Chart View (Navigating) with optional-purchase Navionics® Cartography
13
14
1
2
1 Next Waypoint
2 Depth
3
XTE (Cross Track Error): Distance of Boat from Route
4 Speed: the measurement of the boat's progress across a given
distance, and is the speed measurement provided by GPS
5 Course: the current direction the boat is traveling measured
in degrees from North
6 Bearing: Direction to Destination Waypoint
measured in degrees from North
3 4
12
9
7
5
88
11
10
1
8
6
Declutter Icons
Course Projection Line
Cartography
Map Scale
Track
7
8
Boat Icon
9
10
Route
11
Waypoint
12
13
14
