See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
Multi-Purpose Spray Guns are designed
to spray most types of paints and
materials. They are ideal for home,
farm, and commercial uses.
• Comes from the factory as a pressure
feed, non-bleeder type; convertible
to siphon feed, bleeder type or any
combination of these types
• Uses internal or external mix air caps.
• Has fluid control knob.
• Adjusts for vertical or horizontal
patterns.
• May be used with a paint tank.

Specifications

Feed Type . . . . . . . . . Pressure/Siphon
Mix Type . . . . . . . . . Internal/External
Bleed Type . . . . Bleeder/Non Bleeder
Fluid Nozzle I.D. . . . . . .051" (1.3mm)
Max. Inlet
Air Pressure . . . . . . . . . . . . . . . 50 PSIG
Air Req'd . . . . . . . . . . . . . 2.0 Average
(SCFM @ 40 PSI) . . . . . 3.5 Continuous
Pattern Size . . . . . . . . . . 6.5" @ 50 PSI
8" Distance from work piece
Air Inlet . . . . . . . . . . . . . . .1/4 NPS (M)
Fluid Inlet . . . . . . . . . . . . . 3/8 NPS (M)
Fluid Nozzle
Material . . . . . . . . . . Zinc plated steel
Fluid Needle
Material . . . . . . . . . . . . Stainless steel

Safety Guidelines

This manual contains information that
is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2003
Multi-Purpose

Spray Gun

EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
Danger indicates
DANGER
!
an imminently
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
Warning indicates
WARNING
!
a potentially
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
Caution indicates a
CAUTION
!
potentially
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
Notice indicates
NOTICE
important
information, that if not followed, may
cause damage to equipment.
Unpacking
After unpacking the product, inspect
carefully for any damage that may
have occurred during transit. Make
sure to tighten fittings, bolts, etc.,
before putting unit into service.
Do not operate
WARNING
!
tool if damaged
during shipping, handling or use.
Damage could result in bursting and
cause injury or property damage.
Spray Gun Terms
FEED – Method used to bring material
into the gun for spraying.
PRESSURE FEED – Method of material
feed where a canister or paint tank is
pressurized to force material to the
gun. Either internal or external mix air
caps are used with this method.
Pressure feed is generally used for
spraying heavy bodied materials or for
large size projects.
SIPHON FEED – Method of material
feed where atmospheric pressure
creates a partial vacuum to siphon
material to the gun. Only external mix
air caps are used with this method.
Siphon feed is used with light bodied
materials.
GRAVITY FEED – Method of material
feed similar to the siphon feed method.
However, the cup is inverted to create a
positive fluid pressure at the nozzle.
MIX – The mixing of material and air
when spraying.
INTERNAL MIX – Process where the air
and material are mixed inside the air
cap just before being sprayed. This
method is best for heavy bodied, slow
drying materials and can only be used
with the pressure feed method. Do not
use fast drying materials with internal
mix. The material will dry inside and
quickly clog the air cap.
EXTERNAL MIX – Process where the air
and material are mixed just after
leaving the nozzle. This type of mix
should be used for fast drying materials
and when a high quality finish is
needed.
BLEEDER/NON-BLEEDER – Indicates
whether air flows through the gun
continuously or as the trigger is pulled.
BLEEDER – In this mode, air passes
continuously through the gun whether
spraying or not. This mode is generally
used when the air is supplied by a
continuously running compressor that
does not have a tank.
NON-BLEEDER – In this mode, air flows
only when the trigger is pulled. This
IN283801AV 3/03
HDS420
