Specifications
Depth Capability
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1500 ft (500 m)
Power Output
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500 Watts (RMS); 4000 Watts (Peak-To-Peak)
Operating Frequency
917c Combo: . . . . . . . . . . . . . . . . 200 kHz and 83 kHz DualBeam PLUS™
957c Combo: . . . . . . 200 kHz, 83 kHz and 455 kHz QuadraBeam PLUS™
Area of Coverage
917c Combo: . . . . 60° @ -10 dB in 83 kHz and 20° @ -10 dB in 200 kHz
957c Combo: . . . . . . . 60° @ -10 dB in 83 kHz; 20° @ -10 dB in 200 kHz
and 35° (2) @ -10 dB in 455 kHz (90° Total Coverage)
Target Separation . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1/2 Inches (63.5 mm)
Power Requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-20 VDC
LCD
917c Combo: . . . . . . . . . . . . . . . . . 480 V x 800 H; 7" Diagonal Color TFT
957c Combo: . . . . . . . . . . . . . . . . . 480 V x 800 H; 8" Diagonal Color TFT
Transducer
917c Combo: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . XNT 9 20 T
957c Combo: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . XNT 9 QB 90 T
Transducer Cable Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 ft (6 m)
NOTE: Product specifications and features are subject to change without notice.
NOTE: Humminbird® verifies maximum stated depth in saltwater conditions,
however actual depth performance may vary due to transducer installation,
water type, thermal layers, bottom composition and slope.
POLICY ON ENVIRONMENTAL COMPLIANCE: It is the intention of
Humminbird® to be a good corporate citizen and comply and meet all known and
applicable environmental regulations in the areas and countries where our
products are sold. We will promote and implement environmentally sound
processes in support of national and international regulations.
ROHS STATEMENT: Product designed and intended as a fixed installation or
part of a system in a vessel may be considered beyond the scope of Directive
2002/95/EC of the European Parliament and of the Council of 27 January 2003
on the restriction of the use of certain hazardous substances in electrical and
electronic equipment.
WEEE STATEMENT: Product designed and intended as a fixed installation or
part of a system in a vessel may be considered beyond the scope of Directive
2002/96/EC of the European Parliament and of the Council of 27 January 2003
on waste electrical and electronic equipment (WEEE).
CALIFORNIA PROPOSITION 65 STATEMENT: Lead in cable jackets and boots
is restricted to 300 parts per million or less as determined by ICP-AES test
methods.
