Note
For any keypress on the
Keychain Touchpad, hold
the button until the indicator
light blinks.
Note
Panic alarms need to be
silenced from the panel, a
remote handheld touchpad
or another keychain touch-
pad. They cannot be
silenced from the same key-
chain that activated the
alarm.
RF Thermostat
Operation
Programming
Your System
Simon Security System
LOCK Press once to arm doors and windows.
LOCK Press twice to arm doors, windows, and Motion Sensors.
LOCK Press 3 times to arm doors, windows, Motion Sensors, and to acti-
vate the Latchkey option.
LOCK and UNLOCK
Press both buttons simultaneously for 3 seconds to send a panic (intru-
sion, silent, or non-medical emergency) alarm to the central monitoring
station. Check with the installer to find out how the keychain touchpad
panic buttons will operate
UNLOCK Press to disarm your security system.
STAR Can be programmed to control a device connected to a universal module.
These guidelines must be followed for RF Thermostat operation:
• The panel needs to be armed to Level 4 (Doors & Windows and Motion Sensors)
to enter Energy Saving Mode.
• If there are no Motion Sensors in the system, the Motion Sensors button must still
be pressed (armed to level 4).
• Both Option 81 and 82 can be turned on at the same time.
• Thermostat has to be in Auto Mode for Options 81 and 82 to work correctly.
• When the panel is disarmed the thermostat returns to normal operating mode.
The programming decals are visible when you open the panel cover (see Figure 1.).
These decals are designed to make system programming easier for you. Always begin
by entering your access code. Then, choose an operation from the START MENU.
Follow the prompts and flow arrows to complete the desired task. Notice the button
flow diagrams following the Instruction Summary.
1.
Press Down
Doors & Motion
Windows Sensors Status
H O M E S E C U R I T Y
Arm
Disarm System
1 / 2 3 / 4 5 / 6 7 / 8 9 / 0
C O D E
Special
Doors Motion Time Sensor On Off
H O M E C O N T R O L
Chime Lights
E M E R G E N C Y
FIRE POLICE AUX
Test Weekly
Figure 1. Opening the panel cover

Programming Instructions

Use the following instructions to access the programming buttons and programming
decals.
2.
Open
Version 3 START MENU
Add Delete Cancel Test
System should be checked
by a qualified technician
* Press for program
at least every three years.
information. Cover
MAIN MENU
Light Sensor/ Access Clock
Control Option # Remote Code Set
* * *
0 1 2 3
CONTROL MENU Note:
Entry/Exit
Hold key or press
Unit # Delay Sensors Time - Hours +
* * * repeatedly until you
hear the desired item.
4 5 6 7 8 9
Instruction
Delete
Summary - Minutes +
To delete an option or access code
Delete
Add Option
press and follow the voice
Option #1: Panel Beeps prompting.
Option #2: Panel Voice DONE
Add Access Code
Option #3: Latchkey Time
Cancel
Option #36: Sensor Activated Light Lockout Start Time Add Access Code DONE
If you make a mistake or want to
Option #37: Sensor Activated Light Lockout Stop Time Press , then
Option #41: Chime Voice Cancel
See Note
Option #42: Speaker Volume start over press
use red numbers to enter 4-digit code.
Option #43: Pager Phone Number
Option #55: Status Beep Volume Sensor or Phone Test
Set Clock
Test
Add Option # Clock Set Hours Minutes DONE
To select a test, press and
Press and follow voice prompts. Press
follow the voice prompting.
See Note See Note
