GPF2718JB
Owner's Manual
.
Deluxe LP Gas Grill
SAVE THESE INSTRUCTIONS FOR FUTURE
.
REFERENCE. IF YOU ARE ASSEMBLING THIS UNIT
FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM
OR HER TO SAVE FOR FUTURE REFERENCE.
FOR CUSTOMER SERVICE OR
TECHNICAL HELP
WWW.BBQTEK.COM
SEND EMAIL TO
SERVICE@BBQTEK.COM
CALL 1-877-885-8227,
6 A.M. –
,
PLEASE VISIT
OR
4:30
P.M. (PST), MONDAY-FRIDAY.
0
Printed in China
Advertisement
Table of Contents
Related Manuals for BBQ GPF2718JB
Summary of Contents for BBQ GPF2718JB
- Page 1 FOR CUSTOMER SERVICE OR WARNING TECHNICAL HELP PLEASE VISIT FOR YOUR SAFETY : WWW.BBQTEK.COM SEND EMAIL TO For Outdoor Use Only SERVICE@BBQTEK.COM CALL 1-877-885-8227, (outside any enclosure) 6 A.M. – 4:30 P.M. (PST), MONDAY-FRIDAY. Printed in China GPF2718JB Owner’s Manual...
-
Page 2: Grill Operation
NOTE: This grill must be used with propane gas only (propane gas cylinder not included). Always keep this manual for convenient future reference. GPF2718JB Owner’s Manual... -
Page 3: Table Of Contents
For Your Safety....................3 Illustrated Parts List ..................5 Hardware List.....................6 Assembly Instructions..................7 Operating Your Grill..................14 Connecting Gas Cylinder........15 Checking for Leaks..........15 Lighting Your Grill..........15 Excess Flow Safety Valve Reset Procedure..17 Care and Maintenance..................18 Award-Winning Barbecue Recipes..............19 Troubleshooting....................20 Warranty Program....................22 GPF2718JB Owner’s Manual... -
Page 4: For Your Safety
4. Move gas hoses as far away as possible from hot surfaces and dripping hot grease. 5. Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. GPF2718JB Owner’s Manual... - Page 5 Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. GENERAL INFORMATION 1. A propane gas cylinder is required for operation. 2. This gas grill is NOT intended for commercial use GPF2718JB Owner’s Manual...
-
Page 6: Illustrated Parts List
14. Right Side Shelf… ….1pc 15. Grill Body Assembly…1pc 16. Warming Rack……...1pc 17. Cooking Grid………..2pcs 18. Heat Plate…….….…1pc 19. Side Burner Assembly 20. Bottle Holder……..…1pc ………………………1pc 21. Grease Cup Support..1pc 22. Grease Cup………..1pc 23. Side Valve Frame…..1pc GPF2718JB Owner’s Manual... -
Page 7: Hardware List
Side Burner Knob 5pcs M6 Flat Washer M4 Flat Washer 4pcs Screwdriver 4pcs Hexagon Wrench M4 Long Screw 1pcs 2pcs M4 Short Screw 2pcs M10 Flat Washer 2pcs M10 Nut Parts & hardware shown above are not to scale. GPF2718JB Owner’s Manual... -
Page 8: Assembly Instructions
Screw one M10 nut (H) on each end of the axle toward the wheel and tighten all nuts using the hexagon wrench provided. G x2 Cover one hub cap (5-1) on each wheel. H x2 GPF2718JB Owner’s Manual... - Page 9 Make certain the direction of the grease pan is followed with the instructions on the sticker. Screw one M6 bolt (A) into each pre-drilled hole. Go back to tighten all the bolts using the hexagon wrench provided. GPF2718JB Owner’s Manual...
- Page 10 Repeat the procedure for the side shelf support R-F & L-B (12) with the left back side and right front side of the cart assembly. Go back and tighten all the bolts using the hexagon wrench provided. A x8 GPF2718JB Owner’s Manual...
- Page 11 Tighten all nuts using the hexagon wrench provided. Put the cover (9-1) upon the smoke box. Install the heat plate (18) inside the grill body. Put the cooking grid (17) upon the heating plate. Put the warming rack (16) upon the cooking grid. GPF2718JB Owner’s Manual...
- Page 12 Align the holes on the bottom of burner assembly with the holes on the valve frame. Insert one M6 flat washer (D) and one M6 short screw (C) into the pre-drilled hole. Tighten the M6 short screw using the screwdriver provided. GPF2718JB Owner’s Manual...
- Page 13 Step 12 (Install the grease cup support and grease cup) Install the grease cup support (21) by inserting the hooks on the grease cup support into the holes on the grease pan. Place the grease cup (22) upon the grease cup support. GPF2718JB Owner’s Manual...
- Page 14 Place gas tank upon the tank seat on bottom panel Step 14 Pull the gas tank clip towards the gas tank to lock it in place and make certain the gas tank is secure. Connect the regulator with gas the gas tank. GPF2718JB Owner’s Manual...
-
Page 15: Operating Your Grill
Never store a spare propane cylinder under or in the vicinity of this grill, or in the vicinity of another potential heat source. Never fill the propane cylinder beyond 80% full. Warning: Don’t store spare gas cylinder in or near grill. GPF2718JB Owner’s Manual... -
Page 16: Connecting Gas Cylinder
The burner should light. If the burner does not light, return the valve knob to the “OFF” position immediately. Wait five minutes for the gas to clear and repeat the procedure. After burner is lit, repeat the procedure with any other burner desired GPF2718JB Owner’s Manual... - Page 17 Confirm that the burner is properly lit and that the flame pattern is as desired (see fig. A, B and C below for the proper flame patterns). If the flame pattern is other than normal, consult the troubleshooting guide on page 20 for corrective action. GPF2718JB Owner’s Manual...
-
Page 18: Excess Flow Safety Valve Reset Procedure
13. When all front burners are lit, close the grill lid. 14. Wait for 10-15 minutes, the temperature should reach 400°F – 450°F WARNING: The cylinder valve always has to be above the horizontal position, for the cylinder to have vapor withdrawl only. WRONG WRONG WRONG CORRECT GPF2718JB Owner’s Manual... -
Page 19: Care And Maintenance
Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. GPF2718JB Owner’s Manual... -
Page 20: Award-Winning Barbecue Recipes
Cooking times will vary according to the vegetables Combine all ingredients and marinate steak for 7-8 chosen. hours. Remove meat from marinade and grill over very high heat to desired doneness. Heat leftover marinade to a boil and pour over grilled steak to serve. GPF2718JB Owner’s Manual... -
Page 21: Troubleshooting
Spider webs or insect nest in Clean venturi. venture. Food residue, grease or seasoning Clean burner. salt on burner. Poor alignment of valve to burner Assure burner venturi is properly venturi. engaged with valve. GPF2718JB Owner’s Manual... - Page 22 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8” increments until flames are correct. *Propane Models must be open a minimum of 1/8” *Natural Gas Models must be open a minimum of 1/16” GPF2718JB Owner’s Manual...
-
Page 23: Warranty Program
1-877-885-8227, 6:00 A.M. to 4:30 P.M. (PST), Monday through Friday. Manufactured by: Lucas Innovation Inc. Xie Keng District, Qing Xi Town, Dong Guan, Guang Dong, China. Printed in China GPF2718JB Owner’s Manual...
