TransTel Communications TD-824i User Manual

Digital series single line telephone sets
Hide thumbs Also See for TD-824i:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Digital Series
TD-824i
TD-1648i
User Guide
Single Line Telephone Sets

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TD-824i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TransTel Communications TD-824i

Summary of Contents for TransTel Communications TD-824i

  • Page 1 Digital Series TD-824i TD-1648i User Guide Single Line Telephone Sets...
  • Page 2 Notification Notification is hereby given that TransTel Communications Inc. reserves the right to modify, change, update or revise this document from time to time as required without the prior obligation to notify any person, company or organization. Further, TransTel makes no warranty or representation, either express or implied, with respect to merchantability, or fitness of it's products for a ©...

  • Page 3: Table Of Contents

    TD-824i / TD-1648i Single Line Telephone User Guide Table of Contents Automatic Wake Up ..............4 Barge In (Override) ..............5 Call Doorphone................. 5 Call Forwarding................. 6 Call Pickup................7 Call Split ................... 8 Call Transfer ................8 Centrex/PABX Flash ..............9 CO Line Access ................

  • Page 4: Automatic Wake Up

    Automatic Wake Up Description: Automatic Wake Up allows you to program an audible indicator to notify you at a specific time. Once programmed, a timed reminder will automatically cancel upon maturation. To program: 1. Lift Handset . 2. Dial [7], [0], [0]. Enter the time that you want the wake up to activate in 24 hour format (hh:mm).

  • Page 5: Barge In (Override)

    Barge In (Override) Description: Barge In allows you to enter an existing conversation. Depending on system programming, you may barge in on a station or a CO line. 1. Lift Handset. 2. Dial a station number or directly access an outside line by dialing [8], [0], plus the line number (1-8).

  • Page 6: Call Forwarding

    Call Forwarding Description: Call Forwarding allows a station user to have his calls re-routed to another station within the system based on several different conditions. Types: All Calls (Always) Busy No Answer Busy/No Answer To program call forwarding on your telephone: 1.

  • Page 7: Call Pickup

    Incoming CO Line. A CO line is ringing the system. 1. Lift Handset and dial 8, plus the line number that is ringing (01-08 on TD-824i and 01-16 on TD-1648i. 2. If the line is ringing, you will be connected to it. If it is busy, you will receive busy tone.

  • Page 8: Call Split

    Call Split (Brokers Call) Description: Call Split allows you to alternate between two different parties. 1. Establish the first telephone call. 2. Press hookswitch. The first caller is on hold. 3. Establish the second call. 4. You now have both calls established. You may press hookswitch to alternate between the two callers as many times as you wish.

  • Page 9: Centrex/Pabx Flash

    1. Lift Handset . 2. Dial [8], plus the two digit line number (01-08 on the TD-824i, 01- 16 on the TD-1648i) that you want to access. 3. If the line is not in use and you are allowed access to the line, you will be connected to the line and you will hear CO dial tone.

  • Page 10: Co Line Queuing

    1. Lift Handset . 2a. Dial [9] for an available line in your CO group OR 2b. Dial [8] plus the line number (01-08 for TD-824i, 01-16 for TD- 1648i) for direct CO access. 3. The group (or individual line) is busy. You hear busy tone.

  • Page 11: Conference

    1. Lift Handset . 2. Dial a station number or directly access an outside line by dialing [8] plus the line number (01-08 TD-824i, 01-16 TD-1648i). You receive busy tone. 3. Press [#]. If you are allowed, you will be added to the conversation.

  • Page 12: Do Not Disturb

    Do Not Disturb Description: Do Not Disturb allows you to make your telephone Description: unavailable to other callers . This includes both intercom calls from other stations and any outside calls that would normally ring at your station. To activate: 1.

  • Page 13: Forced Account Code

    Forced Account Code Forced Account Codes allow you to override the toll control restrictions that may be in place on your telephone set. Only one code is valid on a telephone set with Forced Account Code capability. set. , [4], plus the Forced Account Code entry. ount code is entered correctly, you will be connected to vailable line in your dial 9 group.

  • Page 14: Intercom Calling

    Description: Intercom Calling 1. Lift Hands 2. Dial a stat Description: You may call other stations within the TD-824i/1648i 3a. If the stati system. a message 1. Lift Handset. to indicate 2. Dial the station with whom you wish to speak.

  • Page 15: Last Number Redial

    . The TD-824i/1648i will access an outside telephone automatically dial the number that you manually dialed in ove. tatus of the original call is not important for Last Number It does not matter whether the call is answered, doned, busy, or does not answer.

  • Page 16: Off Hook Voice Announce

    4. If the called station is on a Speakerphone call, you will continue to hear busy tone. Operator Access Description: TransTel TD-824i/1648i systems may have one or more stations designated as system operators. 1. Lift Handset. 2. Dial [0]. 3. The station programmed as your operator will ring.

  • Page 17: Paging

    Paging Description: Paging allows you to make a voice announcement ® over some or all Superkey Electronic Telephone Sets. If your system is equipped, you may also make a voice announcement over external public address equipment. Types: Internal Zone Paging Internal All Zone Paging External Zone Paging External All Zone Paging...

  • Page 18: Room Monitor

    To program a 1. Lift Hands 2. Dial [7], number (0 3. If you wan Room Monitor (TD-824i first line in Description: Room Monitor allows you to monitor the ambient 4. Enter the t activity in another room. 5. Hang up.

  • Page 19: Speed Dialing

    Speed Dialing Speed Dial allows single line telephone users to access numbers stored in the telephone system. m Speed Dial onal Speed Dial stem Speed number: 5], plus the three digit speed dial storage location. sonal Speed number: set. , [0] plus your speed dial location (0-9). a personal speed dial number: set.

  • Page 20: Station Lock/Unlock

    Station Lock/Unlock Description: Station lock allows you to restrict you telephone from making calls to any numbers other than those that appear in the system list of common allowed numbers. To lock: 1. Lift Handset 2. Dial [7], [0], [9]. 3.

  • Page 21: Timed Reminder

    Timed Reminder Description: Timed Reminder allows you to program an audible indicator to notify you at a specific time each day. Once programmed a timed reminder will remain in the system until de-activated. To program: 1. Lift Handset . 2. Dial [7], [0], [0]. Enter the time that you want the reminder to activate in 24 hour format (hh:mm).
  • Page 22 System Speed Dial Entries System Speed Dial. Dial 75 + 3 digit speed dial code. Issue 2.0 March 2006...
  • Page 23 Personal Speed Dial Entries System Speed Dial. Dial 750 + single speed dial digit code. Numeric Dialpad...
  • Page 24 Issue 2.0 / April 2006...

This manual is also suitable for:

Td-1648i

Table of Contents
