Front panel

Earpiece
Listen to a phone call
from here.
GPS
Press to launch the GPS
navigation software.
TALK/SEND
• Press to answer an
incoming call or dial a
number.
• During a call, press
and hold to toggle
the speakerphone on
and off.
• Press and hold to
use Voice Speed Dial.
(See Chapter 1 for
details.)
* LED shows:
• Flashing green light when there are new SMS, MMS or e-mail messages, missed calls, or
reminders.
• Solid green light when the device is connected to the power adapter or a computer and the
battery is fully charged.
• Solid amber light when the battery is being charged.
• Flashing amber light when the remaining battery level reaches below 10%.
Notification LED
* See description below.
Touch Screen
Getting Started 5
4-WAY NAVIGATION WHEEL
with ENTER button
• Rotate the wheel or press this
multi-directional control up,
down, left, or right to move
through menus and program
instructions; carry out the
selection by pressing the
centre button.
• In some programs such as
Camera and Opera Mobile,
rotate the wheel to zoom in
or out.
FOOTPRINTS
Press to launch Footprints. See
Chapter 10 for details.
END
• Press to end a call or return to
the Home screen.
• Press and hold to lock the
device.
(To customise the End key,
tap Start > Settings >
Personal tab > Buttons >
End Key tab.
