Lancom 1721+ VPN Manual page 6

LANCOM 1721+
Management
Security
Scripting
SNMP
Timed control
Diagnosis
LANCAPI
CAPI Faxmodem
Statistics
Statistics
Accounting
Export
Hardware
Power supply
Environment
Housing
Fans
Power consumption (max)
Declarations of conformity
CE
Package content
Manual
CD
Cable
Cable
Cable
Cable
Power supply unit
Support
Warranty
Software updates
Options
VPN
Advance Replacement
Warranty Extension
Fax Gateway
Access rights (read/write) over WAN or LAN can be set up separately (Telnet/SSL, SSH, SNMP, HTTPS/HTTP), access control list
Scripting function for batch- programming of all command- line parameters and for transferring (partial) configurations,
irrespective of software versions and device types, incl. test mode for parameter changes. Utilization of timed control (CRON) or
connection establishment and termination to run scripts for automation. Scripts can send e- mails with various command line
outputs as attachments
SNMP management via SNMP V2, private MIB exportable by WEBconfig, MIB II
Scheduled control of parameters and actions with CRON service
Extensive LOG and TRACE options, PING and TRACEROUTE for checking connections, LANmonitor status display, internal logging
buffer for SYSLOG and firewall events, monitor mode for Ethernet ports
Available for all LANCOM routers with integrated ISDN interface. LANCAPI provides CAPI 2.0 features for Microsoft Windows to
utilize ISDN channels over the IP network
Softmodem for Microsoft Windows that makes use of LANCAPI to send and receive faxes via ISDN
Extensive Ethernet, IP and DNS statistics; SYSLOG error counter
Connection time, online time, transfer volumes per station. Snapshot function for regular read- out of values at the end of a
billing period. Timed (CRON) command to reset all counters at once
Accounting information exportable via LANmonitor and SYSLOG
12 V DC, external power adapter (230 V)
Maximum operating temperature 50ºdesigned for continuous operation at const. 35°C over 5 years; humidity 0–95%; non-
condensing
Robust synthetic housing, rear connectors, ready for wall mounting, Kensington lock; 210 x 45 x 140 mm (W x H x D)
None; fanless design without rotating parts, high MTBF
ca. 7 Watts
EN 55022, EN 55024, EN 60950
Printed User Manual (DE, EN) and Quick Installation Guide (DE/EN/FR/ES/IT/PT/NL)
CD with firmware, management software (LANconfig, LANmonitor, LANCAPI) and documentation
Serial configuration cable, 1.5m
1 Ethernet cable, 3m
ADSL cable, 3m
ISDN cable, 3m
12 V DC, external power adapter (230 V)
3 years
Support via Hotline and Internet KnowledgeBase
Regular free updates (LCOS operating system and management tools) via Internet
LANCOM VPN- 25 Option (25 channels), item no. 60083
LANCOM Next Business Day Service Extension CPE, item no. 61411
LANCOM 2- Year Warranty Extension CPE, item no. 61414
LANCOM Fax Gateway Option activates 'hardfax' within the router. Supports 2 parallel fax channels with LANCAPI ('fax group
3' without use of CAPI Faxmodem), item no. 61425
Scope of features: as of LCOS version 7.8x
