BBQ GSF2414NS Owner's Manual

Deluxe lp gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
DANGER
Failure to follow these
instructions could result in fire
or explosion that could cause
property damage, personal
injury or death.
DANGER
DO NOT use gas grill for indoor
cooking or heating. TOXIC fumes
can accumulate and cause
asphyxiation. DO NOT use in or
on boats or recreational vehicles.
PROP 65 WARNING
Chemicals known to the state of
California to cause cancer, birth
defects or other reproductive
harm are created by the
combustion of liquid propane
gas
.
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only.
(outside any enclosure)
GSF2414NS
Owner's Manual
Deluxe LP Gas Grill
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. IF YOU ARE ASSEMBLING THIS UNIT
FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM
OR HER TO SAVE FOR FUTURE REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@PYROMAGICBBQ.COM
CALL 1-877-885-8227 (TOLL-FREE),
6 A.M. – 5 P.M.(PST),MONDAY-FRIDAY.
ITEM # 122223
OR
Printed in China

Advertisement

Table of Contents
loading

Related Manuals for BBQ GSF2414NS

Summary of Contents for BBQ GSF2414NS

  • Page 1 FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM FOR YOUR SAFETY: OR HER TO SAVE FOR FUTURE REFERENCE. FOR CUSTOMER SERVICE, EMAIL TO For Outdoor Use Only. SERVICE@PYROMAGICBBQ.COM (outside any enclosure) CALL 1-877-885-8227 (TOLL-FREE), 6 A.M. – 5 P.M.(PST),MONDAY-FRIDAY. Printed in China GSF2414NS Owner’s Manual...

  • Page 2: Grill Operation

    Grill Operation 1-2-3 Before Grilling, Step 1 Keep your grill a safe distance away from your property.* Step 2 Always Perform a Leak Test on all connections and hoses.* Step 3 Keep children away from the grill. During Grilling, (To avoid tripping safety valves, please follow these instructions carefully!) Step 1 First open lid and turn gas valve on slowly.

  • Page 3: Table Of Contents

    Table of Contents For Your Safety ....................3 Illustrated Parts List .....................5 Hardware List ......................6 Assembly Instructions ..................7 Operating Your Grill ...................14 Propane tank Connection ........15 Checking for Leaks ..........15 Lighting Your Grill ..........15 Excess flow safety valve reset procedure ………17 Care and Maintenance ........18 Award-Winning Barbecue Recipes ..............19 Troubleshooting ....................20...

  • Page 4: For Your Safety

    For Your Safety Dear Valued Customer, Congratulations on your new barbecue grill purchase! You’ve made the right choice. In this manual, you will find assembly instructions, suggestions for grilling and helpful hints, as well as guidelines for the safe operation, proper care and use of your grill.
  • Page 5 Safe Locations for Use of This Outdoor Grill DANGER Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational vehicle, to prevent a possible fire and to prevent the possibility of carbon monoxide poisoning or asphyxiation. WARNINGS Do not use this appliance under overhead combustible surface or covered area (e.g., awnings, umbrellas, porches or gazeboes).

  • Page 6: Illustrated Parts List

    Illustrated Parts List 1. Bottom Front Panel ---1pc 2. Bottom Back Panel--1pc 3. Bottom Left Beam ---1pc 4. Bottom Right Beam-----1pc 5. Wheel caps-------------2 pcs 6.Wheels----------------2 pcs 7. Wheel Axle-------------1pc 8. Top Front -Panel----------1pc 9. Top Back Panel --------1pc 10. Top Right Beam----1pc 11.

  • Page 7: Hardware List

    Hardware List Screwdriver 35pcs M6 Bolts M6 Washers 6pcs M6 Nuts 2pcs M10 Nuts M6 Spring Washers 2pcs 2pcs Wrench M10 Washers 2pcs M6 Fiber Washers 4pcs Hardware listed above is not scaled to exact size (A screwdriver is included for your convenience.) GPF2414-NS Owner’s Manual...

  • Page 8: Assembly Instructions

    Assembly Instructions Remove all contents from the carton packaging. Make sure all parts are present before attempting assembly. Once the grill is fully assembled, go back and check to make certain all the bolts are tight. Tighten again with the screwdriver provided if it is necessary.
  • Page 9 Step 3 Loosen the screw on the bottom back panel. Align the narrow holes on the top back panel (9) with the holes on the bottom back panel. Tighten the loosen bolts by hand until secure. Repeat the procedure for top front panel (8) with bottom front panel.
  • Page 10 Step 5 Align the holes on the top tank hook (12) with the holes on the top right beam. Screw a M6 bolt (A) into pre-drilled hole. Tighten by hand until secure. Align the holes on the bottom tank hook (13) with the holes on the bottom right beam.
  • Page 11 Step 7 Open the top lid. Align the holes on the any one corner of grill body assembly with the hole on the step 6 assembly. Screw a M6 bolt (A) with a M6 washer (D) and M6 fiber washer (I) into the pre-drilled hole. Tighten by hand until secure.
  • Page 12 Step 9 Align the holes on the LB/RF shelf support (17) with the holes on the left back side of the grill body. Screw a M6 bolt (A) into each the pre-drilled hole. Tighten by hand until secure. Repeat the procedure for LF/RB (18) shelf support. Align the holes on the tank partition (27) with the holes on the LB/RF shelf support (17) and the holes on the right front side of the grill body.
  • Page 13 Step 11 Open the top lid. Place the heat plate (21) on inside of the grill. Place the cooking grid (22) upon the heating plate. Step 12 Insert the four ends of the warming rack (23) into the holes on the top lid and grill body. GPF2414-NS Owner’s Manual...
  • Page 14 Step 13 Hook the grease cup support (24) into the grooves beneath the grill body. Place the grease cup (25) on the grease cup support. Step 14 Place the gas tank on the top tank hook and bottom tank hook. Screw the gas regulator into the gas tank valve.

  • Page 15: Operating Your Grill

    Fully Assembled View Operating the Grill CAUTION: Use only the regulator provided. If a replacement is necessary, call our customer service center. The use of unauthorized parts can create an unsafe condition and environment. The propane gas supply cylinder used must be constructed and marked in accordance with the Specifications for Propane Gas Cylinders of the U.S.

  • Page 16: Propane Tank Connection

    LP (Propane) Gas Supply Connection Always place the propane cylinder on the tank brackets located on the right side of the cart. Always confirm that all burner control knobs are in the OFF position before activating the gas supply. Before connection, be sure that there is no debris caught in the head of the gas cylinder, head of the regulator valve, or in the head of the burner and burner ports.
  • Page 17 Using the Lighting Stick to Light the Main Burners Remove the cooking grid from the burner you wish to light. Insert a match into the end of lighting stick. Light the match. Once lit, place the flame through the hole on grill body to reach the burner ports. (As the fig.

  • Page 18: Excess Flow Safety Valve Reset Procedure

    Flare-ups “Flare-ups” sometimes occur when food drippings fall onto the hot heat distribution plate or burners and ignite. Some flaring is normal and desirable, as it helps impart the unique flavors associated with grilled foods. Controlling the intensity of the flare-ups is necessary, however, in order to avoid burned or unevenly cooked foods and to prevent the possibility of accidental fire.

  • Page 19: Care And Maintenance

    Care and Maintenance IMPORTANT Always allow to completely cool off before covering your grill to prevent corrosion from condensation Caution: All cleaning and maintenance should be done when the grill is cool, with the fuel supply turned off at the control dial and the propane cylinder disconnected.

  • Page 20: Award-Winning Barbecue Recipes

    Award-Winning Barbecue Recipes Never-fail Barbecue Sauce Hardcore Grilled Trout Ingredients: Ingredients: ¼ cup Finely chopped onion ¼ cup Lemon or lime juice 2 tablespoons Melted butter 2 tablespoons Butter or margarine ¼ cup Brown sugar, firmly packed 2 tablespoons Vegetable oil 1 tablespoon Worcestershire sauce 2 tablespoons...

  • Page 21: Troubleshooting

    Troubleshooting Problem Possible Cause Prevention/Cure Burner will not light using knobs or Wires/or electrode covered with Clean wire and /or electrode with ignitor cooking residue. rubbing alcohol. Electrode and burners are wet. Wipe dry with cloth. Electrode cracked or broken – Replace electrode sparks at crack.
  • Page 22 Flame blow out High or gusting winds Turn front of grill to face wind or increase flame height Low on propane gas. Replace or refill propane tank. Excess flow valve tripped Refer to the Excessive flow safety valve reset procedure on page 18 Flare-up Grease buildup.

  • Page 23: Warranty Program

    Warranty Program Proof of purchase is required to access this warranty program, which is in effect from the date of purchase. Inability to provide proof of purchase or after the warranty has expired, customers will be subject to parts, shipping and handling fees. Product Registration is required to receive full warranty coverage, which is in effect from the date of purchase.
