Specifications - Extech Instruments 42510A User Manual

Specifications

Range / Resolution 0.1° resolution from -58.0 to 999.9°F (-50.0 to 650.0°C);
1° resolution from 1000°F to 1200°F
Accuracy -58°F to -31°F (-50°C to -35°C)
-31°F to 28°F (-35°C to -2°C)
28°F to 200°F (-2°C to 94°C)
200°F to 400°F (94°C to 204°C)
400°F to 800°F (204°C to 426°C)
800°F to 1200°F (426°C to 650°C)
Note: Accuracy is specified for the following ambient temperature
range: 64 to 82°F (18 to 28°C)
Emissivity 0.10 to 1.00 adjustable
Field of View D/S = Approx. 12:1 ratio (D = distance; S = spot or target)
Laser pointer Class 2 laser < 1mW power; Wavelength: 630 to 670nm
IR Spectral response 8 to 14 μm
Repeatability ± 0.5% of reading or ± 1.8
General Specifications
Display
Response time
Over range indication
Operating Temperature
Operating Humidity
Storage Temperature
Power Supply
Automatic Power Off
Weight
Dimensions
±9°F/4°C
±5°F/3°C
±3°F/2.5°C
±(1.0%rdg + 2°F/1°C)
±(1.5%rdg + 2°F/1°C)
±(2.0%rdg +2°F/1°C)
o o
F/1 C; whichever is greater
Backlit LCD display with function indicators
300ms
"---------"
o o o o
32 F to 122 F (0 C to 50 C)
10% to 90%RH operating, <80%RH storage.
o o
14 to 140 F (-10 to 60 C)
9V battery
7 seconds, with LOCK to disable
6.4 oz. / 180g
3.2 x 1.6 x 6.3" (82 x 42 x 160mm)
8 42510A V3.2 9/08
