ZALMAN CNPS8900 Series User Manual

ZALMAN CNPS8900 Series User Manual

Intel socket 1366/1156/1155/775 cpu amd socket fm1/am3+/am3/am2+/am2 cpu

Advertisement

Quick Links

User's Manual
Core i7 Extreme
Core i7
Core i5
Core i3
AMD Socket FM1/AM3+/AM3/AM2+/AM2 CPU
Zambezi
Llano
Phenom II
Phenom
CNPS8900 Series
Intel Socket 1366/1156/1155/775 CPU
Core 2 Extreme
Core 2 Quad
Core 2 Duo
Athlon II
Athlon X2
Athlon FX
Athlon
To ensure safe and easy installation, please read
the following precautions.
www.ZALMAN.com
Pentium Dual-Core
Pentium D
Pentium 4
Celeron D
Opteron Dual-Core
Opteron
Sempron
Ver 1.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CNPS8900 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ZALMAN CNPS8900 Series

  • Page 1 User's Manual CNPS8900 Series Intel Socket 1366/1156/1155/775 CPU Core i7 Extreme Core 2 Extreme Pentium Dual-Core Core i7 Core 2 Quad Pentium D Core i5 Core 2 Duo Pentium 4 Core i3 Celeron D AMD Socket FM1/AM3+/AM3/AM2+/AM2 CPU Zambezi Athlon II...
  • Page 2: Specifications

    Product design and specifications may be revised to improve quality and performance. Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due to external causes, including but not limited to, improper use, problems with electrical power, accident, neglect, alteration, repair, improper installation, or improper testing.
  • Page 3 Backplate Cooler Side Caps Nuts User’s Manual Bolts (Cooler) Bolts (Clip) Extension Fan Cable Loading Block Double-sided Tape Thermal Grease (ZM-STG2M) 2) Intel 구성품 2) Intel Components 3) AMD Components AMD Clip Intel Clip (Socket FM1/AM3+/AM3/AM2+/ AM2) (Socket 1366/1156/1155/775) WWW.ZALMAN.COM...
  • Page 4 A . Intel Socket 1366/1156/1155/775 Installation ① Install the Intel clip to the base of cooler using the bolts (Clip). Please make sure to put the curved part of clip toward the base as shown in the image. Intel Clip WWW.ZALMAN.COM...
  • Page 5: Installation

    Please note the orientation of the Nuts and the Side Caps. ③ Socket 1366/1156/1155 Installation Attach Double-sided Tape to the center of the Backplate and remove the Double-sided Tape’s Cover. ※ Installation of Socket 1366/1156/1155 does not require the Loading Block. Double-sided Tape WWW.ZALMAN.COM...
  • Page 6 Remove the Sticker Cover from the Lower Tier of the Loading Block and attach to the Backplate. Loding Block Attach Double-sided Tape to the Loading Block and remove the Double-sided Tape Cover. Double-sided Tape Caution Please note of the orientation of the Loading Block's Installation. WWW.ZALMAN.COM...
  • Page 7 The vertical installation can affect the performance of heat dissipation. ⑦ Connect the cooler’s 4-pin connector to the motherboard’s CPU Fan header. Caution Please make sure that PWM Control Mode is activated in the motherboard’s BIOS settings. WWW.ZALMAN.COM...
  • Page 8 Please make sure to put the curved part of clip toward the base as shown in the image. AMD Clip ② Install the side cap to the Backplate. Caution Please note of the orientation of Nuts and side Caps. WWW.ZALMAN.COM...
  • Page 9 ③ Remove the Sticker Cover from the Lower Tier of the Loading Block and attach to the Backplate. Loading Block Attach Double-sided Tape to the Loading Block and remove the Double-sided Tape Cover Double-sided Tape Caution Please note of the orientation of the Loading Block's Installation. ④ Take away the fixed Clip support from the motherboard. WWW.ZALMAN.COM...
  • Page 10 CPU and then fasten the Bolts (Cooler) to install the Cooler. ⑦ Connect the cooler’s 4-pin connector to the motherboard’s CPU Fan header. Caution Please make sure that PWM Control Mode is activated in the motherboard’s BIOS settings. WWW.ZALMAN.COM...

This manual is also suitable for:

Cnps8900 extremeCnps8900 quiet
