Parameter Status P A R A M E T E R S T A T U S P r e s s <... -
Page 69: Port Status
Page 69 A U D D E M U X : x x x x x x x x x A U D I O P O R T S : ( y y y y y ) Where xxÉxx indicates the presence of the DSP which allows for multiple (>1) audio output ports, either INSTALLED or NOT INSTALLED. -
Page 70: Relay Status
Page 70 Where xxÉxx shows if COMPEL (printer-device) E-mail is enabled or not. M O D E M : b b b b b p d s P R I N T E R : b b b b b p d s RS232 settings for modem and printer devices: bbÉbb is baud rate, p is parity (N for none, E for Even, and O for Odd), d is number of data-bits, and s is number of stop bits. -
Page 71: Navigation Help
Page 71 L A T T I C E P L D : x x x x x x Where xxxxxx is the version string for the Lattice PLD code. S E C U R E M I C R O : Where x.x is the version number of the secure (decryption) microprocessor. - Page 72 Page 72 P r e s s < S e l e c t > s t a r E d I m o d e P r e s s < U p - D o w n > c h a n g e l u e P r e s s...
- Page 73 Page 73 This Page Intentionally Left Blank Page 73 of 77 UTY4000-003...
-
Page 74: Appendix Cglossary Of Terms
Page 74 APPENDIX C GLOSSARY OF TERMS AMBER - An LED with the red and green both ÒOn.Ó ASIC Ð Application-specific Integrated Circuit: A general term for any highly integrated circuit (in a single package that historically very complex operations solders to a printed-circuit-board) implementing. - Page 75 Page 75 FLUTTER Ð An LED that is ON for 50 Ms and OFF for 50 Ms, with the pattern continuing for some time, is said to ÒFlutter.Ó See Table 13, Page 30. Also, see ÒBlinkÓ and ÒFlash.Ó MCPC Ð Multiple-Channel-Per-Carrier. Means that one or more services or programs are present on a particular radio-frequency carrier.
- Page 76 Page 76 APPENDIX D service@wegener.com Fax (770) 232-0621 RMA REQUEST Company Name: _____________________________________________________ Bill-To Address: ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ Ship-To Address: _____________________________________________________ ______________________________________________________ ______________________________________________________ Contact Name: _____________________________________________________ Phone #: ____________________ Fax #: ___________________ Complete Model #: __________________ Serial #: __________________________ In Warranty? Yes Problem: __________________________________________________________ __________________________________________________________________...
- Page 77 Page 77 This Page Intentionally Left Blank Page 77 of 77 UTY4000-003...
-
Page 78: Record Of Revisions
Record of Revisions (Effective from July 23, 1997) Date of Rev. Page No. Description of Change Chang Level Initial Release E-78UTY4000-003...
