Page 10: General Description – Introduction
FCC Registration Number The TransTel TD-1648i/TDS-600 is registered with the FCC in a dual registration capacity enabling the system to operate as a key system only or as a hybrid system. The FCC Registration Numbers are 3A7KF03BGDS600 for key systems registration and 3A7MF03BGDS600 for hybrid operation.
Page 11: Compatibility Of The Telephone Network And Terminal Equipment
In the event of problem, you should contact your equipment supplier in the first instance.’ ISDN Installation For the ISDN unit (G2-SIU), TD-1648i/TDS-600 only offers ISDN S/T interface connection behind NT1 device. It could not be connected to “U” interface directly.
Page 12 Description The TD-1648i/TDS-600 is an advanced ISDN Digital hybrid telephone system employing a microprocessor stored program and digitally controlled solid state Time-division switching. The TD-1648i/TDS-600 system is specifically designed for small business as well as residential applications. At the forefront of the system design is a universal concept to adapting and connecting with a variety of communications devices.
Page 13: Key Highlights Of The Td-1648I/Tds-600 Series Include
Easy Installation • “Factory Ready” - All TD-1648i/TDS-600 Telephone systems are "ready to go" right out of the box. A well thought out default database is factory installed on each system which meets the needs for most installations. This alleviates hours of on site time, minimizing installation costs for both dealer and customer.
Page 14: Hybrid Phone
Hybrid Phone Use your current telephone equipment, such as Modems, cordless telephones, Answering machines, etc. Just plug this equipment into the Analog port of the key telephone and the call can be automatically transferred to the equipment when you are busy or do not answer. No extra wiring and programming. This feature provides easy installation and programming-free transfer of calls from the key telephone to Analog Single Line equipment.
Page 15 TransTel TD-1648i / TDS-600 - General Description TransTel Telephone Model DK-1D / DK1-S DK-ACP Access Control Phone TransTel Telephone Model DK-2 DK-ATA Analog Terminal Adapter...
Page 16: Mechanical Specifications (Key Service Unit)
MAXIMUM LOOP RESISTANCE/IMPEDANCE Key Telephone Less than 40 ohms 26 AWG / Single Line telephone Less than 800 ohms 26 AWG / Doorphone Less than 40 ohms Music Source Input Impedance 600 ohms Maximum Input 0.775 VRMS INTERNAL RELAY CONTACTS Type SPST Rating...
Page 17: Features
TransTel TD-1648i / TDS-600 - General Description Features System Features Account Code Capability ISDN Attendant Console Assignment Call Charge Metering Information Attendant Overflow Caller Identification Automatic Line Access Direct Inward Dialing Automatic Line Search Call Forward Internal / External Automatic Ringdown...
Page 19: Advisory Messages
TransTel TD-1648i / TDS-600 - General Description Station Features Advisory Messages Flash (Open Loop Timed Flash) System Hands-free Answer Back Personal Hearing Aid Compatibility Access to System Programming Headset Compatibility Account Code Capability Hold (Exclusive / System) Auto Hold Hold Recall...
Page 20: Parts & Peripherals
Parts & Peripherals System Modules Model Description G2-MMD KSU with Power Modular G2-MPU G2 128/144/300/600 Main CPU Controller G2-IPU G2-1648 Main CPU Controller / G2 128/144/300/600 Interface Control Card. G2-MSU Multi-Service Card (External Paging/ Relay/ Sensor / RS232/ MODEM Interface/ Door Phone / External MOH Interface) G2-TKU Trunk Card : 4 CO lines G2-PIU...
Page 21: System Installation - Introduction
G2-CIC Card (Caller ID Card - four port circuits) Digital Station Unit (G2-STU) • Voice Mail Unit (G2-VMU) • LAN Management Unit (G2-LMU) • Metering Card (G1-MDC) NOTE: Please follow the directions step by step. The TD-1648i/TDS-600 system should be installed in strict accordance with this manual.
Page 22: Site Requirements
Site Requirements Location Choosing the Right Environment • System should be installed in a clean, dry, secure location. This location must have adequate ventilation, and a temperature from 0 to 45 to 113 ), with 10% to 95% non-condensing relative humidity. ¡...
Page 23: Installation
TransTel TD-1648i / TDS-600 Programming Manual Installation Caution 1. This system should be installed by qualified service personnel. 2. Do not install the Power Supply unless you have read the following instructions and completed all the installation and wiring. 3. STATIC SENSITIVE DEVICES! Please handle with care.
Page 24: Card Introduction
Card Introduction 1. CN1: Power socket to connect to the main 11. CN12: STU 1 slot power unit (G2-PWU) 12. CN13: STU/SLU 2 slot 2. JP1: Reset jumper for flash memory 13. CN14: STU/SLU 3 slot 3. SW1: Cabinet position selection 14.
Page 25: Installing Cpu And Option Cards
TransTel TD-1648i / TDS-600 Programming Manual Installing CPU and option cards G2-IPU 1. SW1: Reset button 2. JP1: Terminators for bus expansion of multi-cabinet. 3. JP2: Terminators for bus expansion of multi-cabinet. 4. Socket for the HDLC controller for bus expansion of multi-cabinet.
Page 26: G2-Msu- Multi Service Card
G2-MSU- Multi Service Card 1. JP1: Grounding Jumper for some specific external paging device 2. MODEM connector for the external MODEM connection to the system 3. RS232 connector 4. Relay / Sensor / External Paging connector 5. CN3: Door Phone Interface (for DPU05) 6.
Page 27: G2-Stu Digital Station Card
TransTel TD-1648i / TDS-600 Programming Manual G2-VSC- Voice Service Card G2-STU Digital Station Card Install this G2-STU card on STU1, STU/SLU2, …, STU/SLU5 slot of the G2-MBU.
Page 28: G2-Slu Analog Station Card
G2-SLU Analog Station Card Install this G2-SLU card on STU/SLU2, …, STU/SLU5, SLU6 slot of the G2-MBU. G2-TKU- 4 Port CO Line Card Install G2-CIC card or G1-MDC card on G2-TKU (optional). Install this G2-TKU card on TKU1/TKU2/TKU3/TKU4 slot of the G2-MBU. Connect an attached cable between CN4 of G2-TKU to CN3 of G2-SLU for power failure transfer.
Page 29: G2-Cic- Caller Id Card
TransTel TD-1648i / TDS-600 Programming Manual G2-CIC- Caller ID Card Adjust JP1 of G2-CIC card for G2 use. And then install G2-CIC card on CN6/CN7 of G2-TKU card. Misalignment could damage both cards or the system.
Page 30: G2-Siu Isdn S/T Interface Card
G2-SIU ISDN S/T Interface Card Install this G2-SIU card on TKU1/SIU1 or TKU2/SIU2 slot of the G2-MBU. JP3(A,B,C): DC feeding jumper. Default is no DC output. If the internal ISDN device does not offer local power and need DC feeding to work. The related jumper of this internal ISDN interface needs to be set to “on”. Issue 1.0 March, 2006...
Page 31: Voltage Selection Check
TransTel TD-1648i / TDS-600 Programming Manual Caution: 1. When this jumper is on, users cannot loop “S” interface back to another “T” interface for testing purpose. Otherwise, it will damage this card! 2. Incorrect jumper set will also damage this card.
Page 32: Replace Fuses Of Power Supply
Replace Fuses of Power Supply Replace Cover Replace the cover and install the 4 screws removed earlier. Preparing the External Battery Backup The Key Service Unit can have two battery backup devices BBOX1 connected for emergency power when a power failure takes place. If you are installing an optional Battery Backup (BBOX1), make certain that there is adequate room for its installation.
Page 33: Charging The Battery
TransTel TD-1648i / TDS-600 Programming Manual Do Not Connect the Battery Backup at this time! Battery Backup should not be connected to the System power supply until all power up testing has been completed! Charging the Battery The rechargeable batteries are automatically charged when the KSU is plugged in.
Page 34: System Ground
Do not connect the grounding wire of the KSU to a computer, telex, or any other external device. Connecting Stations The station cabling for the TD-1648i/TDS-600 should be a home run from the jack to the telephone room. The termination should be at conventional 66 type connecting blocks or Krone or directly to the provided station connectors.
Page 35: Digital Key Telephone – Dk1 Series, Dk2 Phones And Dss Console
TransTel TD-1648i / TDS-600 Programming Manual Digital Key Telephone – DK1 Series, DK2 Phones and DSS Console Terminate the station wires with the connectors that are provided. The stations will connect to the G2-STU of KSU using the center two pins only (pins 2 - 3).
Page 36: Digital Key Telephone – Dk-1D Or Dk-1S With Slc1 Circuit Pack Installed
Digital Key Telephone – DK-1D or DK-1S with SLC1 Circuit Pack installed Terminate the station wires with the connectors that are provided. The digital station will connect to the G2- STU of KSU. Connections are to the center two pins of the connector (pins 2 – 3). Connect Tip terminal with GRN terminal (screws) of the modular jack, Ring with RED.
Page 37: Access Control Telephone – Acp
TransTel TD-1648i / TDS-600 Programming Manual Access Control Telephone – ACP Terminate the station wires with the connectors that are provided. The stations will connect to the G2-STU of KSU. Connections are to the center two pins of the connector (pins 2 – 3).
Page 38: Single Line Telephone (Connected To G2-Slu)
Telephones. Door Phone Connection One Door phone may be connected to the TD-1648i/TDS-600 system. A cable cover is provided with the KSU. Door phone cable can enter from either the top or bottom as desired. Remove one or both ends of the cover as required and route the door phone cable through the hole.
Page 39: Single Line Telephone (Connected To Ata)
TransTel TD-1648i / TDS-600 Programming Manual Single Line Telephone (connected to ATA) Terminate the station wires with the connectors that are provided. The stations will connect to the G2-SLU of KSU. Connect Tip terminal with GRN terminal (screws) of the modular jack, Ring with RED.
Page 40 Example: The following is the point to multi-point connection. The 1st ISDN interface needs the terminator because there is no other ISDN device connected after this ISDN interface of SIU card. The 2nd ISDN interface does not need the terminator because there is an ISDN Modem connected after this ISDN interface of SIU card.
Page 41 TransTel TD-1648i / TDS-600 Programming Manual S-Interface Connection: If the user has programmed the ISDN interface of SIU to a S-Interface, the wiring should be as the following: Bus Configurations on the S/T Interface: Point to Point: d1: 750m ~ 1000m; Length limitation by attenuation of 6dB at 96kHz.
Page 42: Optional Cabling
Connect the door switch to pins 1 and 6 of the RJ-11 connector. Sensor Connection The Sensor connector on TD-1648i/TDS-600 may be used for the External Sensor input. The sensor may be configured for normally open or normally closed operation.
Page 43: Music On Hold Connection
TransTel TD-1648i / TDS-600 Programming Manual Music on Hold Connection • Connect the (optional) external music source to the external Music" input labeled on the KSU. • Use a 1/8” mini plug to connect the music source to the KSU via an approved line isolation unit.
Page 44: Power On And Operational Test
Power On and Operational Test Before connecting the G2-PWU to AC power: Verify that input voltage and input voltage selection jumper on G2-PWU are correct before you power up the system. Recheck the cabling for incorrect connections, loose wires and wiring fragments that may cause short- circuits.
Page 45: Series Model Td-1648I/Tds-600 - Programming Manual
TransTel TD-1648i / TDS-600 Programming Manual Series Model TD-1648i/TDS-600 - Programming Manual Programming Information This document contains the system forms required to program the TD-1648i/TDS-600 and an explanation of the parameters. New Systems We recommend that all new systems have the system memory reset before system programming takes place.
Page 46: Basic Programming Commands
Basic Programming Commands For the first time or infrequent installer, a programming overlay is provided with each Key Service Unit. This overlay, when placed on a TransTel LCD telephone set indicates keys used during programming for easy reference. Experienced installers may program without the overlay. Both key designations are listed below. Note: Keys listed between [ ] indicate the default keys shown on a telephone set.
Page 47: Alphanumeric Entry
TransTel TD-1648i / TDS-600 Programming Manual Alphanumeric Entry The following table indicates the capabilities of the name programming functions if they are selected on the system. System Speed Dial, Personal Speed Dial, Stations, CO Lines and Sensors may be programmed with names.
Page 48: Form 01 - Day Ringing And Ringing Line Preference Assignment
Form 01 - Day Ringing and Ringing Line Preference Assignment Ring Type : Linear / Circular / Hunt / Private / Common (See Form 35-CO-07) Default General: This program assigns each incoming line to ring the programmed stations. The ringing methods can be LINEAR (ring the first available station), CIRCULAR (Ring the next station following the last station who just answered an incoming call), HUNT (Ring the first assigned station for a set period of time (Form 05-08-01) then if no answer ring the next ring assigned station then the next etc.) COMMON AUDIBLE (All stations will ring simultaneously)
Page 49: Form 03 - Door Phone Ringing Assignment Form
This program assigns the door phone to ring the programmed stations. Description: 1. There is one door phone port available in the TD-1648i/TDS-600. 2. Eight stations can be assigned to ring for the door phone. 3. To clear all entries press [REDIAL].
Page 50: Form 04 - Console (Operator) Assignment Form
Form 04 - Console (Operator) Assignment Form Console Group 01 04 – 01 - Default General: This program permits the selection of the consoles (system operators) in each station group. Description: 1. There are 8 console groups (Operators) available. 2. A total of four stations can be set to be the operator/console in each group. 3.
Page 51: Form 05-01 - System Parameters Form - Timers-1
TransTel TD-1648i / TDS-600 Programming Manual Form 05-01 - System Parameters Form - Timers-1 Form 05-01- Range of Entries Default Value Item Valid Description Default Settings Settings 05-01-01 Hold Recall Time 1=60 Sec 05-01-02 Exclusive Hold Recall Time 1=60 Sec...
Page 52 Form 05-01 Continued 05-01-05 - B EMIND YCLE INGING This parameter selects the length of time an incoming trunk call rings the system before a busy ring assigned station is reminded of the call. A muted, one-second ring will be given to the station through the speaker to indicate the call.
Page 53: Form 05-02 - System Parameters Form - Timers-2
TransTel TD-1648i / TDS-600 Programming Manual Form 05-02 - System Parameters Form - Timers-2 Form 05-02- Item Range Of Entries Default Item Valid Description Default Settings 05-02-01 SLT Dial Tone Timeout 5=15 Sec 05-02-02 SLT Inter-Digit Timeout 5=15 Sec 05-02-03...
Page 54 05-02-05 - K ELEPHONE LASH IMER MILLISECONDS This parameter permits the selection of Flash time for Key stations when pressing the [TRF/FL] key or an analog phone which presses flash and then dials 800 while connected to an outside line. After dialing 800 the flash signal will be sent to the CO line and the analog phone will reconnect to the line.
Page 55: Form 05-03 - System Parameters Form - Codes-1
TransTel TD-1648i / TDS-600 Programming Manual Form 05-03 - System Parameters Form - Codes-1 Form 05-03- Code Range Of Entries 0 - 1 0 - 1 0 - 1 0 - 9 0 - 9 2 - 4 0 - 1...
Page 56 05-03-05 - T CCESS The first digit that is checked for verification of a toll call. This has no effect on toll restriction within the system. It is only used to notify SMDR that a particular call is a toll call. See Form 14-01- In the United States, this parameter (if used) will generally be set to 1.
Page 57: Form 05-04 - System Parameters Form - Codes-2
TransTel TD-1648i / TDS-600 Programming Manual Form 05-04 - System Parameters Form - Codes-2 Form 05-04- Item Range of Entries 0 - 1 0 - 2 0 - 1 0 - 4 0 - 1 1 - 2 5 - 7...
Page 58 05-04-05 - R ESERVED 05-04-06 - S PEED ISTRIBUTION This parameter sets the number of speed dial numbers allocated to the system speed dial. Adding extra numbers to system Speed Dial reduces the number of personal Speed Dial numbers available to share between individual stations Numbers after backslash indicate sets available with name feature enabled.
Page 59: Form 05-05 - System Parameters Form - Codes-3
TransTel TD-1648i / TDS-600 Programming Manual Form 05-05 - System Parameters Form - Codes-3 Form 05-05- Item Range of Entries 0 - 1 0 - 6 0 - 9 0 - 9 0 - 9 Default Valid Item Settings Description...
Page 60 05-05-05 - N UNCTION This parameter enables the naming feature for trunks, extensions and speed dials. Features \ Values Display Name instead of number for Extension Directory Dial for Speed Dial Directory Dial for Extension V: The feature is enabled. Note 1: When any of the above features are enabled the total number of speed dial sets will be reduced by 300.
Page 61: Form 05-06 - System Parameters Form - Timer/Codes
TransTel TD-1648i / TDS-600 Programming Manual Form 05-06 - System Parameters Form - Timer/Codes Form 05-06- Item Range Of Entries 0 - 9 0 - 9 0 - 1 0 - 1 0, 1, 3 Default Valid Item Settings Description...
Page 62 05-06-04 - P OLARITY EVERSE ETECTION This parameter is to enable the Polarity Reversal detection feature for incoming caller hang up detection in Australia and some European countries. See Mode 14-01-08 for SMDR setting. Telecom will need to enable polarity reversal at the exchange. When reversal is enabled the system will hang up the exchange line when the incoming caller hangs up and the exchange sends a reversal to the system.
Page 63: Form 05-07 - System Parameters Form - Timer/Codes
TransTel TD-1648i / TDS-600 Programming Manual Form 05-07 - System Parameters Form - Timer/Codes Form 05-07- Item Range of Entries 0 - 1 0 - 1 0 - 1 0 - 7 0 - 9 Default Valid Item Settings Description...
Page 64 05-07-04 - DISA O PERATOR ECALL APABILITY IGITS IALED Setting Situation No dialing after the The VSU has The VSU has already first voice announced that the announced the invalid number announcement from called station is busy or a dialed number that has not the VSU.
Page 65 TransTel TD-1648i / TDS-600 Programming Manual 05-07-08 - R ESERVED...
Page 66: Form 05-08 - System Parameters Form - Timer/Codes
Form 05-08 - System Parameters Form - Timer/Codes Form 05-08-T Item Range of Entries 0 - 9 0 - 1 0 - 9 0 - 1 0 - 8 0 - 9 Default Valid Item Settings Description Default 05-08-01 Ring Hunt Interval 0=0 Sec.
Page 67 TransTel TD-1648i / TDS-600 Programming Manual 05-08-04 - DISA O PERATOR ECALL OCATION NSWER This parameter decides to which Console group an unsuccessful DISA call will be transferred if the called station has transfer enabled in 46-st-04. 0=Console for the Called Station's group (41-st-01)
Page 68: Form 05-09 - System Parameters Form - Misc
Form 05-09 - System Parameters Form - Misc. Form 05-09-T ITem Range of Entries 0 - 1 Default Valid Item Settings Description Default 05-09-01 Reserved 05-09-02 Busy Console Queuing (Intercom Calls) 0=Disable 05-09-03 Loop Disconnect Detection (CPC) 3=320 ms 05-09-04 DISA Busy Tone Detection 0=Disable 05-09-05...
Page 69 TransTel TD-1648i / TDS-600 Programming Manual 05-09-05 - R ESERVED 05-09-06 - UCD E NABLE This parameter is to set the time duration before the system answers an incoming call when the ring assigned station(s) are busy, if a VMU card is installed. The incoming call will show as a normal ring signal on the DSS key and can be answered by the operator at any time even while the voice message is playing to the caller.
Page 70: Form 05-10 - Voice Mail Leading Digits
Form 05-10 - Voice Mail Leading Digits Form 05-10-T Range of Entries Default Valid Item Settings Description Default 05-10-01 0 -9,*,# Leading Digit 1 For Voice Mail Forwarding d = None 05-10-02 Leading Digit 2 For Voice Mail Forwarding d = None 05-10-03 HOLD Leading Digit 3 For Voice Mail Forwarding...
Page 71: Enhanced Protocol
TransTel TD-1648i / TDS-600 Programming Manual Enhanced Protocol Enhanced Protocol is a more sophisticated means of integration with most voice mails. Its use is preferable to that of the integration of 05-10 in most cases. Within the enhanced protocol the TD-824i defines specific types of calls.
Page 72: Message Waiting Digits
All Message Waiting levels for Voice Mail ports must be 9. Message Waiting level is set on Form 46-ext-02. Voice mail ports must be assigned to Hunt Group 1 in the TD-1648i. The Pilot number for Hunt Group 1 is assigned on Form 67-01.
Page 73: Form 05-11 - System Parameters Form - Supplemental
VSU (N TD-1648 UEUING TO OT APPLICABLE ON This parameter is not valid on the TD-1648i. It must be set to 0 = disable queuing in order for DISA to operate. 0 = Disable Queuing 1 = Enable Queuing 05-11-05 - DISA D...
Page 74 05-11-06 - DISA T RANSFER OUNT This function sets the number of times that an unsuccessful DISA call will attempt to retry a station and or transfer to a console after the ringing time set in Mode 05-08-06. A setting of 9 may cause trunks to lock up on systems that are completely unattended overnight.
Page 75: Form 05-12 - System Parameters Form - Miscellaneous
TransTel TD-1648i / TDS-600 Programming Manual Form 05-12 - System Parameters Form - Miscellaneous Form 05-12-T Item Range Of Entries 0 - 4 Default Valid Item Settings Description Default 05-12-01 Call Transfer Method – Key Telephone 0=Key Phone 05-12-02 Reserved...
Page 76 05-12-05 - V OICE NTEGRATION This parameter selects between Standard Voice Mail Call Forward Protocol and the Digit+ Extension protocol. For a full description of Voice Mail Protocol see Mode 05-10. This parameter will also enable or disable muting of the leading digits to the outside caller. 0=Use Form 05-10 DTMF Not Muted 1=Use Digit + Extension spec.
Page 77: Form 05-13 - System Parameters Form - Miscellaneous
TransTel TD-1648i / TDS-600 Programming Manual Form 05-13 - System Parameters Form - Miscellaneous Form 05-13-T Item Range Of Entries Default Valid Item Settings Description Default 05-13-01 Hot Dialing 1=Enable 05-13-02 Immediate SMDR output 0=Disable 05-13-03 Caller ID Buffer Block Size...
Page 78 05-13-04 - R ESERVED 05-13-05 - C ID D ALLER ISPLAY ETHOD defines whether the system will display the incoming name or number when new calls arrive at the system 0 = Display Number of incoming call 1 = Display Name of incoming call 5 = Display Name and number of incoming call 05-13-06 - CTI-T RUNK...
Page 79: Form 05-14 - System Parameters Form - Miscellaneous
TransTel TD-1648i / TDS-600 Programming Manual Form 05-14 - System Parameters Form - Miscellaneous Form 05-14-T Item Range Of Entries 0 - 4 Default Valid Item Settings Description Default 05-14-01 ISDN Recovery 0=Disable 05-14-02 Reserved 0=Reserved 05-14-03 Reserved 0=Reserved 05-14-04...
Page 80: Form 05-16 - System Parameters Form - Miscellaneous
Form 05-16 - System Parameters Form - Miscellaneous Form 05-16-T Item Range Of Entries Default Valid Item Settings Description Default 05-16-01 Reserved 0=Disable 05-16-02 Reserved 0=Reserved 05-16-03 Reserved 0=Reserved 05-16-04 Reserved 0=Reserved 05-16-05 Reserved 0=Reserved 05-16-06 Reserved 0=Reserved 05-16-07 Reserved 0=Reserved 05-16-08 ISDN Event Monitor...
Page 81: Form 06-01 - Relay Assignment Form
TransTel TD-1648i / TDS-600 Programming Manual Form 06-01 - Relay Assignment Form TD-MSC card has 1 dry contact relay. No voltage is provided by the system, the installer will have to provide their own source to suit the application. Only use the relays to switch 24V. They are only designed for low voltage control circuits.
Page 82: Form 07-Gp-Ip - Flexible Key Group Assignment
Form 07-gp-IP - Flexible Key Group Assignment General: This program assigns 8 groups of Flexible key plans for Key phones. Each Key phone can be assigned to use two groups (Form 41-st-(02 & 03)). Database Entry is as follows: 07-Gp-Key. For example: Form 07-01-01 Refers to Form 07 –...
Page 83 TransTel TD-1648i / TDS-600 Programming Manual Program Template For Key Assignment Instructions: When pro- gramming Form 07 to assign Form 07 various features to key groups, use the following key numbers and assign the de- sired feature accordingly. Ex- ample, if you want to make...
Page 84: Dk-2 Key Layout
DK-2 Key Layout Note: Keys 1 through 29 are programmable. Keys 30 – 34 are not currently usable on the TD-1648i Issue 1.0 March, 2006...
Page 85: Dk-3 Key Layout
TransTel TD-1648i / TDS-600 Programming Manual DK-3 Key Layout Note: Keys 31 – 32 are not currently usable on the TD-1648i.
Page 86: Form 08-Gp-Ip - Dss Key Group Assignment
Form 08-gp-IP - DSS Key Group Assignment General: This program assigns 2 groups of Flexible key plans for DSS Consoles. There are a total of 8 key groups available in the TD-1648i. Form 08-01 = DSS Key Group 1 Form 08-02 = DSS Key Group 2 Form 08-03 = DSS Key Group 3 ….
Page 87: Form 09-Nnn-Dp - System Speed Dial
TransTel TD-1648i / TDS-600 Programming Manual Form 09-nnn-DP - System Speed Dial General: This program permits the assignment of up to 500 sets of system speed dialing codes. Description: = 100-599 = Speed dial code, up to 500 sets in total.
Page 88: Form 10-Gp-Ip - Intercom Or Disa Single Digit Assignment
Form 10-gp-IP - Intercom or DISA Single Digit Assignment General: This program permits the stations in one or more station groups to call a specific station by dialing one digit only. To enable station Single Digit Dialing, Form 05-04-07 must be set to 1 = Enabled. The settings in this Form are also used by DISA Single Digit Dialing (Form 05-11-08 to enable for DISA use).
Page 89: Form 11 - Date And Time Settings
TransTel TD-1648i / TDS-600 Programming Manual Form 11 - Date and Time Settings Form 11 - Date and Time Item Input 01= Month 02=Date 03=Year 04=Hour 05=Minute 06=Day of Week (2 digits) (2 digits) (2 digits) (2 digits) (2 digits)
Page 90: Form 13 - System Passwords
Form 13 - System Passwords General: This program permits the assignment of 9 different passwords in the system. Description: The password length is from 1 to 8 digits. All unused digit positions must have ’d’ entered in them. Password No. 1 = Programming Password. System Default is None. Password No.
Page 91: Form 14 - Station Message Detail Recording
TransTel TD-1648i / TDS-600 Programming Manual Form 14 - Station Message Detail Recording Form 14 -01- Item Options 00-99 Default Item Valid Settings Description Default 14-01-01 Call Duration Start Time 0=00 Sec. 14-01-02 Record Incoming Call 0=Record 14-01-03 Record Local Call...
Page 92 14-01-06 - N UMBER OF ECORDS O BE RINTED ETWEEN EADERS This parameter permits the assignment of the number of records between each Header. If the Number = 00, The whole SMDR feature will be disabled. 01-99=Actual Number Of Call Records Between Headers 00=Disable SMDR 14-01-07 - RESERVED: 14-01-08 - D...
Page 93 TransTel TD-1648i / TDS-600 Programming Manual CASE EXPLANATION: CASE 1: October 2, 08:35 A.M., Station 112 made a call (telephone No. is 00116495256611) through line 1. The call lasted 2 minutes and 35 seconds, Account code No. 12345678 was entered for the call and 12-meter pulses were recorded.
Page 94 SMDR OUTPUT DATA FORMAT - NEW W CLI O UTPUT TK S TELEPHONE NUMBER Account MM/DD START DURATION RING UNIT 112 01 001188629645752 12345678 10/02 08:35 00:02'35" 00012 112 02 DDI Num:94150112 10/02 08:45 00:10'20" 00'10" CLI NoAns:294176288 10/02 12:00 00:00'00"...
Page 95: Form 17 - Forced Account Code Assignment
The Forced Account Codes may also be used as DISA passwords to allow call accounting to show which user was making an external call using DISA from outside the system. In the TD-1648i/TDS-600 , Forced Account Codes 25 to 48 can be used for this purpose. This feature will need to be enabled in Mode 05-11-02.
Page 96: Form 18 - Toll Plan Assignment
Form 18 - Toll Plan Assignment This Form assigns Toll Plans to trunk lines. The Toll plans are to be written in Forms 51 to 59 and 61 to 66. Description: 10 toll plans can be used. Each Toll Plan assigns each trunk line a Toll Class. It is possible to allow a toll class to have different restriction level on a line by line basis.
Page 97 TransTel TD-1648i / TDS-600 Programming Manual Form 18 - Toll Plan Assignment 18-00 - ITem Item Default 18-01 - ITem Item Default 18-02 - ITem Item Default 18-03 - ITem Item Default 18-04 - ITem Item Default 18-05 - ITem...
Page 98: Form 20 - Day/Lunch/Night Service Switching Schedule
Form 20 - Day/Lunch/Night Service Switching Schedule This program assigns daytime from Sunday to Saturday for automatic night switching and sets lunchtime to allow the VSU to play a different message for this period. All times must be in 24 hour format. Day Service Day Service Lunch Service...
Page 99: Form 25 - Reset Data To System Default
TransTel TD-1648i / TDS-600 Programming Manual Form 25 - Reset Data to System Default This program resets all data to System Default. All new systems must be reset to default before any programming in case corruption has been caused during handling or shipping. When using item 3 or 4 these must be done AFTER the system reset is performed.
Page 100: Form 29 - Co Line Specifications #1
Form 29 - CO Line Specifications #1 Data Range Default Item Valid Description Default Settings 29-tk-01 CO Line Length 0=0 km 29-tk-02 UCD-1 Function Enable 0=Disable 29-tk-03 ISDN Incoming Call Type 0= InBlock 29-tk-04 Set Ring Frequency (KPU Only) 0=H/set Setting 29-tk-05 Allow Audible Ring for Incoming Calls 0=All Stations...
Page 101 TransTel TD-1648i / TDS-600 Programming Manual -03 - ISDN I NCOMING This feature allows the user to set ISDN line to fit different incoming call types. 0 = InBlock Sending. The ISDN Central Office will send “Extension Called Party Number” or “Extension Sub- address Number”...
Page 102 -07 - CO D ELAYED IMER TO UNTING ROUP This parameter sets the delayed ringing time for an incoming call to the hunt group. If the stations in the Ringing Line Preference Assignment (Form 01/02) do not answer the incoming call within the timer listed below, the call will overflow to the pre-assigned hunt group (mode 29-TK-08).
Page 103: Form 35 - Co Line Specifications #2
TransTel TD-1648i / TDS-600 Programming Manual Form 35 - CO Line Specifications #2 Data Range Default Item Valid Description Default Settings Settings 35-tk-01 Trunk Type 0=CO 35-tk-02 Dialing Signal 1=DTMF 35-tk-03 External Call Forward 0=No 35-tk-04 DISA 0=No 35-tk-05 Pick Up...
Page 104 Form 35 Continued -05 - L NABLE LLOWS A NON RINGING STATION TO ANSWER AN INCOMING CALL Enable = An incoming call on this line can be answered by non-ringing stations. Disable = An incoming call on this line can not be answered by non-ringing stations. This feature is to assign "Private Lines"...
Page 105: Form 36 - Co Line Groups (Dial 9 Groups)
TransTel TD-1648i / TDS-600 Programming Manual Form 36 - CO Line Groups (Dial 9 Groups) General: This program permits each line to be assigned to different line (trunk) groups. There are eight groups in total. Description: In the bottom data-setting area, the line number (01-16) means that the trunk is included in the specified group.
Page 106: Form 37 - Busy Out Co Trunk
Form 37 - Busy Out CO Trunk This program permits the trunk line to be locked (busy out) by a Technician. This feature is used when the user does not want to use the trunk or to remove a problem line. When the trunk is set to BUSY OUT, the LCD display on the phone will display "...
Page 107: Form 38 - Alternate Co Line Groups (Dial 87 Groups)
TransTel TD-1648i / TDS-600 Programming Manual Form 38 - Alternate CO Line Groups (Dial 87 Groups) General: This program permits each line to be assigned to different groups which can be accessed by dialing [87]. There are 8 groups in total. This group will be available to a station in addition to it's dial 9 group. Set outgoing calls to start from the highest installed line and program in descending order to the lowest line installed.
Page 108: Form 39-000-Ip - Sensor Assignments
The SENSOR type may be normally open or normally closed and can be set to be activated in Day or Night switching or in both. Parameters 39-02 in the TD-1648i/TDS-600 set each sensor contact to be a normally open or normally closed type and set whether to work in Day or Night Mode or both.
Page 109: Form 40 - Station Class Of Service (Part 1)
TransTel TD-1648i / TDS-600 Programming Manual Form 40 - Station Class of Service (Part 1) Valid Item Settings Description Default 40-st-01 0-9,d Override/OHCA Level 1=Low 40-st-02 Monitor Level 1=Low 40-st-03 Limit Call Duration 0=No 40-st-04 Station Loud Bell 0=No 40-st-05...
Page 110 -06 - P AGING PEAKER This feature is useful for someone who should not be disturbed by paging calls. 0="All Page" will alert this station 1= "All Page" can not be received by this station -07- S TATION NLOCK TATUS If a phone becomes locked accidentally or the user forgets their lock code, this parameter will unlock the phone.
Page 111: Form 41 - Station Specifications
TransTel TD-1648i / TDS-600 Programming Manual Form 41 - Station Specifications Valid Item Settings Description Default 41-st-01 Station Group / Agent Group for UCD 41-st-02 Key Group For KeyPhone 41-st-03 Shift Key Group For KeyPhone 0=None 41-st-04 Dial 9 trunk group...
Page 112: Form 42 - Personal Speed Dial Table Assignment
Form 42 - Personal Speed Dial Table Assignment Default Numerical -01 DSS -02 42-___- 42-st-IP SPD-T st = Station No. (2-4 digits) IP = 01-02 blocks (2 max.) for a Station b1 b2 Block 1 of Individual Speed Dial Codes (00-09 or DSS11~DSS20) Block 2 of Individual Speed Dial Codes (DSS1-10) General: This program divides sets of Individual Speed Dial into blocks for use by Stations.
Page 113: Form 43 - Port Assignments
Reserved 43-cn-08 00-99 Reserved cn = Position Number on Card (11-68) In the TD-1648i/TDS-600 , the port number consists of 2 digits 11~18: station ports on the 1 G2-STU card. 21~28: station ports on the 2 G2-STU or G2-SLU card...
Page 114 -03 – DSS K PORT ROUP SSIGNMENT This parameter is only of value if the device connected to the port is a DSS console. This number refers to the DSS key group to which the DSS will belong. DSS key group assignments (key maps) are configured on Form 08-group-key.
Page 115: Form 44 - Station Class Of Service (Part 2)
TransTel TD-1648i / TDS-600 Programming Manual Form 44 - Station Class of Service (Part 2) Valid Item Settings Description Default 44-st-01 System Alarm 0=Enable 44-st-02 Hold feature 0=Enable 44-st-03 Call Split 0=Disable 44-st-04 Manual Line 0=Disable 44-st-05 Headset feature 0=Disable...
Page 116 -06 - D : (System Programming Access) EFAULT ASSWORD If enabled, a station will have access to system programming. If not, the station will be unable to access system programming. 0=Enable 1=Disable -07 - DTMF R ECEIVER ONTROL FOR OICE MAIL ORTS This program controls the operation of DTMF detectors for each Voice mail Port.
Page 117: Form 45 - Station Class Of Service (Part 3)
TransTel TD-1648i / TDS-600 Programming Manual Form 45 - Station Class of Service (Part 3) Valid Item Settings Description Default 45-st-01 Intercom Call Limitation 0=Disable 45-st-02 Reserved 45-st-03 Reserved 45-st-04 Trunk Access 0=Enable 45-st-05 Inter-Group Station to Station Calls 0=Enable...
Page 118 -07 - S YSTEM PEED CCESS If this parameter is disabled then the station will not be able to access any of the Speed Dial numbers which have been unrestricted in Mode 05-05-03/04 if they conflict with the stations toll restrictions 0= Enabled –...
Page 119: Form 46 - Station Class Of Service (Part 4)
TransTel TD-1648i / TDS-600 Programming Manual Form 46 - Station Class of Service (Part 4) Valid Item Settings Description Default 46-st-01 Dial [87] Trunk Group 0= None 46-st-02 Send Message Wait Signal Level 1= Low 46-st-03 Automatic Answer Capability / Internal CLIP...
Page 120 -04 - DISA R ECALL APABILITY PERATOR NSWER If this parameter is enabled then when a DISA call rings an extension but the station is busy or does not answer (depending on setting) after the voice message announcing the status of the station is heard, the system will recall the operator after the assigned DISA transfer time.
Page 121 TransTel TD-1648i / TDS-600 Programming Manual -08 - R : (Applies only to stations equipped with Single Line INGLE ELEPHONE Telephones) This parameter allows selection of different ringing types for single line telephone. Use this feature for some Voice Mails, Answer Machines which are unable to detect the double ring cadence for intercom calls or where an incorrect ring count is detected before answer..
Page 122: Form 47-St-Ip - Hot Line Assignment
Form 47-st-IP - Hot Line Assignment St = Station No. (2-4 digits) 47-st HOT LINE Data. ( Extension Mode ) 47-st HOT LINE St= Station No. (2-4 digits) Data. ( SPEED DIAL Mode ) SPD:000 General: This feature allows a user to lift the handset and directly call a specific outside party through System Speed Dial or an Intercom Extension without dialing any digits.
Page 123: Form 50 - Station Class Of Service (Part 5)
TransTel TD-1648i / TDS-600 Programming Manual Form 50 - Station Class of Service (Part 5) Valid Item Settings Description Default 50-st-01 Reserved 50-st-02 Reserved 50-st-03 ISDN Incoming Call Display type 0=CLI 50-st-04 CTI-Extension Status Report 0=Disable 50-st-05 Voice Mail Auto Logon Function...
Page 124: Form (51 To 59)-Code-Ip - Toll Plans – Allowed Digits – Class 1 To 9
Form (51 to 59)-code-IP - Toll Plans – Allowed Digits – Class 1 to 9 Toll Control Forms Forms 51 through 56 set exceptions (allow) to rules defined in corresponding forms 61 through 66. Form 51 & 61 correspond to toll class setting 1 as per Form 18 of the Td-824i. Forms 52 & 62 correspond to toll class setting 2, through forms 56 &...
Page 125: Form (61 To 66)-Code-Ip - Toll Plans – Restricted Digits – Class 1 To 6
TransTel TD-1648i / TDS-600 Programming Manual Form (61 to 66)-code-IP - Toll Plans – Restricted Digits – Class 1 to 6 General: This program sets Restricted numbers for Toll Class 1. These forms should be read in conjunction with Forms 51 to 56.
Page 126: Toll Control Examples
Toll Control Examples This example is based on a location where 911 is enabled and all local calls are placed by dialing a 7 digit number. The customer wants calls only allowed to 911 and 1-800, 1-888 and 1-877. No local calls are permitted. Set Form 41-11-05/06 = 7 When this form is set and Form 57 is still at default then station 11 will be totally restricted.
Page 127: Form 67 - Hunt Group Pilot Number Assignment
UMBER There are 10 Hunt Groups available in the TD-1648i/TDS-600 . Each Hunt Group is assigned a Pilot Number in this form. . It must be a unique number (it cannot be the same as an extension). It must be within the range of valid numbers for extensions (2 digit numbering plan 10-69, 3 digit numbering plan 100-699, 4 digit numbering plan 1000-6999).
Page 128: Form 68 - Day Hunt Group Assignments
System default 00 00 00 00 00 General: This program sets Stations into Hunting Groups 1 to 10 for the TD-1648i/TDS-600 assigns the order in which they will be accessed during Daytime. Description: There are 10 Hunt Groups available and 16 stations can be assigned into each group for Day and 16 for Nighttime.
Page 129: Form 69- Night Hunt Group Assignments
System default 00 00 00 00 00 General: This program sets Stations into Hunting Groups 1 to 10 for the TD-1648i/TDS-600 assigns the order in which they will be accessed during Night Service. Description: There are 10 Hunt Groups available and 16 stations can be assigned into each group for Day and 16 for Night Service.
Page 130: Form 70-Cd-Ip - Isdn Interface Specifications Program
2= Point to Multi-point and ignore the unknown MSN or DDI number (not assigned in mode 72) This application is normally for other ISDN device (e.g. ISDN TA, ISDN video conference, ISDN card, …) that is connected to NT1 with TD-1648i/TDS-600 together. Cd= 04 is for ISDN PLL (Phase Loop Lock) 0= Auto detect 1= Lock this ISDN line for PLL.
Page 131: Form 71-Tk - Reserved For Future Used
TransTel TD-1648i / TDS-600 Programming Manual Form 71-tk - Reserved for Future Used This form is reserved for future use. Form 72-St - ISDN Called Party Extension Number Assignment St= Extension Number 72-St ST NUM System default dddddddddddd 00 General: Assigns an ISDN MSN/DDI number to a station or station hunting group.
Page 132: Form 73-St - Isdn Extension Sub-Address Assignment
Form 73-St - ISDN Extension Sub-Address Assignment St= Extension Number 73-St ST Sub Add System default dddd General: Assigns ISDN Sub-Address Numbers to the internal extensions. Description: If the ISDN incoming call has the information of the Sub-Address number, system will ring this desired extension directly.
Page 133: Form 75-Num-Ip - Lcr - Analysis Table
TransTel TD-1648i / TDS-600 Programming Manual Form 75-Num-IP - LCR - Analysis Table Num = 001-500 75-Num-IP Dg Tab System Default. - - - - - - - - - - Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- -----------...
Page 134: Form 76-Num-Tm - Lcr – Routing Table
Form 76-Num-Tm - LCR – Routing Table 76-Num-Tm Rou Ta Num = 01~60 Tm = Time Schedule A, B, C System Default. 00 00 0 00 0 00 Item Display Pointer Data Programming Data Description Default ---------- ---------- ----------------------------------------------------------- ----------- 01,02 00~23 Starting Hour of this Routing Table...
Page 135: Form 77-Num - Lcr – Modifying Table
TransTel TD-1648i / TDS-600 Programming Manual Form 77-Num - LCR – Modifying Table 7 7 - N u m - I P M o T a b Num = 01~99 0 0 d d d d d d d d d d System Default.
Page 136: Form 78-St-Ip - Station Class Of Service – 6
Form 78-st-IP - Station Class of Service – 6 st = Station No. (2-4 digits) IP = 01-08 78-st-IP STCOS System Default 0 0 0 0 0 0 0 0 Valid Item Settings Description Default 78-st-01 LCR - Routing Level 78-st-02 LCR –...
Page 137 TransTel TD-1648i / TDS-600 Programming Manual -03 - 1A2 E MULATION TATION ROGRAMMING When an extension talks with a trunk, other extensions can make a conference by pressing this trunk's button if 1A2 Emulation is allowed. 0 = No 1A2 Access...
Page 138: Form 83-St-Ip - Caller Id Block Assignment
Form 83-st-IP - Caller ID Block Assignment st = Station No. (2-4 digits) IP = 01-02 83-st-IP CLI-T blocks (2 max.) for a Station b1 b2 b1/b2: Block 1/2 of Caller ID buffer for each extension General: This program divides sets of Caller ID history buffer into blocks for use by extension. Description: Program 05-13-03, the Individual CLI history buffers are assigned: 05-13-03...
Page 139: Form 84-Ip - Home Area Code
TransTel TD-1648i / TDS-600 Programming Manual Form 84-IP - Home Area Code 84-01-01 NNN = Assigned home area code (3 digits maximum) General: This program assigns the home area code for the Caller ID redial feature. Description: 3-digit input maximum for this entry.
Page 140: Form 86-Nnn-Ip - Office Code Redial Pattern
Form 86-nnn-IP - Office Code Redial Pattern 86-nnn nnn = office code N = Redial Pattern General: This program assigns the redial pattern for different office co7des. Description: 0 = Redial pattern is NXX-XXXX (Local call: 7 Digit) 1 = Redial pattern is 1-NXX-XXXX (Local Toll: 1 + 7 Digit) 2 = Redial pattern is 1-NXX-NXX-XXXX (Local Toll: 1 + 10 Digit) CID Redial Feature for USA Market Retrieve the...
Page 141: Programming Cross Reference
TransTel TD-1648i / TDS-600 Programming Manual Programming Cross Reference Incoming Calls Ringing Assignment 01-tk-stn Day Ringing And Ringing Line Preference Assignment 02-tk-stn Night Ringing And Ringing Line Preference Assignment 05-01-05 Busy Reminder Tone Interval (Off-Hook Ringing / Busy - Camp-On)
Page 142: Intercom Calls
Intercom Calls Intercom Call Signaling 05-03-03 Intercom call signaling to electronic telephone sets Step Call 05-07-01 Intercom Step Call Type 41-stn-01 Station Group Assignment Dial Tone Pattern 05-03-07 SLT Dial Tone Pattern Options 05-04-07 Intercom Single Digit Dialing 10-grp-xx Single Digit Dialing Assignment 41-stn-01 Station Group Assignment Direct Station Select...
Page 143: Disa Single Digit Dialing
TransTel TD-1648i / TDS-600 Programming Manual 05-08-04 DISA Operator Recall Location ( No Answer) 05-08-06 DISA No Answer Recall Timer 05-08-07 DISA Transfer Timer - No digits dialed 05-11-06 DISA Transfer Count - Console busy 05-11-02 DISA Password - Optional extra passwords...
Page 144: Forced Account Codes
Forced Account Codes 17-nn Creating Account Codes 40-stn-08 Assigning Account Codes to Stations Call Limit 05-04-03 Call Limit Type 40-stn-03 Call Limit Duration (Class of Service - per station) Passwords 13-01 System Programming Password (default=none) 13-02 DISA Password (for using a trunk on DISA call) 13-03 Toll Override Password 13-04...
Page 145: Miscellaneous
TransTel TD-1648i / TDS-600 Programming Manual Miscellaneous Monitor 40-stn-02 Station Monitor Level Paging 40-stn-05 Station Paging Access 40-stn-06 Receive Page Over Speaker 41-stn-01 Station Page Group Call Forward No Answer Transfer Time 05-01-08 Call Forward-No Answer Timer Hot Line 09-spd-nn System Speed dial number for Hot Line use...
Page 146: By Program Type In Alphabetical Order
By Program Type in Alphabetical Order System Parameters 12/24 Hours Clock 05-04-04 ACD - 1 Enable Time 05-09-06 ACD - 1 Release Time 05-09-08 ACD - 1 Segment 2 Recall Time 05-09-07 Action For Call Duration Limiting 05-04-03 Auto Redial Pause Time 05-05-08 Auto Redial Ringing Time –...
Page 147 TransTel TD-1648i / TDS-600 Programming Manual Least cost routing (analysis table) 75-NUM...
Page 148 Least cost routing (modifying table) 77-NUM Least cost routing (routing table) 76-NUM Least cost Routing – Weekly Holiday 05-13-07 Least cost Routing – Weekly Weekend 05-13-08 LED Indication Of Check In/Check Out 05-12-07 Linear/Circular Trunk Group Access 05-12-06 Make/Break Ratio 05-03-01 Message Waiting Method For Analogue Phones 05-04-08...
Page 149: Class Of Service/Station Programming
TransTel TD-1648i / TDS-600 Programming Manual Class Of Service/Station programming Access Paging 40-ST-05 ACP Assign key card to door phone ACP Delete key card ACP Password 13-05 ACP Encode key card ACP Register key card Alarm signaling type 44-ST-08 Allow Trunk Access...
Page 150 System speed dial access (all/only restricted area) 45-ST-07 Telephone/ACP setting 46-ST-08 Toll Plan – Day 41-ST-05 Toll Plan – Night 41-ST-06 Use Engineering Password 44-ST-06 Issue 1.0 March, 2006...
Page 151: Transtel Key Telephone Operation Manual
TransTel TD-1648i / TDS-600 Programming Manual TransTel Key Telephone Operation Manual. Introduction This section is devoted to an explanation of the implementation and operation of TransTel electronic telephones (keysets). Included are normal functions that are available to most station users and functions that are available only to console operators.
Page 152: Answering Calls
Alternate Trunk Group Access (Dial 87) In some applications, you may have more than one type of outside line. If you do, you will probably use this method to access your secondary lines. Lift the handset or Press SPKR. Dial 87. You will be connected to an available line in your alternate trunk group.
Page 153: Answering A Doorphone
External Calls Not Ringing At Your Set Calls With CO Line Appearance: Incoming calls on a line that appears on your set may be picked up by pressing the flashing CO line key. You will be connected to the call. Note: This feature depends on system programming.
Page 154: Automatic Last Number Redial
2. Press [MSG]. Your telephone set will return to an idle condition. To respond to a Callback: 1. If you are on a conversation and a callback has been left on your telephone and you have an LCD display it will indicate in the lower portion of the LCD: MSG ST:XX Also, your Message key will flash.
Page 155: Automatic Saved Number Redial
Automatic Saved Number Redial This feature is similar to Automatic Last Number Redial, but it adds the ability for you to save a number, dial some other calls and then come back to it later. After you have dialed an outside call, Press SAVE.
Page 156: Call Forwarding
Redial Caller ID Number: 1. Press the [REDIAL] key. The system will place the call for you automatically. The current Caller ID record will be dialed back. Delete Caller ID Record: 1. While reviewing a Caller ID record, you may delete it by pressing the [TSF] key. To exit Caller ID Review Mode: 1.
Page 157: To Forward Calls When You Don't Answer Or Are Busy
To forward calls when you don’t answer or are busy: Press PGM. Enter CFD Dial the extension number where you want to forward your calls. Enter 3 for No Answer / Busy Conditions. Dial the extension number where you want to forward your calls. Your telephone will return to idle.
Page 158: Call Swap
Press 8 on the dial pad. Press 1 - 8 for the group that you want to pick up. You will be connected to the caller. Call Swap If you want to alternate between two callers, this feature allows you to do so quite easily. You are speaking with the first caller.
Page 159: Conference
2. Dial the extension number to be unrestricted. 3. Press [SAVE]. 4. Press [SPK] to return the set to idle. Check Out: 1. Press [Hotel] and the digit 2. 2. Dial the extension number to be restricted. 3. Press [SAVE]. 4.
Page 160: Selecting Day Or Night Mode When In Manual Switching Mode
operator to do this. The change from day to night service may be either automatic, or it may be under manual control of the operator. Selecting Manual or Automatic Switching: Press PGM. Press TRF/FL. Your telephone will display the current mode (day or night) and status (automatic or manual). By pressing the * key you will “toggle”...
Page 161: Direct Trunk Access
Direct Trunk Access Using this method, you can “punch in” to an outside line. Lift the Handset or Press SPKR (Optional). Press CO trunk button. You will be connected to the CO line you pressed (if you have access to it). Do Not Disturb You can block incoming ringing from individual extensions, including paging announcements to them.
Page 162: Flash (To An Outside Telephone Line)
Digital LCD telephones allow you to select, activate and program most system features even if you do not have all the keys that are required to program. This is called the feature menu. 1. Press [PGM],[0] . The LCD will begin scrolling through the feature menu. Each menu item will be displayed for two seconds.
Page 163: Immediate Co Line Access
Handsfree Dialing (External): 1. Press a [CO] line button or dial [9]. The [SPK] follwed by the [MIC] button will light and you will be connected to an outside line. 2. Dial the number that you wish to reach. You will hear all call progress over the telephone's internal speaker.
Page 164: Lock / Unlock Smdr From Console
Lock / Unlock SMDR from Console If your system is equipped with an RS-232 port and is using a printer to keep a telephone log, you can temporarily suspend the output of the RS-232 port so you can change the paper on the printer or for any other reason where the printer needs to go off line.
Page 165: Operator Timed Reminder Or Wake Up
Operator Timed Reminder or Wake Up Note: This sets a message only on your own station! Press PGM. Press HOLD. Press 8. Enter the time you want the reminder to occur (must be in 24 hour format). Enter the duration (01 through 98). That is how long you want the reminder period to be. This type of reminder will occur every day at the same time.
Page 166: Saved Number Redial
Saved Number Redial Saved Number Redial allows you to save a telephone number for use at a later time. This feature is in addition to Last Number Redial. Automatic Save: 1. You have dialed an outside call. The number does not answer or is busy. 2.
Page 167: Speed Dial Programming
Press SPD key. Dial 100 through xxx (for system speed dial). OR Dial 00 through 09 (for personal speed dial). OR press a DSS button (for personal speed dial). Speed Dial Programming There are three types of speed dial in the system, numeric personal speed dial, DSS personal speed dial and system speed dial.
Page 168: Station Lock / Unlock
Press the DSS button that you want to enter (DSS button 1 through 10). (If you want the speed dial number to access a specific telephone line every time it places the call, Press the MIC button and dial 0 plus the line number. Otherwise skip this step.) Enter the telephone number you want to dial.
Page 169: Timed Reminder Or Wake Up
While on the Speakerphone: Lift the handset. You are now in the handset mode. Timed Reminder or Wake Up With this feature, you can set an appointment reminder, that will alert you only once, or you can set a daily reminder that will happen every day at the same time (like when it’s time to stop working and go home).
Page 170: To Playback (Operator Only)
Please note that you cannot record one message and then record another message at another time. When you record a message, you must record all messages, one after another. In the future, if you need to update a message, it will be necessary that you re-record all messages. To Playback (Operator only): Lift handset or press SPKR.
Page 171: Voice Mail Message Retrieval
Voice Mail Message Retrieval When messages have been left in your voice mailbox, you will notice a flashing MSG key on your telephone set. LCD equipped digital telephones will also have an indication of xx Messages. To retrieve your messages: 1.
Page 172: Intercom (As Doorphone)
Access Control Phone Operation Manual Intercom (as doorphone) Operation: 1. Press to call the associated hunt group and open the door; or 2. Dial extension number, then press to call an individual extension to answer and open the door. Note: calls the hunt group according to TD-824i system settings: ACP Hunt Group Routing - See Programming Form 46-st-07 (0-9 = Group 1 - Group 10) Hunt Group Pilot Number - Form 67-GP (GP = 01-10)
Page 173: Burglary Report
Burglary Report When the sensor is opened, ACP will signal PC for application of warning or asking help. (Not currently available) Time Display When ACP is idle, display will show the time (’08.30’ for 8:30AM). As a wall mount phone When ACP is in use of as a wall mount phone, ‘auto answer’...
Page 174: Dial 9 Access (System Option)
Station Function Form 46-st-08 There are three parameters under control of 46-st-08. 1. ACP Functions as: Doorphone b. Wall Mount Telephone 2. Door lock function activates the relay: in the ACP b. in the KSU. 3. Security Access is: a. Via password OR Identification Card b.

This manual is also suitable for:

Tds 600 series

TransTel Communications TD-1648i Installation Instructions Manual

Isdn Installation

Key Highlights of the Td-1648I/Tds-600 Series Include

Features

System Installation - Introduction

Site Requirements

Series Model Td-1648I/Tds-600 - Programming Manual

Programming Cross Reference

Transtel Key Telephone Operation Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TransTel Communications TD-1648i

Summary of Contents for TransTel Communications TD-1648i

This manual is also suitable for:

Table of Contents
