Description
Meter Description
1.
IR Sensor and Laser pointer
2.
LCD Display
3.
Function Buttons
4.
Measurement Trigger
5.
Battery compartment
Function buttons
(Laser) and ▲ (UP) arrow button
(Backlight) and ▼ (DOWN) arrow button
MODE button
Display Description
1.
SCAN, measurement in progress
2.
HOLD, last measurement locked in display
3.
Laser pointer active
4.
Power locked ON
5.
High limit alarm
6.
Low limit alarm
7.
C or F temperature units
8.
Main temperature display
9.
Low battery icon
10. MAX or MIN icon
11. Emissivity setting
12. Emissivity icon
13. MAX or MIN temperature display
3
1
2
3
4
5
42510A V3.2 9/08
