  • Page 1 Any reproduction or retransmittal of this publication, or any portion thereof, without the expressed written permission of PS Engineering, Inc. is strictly prohibited. For further information contact the Publications Manager at PS Engineering, Inc., 9800 Engineering, Inc. is strictly prohibited. For further information contact the Publications Manager at PS Engineering, Inc., 9800 Engineering, Inc.

  • Page 2: Table Of Contents

    Section IV- Warranty and Service ..............................4-1 ..................................... 4-1 ARRANTY .................................. 4-1 ACTORY ERVICE Appendix A – MB10 Installation Drawings ............................. A Appendix B, J10 Interconnect ................................B Appendix C- Instructions for FAA Form 337 and continuing airworthiness ..................C FAA F 337............................C NSTRUCTIONS FOR ..................

  • Page 3: Section I General Information

    050-023-0101 EQUIPMENT DESCRIPTION The MB10-is a 3-light 75 MHz Marker Beacon receiver and indicator. This provides the necessary Marker Beacon lights and audio indications necessary for an Instrument Landing System (ILS) approach. A switch labeled Hi/Lo/TST allows the pilot select high or low sensitivity as well as test and mute modes.

  • Page 4: Equipment Supplied

    Audio Output: 38 mW <5% THD typical EQUIPMENT SUPPLIED 1 ea. of the following units: Model Description Part Number MB10 MB10 Marker Beacon Receiver and Indicator. 050-023-0100 MB10R MB10 Marker Beacon Receiver (remote) 050-023-0101 MB10 Installation Kits: 250-023-0100 250-023-0101 Description...

  • Page 5: Section Ii - Installation

    Section 1.6 (B). If any claim is to be made, save the shipping material and contact the freight carrier. Do NOT return units damaged in shipping to PS Engineering. If the unit or ac- cessories show any sign of external shipping damage, contact PS Engineering to arrange for a replacement.

  • Page 6: Mounting Requirements

    2.3.3 Connector Assembly The MB10 uses a 15 pin, solder cup Sub D connector. The antenna connector is BNC type, Female on unit. Cable Harness Wiring Referring to the appropriate Appendix, assemble a wiring harness as required for the installation. All wires must be MIL-SPEC in accordance with current regulations.

  • Page 7: Power

    2.4.1 Power The MB10-Series are compatible with both 14 and 28 Volt DC systems. A 0.5 Amp circuit breaker is re- quired for all installations. Power and ground wires should be #22 connected to J10 Pin 1. Connect airframe ground to J10 Pin 9only. No dropping resistors are required.

  • Page 8: Mb10 Pin Assignments

    Panel Installation The MB10 panel mount is installed from the back of the panel. After the holes are drilled, carefully feed the lamps and their wires through the lamp holes. Then secure the unit to the panel with the two #4-40 screws through the front plate, instrument panel, and into the unit.

  • Page 9: Remote Installation

    PS Engineering's warranty. Operational Checkout 2.9.1 Required Test Equipment In order to return an aircraft to service after installation of the MB10, the installer must have access to a Marker Beacon signal generator: IFR NAV401L, NAV402AP, IFR4000 TIC T-30D, T-36C Equivalent test equipment is acceptable as long as the testing requirements can be met.
  • Page 10 PS Engineering MB10 Marker Beacon Receiver Installation and Operator’s Manual Return completed warranty registration application to PS Engineering, or complete online at www.ps- engineering.com. 200-023-0001 Page 2-6 Rev. 10, Sept. 2016...

  • Page 11: Section Iii Operation

    GENERAL INFORMATION SCOPE This section provides detailed operating instructions for the PS Engineering MB10, Marker Beacon system. Please read it carefully before using the MB10 so that you can take full advantage of its capabilities. Figure 3-1 MB10 front panel Power Unit power is on whenever the avionics bus is energized.

  • Page 12: Section Iv- Warranty And Service

    PS Engineering, Inc. The risk of loss or damage to the product is borne by the party making the shipment, unless the purchaser requests a specific method of shipment. In this case, the purchaser assumes the risk of loss.

  • Page 13: Appendix A - Mb10 Installation Drawings

    PS Engineering MB10 Marker Beacon Receiver and Indicator System Installation and Operator’s Manual Appendix A – MB10 Installation Drawings Mounting Plate Instrument Panel 4.97 in 4-40 screw x 2 6.47 in Figure 5-1 Panel Mounting view 1.28 in 0.85 in Ø0.166 in...
  • Page 14 PS Engineering MB10 Marker Beacon Receiver and Indicator System Installation and Operator’s Manual 6.98 in 3.25 in 3.25 3.75 4.95 in Ø0.14 in 4 places 0.95 in 2.28 in Figure 5-3 Remote Mounting with 430-023-0030 (x2) flanges. Not to Scale...

  • Page 15: Appendix B, J10 Interconnect

    PS Engineering MB10 Marker Beacon Receiver and Indicator System Installation and Operator’s Manual Appendix B, J10 Interconnect MB10 Sub-D DB-15 Male Power In 11-33 VDC Aircraft Ground Marker Audio Hi Audio System Marker Audio Lo White Lamp Output Active Hi...

  • Page 16: Appendix C- Instructions For Faa Form 337 And Continuing Airworthiness

    Aircraft equipment list, weights and balance amended. Compass compensation checked. A copy of the operation instruc- tions, contained in PS Engineering document 202-023-( ), revision ( ), dated ( ), is placed in the aircraft records. All work accomplished listed on Work Order...

  • Page 17: Appendix D Rtca Do160E Environmental Qualification Form

    PS Engineering MB10 Marker Beacon Receiver and Indicator System Installation and Operator’s Manual Appendix D RTCA DO160E Environmental Qualification Form Marker Beacon Receiver Part Number: 050-023-( ) FAA TSO Number:C35d Manufacturer: PS Engineering Incorporated 9800 Martel Road Lenoir City TN 37772...
