Autostart AS-6650TW-FM User Manual

Two-way 6-button lcd automatic/manual transmission remote starter system with full alarm system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
T W O - W A Y
T R A N S M I S S I O N
A note concerning the battery inside the transmitter:
Depending on your usage of the transmitter, the battery can last anywhere between 3 to
6 months. When the battery is low, the transmitter will produce two beeps in a repetitive
cycle. At that point you should replace your battery with a new one. That is why we
recommend that you keep a spare battery somewhere handy such as the glove
compartment.
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (EIRP) is not more than that required for successful communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to
this equipment. Such modifications could void the user's authority to operate the equipment.
DOC.: 1.13
- 2W-FM-LCD-6020-CMB-A-M
6 - B U T T O N
W I T H
F U L L
AS-6650TW-FM
User Guide
It is the responsibility of the vehicle operator to ensure their vehicle
is parked in a safe and responsible manner.
1.
a) Manual transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in the NEUTRAL
position and the parking brake is engaged in order to avoid accidents
upon remote starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to
avoid accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is disabled
or put into valet mode before servicing.
L C D
A U T O M A T I C / M A N U A L
R E M O T E
S T A R T E R
A L A R M
S Y S T E M
WARNING
- September 14, 2007 -
S Y S T E M
- MO -
Assembled in Canada

Advertisement

Table of Contents
loading

Related Manuals for Autostart AS-6650TW-FM

Summary of Contents for Autostart AS-6650TW-FM

  • Page 1 W I T H F U L L A L A R M S Y S T E M AS-6650TW-FM User Guide WARNING It is the responsibility of the vehicle operator to ensure their vehicle is parked in a safe and responsible manner.

  • Page 2: Table Of Contents

    Table of Contents Introduction ............2 Relock............10 Vehicle Presets..........2 Secure Lock ..........10 Heater & Heated Seat ........2 Turbo Mode ..........10 Windshield Wipers, Radio & Headlights ..3 Remote Trunk Release ......10 Remote-Starting Your Vehicle ......3 Engine Run Time........

  • Page 3: Windshield Wipers, Radio & Headlights

    Windshield Wipers, Radio & Headlights Certain vehicles require the radio and / or windshield wiper and / or headlight circuits to become energized while running under remote start. When leaving the vehicle you must ensure that the windshield wiper and headlight switches are .

  • Page 4: Driving Off

     seconds later, the engine will start the parking lights will remain on during the pre-programmed run time of the engine. The remote control will play a second melody to confirm that the engine has started. If the vehicle does not start at the first attempt, the system will shut down. If your vehicle is equipped with an automatic transmission, there will be 3 start attempts before the system gives up.

  • Page 5: Turbo Mode

    Within 20 sec. push on the transmitter. LOCK UNLOCK START/STOP The parking lights will flash 3 times quickly and remain lit. Remove the key: the engine will go on running. Exit the vehicle and close the door. Press the button until the system is armed (the doors will be locked if remote door lock TRUNK is installed).

  • Page 6: Ignition Valet

    2. Within 3 seconds, press and release the valet button. The parking lights will flash twice and the L.E.D. will turn itself off. — The icon will disappear from your LCD remote. Note: Once valet mode is activated, the remote starter and alarm functions will be disabled. Ignition Valet This feature will allow you to remotely put your system into valet mode by using the ignition key instead of the valet button as above.

  • Page 7: Panic Mode

    The transmitter will beep once and the icon will display. To take the system o u t o f home valet mode: • Turn the ignition key to the position. IGNITION ON (RUN) The system will warn you if someone attempts to start your vehicle while it stands in Home Valet Mode.

  • Page 8: Temporary Chirp Delete

    • Press the button until you hear a beep. Release the button and will FUNCTION FUNCTION appear on the display. Then press the button for 3 seconds (the parking lights will START/STOP flash once). When the system exits cold weather mode, the remote control will beep once and the icon will disappear.

  • Page 9: Shock Sense, Warn-Away Sense

    Note: If the starter kill is installed, your vehicle will benefit from a protection against starter motor damage that could occur after remote-starting the engine should the user, by force of habit, turn the ignition key to the position. CRANK Shock Sense, Warn-away Sense Your system will react to a full shock by triggering the alarm;...

  • Page 10: Ignition Re-Lock

    Ignition Re-lock On systems of this series, when ignition-controlled door locks are enabled and the ignition key is in position, should any door be unlocked and opened, all doors will be relocked IGNITION ON (RUN) next time the brake pedal is pressed. Relock If you unlock the doors with the remote transmitter, but do not open any doors, hood or trunk, or turn ignition within 30 seconds, the doors will automatically relock and rearm the system.

  • Page 11: Multi-Car Operation

    Press the button for 1 second and release; you will hear a beep. L-01 will appear on the screen. Immediately press the button and hold it until the temperature is displayed on the LCD screen. Note: to change the temperature from Celsius to Fahrenheit, press simultaneously.

  • Page 12: Multi-Level Features (Default State)

    Multi-Level Features ( default state) Basic Features (press the button 1X FUNCTION ......... aux 2 FUNCTION LOCK: ........cold weather FUNCTION START/STOP Multi-Car Operation (press the button 2X) FUNCTION :....car lock FUNCTION FUNCTION LOCK :....car unlock FUNCTION FUNCTION UNLOCK : ..

  • Page 13: Intrusion Codes Through The Led Light

    Level 2 Multi car operation (requires pressing the button 2X) FUNCTION Level 3 Basic features (requires pressing the button 3X) FUNCTION Option 4: Level 1 Basic features (requires pressing the button 1X) FUNCTION Level 2 Customized features (requires pressing the button 2X) FUNCTION Level 3 (...

  • Page 14: Using The Remote Control

    • The operating range will be somewhat lower on vehicles equipped with an aftermarket or factory alarm. Using the Remote Control Function Button: . Turns On the backlight . For accessing Multi-level Button AUXILIARY . Activates AUX 2 functions . Or Stops the engine (If programmed as Stop Button) LOCK Button:...

  • Page 15: Transmitter Mode Selection

    Light ON ON for 5 seconds Press the button once. Transmitter Mode Selection FUNCTION BUTTON PRESSED ICON BUZZER INSTRUCTIONS /DESCRIPTION Press the button then UNLOCK POWER-SAVING Melody press FUNCTION LOCK MODE simultaneously VIBRATION MODE Vibrates 4 times Press once to switch the Alarm ALARM CLOCK Clock ON Melody...

  • Page 16: Cold Weather Mode

    Cold Weather Mode FUNCTION BUTTON PRESSED ICON BUZZER INSTRUCTIONS /DESCRIPTION TO ENTER COLD BEEP Press and release then WEATHER MODE TO EXIT COLD press and hold for 3 None BEEP WEATHER MODE seconds. Home Valet FUNCTION BY PRESSING ICON BUZZER INSTRUCTIONS / DESCRIPTION Step 1 : Press...

  • Page 17: Lcd Transmitter Operation (Second Car Control)

    LCD Transmitter Operation (Second Car Control) Basic Vehicle Operation FUNCTION BUTTON PRESS ICON BUZZER DESCRIPTION Locks the doors LOCK 1 Beep and arms the Starter Kill (if installed) and the alarm. Unlocks the doors and disarms UNLOCK 2 Beeps the Starter Kill (if installed) and the alarm.

  • Page 18: Diagnostics - Parking Light Flash Table

    Diagnostics – Parking Light Flash Table Flashes Description • Doors locked, Alarm and starter kill armed. • Start signal received by the module. • Run time has expired. • Cold weather mode cancelled. • button pressed. TRUNK • Remote start attempt cancelled by remote. •...
