EPSON Stylus CX3100/3200

4.1.4 Service Dispatch Standard

When this machine is completely repaired and returned to the user, confirm finally
according to Check Points in the right list.
Table 4-3. Check List
Classification Part
Printer unit Self test Operation is normal?
On line test Print is normally done?
Print head (nozzle Ink gets out normally from all the
check pattern print) nozzles?
CR mechanism CR smoothly operates?
CR makes abnormal sound during
its operation?
Paper loading Paper is smoothly loaded?
mechanism
Paper jam does not happen?
Paper does not warp during paper
loading?
Multiple papers are not fed?
Abnormal sound is not heard during
paper loading?
There is no alien substance at paper
route?
Disassembly and Assembly
Check item Check column
OK / NG
OK / NG
OK / NG
OK / NG
OK / NG
OK / NG
OK / NG
OK / NG
OK / NG
OK / NG
OK / NG
Table 4-3. Check List (continued)
Classification Part
Scanner unit Mechanism
CR mechanism
Lamp
On line test On line test
Copy Copy
Adjustment Designated
adjustment items
Lubrication Designated
lubrication items
Function Version of
firmware
Dispatch Ink cartridge
packing
Waste ink porous
pad
Protection during
distribution
Others Attached goods
Overview
Revision A
Check item Check column
Glass surface is not dirty? OK /
Alien substance is not mixed in the
OK /
CR movement area?
CR smoothly operates? OK /
CR operates together with scanner
OK /
unit?
CR makes abnormal sound during
OK /
its operation?
Lamp normally turns on and white
reflection test is done near home OK /
position?
Operation is normal? OK /
Local copy is normal? OK /
Adjustment condition is suitable?
OK /
Lubrication is done at designated
OK /
place?
Lubrication volume is suitable? OK /
The newest version
OK /
Ink cartridge is normally installed? OK /
Remained life of waste ink porous
OK /
pad is sufficient?
Printer CR is in the cap position? OK /
Scanner CR is locked? OK /
All of attached goods from users are
OK /
packed?
NG
NG
NG
NG
NG
NG
NG
NG
NG
NG
NG
NG
NG
NG
NG
NG
NG
37
