EPSON Stylus CX3100/3200
Use only recommended tools for disassembling, assembling or
C A U T I O N
adjusting the machine.
Observe the specified torque when tightening screws.
Apply lubricants and adhesive as specified.
Once you have disassembled this machine, make the specified
adjustments.
(See Chapter 5 for details.)
At assembly, make sure that the ink tube has been installed in
the correct position. If it is not in the correct position, ink can
leak.
Never remove the ink cartridge from the carriage unless this
manual specifies to do so.
When transporting the printer after installing the ink
cartridge, be sure to pack the printer for transportation
without removing the ink cartridge.

4.1.2 Tools

Use only specified tools to avoid damaging the machine.
Table 4-1. Tools
Tool Name
Phillips screw driver #2
Phillips screw driver #1
Tweezers
Hexagonal box driver
(opposite side: 5.5mm)
M3 (5.5mm) wrench
Radio pliers
Acetate tape
Tension gauge (2000cN)
Disassembly and Assembly
Available from Tool Code
EPSON 1080532
EPSON 1080530
EPSON 1080561
EPSON 1080584
EPSON -
EPSON -
EPSON 1003963
EPSON 1213123

4.1.3 Screws

No. Description
1 CBP-Tite *x* F/Ni
2 C.C.P-Tite *x* F/Zb
3 C.B.S. *x* F/Zn
4 C.C.S-Tite *x*
5 C.B.S-Tite *x* F/Zn
6 C.B.S-Tite (P4) *x* F/Zn
7 Bind B-Tite sems W2, 2.5x5F/Zb
8 C.B.(O) SCREW *x* F/Zg
9 C.B.P-Tite *x* F/Zn
10 M3 Hexagon nut
*x*: Screw nominal size x nominal length
Overview
Table 4-2. Screws
Appearance
Revision A
36
