WARNING
Improper installation,
adjustment, alteration, service or
maintenance can cause injury or
property damage.
Read the installation,
operation and maintenance
instructions thoroughly before
installing or servicing this
equipment.
DANGER
Failure to follow these
instructions could result in fire
or explosion that could cause
property damage, personal
injury or death.
DANGER
DO NOT use gas grill for indoor
cooking or heating. TOXIC
fumes can accumulate and
cause asphyxiation. DO NOT
use in or on boats or
recreational vehicles.
PROP 65 WARNING
Chemicals known to the state of
California to cause cancer, birth
defects or other reproductive
harm are created by the
combustion of propan
WARNING
FOR YOUR SAFETY :
For Outdoor Use Only
(outside any enclosure)
GPF2414C
Owner's Manual
Deluxe LP Gas Grill
e.
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. IF YOU ARE ASSEMBLING THIS
UNIT FOR SOMEONE ELSE, GIVE THIS
MANUAL TO HIM OR HER TO SAVE FOR
FUTURE REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8227 (TOLL-FREE),
6:00 A.M. – 4:30 P.M.(PST), MONDAY-FRIDAY.
0
ITEM # 239851
Advertisement
Table of Contents
Related Manuals for BBQ GPF2414C
Summary of Contents for BBQ GPF2414C
- Page 1 MANUAL TO HIM OR HER TO SAVE FOR FOR YOUR SAFETY : FUTURE REFERENCE. FOR CUSTOMER SERVICE, EMAIL TO For Outdoor Use Only SERVICE@BBQTEK.COM OR (outside any enclosure) CALL 1-877-885-8227 (TOLL-FREE), 6:00 A.M. – 4:30 P.M.(PST), MONDAY-FRIDAY. GPF2414C Owner’s Manual...
-
Page 2: Grill Operation
Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this manual before attempting to use this gas barbecue grill to prevent possible bodily injury or property damage. Always keep this manual for convenient future reference. GPF2414C Owner’s Manual... -
Page 3: Table Of Contents
For Your Safety....................3 Illustrated Parts List ..................5 Hardware List....................6 Assembly Instructions..................7 Operating Your Grill..................13 Connecting Gas Cylinder.................13 Checking for Leaks..................14 Lighting Your Grill....................14 Excess flow safety valve reset procedure............15 Care and Maintenance..................16 Award-Winning Barbecue Recipes..............18 Troubleshooting....................19 Warranty Program....................21 GPF2414C Owner’s Manual... -
Page 4: For Your Safety
4. Move gas hoses as far away as possible from hot surfaces and dripping hot grease. 5. Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. GPF2414C Owner’s Manual... - Page 5 Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. GENERAL INFORMATION 1. A propane gas cylinder is required for operation. 2. This gas grill is NOT intended for commercial use. GPF2414C Owner’s Manual...
-
Page 6: Illustrated Parts List
QQ. Side shelf support RR. Side shelf support SS. Left Side Shelf…..…...1pc TT. Right Side Shelf……...1pc Left-Front/Right-Back…..2pcs Right-Front/Left-Back…..2pcs UU. Heating Plate………..1pc VV. Cooking Grate.....1pc WW. Side burner grate…..1pc XX. Warming Grate……..1pc YY. Cup Support…………..1pc ZZ. Grease cup…….……..1pc GPF2414C Owner’s Manual... -
Page 7: Hardware List
Wheel Nut 2pcs 2pcs Plastic Washer Knob 2pcs Flat Washers 2pcs 2pcs Wrench screwdriver Lock Washers 2pcs Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). GPF2414C Owner’s Manual... -
Page 8: Assembly Instructions
Align the holes on the bottom beam (EE) with the holes on the right frame piece and left flame piece respectively. Screwing one M6 bolt (A) into each pre-drilled hole. Tighten all bolts using the screwdriver provided. GPF2414C Owner’s Manual... - Page 9 Screwing one M6 bolt (A) into the hole. Align the hole on bottom hook (JJ) with the hole on the bottom of the left frame piece. Screwing one M6 bolt (A) into the hole. Tighten all bolts using the screwdriver provided. GPF2414C Owner’s Manual...
- Page 10 Step 8 Align the holes on top beam (NN) with the holes on the back of the cart. Screw one M6 bolt (A) into the hole. Tighten all bolts using the screwdriver provided. GPF2414C Owner’s Manual...
- Page 11 Insert the four pre-inserted bolts under the left side shelf (SS) into the four holes in the side supports. Tighten all the bolts by hand. Repeat the procedure for the right side shelf (TT). Tighten all bolts using the screwdriver provided GPF2414C Owner’s Manual...
- Page 12 Place the heating plate (UU) upon the burner inside the grill body. Place the cooking grate (VV) upon the heating plate. Step 14 Insert the supports of warming grate (XX) into the hole on lid and grill body. GPF2414C Owner’s Manual...
- Page 13 Step 16 Place the cylinder upon the bottom hook. Push the cylinder toward the top hook to hook it. Connect the regulator to the cylinder by turning it clockwise. Fully Assembled View Left Side Right Side GPF2414C Owner’s Manual...
-
Page 14: Operating Your Grill
Do not use matches, lighters or a flame to check for leaks. Do not use grill until all leaks have been stopped. If you are unable to stop a leak, disconnect the propane supply, call for gas appliance service or your local propane gas supplier. GPF2414C Owner’s Manual... -
Page 15: Checking For Leaks
“HIGH”. This will “heat clean” the internal parts and dissipate odor from the manufacturing process and painted finish. Clean the grill after each use. DO NOT use abrasive or flammable cleaners. This may damage parts of the grill and cause a fire. GPF2414C Owner’s Manual... -
Page 16: Excess Flow Safety Valve Reset Procedure
LP tank valve. ● This procedure is effective with all LP Tank sizes as well as Natural Gas. When performing the procedure on a Natural Gas model, simply substitute "Natural Gas valve" for "LP Tank". GPF2414C Owner’s Manual... -
Page 17: Care And Maintenance
Burning off the grill after every use (approx. 15 minutes) will keep excessive food residue from building up. Recommended cleaning materials - Mild dishwashing liquid detergent Hot water Nylon cleaning pad Wire brush Paper clip Putty knife/scraper Compressed air DO NOT use cleaners that contain acid, mineral spirits or xylene. GPF2414C Owner’s Manual... - Page 18 Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. GPF2414C Owner’s Manual...
-
Page 19: Award-Winning Barbecue Recipes
Combine all ingredients and marinate steak for 7-8 Cooking times will vary according to the vegetables hours. Remove meat from marinade and grill over chosen. very high heat to desired doneness. Heat leftover marinade to a boil and pour over grilled steak to serve. GPF2414C Owner’s Manual... -
Page 20: Troubleshooting
Burn grill for 15 minutes with the lid closed. manufacturing oils. Clean venturi. Spider webs or insect nest in venturi. Clean burner. Food residue, grease or seasoning salt on burner. Assure burner venturi is properly engaged Poor alignment of valve to burner with valve. venturi. GPF2414C Owner’s Manual... - Page 21 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8” increments until flames are correct. *Propane Models must be open a minimum of 1/8” *Natural Gas Models must be open a minimum of 1/16” GPF2414C Owner’s Manual...
-
Page 22: Warranty Program
If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8227, 6:00 A.M. to 4:30 P.M. (PST), Monday through Friday. Distributed by: L G Sourcing, Inc. P.O. Box 1535 North Wilkesboro, NC 28659 USA Printed in China GPF2414C Owner’s Manual...
