Autostart AS-6450VTW-FM User Manual

Autostart two way led automatic/manual transmission remote starter with full alarm system user guide
Hide thumbs Also See for AS-6450VTW-FM:
Table of Contents

Advertisement

Quick Links

Download this manual
T W O - W A Y
T R A N S M I S S I O N
A S - 6 4 5 0 v T W - F M
FCC USER NOTICE (U.S.A.):
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to
this equipment. Such modifications could void the user's authority to operate the equipment.
DOC. 1.00
-AS-6450vTW-FM -
L E D
W I T H
F U L L
User Guide
It is the responsibility of the vehicle operator to ensure their vehicle
is parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in the NEUTRAL
position and the parking brake is engaged in order to avoid accidents
upon remote starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to
avoid accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is disabled
or put into valet mode before servicing.
- October 18, 2007 -
A U T O M A T I C / M A N U A L
R E M O T E
S T A R T E R
A L A R M
S Y S T E M
WARNING
- MO -
Assembled in Canada

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS-6450VTW-FM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Autostart AS-6450VTW-FM

Summary of Contents for Autostart AS-6450VTW-FM

  • Page 1 (Note: Make sure that the automatic vehicle cannot start in "Drive".) 2. It is the user's responsibility to ensure that the remote starter is disabled or put into valet mode before servicing. FCC USER NOTICE (U.S.A.): This device complies with Part 15 of the FCC Rules.

  • Page 2: Table Of Contents

    Using the Remote Control Your remote starter is equipped with a 5-button, multi-channel, 2-way remote control. It can operate two independent vehicles equipped with the same remote starter (see Multi-car operation section on page 15). The functions of the transmitter are as follows: P.

  • Page 3: Feature Confirmation Chart

    • Pressing and holding the constant pulse as long as the constant pulse can be configured to activate certain functionalities such as rolling up the windows – Please refer to your installer to see if your vehicle is compatible with this option.

  • Page 4: Vehicle Status Request

    Vehicle Status Request The status request feature allows the user to see the status of the vehicle i.e.: if the doors are locked or unlocked or if the vehicle is in cold weather mode, home valet mode, in valet mode or how much time is left in the run time cycle.

  • Page 5: Status Request When The Engine Is Running

    Status Request When the Engine is Running When the vehicle’s doors are locked: Run time Stage stage If there is more than 3/4 of run time cycle stage stage If there is more than half of run time cycle stage stage If there is more than 1/4 of run...

  • Page 6: Alarm Status

    Alarm Status Status Stage If door is Door opened If hood is Hood opened If ignition is Ignition turned ON If shock Shock activated If trunk is Trunk opened Remote Valet switch Finder on for 3 sec How Run Time Cycles Work LED #1 will turn Run time cycle itself off when ...
  • Page 7 SHIFT SHIFT SHIFT SHIFT Customized Features (press the (May not be applicable for certain vehicles) Your installer can add customized features such as turning on the radio, opening sliding doors, etc. SHIFT SHIFT SHIFT SHIFT SHIFT SHIFT SHIFT SHIFT Setting Transmitter Features (press the By default, the multi-level features are programmed as follows: Level 1 (Basic Features) Level 2 (Multi car operation)

  • Page 8: Remote Starting Your Vehicle

    1 second. The parking lights will come START/STOP transmitter will beep once to inform you that the remote starter has received your signal. Approximately 5 seconds later, the engine will start. The transmitter will beep 3 times and the parking lights will remain If the vehicle does not start at the first attempt, the system will shut down.

  • Page 9: Vehicle Presets

    This feature allows you to let the remote starter take control of the vehicle (i.e. no Key in the Ignition Switch) while the engine is running.

  • Page 10: Turbo Mode

    To leave the vehicle in Idle Mode if your vehicle has an automatic transmission: With the engine running, make sure to release the brake pedal and press the button (to unlock the doors, if installed) or the until the parking lights come on or you hear a series of clicks. Remove the key and exit the vehicle.

  • Page 11: Valet Modes

    TRUNK Valet Modes When your vehicle is in valet mode, the remote starter functionalities and alarm are disabled. If the vehicle needs to be serviced, or if you park it indoors, valet mode will prevent the engine from being remote started accidentally.

  • Page 12: Home Valet Mode

    The parking lights will flash 2 times. The LED will turn off. Note: Once the remote valet is activated, the remote starter and alarm functions will be disabled. Home Valet Mode If configured at installation, this feature will set the vehicle to a no-remote-start mode: if the vehicle is parked indoors there is no danger of it starting accidentally by remote control.

  • Page 13: Advanced Features: Installation-Programmable Options

    In passive mode, the starter kill will automatically arm 30 seconds after the last door is closed or the ignition is turned off. The remote starter will not arm if a door, hood or trunk is left open, or if you re-open a door, hood or trunk within the 30-second delay.

  • Page 14: Priority Door Access

    With this added security feature, the system will prevent your vehicle from starting with the ignition key when armed. If your remote starter was installed with the starter kill option, one will not be able to start your vehicle with the key unless the system has been unlocked and disarmed first, or put into valet mode.

  • Page 15: Home Valet

    Engine Run Time If you have a gas engine, your remote starter can be programmed to run the engine for 3, 15, or 25 minutes (15 minutes by default). If you have a diesel engine, the remote starter can be programmed to run the engine for 8, 20, or 30 minutes (20 minutes default).

  • Page 16: Siren Or Horn Chirps

    Siren or Horn Chirps by default.) The siren will chirp to confirm basic operations on the system: • By default, upon locking the doors the siren will give one chirp if all doors, hood or trunk are closed. • If a zone is open as the system is armed, the siren will give three chirps. •...

  • Page 17: Intrusion Codes Through The Led Light

    Intrusion Codes through the LED Light If there has been an intrusion in the vehicle while it was locked and armed, the LED will provide an intrusion code matching the type of the intrusion that took place. Disarm the alarm ( the intrusion.

  • Page 18: Diagnostics - Parking Light Flash Table

    Diagnostics – Parking Light Flash Table Flashes • Doors locked, alarm and starter kill armed • Run time has expired • TRUNK • Remote start attempt cancelled by remote • Doors unlocked, starter kill disarmed • Exiting ignition valet • Power ON to OFF (automatic transmission) 2 slow flashes then •...

  • Page 19: Limited Lifetime Warranty

    In all cases, the consumer must return the remote starter module to the point of purchase, and must provide a copy of the proof of purchase to said retailer. A remote starter module will be returned to the retailer for the consumer to claim within a 4 (four)-week period.
