QUAD FULL HIGH DEFINITION MONITOR
MODEL
56P-QF60LCU
USER'S MANUAL
Warning:
This user's manual is important to you. Please read it before using your product.
Be sure to follow the directions below.
This product requires special installation to prevent
falling or toppling.
Please ask installation specialists for installation.
Don't attempt to install the product by yourself.
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric 56P-QF60LCU
Summary of Contents for Mitsubishi Electric 56P-QF60LCU
- Page 1 QUAD FULL HIGH DEFINITION MONITOR MODEL 56P-QF60LCU USER'S MANUAL Be sure to follow the directions below. This product requires special installation to prevent Warning: falling or toppling. Please ask installation specialists for installation. Don't attempt to install the product by yourself.
-
Page 2: Table Of Contents
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning fl ash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Important Safeguards
Important safeguards Please read all these instructions regarding your monitor and 10. Power sources retain them for future reference. Follow all warnings and instruc- This product should be operated only from the type of power tions marked on the monitor. source indicated on the marking label. - Page 4 Annex IV. Don't expose the LCD panel to impact. The LCD panel may be damaged, causing injury or breakdown. Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from your household waste.
-
Page 5: Contents
This is class A information technology equipment. When used in a household environment, this product may cause radio interface. In such a case, the user may be required to take suitable countermeasures. Contents Your new 56P-QF60LCU monitor box should contain the following: • Monitor • User’s Manual * Remember to save your original box and packing material to transport or ship the monitor. -
Page 6: Parts Name And Functions
Parts Name and Functions Front panel EXIT MENU (1) POWER button ( ) Switches the power on/off. (2) Buttons for menu settings These buttons cannot be used. (3) Remote control sensor and power lamp Receives the signal from the remote control (when using the optional wireless remote control). -
Page 7: Rear Panel
Rear panel DVI-D INPUT1 INPUT2 INPUT3 INPUT4 RS-232C POWER (1) Main Power Switch (4) RS-232C connector On/Off Switch to turn main power on/off. Connect the RS-232C cable with the RS-232C connector of the computer for control the monitor. (2) AC IN connector Connects with the power cord. -
Page 8: Installation
Installation To avoid monitor from falling Warning: Take measures to prevent the monitor from falling over in case of an earthquake or other disaster to lessen the probability of injury and damage resulting from fall. Be sure to follow the directions below. As shown in the fi... -
Page 9: Cooling Fan
For longer use To use the product for a long time, you are recommended to follow the instructions below. You can change the settings of the product using the accessory application software “QF60LC_Control.” For details of the application software, see the QF60LC_Control software operation manual. Turn off the product when it is not used. -
Page 10: Installation Conditions
This product is designed to be resistant to adverse environmental conditions. However, note the following for longer use. • The display quality of the panel (such as brightness, uniformity, and afterimage) degrades, depending largely on the usage and installation condition. Pay attention to the following points and use the product correctly. - Page 11 Note the following when using the product continuously for a long time. • The backlight used in the LCD monitor has a lifetime. The brightness of the backlight decreases with the duration of use. • When the same image is kept displayed for a long time, its afterimage may be left on the screen after the displayed image is changed.
-
Page 12: Connections
• First turn off the power of all the attached equipment and make connections. • Refer to the user manual included with each separate piece of equipment. DVI-D cable DVI-D Computer 56P-QF60LCU (Rear panel) DVI-D INPUT1 INPUT2 INPUT3 INPUT4 Recommended video signal timing for this product is as follows. -
Page 13: Basic Operation
Basic operation Power ON procedures 1. Turn the Main Power Switch on the rear of the product to ON to turn on the main power. The power lamp blinks green and then illuminates red. (You cannot turn on the power Main Power Switch while the lamp is blinking green.) (Rear panel) -
Page 14: Troubleshooting
Troubleshooting Consult the following table for troubleshooting a problem. Symptom Cause and remedy Reference page The monitor displays nothing. (The power lamp doesn't Check that the power cord is connected securely. illuminate.) Using other device, check that the wall outlet is receiving power. -
Page 15: Specifi Cations
Specifi cations Model 56P-QF60LCU Surface treatment Glossy Diagonal 56.2” (142.75 cm) Viewable size 1244.16 × 699.84 mm Resolution 3840 × 2160 Pixel pitch 0.108(H) × 0.324(V) Color 16,770,000 View angle (Typ.) * 88° (Horizontal), 88° (Vertical) Brightness (Typ.) 500 cd/m Contrast ratio (Typ.) -
Page 16: Pin Assignment
Pin Assignment 1) INPUT 1 - 4 PIN No. Name PIN No. Name TX 2- DVI-D 24-pin TX 2+ +5V Power Shield (TX2/TX4) Ground Hot Plug Detect TX 0- DDC-Serial Clock TX 0+ DDC-Serial Data Shield (TX0/TX5) TX 1- TX 1+ Shield (TXC) Shield (TX1/TX3) TXC +... - Page 17 MITSUBISHI ELECTRIC CORPORATION 1 Zusho Baba, Nagaokakyo-City, Kyoto Japan 871D502A30 Printed in Japan...
