In-Flight Entertainment System
With MP3/Compact Disc Player
AM/FM Radio Receiver
With Satellite Radio Option
FAA-STC/PMA Approved
Installation and Operation Manual
In certified aircraft, warranty is not valid unless this product is installed by an
Any reproduction or retransmittal of this publication, or any portion thereof, without the expressed written permission of PS Engi-
neering, Inc. is strictly prohibited. For further information contact the Publications Manager at PS Engineering, Inc., 9800 Martel
200-739-0001
Road, Lenoir City, TN 37772. Phone (865) 988-9800.
9800 Martel Road
Lenoir City, TN 37772
P
X
E
7
3
P
X
E
7
3
High-fidelity Stereo
Document P/N 200-739-0001
Revision 2
January 2005
Authorized PS Engineering dealer.
PS Engineering, Inc. 2005 ©
Copyright Notice
0
0
-
S
R
0
0
-
S
R
Rev. 2, January 2005
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PS Engineering PXE7300-SR
Summary of Contents for PS Engineering PXE7300-SR
- Page 1 Copyright Notice Any reproduction or retransmittal of this publication, or any portion thereof, without the expressed written permission of PS Engi- neering, Inc. is strictly prohibited. For further information contact the Publications Manager at PS Engineering, Inc., 9800 Martel 200-739-0001 Rev.
-
Page 2: Table Of Contents
Table of Contents SECTION I GENERAL INFORMATION................ 1-1 INTRODUCTION......................1-1 SCOPE ..........................1-1 EQUIPMENT DESCRIPTION ..................1-1 APPROVAL BASIS ......................1-1 SPECIFICATIONS......................1-2 EQUIPMENT SUPPLIED ..................... 1-3 EQUIPMENT REQUIRED BUT NOT SUPPLIED ............ 1-3 APPROVED AUDIO SYSTEMS................... 1-4 LICENSE REQUIREMENTS ..................1-4 1.10 SUBSCRIPTION REQUIREMENTS (O SR O... - Page 3 PS Engineering PXE7300-SR IFE System Installation and Operator’s Manual ......................3-2 ADIO ECEPTION ....................3-2 ADIO RESET UNCTION SIRIUS M ..................3-3 ODULE PERATION 3.5.1 SIRIUS SIGNAL DROP OUT: ..................3-4 (7) ..................... 3-4 ISPLAY IMMING SECTION IV- WARRANTY AND SERVICE..............4-1 ........................
-
Page 4: Section I General Information
Before installing and/or using this product, please read this manual completely. This will ensure that you will take full advantage of all the advanced features in the PXE7300. SCOPE This manual provides detailed installation and operation instructions for the PS Engineering PXE7300- series of IFE Systems. This includes the following units: Model... -
Page 5: Specifications
Height: 5.5 in. (14.0 cm) Width: 1.50 in. (3.8 cm) Depth: 7.75 in. (19.7 cm) WEIGHT (With Rack & Connectors): 2.6 lb. (1.2 kg) POWER REQUIREMENTS: Voltage: 11 to 33 VDC Maximum Current 0.9 Amp (Power provided by PXE7300-SR Unit) 200-739-0001 Page 1-2 Rev. 2, January 2005... -
Page 6: Equipment Supplied
PS Engineering PXE7300-SR IFE System Installation and Operator’s Manual EQUIPMENT SUPPLIED 1 ea. of the following units: SIRIUS Radio Option, PXE7300-SR Model Part Number Description PXE7300-SR 11970, Option SR IFE System for use with SIRIUS Radio Module PXE7300 Installation Kit: 250-730-0001... -
Page 7: Approved Audio Systems
PS Engineering PXE7300-SR IFE System Installation and Operator’s Manual APPROVED AUDIO SYSTEMS This is a list of audio system that the PXE7300 should interface with adequately. Approved Audio Systems, PXE7300 Certified interface is approved only for audio systems that are FAA-TSO approved. -
Page 8: Section Ii - Installation
Section 1.6 (B). If any claim is to be made, save the shipping material and contact the freight carrier. Do NOT return units damaged in shipping to PS Engineering. If the unit or an accessory shows any sign of external shipping damage, contact PS Engineering to arrange for a replace- ment. -
Page 9: Pxe7300 Mounting Rack Installation
PS Engineering PXE7300-SR IFE System Installation and Operator’s Manual Avoid installing the PXE7300 close to high current devices or systems with high-voltage, pulse type out- puts, such as DME or transponders. The PSM7390 must be rigidly mounted to the aircraft structure in an area where avionics are typically in- stalled, in accordance with FAA Advisory Circular AC 43.13-2A (or later revision) Chapter 2, Section 24,... -
Page 10: Connector Assembly
Refer to FAA Advisory Circular 43.13-1B and 2A for more information. Failure to use correct techniques may result in improper operation, electrical noise or unit failure. Damage caused by improper installation will void the PS Engineering warranty. PS Engineering can provide a custom made harness, visit www.ps- engineering.com for more information. -
Page 11: Power
3 to 5 AM stations. In contrast to an ADF, where audio fidelity is not important, the PXE7300 re- quires higher signal levels to ensure fidelity. For optimum performance, some installers may desire an external AM/FM antenna. PS Engineering recommends a Comant CI-222-series, installed in accordance with AC43.13-1A, Chapter 3. -
Page 12: Unswitched Summed Audio
PS Engineering PXE7300-SR IFE System Installation and Operator’s Manual The included antenna can be mounted wherever convenient inside the cockpit, as long as it is in a window. Verify that the antenna is not an impediment to crew vision outside the cockpit when installed, For optimal operation, it should be near the windshield. -
Page 13: Satellite Radio Antenna Installation
PS Engineering PXE7300-SR IFE System Installation and Operator’s Manual Mounting split washer 3 ea. (M5) Mounting nuts PSM7390 3 ea. (M5) Radio Module 430-790-5000 Mounting Rack Screws 475-739-5268 (AN526-832R8) Aircraft Shelf 0.125" AL, 2024-T3 6 ea. #8 - 32 Nuts 475-739-0832, (AN365,) w 12 ea. -
Page 14: Post Installation Checkout
Post Installation Checkout After wiring is complete, verify power is ONLY on pin 21 of the connector, and airframe ground on bot- tom connector pin 22. Failure to do so will cause serious internal damage and void PS Engineering's war- ranty. -
Page 15: Sirius Module Checkout
SIRIUS Module Checkout Position the aircraft with a clear view of the sky. Turn on the PXE7300-SR and cycle the “Mode” until SR shown in the display. Select SIRIUS Channel 184 (preview channel). Verify that the no error message appears in the display, and a valid audio stream is detected. -
Page 16: Final Inspection
This interruption will be variable, depending on AGL altitude, distance, number of ground-based transmitters and azimuth to the transmitters. PS Engineering, Inc. does not guarantee SIRIUS Satellite Radio coverage in all areas, or the suitabil- ity of the SIRIUS Satellite Radio for any particular geographical area. -
Page 17: Section Iii Operation
PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual Section III OPERATION GENERAL INFORMATION SCOPE This section describes the operation of the PXE7300 In-Flight Entertainment system. Operating controls consist of two rotary knobs with push-push switches, and four buttons. -
Page 18: The R/S Button (4)
In contrast to an ADF, where audio fidelity is not important, the PXE7300 requires higher signal levels to ensure fidelity. For optimum performance, some installers may desire an external AM/FM antenna. PS Engineering rec- ommends a Comant CI-222-L. Another alternative is to connect the PXE7300 antenna input to an unused VOR port of the VHF NAV antenna splitter. -
Page 19: Sirius Module Operation
Table 1- PXE7300 Modes SIRIUS Module Operation The PSM7390 SIRIUS Satellite radio module is completely controlled by the PXE7300-SR unit. To acti- vate, push the “Mode” button until SR and channel number, are displayed on the PXE7300. When the module is activated by subscription, and the antenna has a clear view of the sky, SIRIUS audio will be pre- sent in the entertainment system. -
Page 20: Sirius Signal Drop Out
This interruption will be variable, depending on AGL altitude, distance, number of ground- based transmitters and azimuth to the transmitters. PS Engineering, Inc. does not guarantee SIRIUS Satellite Radio coverage in all areas, or the suitabil- ity of the SIRIUS Satellite Radio for any particular geographical area. -
Page 21: Section Iv- Warranty And Service
PS Engineering, Inc. The risk of loss or damage to the product is borne by the party making the shipment, unless the purchaser requests a specific method of shipment. In this case, the purchaser assumes the risk of loss. -
Page 22: Appendix A - Mp3 Creation
PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual Appendix A – MP3 Creation Creating MP3s from an Audio CD Start MusicMatch JukeBox.(www.musicmatch.com) Press the recorder button, which is the small red dot located in the top right corner. This will open the recorder window located at the bottom of the screen. -
Page 23: Appendix B - Installation Drawings
PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual Appendix B – Installation Drawings New Installation Figure 6-1 Panel Location Drawing (Typical) 120-973-8801 200-739-0001 Appendix D Rev. 2, January 2005... -
Page 24: Audio Panel
PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual FS 76.5 Top of windshield AM/FM Antenna Power to Circuit Breaker PSM7390 Cable (Note 1) (for Sirius System Only) Mounting Tray, 430-790-5000 PSM7390 Unit Location (Sirius System Only) - Page 25 PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual 6.25 1.97 Existing Avionics Mounting Rails (see detail A) Detail A B & C B & C #6-32 Screws 475-632-0012 (6 plcs) Clipnuts 475-630-0002 (6 plcs) 120-425-4402...
- Page 26 PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual Ø0.560in Rivet, as required, Min 1.0 between doubler NAS1097AD40-(GRIP) and existing structure 0.125" diameter Antenna Outline 2.000in 1.000in 0.826in Ø0.140 (4 places) 1.660 in Min 1.0 between doubler...
- Page 27 PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual Breaker Added was ADF Figure 6-5 Circuit breaker installation drawing 120-973-8802 (typical) 200-739-0001 Appendix D Rev. 2, January 2005...
-
Page 28: Appendix C Connector Interconnect
PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual Appendix C Connector Interconnect PXE7300 Connector NOTE 3 14- 28 VDC Aircraft Power (2 A Breaker standard 11970 units) 5 A Breaker for SR units) Aircraft Ground... -
Page 29: Airworthiness
Aircraft equipment list, weights and balance amended. Compass compensation checked. A copy of the opera- tion instructions, contained in PS Engineering document 200-730-( ), revision ( ), dated ( ), is placed in the aircraft records. All work accomplished listed on Work Order... -
Page 30: Master Drawing List
PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual Master Drawing List The following drawings are contained on the FAA-Approved Master Drawing List: PXE7300 Master Drawing List 002-739-2001 R1 Drawing Title In this Part Number Revision... - Page 31 PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual 200-739-0001 Appendix E Rev. 2, January 2005...
-
Page 32: Qualification Form
PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual Appendix E RTCA DO160D/EUROCAE ED-14D Enviro nmental Qualification Form Part Number: 11970 Manufacturer: PS Engineering Incorporated 9800 Martel Road Lenoir City TN 37772 Conditions Section Conducted Tests Temperature and Altitude... - Page 33 PS Engineering PXE7300 SR SIRIUS Satellite Radio IFE System Installation and Operator’s Manual Nomenclature: Satellite Radio Receiver Module, PSM7390 Part Number: 010-731-1030 Manufacturer: PS Engineering Incorporated 9800 Martel Road Lenoir City TN 37772 Conditions Section Conducted Tests Temperature and Altitude...
