Installation Quick Start Guide
General Information
The
WEGENER SMD 515
SMD 515
brilliant wide screen pictures with as little as 6Mbps of data. Additional information may be found
on the
WEGENER
This product incorporates copyright protection technology that is protected by U.S. patents and
other intellectual property rights. Use of this copyright protection technology must be
authorized by Macrovision, and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
Unpacking and Inspection
The box containing the unit should include:
The SMD 515 Unit
This Quick Start Guide
Component Video Cable
Composite Video/Stereo Audio Cable
Carefully unpack the unit and the ac power cord and inspect for obvious signs of physical damage
that might have occurred during shipment. Any damage claims must be reported to the carrier
immediately. Be sure to check the package contents carefully for important documents and
materials.
Save the original packing materials and shipping containers in case the unit must be
NOTE:
returned for repair. Packing the unit in another container in such a way that the unit is
damaged will void the warranty.
Environmental Operating Conditions and Physical Specifications
The table below lists the
Item/Limit
Use
Altitude
Temperature Range
Relative Humidity (max.)
Weight
Dimensions (H x W x D)
Input Power Rating
www.wegener.com
SMD 515
Streaming Media Decoder
accelerates access to High Definition (HD) theater-quality video. The
supports MPEG-4 AVC (also known as ITU-T H.264) HD decoding. AVC HD can deliver
web site at www.wegener.com.
environmental limits and physical specifications
SMD 515
Indoor
Up to 2000 meters
o
o
10
C to 45
C
80% for temperatures up to 31
5 pounds or 2.25 kilograms with PVR option installed
2.1" x 10.6" x 9.0" or 53.3 mm x 269.2 mm x 228.6 mm
12VDC 2.3A
Specification
o
C decreasing linearly to 45
800071-01C
A UL Safety Sheet
An AC Power cord
Power Supply Module
IR remote control (optional)
o
C
Printed in USA
