Summary of Contents for Mitsubishi Electric Untitle LDT37Iv
-
Page 3: Table Of Contents
Index Important Information ... Safety Precautions, Maintenance & Recommended Use ... Contents ... Parts Name and Functions ... Control Panel ... Terminal Panel ... Wireless Remote Control ... Operating Range for the Remote Control ... Handling the remote control ... Setup Procedure ... -
Page 4: Important Information
Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Wash- ington, D.C., 20402, Stock No. 004-000-00345-4. Mitsubishi Digital Electronics America, Inc. 9351 Jeronimo Road, Irvine, California 92618 U.S.A. +1 - (949) 465-6000 Computer Monitor Class B Peripheral LDT371V (BJ544) We hereby declare that the equipment specified above English-2... -
Page 5: Declaration Of The Manufacturer
Important Information TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED. REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. -
Page 6: Safety Precautions, Maintenance & Recommended Use
Safety Precautions, Maintenance & Recommended Use FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE LDT371V LCD COLOR MONITOR: • DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. -
Page 7: Contents
Contents Your new LDT371V monitor box* should contain the following: • LCD monitor • Power Cord (3m) • Video Signal Cable (4m) • User’s Manual • Wireless Remote Control and AAA Batteries • Clamper x 2 • Screw for Clamper x 2 Main switch cover * The supplied power cord varies depending on destination. -
Page 8: Parts Name And Functions
Parts Name and Functions Control Panel EXIT POWER button ( Switches the power on/off. See also page 18. MUTE button Switches the audio mute ON/OFF. INPUT button Acts as SET button with OSD menu. (Toggle switches between [RGB1], [RGB2], [RGB3], [DVD/HD], [VIDEO<S>] and [VIDEO] .) PLUS button... -
Page 9: Terminal Panel
Terminal Panel AC IN connector Connects with the supplied power cord. RGB 1 IN (DVI-D) To input digital RGB signals from a computer. * This connector does not support analog input. RGB 2 IN (mini D-Sub 15 pin) To input a analog RGB signals from a computer or other RGB equipment. -
Page 10: Wireless Remote Control
Wireless Remote Control POWER button Switches the power on/off. * If Power Indicator is not glowing, then no controls will work. INPUT button Selects from input signal, [RGB1], [RGB2], [RGB3], [DVD/ HD], [VIDEO<S>] and [VIDEO]. AUDIO INPUT button Selects from input audio signal, [AUDIO1], [AUDIO2], [AUDIO3] SIZE button Selects picture size, [FULL], [NORMAL], [WIDE] and [ZOOM]. -
Page 11: Operating Range For The Remote Control
Operating Range for the Remote Control Point the top of the remote control toward the LCD monitor's remote sensor during button operation. Use the remote control within a distance of about 7 m/23 ft. from the front of the LCD monitor's remote control sensor and at a horizontal and vertical angle of within 30°... -
Page 12: Setup Procedure
Setup Procedure 1. Determine the installation location CAUTION: DO NOT ATTEMPT TO INSTALL THE LCD MONI- TOR BY YOURSELF. Installing your LCD display must be done by a qualified technician. Contact your dealer for more information. CAUTION: MOVING OR INSTALLING THE LCD MONITOR MUST BE DONE BY TWO OR MORE PEOPLE. - Page 13 To reduce the risk of “image persistence”, please adjust the following items based on the application being used. “SCREEN SAVER” (See page 24), “SIDE BORDER COLOR”(See page 24), “DATE & TIME” (See page 27), “SCHEDULE”(See page 27). 11. Installing and removing stand How to install stand 1.
-
Page 14: How To Mount And Attach Options To The Lcd Monitor
How to Mount and Attach Options to the LCD Monitor You can attach mounting accessories to the LCD monitor in one of the following two ways: 1. In the upright position 2. Lay the screen face down Table Lay the protective sheet on a table, which was wrapped around the monitor when it was packaged, beneath the screen surface so as not to scratch the screen face. -
Page 15: Connections
Connections Before making connections: First turn off the power of all the attached equipment and make connections. Refer to the user manual included with each separate piece of equipment. Wiring Diagram Wiring Diagram English-13... -
Page 16: Connecting A Personal Computer
Connecting a Personal Computer Connecting your computer to your LCD monitor will enable you to display your computer's screen image. Some video cards may not display an image correctly. Connect the LCD Monitor to a Personal Computer • To connect the RGB 2 IN connector (mini D-sub 15 pin) on the LCD monitor, use the supplied PC - Video RGB signal cable (mini D-sub 15 pin to mini D-sub 15 pin). -
Page 17: Connecting With Digital Interface Equipment
Connecting with Digital Interface Equipment Connections can be made with equipment that is equipped with a digital interface compliant with the DVI (Digital Visual Interface) standard. Connect the LCD Monitor to a Computer with a Digital Output • The RGB 1 IN connector also accepts a DVI-D cable. •... -
Page 18: Connecting A Dvd Player With Component Out
Connecting a DVD Player with component out Connecting your DVD player to your LCD monitor will enable you to display DVD video. Refer to your DVD player owner’s manual for more information. Connect the LCD Monitor to a DVD Player •... -
Page 19: Connecting To A Stereo Amplifier
Connecting to a Stereo Amplifier You can connect your stereo amplifier to your LCD monitor. Refer to your amplifier owner's manual for more information. Connect the LCD Monitor to a Stereo Amplifier • Turn on the LCD monitor and the amplifier only after all connections have been made. •... -
Page 20: Basic Operation
Basic Operation Power ON and OFF Modes The LCD monitor power indicator will turn green while powered on or red in off mode. The monitor can be powered on or off using the following three options: Main Power Switch Power Button 1. -
Page 21: Power Indicator
Power Indicator Power Indicator Status Power ON Green Power OFF Power Standby when Red On “SCHEDULE” is enable Green Blinking Power Standby Red, Green Diagnosis (Detecting failure) Red Blinking * See troubleshooting on page 32 Using Power Management The LCD monitor follows the VESA approved DPM Power Management function. -
Page 22: Osd (On-Screen-Display) Controls
OSD (On-Screen-Display) Controls Press MENU button to open Main menu. Press UP or DOWN button to select sub-menu. Remote Control Press UP or DOWN button to select. Control Panel UP or DOWN button OSD screen Main-Menu PICTURE Sub-Menu BRIGHTNESS CONTRAST SHARPNESS BLACK LEVEL NOISE REDUCTION... -
Page 23: Screen
TINT *:INPUT DVD/HD, VIDEO only COLOR *:INPUT DVD/HD, VIDEO only COLOR CONTROL *:INPUT RGB1,2,3 only COLOR TEMPERATURE PICTURE RESET Main-Menu SCREEN Sub-Menu H POSITION V POSITION CLOCK *:INPUT RGB2/3 only CLOCK PHASE *:INPUT RGB2/3 only Adjust the tint of the screen. Press + button the flesh tone color becomes greenish. -
Page 24: Sound
ZOOM MODE CUSTOM ZOOM H RESOLUTION *:INPUT RGB1/2/3 only V RESOLUTION *:INPUT RGB1/2/3 only SCREEN RESET Main-Menu SOUND Sub-Menu BALANCE TREBLE BASS AUDIO RESET You can select “FULL”, “NORMAL” and “CUSTOM”. (INPUT RGB1/2/3 only) You can also select “FULL”, “NORMAL” “DYNAMIC”... -
Page 25: Picture In Picture
Main-Menu PIP(PICTURE IN PICTURE) Sub-Menu PIP SIZE PIP AUDIO PIP RESET Main-Menu CONFIGURATION 1 Sub-Menu AUTO SETUP *:INPUT RGB2/3 only AUTO ADJUST *:INPUT RGB2/3 only POWER SAVE LANGUAGE Selecting the size of picture inserted at the "Picture-in-Picture" (PIP) mode. "Large", "Middle" and "Small" are available. Selecting the sound source in PIP mode. -
Page 26: Configuration 2
SCREEN SAVER COLOR SYSTEM *:INPUT VIDEO only SIDE BORDER COLOR CONFIGURATION RESET FACTORY RESET Select "SCREEN SAVER" functions to reduce the risk of the "image persistence". GAMMA: The display gamma is changed and fixed when selected "ON". COOLING FAN: The built in cooling fan is always on when set "ON". -
Page 27: English
Main-Menu CONFIGURATION 2 Sub-Menu OSD TURN OFF INFORMATION OSD OFF TIMER OSD H POSITION OSD V POSITION MONITOR INFO The OSD control menu will stay on as long as it is use. In the OSD Turn Off submenu, you can select how long the monitor waits after the last touch of a button to shut off the OSD control menu. -
Page 28: Advanced Option
Main-Menu ADVANCED OPTION Sub-Menu INPUT RESOLUTION *:INPUT RGB2/3 only BLACK LEVEL EXPANSION *:INPUT VIDEO only GAMMA SELECTION SCAN MODE *:INPUT DVD/HD VIDEO only SCAN CONVERSION FILM MODE *:INPUT DVD/HD, VIDEO only IR CONTROL TILING Selects to decision of input signal about below timings, 1024x768, 1280x768 and 1360x768. -
Page 29: English
HEAT STATUS POWER ON DELAY DATE AND TIME SCHEDULE ADVANCED OPTION RESET English English English English English NOTE 1: IMAGE PERSISTENCE Please be aware that LCD Technology may experience a phenomena known as Image Persistence. Image Persistence occurs when residual or “ghost” image of a previous image remains visible on the screen. Unlike CRT monitors, LCD monitors’ image persistence is not permanent, but constant images being displayed for a long period of time should be avoided. - Page 30 < Recommendations > For preventing the fast transition to Image Sticking, and for longer life usage of LCD, following are recommended. 1. Fixed image should not be displayed for long period, and changed to another images with short cycle. 2. When no use, please turn off the monitor by remote control, or use Power Management Function of monitor or use Schedule Function of monitor.
-
Page 31: Note
Controlling the LCD monitor via RS-232C Remote Control This LCD monitor can be controlled by connecting a personal computer with a RS-232 terminal. Functions that can be controlled by a personal computer are: • Power ON or OFF • Switching between input signals Connection LCD Monitor + PC NOTE: If your PC (IBM or IBM compatible) is equipped only with a 25-pin serial port connector, a 25-pin serial port... - Page 32 3) Control sequence (1) The command from a computer to the LCD monitor will be sent in 600ms. (2) The LCD monitor will send a return command 600ms* after it has received and encoded. If the command isn’t received correctly, the LCD monitor will not send the return command. (3) The personal computer checks the command and confirms if the command, which has been sent, has been executed or not.
-
Page 33: Features
Features Reduced Footprint: Provides the ideal solution for environments requiring superior image quality but with size and weight limitations. The monitor’s small footprint and low weight allow it to be moved or transported easily from one location to another. Color Control Systems: Allows you to adjust the colors on your screen and customize the color accuracy of your monitor to a variety of standards. -
Page 34: Troubleshooting
Troubleshooting No picture • The signal cable should be completely connected to the display card/computer. • The display card should be completely seated in its slot. • Front Power Switch and computer power switch should be in the ON position. •... -
Page 35: Specifications
Specifications Specifications Product Specifications Diagonal: LCD Module Pixel Pitch: Resolution: Color: Brightness: Contrast Ratio: Response time: View Angle: Design View Distance: Horizontal: Frequency Vertical: Pixel Clock Viewable Size Input Signal Video: PC-Input: Sync: Input-terminal: VIDEO Input: AUDIO Input: RS-232C: Output Signal Video: PC-Output: Sync:... -
Page 36: Pin Assignment
Pin Assignment 1) Analog RGB input (MiniDsub15p): R G B 2 Pin No Name Video Signal Red Video Signal Green Video Signal Blue DDC-GND Red-GND Green-GND Blue-GND +5V (DDC) SYNC-GND DDC-SDA H-SYNC V-SYNC DDC-SCL 2) S-VIDEO input: V I D E O Pin No Name Y (Luminance) - Page 37 MITSUBISHI Contact Information North America MESCA (Mitsubishi Electric Sales Canada Inc.) http://www.mitsubishielectric.ca Information Technologies Group, 4299 14th Avenue, Markham, Ontario L3R 0J2, Canada Sales Phone :+1-(905) 475-7728 :+1-(905) 475-7958 E-mail :projectors@mitsubishielectric.ca Technical Phone :+1-(905) 475-7728 :+1-(905) 475-7958 Customer Care E-mail :support@mitsubishielectric.ca MDEA (Mitsubishi Digital Electronics America, Inc.) (Warranty Registration)
